Fotodiox SkyFiller Series User manual

SkyFiller
1x2
O
Bi-Color LED
SkyFiller
1x1
O
Bi-Color LED
1100 Lakeside Dr Gurnee , IL60031, United States
Toll Free:[phone]
Local & International: [phone]
Fax: [phone]
Http://www.fotodioxpro.com
Fotodiox Inc.
w w w . f o t o d i o x p r o . c o m
R
R

1.Do not disassemble or modify the light.
2.Do not operate with wet hands; doing so may cause electric shock.
3.Do not operate in environments near flammable gasses or volatile liquids as this may increase the risk of
explosion/fire.
4.Do not operate in enclosed spaces where heat buildup can be extreme, such as a car on a sunny day. The
increased heat may cause premature failure of the lighting unit.
5.Do not touch the plug or AC adapter with wet hands; doing so may cause electric shock.
6.Do not damage, disassemble, twist or modify the power cord as it may increase the risk of fire or electric shock.
7.Do not place under heavy objects.
8.Keep the light clean with a soft, dry cloth.
9.ONLY use the provided control box. Using other control boxes may result in damage to your light. Please
contact [e-mail] should you need a replacement.
10.Avoid impact to the LCD screen; impact may damage it..
11.Avoid dust and debris buildup as this will affect the illuminance and color temperature.
12.Be sure to secure the power box in a location where risk of damage caused my falling is minimal.
Warnings:
Skyfiller SF50/SF70
12
LED PORTABLE LIGHT LED PORTABLE LIGHT
Packing list:
1.Composed of ultra bright chip LEDs with a lifespan of up to 50,000 hours. These LEDs have a standardized
color temperature with a CRI and TLCI of 96 or greater.
2.The Sky Filler is lightweight, easy to transport and durable due to the use of PC hollow material and a metal
heat sink.
3.The power control box can be connected to battery power for easy use on location
4.The LCD screen displays real-time data for color temperature and brightness.
5.The solid metal magic arm bracket allows the light to be securely mounted and easily adjusted.
6.The Sky Filler is heat-free and provides stable, consistent output.
7.Flicker-free and uniformly dimmable from 10%-100% due to the PWM integrated design.
8.Bi-color design is adjustable from 2800K to 6500K.
9.Suitable for indoor and outdoor photography and videography. Great for studio or location shoots including
TV, film, portrait photography and more.
Characteristics:
Light-1PC
Power control box-1PC
Metal connecting plate-1PC
DC Power cable (control box light unit)-1PC AC power cable -1PC
Soft diffuser-1PC
123
45
67
Skyfiller SF50
Remote control-1PC
9
8
Skyfiller SF70
Instruction manual -1PC
Kit bag-1PC
Light-1PC
Power control box-1PC
Metal connecting plate-1PC
DC Power cable (control box light unit)-1PC AC power cable -1PC
Soft diffuser-1PC
123
45
67Remote control-1PC
9
8Instruction manual -1PC
Kit bag-1PC

34
LED PORTABLE LIGHT LED PORTABLE LIGHT
A B C D E F G
Power input cable
Metal mouning plate (detachable)
Stand mount locking screw
Secondary locking screw
Magic arm
Magic arm knob
A
B
C
D
E
F
G
Skyfiller SF50/SF70
A B C D E F G
A B CD E
F G
Power control box:
LCD screen
Operation buttons
AC power input socket
4pin DC input socket
DC output socket (to light unit)
V-mount battery plate
Strap/Safety cable mounting point
A
B
C
D
E
F
G
Parts Diagram:
Soft diffuser

56
LED PORTABLE LIGHT LED PORTABLE LIGHT
Intensity 10%-100% Color temperature 2800K-6500K
LCD display:
Specification:
256pcs ultra bright chip LEDs 396pcs ultra bright chip LEDs
Brightness
Color temperature
CRI
Power
Working voltage
Dimension( for light body)
Dimension( for power control box)
Weight( for light body)
Weight (for Power control box)
Accessories: Soft diffuser, AC power cable, DC power cable, control, bagRemote
Beam angle
SPEC
MODEL
TLCI
2800±150K～6500±200K
2800K:1300lux/1m,352lux/2m
6500K:1439lux/1m,379lux/2m 6500K:2036lux/1m,539lux/2m
2800K:1816lux/1m,496lux/2m
AC100-240V,DC13-17V
Ra:96-98
≥96
50W
13.1x13.1x0.7IN (33.5x33.5x2CM)
9.3x5.5x2.37IN (23.5x14x6.9CM)
3.08Ibs (1.4kg)
2.87Ibs( )1.3kg
120°
Skyfiller SF50 Skyfiller SF70
70W
LED
3.63Ibs (1.65kg)
20.8x12x0.7IN (53x30.5x2CM)
Operating :instructions
1.Set up instructions:
AB
CDAB
CD
(1) Align the four indication points on the metal mounting plate (A, B, C, D) with corresponding holes on the back
of the light unit, rotate the connecting plate counterclockwise until you hear the “click”. The metal mounting
plate is now secured on the light body.
Stand mount locking screw
Magic arm knob
(2) Loosen the stand mount locking screw by turning counterclockwise. Place the metal mounting plate on the
light stand and secure by turning the stand mount locking screw clockwise. Please ensure the light stand stud
is fully inserted into the mounting plate and the screw is securely fastened.The secondary locking screw can
be tightened, loosened or removed using a 4mm hex wrench.

2. Power supply
(1) AC Power: Insert one end of the DC power cable into the DC output socket (F) on the power
control box and the other end into the power input socket on the light. Connect the AC power
cable to the control box. The light now has power.
(2) Battery Power: Insert one end of the DC power cable into the DC output socket (F) on the power
control box and the other end into the power input socket on the light. Attach your V-lock battery
(sold separately) to the V-lock plate on the control box. The light now has power.
78
LED PORTABLE LIGHT LED PORTABLE LIGHT
(3) Turn the magic arm knob counterclockwise to loosen the magic arm, adjust the light to proper
angle and turn the magic arm knob clockwise to secure in place.
Notes:Remove the battery when using AC power; if the battery is left on there is an increased risk of
fire or explosion. Please remove battery when storing for long periods of time to maintain battery
health.
3.Operating Instructions for operation buttons on remote control and power control box
(1) Sound Button:Press once to turn sound on, press again to turn sound off.
(2) Color temperature shortcut button:Each time the button is pressed, the color temperature is cyclically
switched between 2800K, 3200K, 5600K, and 6500K.
(3) Brightness shortcut button:Each time the button is pressed, it is cyclically switched between 25%, 50%, 75%
and 100% intensity.
(4) Color temperature increase button:Each time the button is pressed, the color temperature is increased by
100K up to 6500K. To rapidly increase the color temperature, press and hold the button.
(5) Color temperature decrease button:Each time the button is pressed, the color temperature is decreased by
100K down to 2800K. To rapidly decrease the color temperature, press and hold the button.
(6) Brightness increase button:Each time you press the button, the brightness increases by1%. To increase
intensity rapidly, press and hold the button.
(7) Brightness decrease button:Each time you press the button, the brightness decreases by1%. To decrease
intensity rapidly, press and hold the button.
(8) Power ON/OFF button:Press the button once to turn the light on; press again to turn it off.
ON/OFF Button
Brightness shortcut button
Brightness increase button
Brightness decrease button
Sound button
Color temperature
shortcut button
Color temperature
increase button
Color temperature
decrease button
Magic arm knob

9
LED PORTABLE LIGHT LED PORTABLE LIGHT
The Sky Filler is backed by Fotodiox's 24 month limited warranty
Color Temperature Decrease Button
Power ON/OFF Button
Brightness Shortcut Button
Brightness Increase Button
Brightness Decrease Button
Sound Button/Pairing Button
4.Remote Control function:
Color Temperature Shortcut Button
Color Temperature Increase Button
The remote control and light unit in each box is factory paired. The remote can be paired to another light
or multiple units.
Pairing Instructions:
(1) Turn on the light/lights you wish to pair with the remote control.
(2) Press and hold the Pairing Button for more than 5 seconds, until buzzer sounds.
(3) The light/lights are now paired with your remote control.
Note: When pairing, all light units that are powered on will pair to a single remote control.
