SYK-10 AI-TIRM EO IR Laser Rangefinder Camera
User Manual
2023.05
V1.0

Using this Manual – Legend
Explanation
Tips
Important

1. When not in use, store the SYK-10 AI-TIRM in the package box. The
storage environment is a relative humidity less than 40% at a temperature
of 20±5° C. If the lenses fog up. The water vapor will usually dissipate after
2.
turning on the device for a while.
Do not expose the thermal camera lens to a strong energy source such as
sun, lava or laser beam. The temperature of the observation target should
3.
not exceed 800℃ , otherwise it will cause permanent damage.
Do not place the product under direct sunlight, in areas with poor
4.
ventilation, or near a heat source such as a heater.
Do not frequently power on/o󽗈 the product. After it is turned o󽗈, wait at
least 30 seconds before turning back on, otherwise the product life will be
5.
a󽗈ected.
before installation.
Make sure the gimbal port and gimbal surface are free from any liquid
6. Make sure the gimbal is securely installed onto the aircraft, the microSD
7.
card slot cover is clean and 󽗉rmly in place.
Make sure the gimbal surface is dry before opening the microSD card slot
cover.
8. Do not plug or unplug the microSD card during use.
9. Do not touch the surface of the camera lenses and keep it away from hard
objects. As doing so may lead to blurred images and a󽗈ect the imaging
quality.
10.Clean the surface of the camera lenses with a soft, dry, clean cloth. Do not
use alkaline detergents.
11.When not receiving valid carrier INS data, the yaw shaft of the gimbal will
drift about 15 degrees per hour because of the earth rotation. To make sure
the gimbal attitude corrects, it is necessary to transmit valid carrier INS
data, usually the GNSS should be positioning.
Caution

Introduction 1
Synopsis 1
Characteristics 1
Overview 2
Installation 3
Con󽗉guring & Updating Firmware 4
Con󽗉guring the Camera 4
Updating Firmware 6
Appendix Speci󽗉cations 7
Catalog

1
Introduction
Characteristics
Features AI multi-object detection and tracking, which can constantly track
one of the persons and vehicles intelligently identi󽗉ed in the image.
Carries a 30x zoom camera, a thermal camera and a laser range 󽗉nder.
The
Low-pro󽗉le spherical shape and 3-axis nonorthogonal mechanical stabilized
structure, minimize the gyration radius and the wind resistance of the gimbal.
SYK-10 AI-TIRM
AI
AI is able to spin continually around its yaw axis.
With the GCU, the SYk-1 supports network, UART and S.BUS control. The GCU
control and carrier AHRS fusion, the SYK
supports both private protocol and MAVlink protocol.
-10
Thanks to the Dual-IMU complementary a
A
l
I
go
r
r
o
i
v
th
id
m
e
s
s
w
a
i
s
t
t
h
ab
IM
ili
U
za
t
t
e
i
m
on
p
a
e
c
ra
c
t
u
u
r
r
a
e
cy at
±0.01° .
Can be mounted onto multiple carriers, whether downward or upward.
With the GCU and the Dragon󽗊y software, user can watch the image and
control the gimbal without protocol ducking.
Screen supports overlaying OSD information such as latitude, longitude and
altitude. Image supports shooting point coordinate EXIF save. (EXIF save is not
supported temporarily and will be supported by 󽗉rmware updating)
14~53 VDC wide voltage input.
EO/IR Dual Sensor & 10X Optical Zoom
SYK-10 AI-TIRM is equipped with a high-precision 3-axis gimbal, featuring a 10x optical zoom
camera and a 640x512 thermal imaging camera. It is capable of capturing visible light and thermal
imaging simultaneously, providing more detailed and comprehensive images.
5-1200 m Laser Rangefinder
SYK-10 AI-TIRM camera is also equipped with a laser rangefinder, which provides distance and
positional coordinates of observed targets, assisting in rapid and precise positioning and
improving operational efficiency.
AI Identification and Tracking
SYK-10 AI-TIRM camera is equipped with AI intelligent recognition and military-grade tracking
capabilities. The gimbal can intelligently identify human and cars within the captured images and
continuously lock and track any selected target.
Multiple Mounting Options
SYK-10 AI-TIRM camera supports both upright and inverted installations, allowing for quick and
tool-free attachment to various UAVs or other carrier platforms.
Control & Display Software
The control and display software supports real-time display of the footage on a computer and
enable control over the gimbal. It also supports functions such as capturing photos and recording
User Manual
videos.

2
Overview
1. Damping Platform 2. Thermal Camera
3. Zoom Camera 4. Laser Range Finder
5. Update Port 6. Control Port
7. MicroSD Card Slot
5
4
1
2
3
6
7
SYK-10 User Manual

3
Remove the control port protector.1.
2. Align and insert the 4 pins into the locating holes of the mount platform.
Press down the lock catch to 󽗉x the gimbal. The gimbal can be also 󽗉xed
3.
with screws through the holes on the damping platform.
Plug the gimbal control cable into the control port and install the port
protector back.
Installation
Gently plug or unplug the cable. Avoid hardly pull the cable.
While upward mounted or mounted at carriers with large vibration or
impact, the gimbal should be 󽗉xed with screws nor the quick-release
locks.
Avoid squash the cable while installing the port protector.
Ensure the microSD card slot cover is 󽗉rmly in place to prevent dust or
moisture entering during usage or storage.
The MicroSD card should be con󽗉gured as HDD-FAT32 mode.
User Manual

4
Con󽗉guring & Updating Firmware
Ensure the gimbal and the GCU have both been updated to the latest
󽗉rmware before use. Otherwise, usage may be a󽗈ected.
Ensure the diver of the config module is installed on the computer
before con󽗉guring or updating the 󽗉rmware.
Before con󽗉guring, the computer should be set to a static IP address,
which is in the same network segment with the GCU and the camera
(without IP address con󽗊icts). The default IP address of the GCU and
the camera are 192.168.1.121 and 192.168.1.108.
Do not power o󽗈 the device while updating the 󽗉rmware. Restart the
device once 󽗉rmware update is complete.
1. Connect the gimbal and the GCU with the gimbal control cable. Connect
the computer and the net port of the GCU with the network conversion
module. Power on the devices.
2. Visit http://192.168.1.108/cgi-bin/con󽗉g on the computer (if the IP address
of the camera has been changed, the IP address in the URL should be
replaced with the current camera IP address).
3.
con󽗉guration.
Con󽗉gure the camera in the web page, and click"save"to enable the
Con󽗉guring the Camera
User Manual

5
IP Address / Gateway
Camera IP Address / Camera Gateway.
Udp target / Udp port
Should be con󽗉gured while the stream is in UDP mode.
Stream Bitrate
Image transfer rate, which is in the unit of bps. The higher the stream
bitrate, the clearer the transferred image, yet the higher request to the
bandwidth of the image transmission system.The recommended
range is [2048~8192].
Output Resolution / Output FPS
Default as 1080P / 25FPS
Stream Mode
Stream Media / UDP / GB/T28181. Default as Stream Media. The
Stream Media is RTSP mode; it is necessary to con󽗉gure the UDP
target and UDP port in UDP mode; the GB/T28181 mode is unavailable
temporarily.
Encode Format
H.264 / H.265. Default as H.264.
Save Format
Default as MP4.
Save Stream Bitrate
Image storage rate, which is in the unit of bps. The higher the storage
bitrate, the clearer the storage image, yet the higher request to
the storage rate of the MicroSD card.The recommended range is
[2048~9216].
User Manual

1.
6
Connect the gimbal and the GCU with the gimbal control cable. Connect
the computer and the gimbal update port with the con󽗉g module. Power
2.
on the devices.
Open GimbalCon󽗉g software. Choose the COM port corresponding to the
con󽗉g module. Click "Open Port" and con󽗉rm the software and the gimbal
are connected.
3. Click "Open Firmware" , choose the 󽗉rmware 󽗉le, click "Start Upgrade" and
wait for the updating complete.
Updating Firmware
User Manual

7
Appendix Speci󽗉cations
General
Product Name SYK-10 AI-TIRM
Dimensions 96.4 x 96 x 147mm
Weight 608g
Operating Voltage 14 ~ 53 VDC
Power 10.5W(AVG, ranging o󽗈) / 55W(Peak, ranging on)
Mounting Downward / Upward
Gimbal
Gimbal Type 3-axis Nonorthogonal Mechanical Stabilization
Angular Vibration Range ±0.01°
Controllable Range Pitch: -125°～ +45° , Yaw: ±360° constantly
Max Controllable Speed Pitch: ±200° /s, Yaw:±200° /s
Zoom Camera
Image Sensor 1/2.8'' CMOS; E󽗈ective Pixels: 2.07M
Lens
Focal Length: 4.7~47mm
HFOV: 61.3°～ 6.8°
VFOV: 36.9°～ 3.9°
DFOV: 68.4°～ 7.8°
Optical Zoom Rate 10x
Equivalent Digital Zoom Rate 3x
Min Illumination IRCUT o󽗈: 0.01Lux / F1.6; IRCUT on: 0.0015Lux / F1.6
Object Detection Distance Person: 709.4m, Vehicle:
Object Identi󽗉cation Distance Person : : 141.9m, Vehicle
932.4m
186.5m
Object Veri󽗉cation Distance Person: 70.9m, Vehicle: 93.2m
Thermal Camera
Thermal Imager Uncooled VOx Microbolometer
Lens
Focal Length: 18mm
HFOV: 24°
VFOV: 18°
DFOV: 30.4°
Resolution 640 x 512
Pixel Pitch 12μm
Spectral Band 8~12μm
Sensitivity (NETD) <50mk@25° C
Object Detection Distance Person: 750m, Vehicle: 2300m
Object Identi󽗉cation Distance Person: 187.5m, Vehicle: 575m
Object Veri󽗉cation Distance Person: 93.8m, Vehicle: 287.5m
User Manual

8
Laser Range Finder
Wavelength 905nm
Max Laser Power 1mW
Beam Angle 3.5mrad
Laser Safety Class 1M（IEC 60825-1:2014）
Measurement Accuracy ±1.0m
Measuring Range 5-1200m(φ12m vertical surface with 20%
AI Multi-object Detection & Tracking
re󽗊ectivity)
Object Size 16x16 ~ 128x128 px
Object Identi󽗉cation Delay ＜ 40ms
Tracking Speed ±32 px / 󽗉eld
Tracking Deviation Refresh Rate 30Hz
Tracking Deviation Output Delay ≤ 5ms
Image & Video
Image Format JPEG
Image Resolution 1920 x 1080
EXIF * Shooting point coordinate
Video Format MP4
Video Resolution 1080P@25fps
Stream Encode Format H.264, H.265
Stream Network Protocol RTSP, UDP
Storage
Supported SD Cards Supports a Speed Class 10 MicroSD card
with a capacity of up to 128GB
Supported File System HDD-FAT32
Environment
Operating Temperature -20℃～ 50℃
Storage Temperature -40℃～ 60℃
Storage Humidity ≤ 85%RH（Non-condensing）
* Not supported temporarily and will be supported by 󽗉rmware updating.
