fothermo CPVB-10 User manual

EN
Caravan water heater
(CPVB-10)
Technical description,
installation, operation and
maintenance instructions,
warranty conditions
DE
Caravan Boiler
(CPVB-10)
Technische Beschreibung,
Montage-, Betriebs- und
Wartungsanleitung, Gewähr-
leistungsbedingungen
FR
Chauffe-eau de
caravane (CPVB-10)
Description technique,
instructions de montage,
de fonctionnement et
d’entretien, conditions
de garantie
IT
Boiler per caravan
(CPVB-10)
Descrizione tecnica,
istruzioni per montaggio, fun-
zionamento e manutenzione,
condizioni di garanzia
NL
Caravan Boiler
(CPVB-10)
Technische omschrijving,
installatie, bediening en
onderhoud instructies,
garantievoorwaarden

02
Table of contents
Inhaltsverzeichnis / Table de matières /
Contenuto / Inhoudsopgave
EN
Specications 05
Assembly 06
Water connection 07
Drainage 08
Current source 08
Connecting the current source to the boiler 09
Settings – User interface 10
Further information 11
General warnings 11
Safety instructions 11
Further important notes 12
Technical data 12
Assembly 12
Connection to the water supply 13
Maintenance 15
Malfunction 15
Environmental protection 16
Warranty 16
DE
Spezikationen 17
Montage 18
Wasseranschluss 19
Entleerung 20
Stromquelle 20
Anschluss der Stromquelle an den Boiler 21
Einstellungen–Benutzeroberäche 22
Weitere Informationen 23
Allgemeine Warnhinweise 23
Sicherheitshinweise 23
Weitere wichtige Hinweise 24
Technische Daten 24
Montage 24
Anschluss an die Wasserleitung 25
Wartung und Instandhaltung 27
Störungen 28
Umweltschutz 28
Gewährleistung 28
FR
Spécications 30
Montage 31
Mode de raccordement des tuyaux d’eau 32
Vidange 33
Source de courant 33
Raccordement du chauffe-eau à la source de courant 34

03
Paramètres–Interfaced’utilisateur 35
Plus de renseignements 36
Avertissements généraux 36
Instructions de sécurité 36
Autres renseignements techniques importants 37
Caractéristiques techniques 37
Montage 37
Raccordement à l’alimentation en eau 38
Entretien 40
Perturbation du fonctionnement 41
Protection environnementale 41
Garantie 41
IT
Specicazioni 43
Montaggio 44
Connessioneallareteidrica 45
Drenaggio 46
Fonte di corrente 46
Collegamento della fonte di corrente al boiler 47
Impostazioni – interfaccia d’utente 48
Informazioni aggiuntive 49
Avvertenze generali 49
Istruzioni di sicurezza 49
Altre note importanti 50
Dati tecnici 50
Montaggio 50
Connessione alla rete idrica 51
Manutenzione 53
Guasto 54
Protezione ambientale 54
Garanzia 54
NL
Specicatie 56
Montage 57
Wateraansluiting 58
Aftappen 59
Stroombron 59
Stroombron aansluiten tot de boiler 60
Instellingen–Gebruikersinterface 61
Verdere informatie 62
Algemene waarschuwingen 62
Veiligheidsinstructie 62
Verdere belangrijke opmerkingen 63
Technische gegevens 63

04
IMPORTANT!
Please read these operating instructions carefully
before installing and commissioning the hot water
tank!
WICHTIG!
Bitte lesen Sie diese Bedienungsanleitung vor
Montage und Inbetriebnahme des Warmwasser-
speichers sorgfältig durch!
IMPORTANT !
Veuillez lire attentivement ces instructions d’utili-
sation avant de procéder au montage et à la mise

IMPORTANTE!
Leggere attentamente queste istruzioni per l'uso
prima di installare e mettere in funzione il boiler
per acqua calda!
BELANGRIJK!
Lees deze gebruiksaanwijzing zorgvuldig door
voordat u de boiler installeert en in gebruik
neemt!
Contact
Kontakt/Contact/
Contatto / Contact
fothermo System AG
Beim Mühlbach 3
89171 Illerkirchberg
Germany
[phone]
[e-mail]
Registry court Ulm: HRB 739609
VAT: DE329022123
Montage 63
Wateraansluiting 64
Onderhoud 66
Defecten 67
Milieubescherming 67
Garantie 67

EN
05
Specications Unit Value
Water Heater
Product name CPVB-10
Volume l 9.5
Rated pressure MPa 0.7
IP Class X1
Gross weight (± 3 %) kg 8
Max. water temperature °C 65
Integrated MPP tracker
Integrated reverse polarity protection
Digital display
Boiler made of steel with enamel coating
Boiler dimensions (length, width, height) cm 40x30x33
Min. installation dimensions (length, width, height) cm 53,5x30x33
Water connection G½ (M) ½" standard
Combined check and pressure relief valve
Input
Max. voltage (U) V 42.4
Max. current consumption A 15.5
energy demand (Heating process from 15°C to 65 °C) Wh 580
Max. heating power W 550
Recommended photovoltaic power W150–300
Max. connected photovoltaic power W1500
Specications

EN
06
Assembly
The caravan boiler must be mounted on a solid base plate with four
screws. Use suitable screws or other mounting systems for your base
plate. Optionally, the boiler can also be mounted vertically on a stable
wall.
1.
3. 4.
2.
Horizontal and vertical installation of the
photovoltaic boiler is possible.
Specicationsofverticalinstallation
• Very low heat losses
• 8 litres of hot water
Specicationsofhorizontalinstallation
• Slightly more heat loss as in vertical installation
• 9.5 litres of hot water

1 2
1 2
3
4
5
EN
07
The supplied drain plug can be connected to enable draining. This can
be done using the T-piece provided as shown in Figure 1.
We recommend integrating the caravan boiler into a water system as

Water connection
Figure 1 Figure 2
1 Valve + T-piece to drain the boiler
2 Non-return / pressure relief valve
3 Water tank e.g. 40 litres
4 12 V pump (lying in the water if necessary).
Recommended pressure min. 0.75bar
5Shower/sink
For safety reasons the non-return/overpressure valve supplied
must be connected to the cold water inlet of the boiler.

EN
08
The water in the boiler must not freeze. Frozen
water in the boiler can cause damage or a defect
of the appliance. If necessary, the contents of the
boiler can be drained via the non-return/overpres-
sure valve and the drain plug. Proceed as follows:
• Ensure that any water that leaks from the
non-return/overpressure valve and the drain
plug can drain away safely. This is important to
prevent possible water damage.
• Disconnect the water heater from any live
electrical wiring.
• 
• Open the drain plug using the vent key
provided.
• Tilt the small lever of the check/relief valve 90 °.
• The water should now drain away. The Drai-
nage is complete when no more water comes
out of the valves.
• Small amounts of water remain in the boiler

cause any damage.
Drainage
Current source
Usable energy sources
The draining water can be hot - risk of scalding!
These steps do not ensure complete emptying of the water tank.

Source Voltage Type
PV module 0–42.4V –
Battery 12 V, 24 V Lead acid, LiFePO4
External energy management 12–42.4V –
When connecting several photovoltaic modules,
these must only be connected in parallel.

EN
09
Connecting the current
source to the boiler
Heating times depending on the input power and source
Source Power Temperature increase /hour
PV module
100W 9°C/h
300W 27°C/h
550W 47°C/h
Battery
12V (ca. 90 W) max. ~8°C/h
24V (ca. 350 W) max. ~32 °C /h

EN
10
Settings – User interface
 button takes you to the next option


To change possible settings on an option page, such as

press the 
Option pages at a glance
Nr Information / Input option
1 Shows the water temperature in °C.
2POWER IN: Shows the instantaneous power consumption of the boiler.
VOLTAGE: Shows the current supply voltage of the boiler.
3 USED PV ENERGY: Displays the total PV energy consumed by the boiler.
4CHANGE MIN. TEMPERATURE: With the button you can change the minimum temperature.
This option interface is not available in all operating modes (see operating modes).
5CHANGE SYSTEM MODE: You can use the button to change the operating mode.
6
Figure 1
Figure 2

EN
11
Settings – User interface Select operating mode
Modes Energy source Description
1: PV Home PV module/
External energy
management
The boiler is heated with photovoltaic electricity. This mode
should be selected if a PV module is connected or if there is an
external energy management system (e.g. solar charge control-
ler with deep discharge protection) that releases the current for
the boiler.
2: 12V Battery 12V Battery As soon as the battery reaches a voltage of 13.5V during the
charging process, the excess energy is used to heat up the
boiler.
3: 12V Battery
Reheat
12V Battery In addition to the excess control as in mode 2, the water is also
heated to this temperature again as soon as the set minimum
temperature is undershot. (But only until the maximum battery
voltage of 12.4 V is reached.)
4: 24V Battery 24V Battery As soon as the battery reaches a voltage of 27.0V during the
charging process, the excess energy is used to heat up the
boiler.
5: 24V Battery
Reheat
24V Battery In addition to the excess control as in mode 5, the water is also
heated up to this temperature again as soon as the set mini-
mum temperature is undershot. (But only until the maximum
battery voltage of 24.8 V is reached.)
Further information
General warnings
Be sure to carefully read the instructions and war-
nings in this manual before installing and operating
the water heater. The information contained in this
manual is intended to familiarize you with the water
heater, the rules of its correct and safe operation,
and the minimum requirements for its maintenance
and servicing. Furthermore, you are obliged to make

will install and potentially repair the appliance. The

of its functionality is not within the distributor's
warranty obligation nor the manufacturer.
These instructions should always be kept near the
appliance for future reference. Compliance with the
rules here described is part of the measures for the
safe use of the product and is considered part of the
warranty conditions.
Safety instructions
WARNING! There is a risk of burns or scalding when
using the appliance!
WARNING! This device can be used by children
from the age of eight and also by people with a lack
of experience and knowledge or reduced physical,
sensory or mental abilities, if they are supervised or
have been instructed in the safe use of the device
and understand the resulting dangers. Children
must not play with the device. Cleaning and user
maintenance shall not be made by children without
supervision.
IMPORTANT! 
the water heater and connect it to the water pipe

the relevant local regulations. The protective devices
provided or recommended by the manufacturer, as
well as all other assemblies, are UNCONDITIONALLY
to be installed!

EN
12
IMPORTANT!
water before connecting it to the electrical sup-
ply! Failure to comply with the electrical connec-

whereby the water heater must not be operated.
IMPORTANT! Observe the maximum permissible
pressure (see chapter: Technical data).
Further important notes
• The device is under pressure. Expansion water
may drip out of the pressure relief valve during
heating.
• Operate the pressure relief valve regularly to
prevent it from getting stuck, e.g. to prevent
limescale deposits.
• Install a type tested pressure relief valve in the
cold water supply line. Note that depending
on the pressure of the supply line, a pressure
reducer may also be required.
• Attach a drain line to the opening of the relief
valve, with an even slope to the drain.
• Dimension the drain line so that the water can
drain unhindered when the overpressure valve
is fully open.
• The opening of the pressure relief valve must
not be blocked.
• This device contains rechargeable batteries
which are not replaceable. However, their de-
fect does not limit the basic functionality.
• The device may be operated up to an altitude of
4000 m above sea level.
• The device owner is responsible for preventing
possible damage due to lightning strikes and
for proper installation of the PV modules with
lightning protection.
Technical data
This water heater can provide hot water from the
mains water supply or other pressure-operated
water supply for several consumers at the same
time. The water used for heating must meet the
requirements of the normative documents for ser-
vice water, in particular: chloride content up to 250
mg/l; electrical conductivity more than 100 µS/cm,
pH value 6.5 - 8 for hot water tanks with enamelled
water tank. The thermal insulation consists of CFC-
free polyurethane foam.
The maximum electrical output of the hot water sto-
rage tank is 550 W. The actual output of the heating
elements depends on both the connected photovol-
taic output and the intensity of the sun's radiation.
The water is heated to a maximum of 65 °C to ensure
protection against scalding. Detailed information
can be found on the data sheet or the nameplate.
The hot water storage tanks are equipped with a
combined non-return and pressure relief valve,
which prevents the water from being over-pressu-
rized while the device is in operation. The water
tanks are made of steel with a high-strength enamel
coating and additional cathodic protection with a
magnesium anode.
Assembly
Always install the water heater lying down, in a dry

assembly as well as for the wall. Make sure that the

forces that act on the boiler or its mounting system
when driving. When choosing a suitable substrate
for the hot water storage tank, the following must
be taken into account:
• Type and material
• Dimensions of the device,
• Type of fastening
• 
• Arrangement of water and electricity lines
• Degree of protection against water splashes
The installation site must comply with the requi-
rements of the water and electrical installation.

provided during installation.

attached mounting rails. Four screws are used for
this. The type, length and diameter of the screws

EN
13

Only with the right screws is it possible to safely
install the boiler.
Connection to the water supply
When connecting the device to the water pipe, plea-
se note the arrows and the information rings around
the cold and hot water pipes (supply and return
pipe). The cold water pipe has a blue ring and is
marked with an arrow pointing to the pipe. An arrow
away from the pipe and a red ring indicate the hot
water pipe. The hot water tank is equipped with a
combined non-return and pressure relief valve. This
is included in the product packaging and MUST be
installed on the cold water line. During this instal-
lation, the arrow on the body of the valve indicating

be followed.
The pipe connections have G½ external threads.
Schematic representations regarding the connection
of the hot water tank are shown in Figures 1 and 2.
The hot water tank works with the pressure of the
water pipe. The water pressure in the water supply
system should be higher than 0.1MPa (1 bar) and
lower than 0.5MPa (5 bar). If the water pipe pressure
is higher than 0.5MPa, a pressure reducing valve
must be installed.
If additional accessories that are not included in
the scope of delivery must be used in accordance
with local regulations, these must be installed in

supply pipes are made of copper or other metal,

as well as when brass fasteners are used, non-metal


WARNING! 

the hot water tank, as well as blocking the side ope-
ning of the combined valve and/or locking its lever!
A drainage system to evacuate the contents of the
boiler or possible dripping water from the side
opening of the combined valve must be provided.
The drain line must be designed with a constant

water tank has been connected to the water pipe,

of the steps to be performed is:
• Fully open the hot water tap at the furthest
point of use.
• Wait until the air has escaped from the system
-
ping point. Run water for about 30 seconds.
• Close the hot water tap at the extraction point.
• 
1, item 5) for 10 seconds. A strong jet of water

valve.
• 
WARNING!-

a malfunction. There may be contamination in the
-
missioning.
WARNING! The combined non-return and pres -
sure relief valve is one of the protective devices that
ensure the safety of the hot water tank. It is strictly
FORBIDDEN to use the water heater with a damaged
or removed/not installed combined non-return and
pressure relief valve (safety valve)!
IMPORTANT! In Denmark, Sweden, Norway and
Finland, the hot water tank may only be connected
to the public water network using a suitable pressure
reducing valve. Local regulations must be observed.
Electrical connection
WARNING! Any electrical connectionmay only be

IMPORTANT! The water heater is powered by di-
rect current. The water heater is protected against
electric shock "class III" and may only be supplied
with safety extra-low voltage (SELV). Only power
sources recommended by the manufacturer may
be connected. A faulty and/or unsuitable power
supply involves a high risk and is likely to cause an
accident. The connection cables of the device must
be replaced if they are damaged.
IMPORTANT! Photovoltaic modules may ONLY
be connected in parallel. When connecting more

EN
14
Parallel
PV-connector
than one photovoltaic module, always use a sui -
table connector for parallel connection. For more
information, refer to the illustration "Parallel PV-
connector". Connecting photovoltaic modules in
series will damage the water heater.
Connection of PV-modules in parallel conguration
only! Serial connection will damage the unit!
The electrical connection to the hot water boiler is

the electrical connection, be sure to check the func-
tionality of the device. The wires of the connection
cable are numbered and should be connected to the
power source as follows:
• Wire numbered “1” to the positive pole of the
source
• Wire numbered “2” to the negative pole of the
source
Connection of the PV modules
IMPORTANT! The installation and electrical par-
allel connection of PV modules may only be carried

third parties. When installing the photovoltaic mo-
dules, the locally prevailing rules and laws must be
complied with.
IMPORTANT! Always lay cables in such a way that
nobody can trip over them or get caught on them.

such a way that there is no strain on the connectors.
Furthermore, it must be ruled out that the cables and
connectors rub against surfaces and edges (e.g. in
the wind) or are permanently in the water.
IMPORTANT! All photovoltaic modules may be
operated with a maximum open circuit voltage (VOC)
of 42.4V.
• Photovoltaic modules must be properly con-
nected to the connection cable.
Dimensioning of the required photovoltaic power:
• The higher the expected number of hours of
sunshine per day of use, the lower the required
PV power.
• The warmer the water supplied from the pipe,
the smaller the required PV power.
• The higher the amount of hot water required
per day, the greater the required PV power.
The following table serves as a guideline for dimen-
sioning the photovoltaic power needed depending
on the climatic conditions:
Climatic conditions CPVB-10
Sun-poor countries
e.g. Northern and Central Europe 300W
Sunny countries
e.g. Southern Europe and Africa 150W
The values shown are guide values. Depending on the
local conditions and the respective usage conditions,
the sensible design of the photovoltaic output can
deviate from the values described.
Extension of the photovoltaic line
If the photovoltaic cable is extended, the MC4 con-
tact plugs must be properly fastened to ensure func-
tionality and safety. Basically, the PV cable should be
kept as short as possible. A length recommendation
depending on the connected PV generator nominal
power can be found in the table below.
Recommendation of the cable dimensioning
cross-
section 2,5 mm² 4mm² 6mm²
Length
(backand
forth)
  > 10 m

EN
15
OTHER IMPORTANT NOTES
Waterleakage
The non-return and pressure relief valve can drip
during normal operation of the water heater due
to the expansion of water during heating. Make sure
that escaping water can always drain away. The
dripping of water is not a defect. The lateral valve
opening must not be closed in any way.
Noise development
Noise may develop inside the device while water is
being heated. This is due to calcareous deposits on
the heating element. Increased limescale formation
can be seen from water temperatures of over 60°C.
This can lead to impairment and damage to the
heating elements and the hot water tank.
Legionella formation
Due to the small volume of the hot water storage
tank, the risk of legionella formation in the system
can be almost completely ruled out. In order to take
precautionary measures, however, the following
measures are recommended:
• Supply of fresh water or regular water withdra-
wal.
• The water is heated at regular intervals to at
least 60°C.
• If the device has not been used for more than a
month, a water change is recommended.
Maintenance
Corrosion protection
Additional corrosion protection is built into every
water heater with an enamelled water tank. This
corrosion protection consists of a magnesium anode

The anode is a consumable item (i.e. wear and
tear during normal device operation). The average
lifespan is 3 years. This lifetime depends in par-
ticular on the operating mode of the device and
on the properties of the warming water. At regular

authorized by the manufacturer or seller should
check the condition of the anode and replace it if
necessary. Compliance with the deadline and timely
replacement of the anode are important conditions

tank. The inspection and renewal of the anode are
not part of the warranty obligations of the manu-
facturer and dealer. Regular cleaning of the water
tank from accumulated limestone is recommended
for safe operation. This cleaning should be done at
least once every two years. When operating with


with a dry cotton cloth. Regular cleaning and re-
moval of limescale is particularly important for the
safe operation of the device. It is advisable to check
the anode of the enamelled water tank at the same
time. These services are not part of the warranty
and must be carried out by competent persons. The
regulations for checking the anode protection and
replacing the anode and removing the collected

warranty period of the device.
Pressure relief valve
To ensure trouble-free and safe operation of the
hot water storage tank, the combined valve must
be checked regularly for any reduced permeability.

water comes out of the side valve opening and wait
about 30 seconds. This check must be carried out



-
cates a malfunction.
There may be contamination in the water line. The

Cleaning
The outer shell and the plastic parts of the hot wa-
ter tank can only be cleaned with a slightly damp
cotton cloth, without aggressive and/or scouring
agents. It is forbidden to clean the device with a
steam device. The hot water storage tank can only

been completely removed.
Malfunction
If a fault occurs while using the hot water tank,
please disconnect all live lines from the device and
contact the manufacturer or your dealer.

EN
16
Environmental protection
This device is marked according to the Waste Elec-
trical and Electronic Equipment (WEEE) Directive.
By ensuring that the device is taken to an appro-
priate disposal center at the end of its life, you are
helping to protect the environment and prevent

health. The - symbol on the hot water tank indi-
cates that the device must not be disposed of with
normal household waste at the end of its service life.
It must be taken to a disposal center with special
facilities for electrical or electronic equipment. The
end user must observe the local disposal regulations
for disposal.
For more information about treatment, recovery
and the recycling process, please contact your city
-
tailer where you purchased the product. Weitere
Informationen über die Behandlung, Verwertung
und über das Recyclingverfahren erhalten Sie bei
Ihrer Stadtverwaltung, bei Ihrem zuständigen Ent-
sorgungszentrum oder bei dem Fachhändler, bei

Warranty
The warranty for the device is only valid under the
following conditions:
• The device is installed in accordance with the
installation and operating instructions.
• The device is only used for its intended purpose
and in accordance with the installation and
operating instructions.
The warranty includes the elimination of all manu-
facturing defects that may occur during the warranty
period. Only professionals authorized by the seller
may carry out the repairs. The warranty does not
cover damage from:
• Improper transport
• Improper storage
• Improper use
• Unsuitable water parameters
• Improper electrical voltage which deviates from
the rated voltage
• Freezing of water
• Exceptional risks, accidents, or other forces
majeure
• Non-observance of the assembly and operating
instructions and
• In all cases when an unauthorized person
attempts to repair the appliance.
In the aforementioned cases, the damage will be
repaired against payment. The warranty of the de-
vice does not apply to parts and components of the
device that are worn out during its normal use, nor
to parts that are dismantled during normal use, to
lights and signal lamps etc., to discoloration of ex-
ternal surfaces, to changes in the Shape, dimensions
and arrangement of parts and components that
have been subjected to an impact inconsistent with
the normal conditions of use of the device. Loss of
performance, material and immaterial damage re-
sulting from the temporary unusability of the device
during repair and maintenance work are not covered
by the warranty of the device.
COMPLIANCE WITH THE REQUIREMENTS SPECIFIED
IN THE MANUAL ARE REQUIRED FOR THE SAFE OPE-
RATION OF THE PURCHASED PRODUCT AND ARE
PART OF THE TERMS OF THE WARRANTY. ANY CHAN-
GES OR MODIFICATIONS TO THE CONSTRUCTION OF
THE PRODUCT BY THE OWNER OR ITS AUTHORIZED
REPRESENTATIVES ARE STRICTLY PROHIBITED. IF
SUCH ACTION OR ATTEMPT IS DETECTED, THE WAR-
RANTY OBLIGATIONS OF THE MANUFACTURER OR
DEALER WILL BE VOID. THE MANUFACTURER RESER-
VES THE RIGHT TO MAKE STRUCTURAL CHANGES
WITHOUT NOTICE, PROVIDED THAT THE SAFETY OF
THE PRODUCT IS NOT COMPROMISED.

17
DE
Spezikationen Einheit Wert
Boiler
Produktmodell CPVB-10
Volumen l 9,5
Nenndruck MPa 0,7
IP-Schutzklasse X1
Gewicht (± 3 %) kg 8
Max. Wassertemperatur °C 65
Integrierter MPP-Tracker
Integrierter Verpolungsschutz
Digitales Display
Boiler aus Stahl mit Emaillebeschichtung
Boilermaße (Länge, Breite, Höhe) cm 40x30x33
Min. Einbaumaße (Länge, Breite, Höhe) cm 53,5x30x33
Wasseranschluss G½ (M) Standard
Kombiniertes Rückschlag- und Überdruckventil
Anschluss
Max. Spannung V 42,4
Max. Stromaufnahme A 15,5
Energiebedarf (Heizvorgang von 15°C auf 65°C) Wh 580
Max. Heizleistung W 550
Empfohlene Photovoltaikleistung W150–300
Max. anschließbare Photovoltaikleistung W1500
Spezikationen

18
DE
Montage
Der Caravan Boiler muss mit vier Schrauben auf einer festen Boden-
platte montiert werden. Nutzen Sie dafür für ihre Bodenplatte geeig-
nete Schrauben oder andere Halterungssysteme. Optional kann der
Boiler auch senkrecht an einer stabilen Wand montiert werden.
1.
3. 4.
2.
Waagrechte und senkrechte Montage des
photovoltaischen Boilers ist möglich.
SpezikationendersenkrechtenMontage
• Relativ geringe Wärmeverluste
• 8 Liter heißes Wasser
SpezikationenderwaagrechtenMontage
• Etwas mehr Wärmeverluste
• 9,5 Liter heißes Wasser

1 2
1 2
3
4
5
19
DE
Um eine Entleerung zu ermöglichen, kann der mitgelieferte Entlee-
rungsstopfen angeschlossen werden. Dies kann mithilfe des beiliegen-
den T-Stücks, wie in Abbildung 1 erfolgen.
Die Einbindung des Caravan Boilers in ein Wassersystem empfehlen
wir wie in Abbildung 2.
Wasseranschluss
Abbildung 1 Abbildung 2
1 Ventil + T-Stück, um Boiler entleeren zu können
2 Rückschlag-/Überdruckventil
3 Wassertank z.B. 40 Liter
4 12V Pumpe (ggf. im Wasser liegend),
empfohlener Druck min. 0,75bar
5Dusche/Waschbecken
Aus Sicherheitsgründen muss am Kaltwassereingang der
Boilers das mitgelieferte Rückschlag-/Überdruckventil an-
geschlossen werden.

20
DE
Das Wasser im Boiler darf nicht einfrieren. Gefrore-
nes Wasser im Boiler kann zu Schäden oder einem
Defekt des Gerätes führen. Bei Bedarf kann der Inhalt
des Boilers über das Rückschlag-/Überdruckventil
und den Entleerungsstopfen abgelassen werden.
Gehen Sie dabei wie folgt vor:
• Stellen Sie sicher, dass aus dem Rückschlag-/
Überdruckventil und dem Entleerungsstopfen
austretendes Wasser sicher ablaufen kann.
Dies ist wichtig zur Vorbeugung von möglichen
Wasserschäden.
• Trennen Sie den Warmwasserspeicher von
jeglichen Spannungsführenden elektrischen
Leitungen.
• Unterbrechen Sie die Kaltwasserzufuhr.
• -
tungsschlüssels den Entleerungsstopfen.
• Kippen Sie den kleinen Hebel des Rückschlag-/
Überdruckventils um 90°.
• 
ist beendet wenn keine Wasser mehr aus den
Ventilen austritt.
• Kleine Mengen Wasser verbleiben auch nach
Entleerung im Boiler. Dies ist in Ordnung und
verursacht keine Schäden.
Entleerung
Stromquelle
Nutzbare Energiequellen

gefahr! Diese Schritte sichern keine vollständige
Entleerung des Wasserbehälters.
Stromversorgung nur bei gefülltem Boiler anschließen.
Quelle Spannung Typ
PV-Modul 0–42,4V –
Akku 12V, 24V Blei-Säure, LiFePO4
Externes Energie Management 12–42,4V –
Beim Anschluss mehrerer Photovoltaikmodule dürfen
diese nur parallel verschaltet werden.
