FOS Technologies PAR ZOOM ULTRA User manual

FOS PAR ZOOM ULTRA
User Manual
IMPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials that old
appliances contain and reduce the impact on human health and the
environment, ensure that this product is recycled at the end of its life.
3
Channel
1
2
3
4
5
6
7
9
8
10
DMX Value
000-255 Zoom 0-100%
000-255 Red intensity 0-100%
000-255 Green intensity 0-100%
000-255 Blue intensity 0-100%
000-255 White intensity 0-100%
001-255 Color Macro
000-010 No function
011-119 Color step changing
120-179 Color cross fade
180-255
000-255
Color step changeing + cross fade
Auto program (CH9) speed from fast to slow
000-255 Master dimmer 0-100%
000-255 Strobe from slow to fast
Descriptions
SPECIFICATIONS
Source: 19*15W RGBW high power LEDs
Beam angle: 10°-60°motorized zoom
0-100% linear dimmer, high speed strobe
DMX,Auto, Master/Slave
DMX Channel: 10ch
IP20 for indoor use only
Power input: AC100-240V 50/60Hz
Power consumption:300W max.
Dimensions: 226*285*380mm
Weight: 6.5 kg

WHAT’S INCLUDED
SAFETY NOTES
The product is for indoor use only.
Always turn off, unplug power and allow fixture to cool before servicing.
Ensure that fixture is properly grounded.
Please keep this User Guide for future consultation.
Always make sure that you are connecting to the proper voltage and that the
line voltage you are connecting to is not higher than that stated on decal or rear
panel of the fixture.
Always disconnect from power before servicing or replacing fuse.
Make sure power cord is never crimped or damaged.
Avaid looking directly into the LED light beam at a close distance!
▪
▪
▪
▪
▪
▪
▪
▪
1
KEY FEATURES
PRODUCT OVERVIEW
19*15W RGBW high power LEDs Power In & Out DMX In & OutFunction buttons
OPERATION INSTRUCTIONS
The FOS PAR ZOOM ULTRA is fully operational in any mounting position,
hanging upside-down, side mounted, or set on a flat llevel surface, etc.
This product has an auto-switching power supply that works with an input
voltage range of 100 to 240 VAC, 50-60Hz.
SETUP
Mounting
2
IMPORTANT!!! Safety cables must always be used when unit is celling or truss
mounted. The safety cable must be capable of holding 10 times the weight of the
fixture.
AC Power
MENU
Zoom
Built-in program
Auto program
Sound program
Display On/Off
LED temperature
Invert display
Built-in program speed
Strobe
DMX address
Red intensity
Green intensity
Blue intensity
White intensity
▪
▪
▪
▪
▪
▪
▪
▪
Source: 19*15W RGBW high power LEDs
Beam angle: 10°-60°motorized zoom
0-100% linear dimmer, high speed strobe
DMX,Auto, Master/Slave
DMX Channel: 10ch
IP20 for indoor use only
Power input: AC100-240V 50/60Hz
Power consumption:300W max.
■ 1 x FOS PAR ZOOM ULTRA
■ 1 x Power cord
■ 1 x User Manual
