FOXEER VTX Reaper Infinity 5W User manual
1. 尺寸: 41*20*17mm
2. 连接口: SMA
3. 显示灯: 3颗LED
4. 重量: 58g
5. 功率:
50mW/500mW/1000mW/2500mW/5000mW
6. 输入: 9~36V
7. 输出: 5V
8. 通道: 40CH
9. 遥控器协议: Tramp
规格：
Reaper Infinity 5W
VTX
1. LED灯说明
功率
说明
频段
通道
红灯
绿灯
蓝灯
LED
短按，进入通道设置，短按设置不同通道；
长按3秒，进入频段设置，短按设置不同频段；
继续长按3秒，进入功率设置，短按设置不同功率。
2. 按键操作方法
长按按键，红灯亮，灭，再次亮起，解锁，解锁状态
下，红灯闪烁，未解锁状态下，红灯常亮。
4. 如何解锁图传功率和频率
双击按键进入PIT模式，红灯灭表示进入了PIT模式，次
模式下，图传输出功率极低。
5. PIT模式
3. 频率表
5865
5733
5705
5740
5658
CH1
5845
5752
5685
5760
5695
CH2
5825
5771
5665
5780
5732
CH3
5805
5790
5645
5800
5769
CH4
5785
5809
5885
5820
5806
CH5
5765
5828
5905
5840
5843
CH6
5745
5847
5925
5860
5880
CH7
5725
5866
5945
5880
5917
CH8
Band A
Band B
Band E
Band F
Channel
Race
Band
Power
(mW) PIT 50 500 1W 2.5W 5W
Reaper Infinity 5W
VTX
1. Size: 41*20*17mm
2. Connector: SMA
3. Display: 3LED
4. Weight: 58g
5. Power: 50mW/500mW/1000mW/2500mW/5000mW
6. Input: 9~36V
7. Output: 5V
8. Channel: 40CH
9. Protocol: Tramp
Spec:
4. Unlock the frequencies and power levels
Long press the "KEY" button until the Red LED (PWR) is
constant on, off, then on again, release the button unlock
the all frequencies and power levels, flashed Red LED means
in unlocked status, constant Red LED means in locked status.
5. PIT Mode On/Off
Double-click the "KEY" button to turn on/off the PIT Mode.
Red LED (PWR) off means PIT mode on; Red LED (PWR) on
means PIT mode off。In PIT mode, VTx outpout extreme low
power.
2. Button Operation
Channel select mode:
Short click, enter CHANNEL setup, only green light is on and
flash, select channel by short presses.
Power select mode:
Continue to press the button for 3s, enter POWER setup, RED
LED is on and flash, select power by simple short presses.
Band select mode:
Continue topress the button for 3s, enter BAND setup, blue
LED on and flash, select band by short click.
1. LED
Description
PowerRed
Band
ChannelGreen
Blue
LED
3. Frequency Table
5865
5733
5705
5740
5658
CH1
5845
5752
5685
5760
5695
CH2
5825
5771
5665
5780
5732
CH3
5805
5790
5645
5800
5769
CH4
5785
5809
5885
5820
5806
CH5
5765
5828
5905
5840
5843
CH6
5745
5847
5925
5860
5880
CH7
5725
5866
5945
5880
5917
CH8
Band A
Band B
Band E
Band F
Channel
Race
Band
Power
(mW) PIT 50 500 1W 2.5W 5W
