Foxtech Map-A7R User manual

1. Description
1. Multi
2. HDMI
3. Power Off *
4. Screen
5. SD Card
6. Menu
7. Thumb Wheel
8. Trigger
* Press down the Power Off button to turn off the camera, and release the button to turn on the camera. After changing the
parameter setting, the camera should be powered off to save the change. Directly cutting off the power won’t save the setting.
MAP-A7R Full-Frame Mapping Camera
©2022 FOXTECH All Rights Reserved 1

2. Insert the SD Card
Insert the SD card into the camera as the arrow indicates. The wrong direction will
lead to damage to the camera.
MAP-A7R Full-Frame Mapping Camera
©2022 FOXTECH All Rights Reserved 2

3. Shutter Setting
Use the Micro USB cable to connect the camera to the computer via Multi-Port. Install
Remote Camera Control software on the computer. When changing the camera
setting, the camera should be powered on.
Click the up/down arrow to adjust the
shutter speed. Press the Power Off button
on the camera to save the setting.
MAP-A7R Full-Frame Mapping Camera
©2022 FOXTECH All Rights Reserved 3

4. Power Supply & Trigger
Please pay a attention
to the dowel pin.
Power & Flight Controller
Yellow: Trigger (Low level)
Blue: Hot shoe (Low level) *
Black *2: GND
Red: Power supply (9~27V)
*If the camera is triggered by the flight controller, do remember to pick out the Hot Shoe, or it will connect with
the Vcc of the flight controller and be damaged.
MAP-A7R Full-Frame Mapping Camera
©2022 FOXTECH All Rights Reserved 4

5. Flight Controller Setting (CUAV V5+, 4.0.7)
Trigger to AUX5; Hot Shoe to AUX6 (or PPK)
CAM_TRIGG_TYPE 1 RELAY
RELAY_PIN 54 AUX5
SERVO14_FUNCTION -1 GPIO
SERVO13_FUNCTION -1 GPIO
CAM_FEEDBACK_PIN 55 AUX6
CAM_RELAY_ON 0 Low
CAM_FEEDBACK-POL 1 Low
