LIVARNO LUX LAH 55 A2 User manual

IAN 102630
CORDLESS TORCH LAH 55 A2
CORDLESS TORCH
Operating instructions
AKUMULATORSKI ROČNI REFLEKTOR
Navodila za uporabo
AKUMULÁTOROVÝ RUČNÝ
REFLEKTOR
Návod na obsluhu
AKUMULÁTOROVÝ RUČNÍ
REFLEKTOR
Návod k obsluze
AKKU-HANDSTRAHLER
Bedienungsanleitung
AKUMULATOROWY REFLEKTOR
RĘCZNY
Instrukcja obsługi
AKKUS KÉZI FÉNYSZÓRÓ
Használati utasítás
CV_102630_LAH55A2_LB4.indd 2CV_102630_LAH55A2_LB4.indd 2 25.08.14 13:0525.08.14 13:05

GB Operating instructions Page 1
PL Instrukcja obsługi Strona 15
HU Használati utasítás Oldal 27
SI Navodila za uporabo Stran 39
CZ Návod k obsluze Strana 51
SK Návod na obsluhu Strana 63
DE/AT/CH Bedienungsanleitung Seite 75
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z wszystkimi
funkcjami urządzenia.
Olvasás előtt kattintson az ábrát tartalmazó oldalra és végezetül ismerje meg a készülék mindegyik
funkcióját.
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.
Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi přístroje.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
CV_102630_LAH55A2_LB4.indd 3CV_102630_LAH55A2_LB4.indd 3 25.08.14 13:0525.08.14 13:05

12 3 4
5
w
t
r
e
6
7
8
q
0
9
CV_102630_LAH55A2_LB4.indd 4CV_102630_LAH55A2_LB4.indd 4 25.08.14 13:0525.08.14 13:05

1
LAH 55 A2
GB
Index
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Information for these operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Limited liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up and connecting to the power supply. . . . . . . . . . . . . . . . . . . . . . 5
Items supplied and transport inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal of the packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Appliance description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Handling and operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Charging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Switching on and off / Selecting the operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Adjusting the carrying handle and the stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Replacing the halogen bulb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposal of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disposal of batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Notes on the Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IB_102630_LAH55A2_LB4.indb 1IB_102630_LAH55A2_LB4.indb 1 25.08.14 12:1625.08.14 12:16

2LAH 55 A2
GB Introduction
Information for these operating instructions
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating instruc-
tions are a part of this product. They contain important information in regard to
safety, use and disposal. Before using the product, familiarise yourself with all of
these operating and safety instructions. Use the product only as described and
only for the specified areas of application. Retain these instructions for future
reference. In addition, pass these documents on, together with the product, to
any future owner.
Copyright
This documentation is copyright protected.
Every duplication and/or reprinting, entirely or partially, as well the as reproduc-
tion of illustrations, also in a modified form, is only permitted with written consent
from the manufacturer.
Limited liability
All technical information, data and instructions for connection and operation
contained in these operating instructions correspond to the latest available at the
time of printing and, to the best of our knowledge, take into account our previous
experience and know-how.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to
observe these instructions, improper use, incompetent repairs, making unauthor-
ised modifications or for using unapproved replacement parts.
Intended use
This appliance is intended as a portable light source for outdoor areas. This appli-
ance is spraywater protected, but is not designed for direct use in the rain. This
appliance has four operating modes (halogen, LED operation, LED ambient light-
ing and LED flashing light). This appliance is not intended for commercial use.
This appliance is not intended for any other use or for uses beyond those men-
tioned. Claims of any kind for damage resulting from unintended use will not be
accepted. The operator alone bears liability.
IB_102630_LAH55A2_LB4.indb 2IB_102630_LAH55A2_LB4.indb 2 25.08.14 12:1625.08.14 12:16

3
LAH 55 A2
GB
Warnings
In these extant operation instructions the following warnings are used:
DANGER
A warning at this risk level indicates a threateningly dangerous
situation
If the dangerous situation is not avoided, it could lead to death or serious
physical injury.
► Pay heed to the instructions in this warning to avoid the death of or serious
physical injury to people.
WARNING
A warning at this danger level signifies a possible dangerous
situation.
If the dangerous situation is not avoided it can lead to physical injuries.
► Follow the directives in this warning to avoid personal injuries.
TAKE NOTE
A warning at this danger level signifies possible property
damage.
If the situation is not avoided it could lead to property damage.
► Follow the directives in this warning to avoid property damage.
NOTICE
► A notice signifies additional information that assists in the handling of the
appliance.
IB_102630_LAH55A2_LB4.indb 3IB_102630_LAH55A2_LB4.indb 3 25.08.14 12:1625.08.14 12:16

4LAH 55 A2
GB Safety
In this chapter you will receive important safety information regarding the handling
of the appliance. This appliance complies with the statutory safety regulations.
Incorrect usage can lead to personal injury and property damage.
Basic Safety Instructions
For safe handling of the appliance observe the following safety information:
■ This appliance may be used by children aged 8 over and by persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, provided that they are under supervision or have been told how
to use of the appliance safely and are aware of the potential risks. Children
must not play with the appliance. Cleaning and user maintenance tasks must
not be carried out by children unless they are supervised.
■ Do not use optical instruments, such as for example a magnifying glass, to
look directly into the beam. There is a risk of receiving severe eye damage.
■ Before use, check the appliance for signs of visible external damage. Do not
put into operation an appliance that is damaged. There will be the risk of a
fatal electrical shock.
■ Arrange for repairs to the appliance to be carried out only by authorised
specialist companies or by the Customer Service Department. Incompetent
repairs can result in significant risks for the user. In addition, warranty claims
become void.
■ Use only the supplied power adapter or the supplied car adapter to charge
this Cordless Handheld Spotlight.
■ The supplied power adapter must be connected only to a properly installed
mains power socket.
■ The mains power socket must be easily accessible, so that in the event of an
emergency the power adapter can be unplugged easily.
■ Ensure that the power adapter and car adapter do not come into contact
with liquids.
■ The power adapter and the car adapter may not be used outdoors, only in
indoor dry rooms.
■ The car adapter may only be connected to the car cigarette lighter or an
on-board power outlet supplying 12 V.
■ Always first connect the Cordless Handheld Spotlight to the power adapter
or the car adapter, then connect the power adapter/car adapter into the
power supply.
IB_102630_LAH55A2_LB4.indb 4IB_102630_LAH55A2_LB4.indb 4 25.08.14 12:1625.08.14 12:16

5
LAH 55 A2
GB
■ In the event of damage to the power adapter/car adapter, in order to avoid
hazards arrange for it/them to be exchanged by authorised personnel or the
Customer Service Department.
■ NEVER use the AC adapter/car adapter with a damaged power cable.
There will be the risk of a fatal electrical shock.
■ NEVER cover up the reflector during operation. There is risk of overheating.
■ Maintain a sufficient distance from the illuminated area (at least
0.5 m), otherwise there is a risk of fire from the generated heat.
■ NEVER operate the appliance without its protective disc.
■ A broken protective disc must be replaced before further use.
There is a risk of personal injury.
Setting up and connecting to the power supply
Items supplied and transport inspection
The appliance is delivered with the following components as standard:
▯ Cordless Handheld Spotlight
▯ Mains power adapter
▯ 12 V car adapter
▯ Carrying strap
▯ These operating instructions
NOTICE
► Check the contents to ensure that they are complete and for signs of visible
damage.
► If the delivery is not complete or is damaged due to defective packaging or
through transportation, contact the Service Hotline (see chapter Service).
Unpacking
♦ Remove all components of the appliance and these operating instructions
from the carton.
♦ Remove all packing material.
WARNING
► Packaging material should not be used as a plaything by children. There is
a risk of suffocation!
IB_102630_LAH55A2_LB4.indb 5IB_102630_LAH55A2_LB4.indb 5 25.08.14 12:1625.08.14 12:16

6LAH 55 A2
GB Disposal of the packaging
The packaging protects the appliance from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging materials into the material circuit saves on raw
material and reduces the amount of waste generated. Dispose of packaging
material that is no longer needed as per the regionally established regulations.
NOTICE
► If possible preserve the appliance's original packaging during the warranty
period so that, in the event of a warranty claim, you can repackage the ap-
pliance ideally for its return.
Appliance description
LED Spotlight
2Halogen Spotlight
3Button to change the handle position
4Carrying handle
5LED Ambient light
6On/Off switch for LED ambient light and LED flashing light
7On/Off switch for halogen and LED operation
8Adjustable stand
9Securing points for carrying strap
10 Charge status indicator green (fully charged)
11 Charge status indicator red (being charged)
12 Charging socket with sealing plug
13 LED Blinking light
14 12 V car-adapter
15 Mains power adapter
IB_102630_LAH55A2_LB4.indb 6IB_102630_LAH55A2_LB4.indb 6 25.08.14 12:1625.08.14 12:16

7
LAH 55 A2
GB
Handling and operation
In this chapter you receive important information for the handling and operation
of the appliance.
Charging the battery
This appliance is equipped with a low-maintenance and securely sealed lead-
acid battery. To obtain an optimum service life for your battery, pay heed to the
following instructions:
■ Before the first use, fully charge the battery over 24 hours using the supplied
mains power adapter 15 .
■ Avoid a deep discharging of the battery. In the event of decreasing bright-
ness, switch the appliance off and recharge the battery. Never operate the
appliance without it being under supervision.
■ Do not store the appliance uncharged, instead, recharge the battery imme-
diately after using the appliance. The battery will be damaged if it is placed
into storage in a discharged condition.
■ A battery discharges itself during prolonged storage. If the appliance is not
to be taken into use over an extended period, recharge the battery at least
every three months.
♦ Switch the Cordless Handheld Spotlight off completely (On/Off switch 6+ 7
at the position “0”).
♦ Connect the low voltage plug of the mains power adapter 15 /car adapter 14
to the charging socket 12 on the Cordless Handheld Spotlight.
♦ Insert the plug of the mains power adapter 15 into a mains power socket
resp. the car adapter 14 into the cigarette lighter/on-board power outlet of
a vehicle.
♦ The charging process begins and the red charge status indicator 11
lights up. When the battery is fully charged, the green charge status indica-
tor 10 lights up additionally.
NOTICE
► The charging time is approximately 15 hours, but with a very discharged
battery it may extend for about 1 to 2 hours.
► Bear in mind that when charging via the car adapter, energy is extracted
from the car battery. Accordingly, when possible charge the appliance
only with the engine running, so that the readiness status of the vehicle
battery remains constant.
IB_102630_LAH55A2_LB4.indb 7IB_102630_LAH55A2_LB4.indb 7 25.08.14 12:1625.08.14 12:16
