Foxtech SYK-10L AI User manual

User Manual
V1.0
SYK-10L AI
2023.07

Using this Manual – Legend
Explanation
Tips
Important

1. The SYK-10L AI equipped with a laser night vision module, which is a Class
3B invisible laser. DO NOT exposure eyes to the beam within 12 meters
or observe the beam by any optical instrument. DO NOT place any
inflammable within 20 centimeters in front of the lighting module.
2. When not in use, store the SYK-10L AI in the package box. The
recommended storage environment is a relative humidity less than 40% at
a temperature of 20±5° C. If the lenses fog up. The water vapor will usually
dissipate after turning on the device for a while.
3. Do not place the product under direct sunlight, in areas with poor
ventilation, or near a heat source such as a heater.
4. Do not frequently power on/off the product. After it is turned off, wait at
least 30 seconds before turning back on, otherwise the product life will be
affected.
5. Make sure the gimbal port and gimbal surface are free from any liquid
before installation.
6. Make sure the gimbal is securely installed onto the aircraft, the microSD
card slot cover is clean and firmly in place.
7. Make sure the gimbal surface is dry before opening the microSD card slot
cover.
8. Do not plug or unplug the microSD card during use.
9. Do not touch the surface of the camera lenses and keep it away from hard
objects. As doing so may lead to blurred images and affect the imaging
quality.
10. Clean the surface of the camera lenses with a soft, dry, clean cloth. Do not
use alkaline detergents.
11. When not receiving valid carrier INS data, the yaw shaft of the gimbal will
drift about 15 degrees per hour because of the earth rotation. To make sure
the gimbal attitude corrects, it is necessary to transmit valid carrier INS
data, usually the GNSS should be positioning.
Caution

Introduction 1
Synopsis 1
Characteristics 1
Overview 2
Installation 3
Con󽗉guring & Updating Firmware 4
Con󽗉guring the Camera 4
Updating Firmware 6
Appendix Speci󽗉cations 7
Catalog

Introduction
Synopsis
The SYK-10L AI equips with a high-accuracy 3-axis nonorthogonal gimbal, a wide-
angle camera and a 30x zoom camera. User can quickly switch to a highly magnified
zoom camera view after recognizing a target in a wide camera view. Thanks to the
laser lighting module, the SYK-10L AI can provide a clear image even in complete
dark environments.
The SYK-10L AI has AI multi-object detection and tracking function. The gimble
camera can intelligently identify the persons and vehicles in the image, and
constantly track one of them.
The SYK-10L AI can be mounted tool-lessly onto multiple carriers, whether
downward or upward. With the GCU and the Dragonfly software, user can watch the
image from the camera and control the gimbal real-timely on a computer.
Characteristics
Features AI multi-object detection and tracking, which can constantly track
one of the persons and vehicles intelligently identi󽗉ed in the image.
Combination of wide-angle camera and 30x zoom camera, which can quickly
switch between overall and detailed view.
Laser night vision module ensures the cameras getting a clear image even in
complete darkness.
Low-pro󽗉le spherical shape and 3-axis nonorthogonal mechanical stabilized
structure, minimize the gyration radius and the wind resistance of the gimbal.
The SYK-10L AI is able to spin continually around its yaw axis.
With the GCU, the D-80AI supports network, UART and S.BUS control. The GCU
supports both private protocol and MAVlink protocol.
Thanks to the Dual-IMU complementary algorithms with IMU temperature
control and carrier AHRS fusion, the SYK-10L AI provides a stabilization
accuracy at ±0.01° .
Can be mounted onto multiple carriers, whether downward or upward.
With the GCU and the Dragon󽗊y software, user can watch the image and
control the gimbal without protocol ducking.
Screen supports overlaying OSD information such as latitude, longitude and
altitude. Image supports shooting point coordinate EXIF save. (EXIF save is not
supported temporarily and will be supported by 󽗉rmware updating)
14~53 VDC wide voltage input.
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 1

Overview
1. Damping Platform 2. Heatsinkz
3. Zoom Camera 4. Wide Camera
5. Laser Lighting Module 6. Update Port
7. Control Port 8. MicroSD Card Slot
1
2
6
5
4
3
8
7
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 2

1. Remove the control port protector.
2. Align and insert the 4 pins into the locating holes of the mount platform.
Press down the lock catch to 󽗉x the gimbal. The gimbal can be also 󽗉xed
with screws through the holes on the damping platform.
3. Plug the gimbal control cable into the control port and install the port
protector back.
Installation
Gently plug or unplug the cable. Avoid hardly pull the cable.
While upward mounted or mounted at carriers with large vibration or
impact, the gimbal should be 󽗉xed with screws nor the quick-release
locks.
Avoid squash the cable while installing the port protector.
Ensure the microSD card slot cover is 󽗉rmly in place to prevent dust or
moisture entering during usage or storage.
The MicroSD card should be con󽗉gured as HDD-FAT32 mode.
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 3

Con󽗉guring & Updating Firmware
Ensure the gimbal and the GCU have both been updated to the latest
󽗉rmware before use. Otherwise, usage may be a󽗈ected.
Ensure the diver of the config module is installed on the computer
before con󽗉guring or updating the 󽗉rmware.
Before con󽗉guring, the computer should be set to a static IP address,
which is in the same network segment with the GCU and the camera
(without IP address con󽗊icts). The default IP address of the GCU and
the camera are 192.168.1.121 and 192.168.1.108.
Do not power o󽗈 the device while updating the 󽗉rmware. Restart the
device once 󽗉rmware update is complete.
1. Connect the gimbal and the GCU with the gimbal control cable. Connect
the computer and the net port of the GCU with the network conversion
module. Power on the devices.
2. Visit http://192.168.1.108/cgi-bin/con󽗉g on the computer (if the IP address
of the camera has been changed, the IP address in the URL should be
replaced with the current camera IP address).
3. Con󽗉gure the camera in the web page, and click"save"to enable the
con󽗉guration.
Con󽗉guring the Camera
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 4

IP Address / Gateway
Camera IP Address / Camera Gateway.
Udp target / Udp port
Should be con󽗉gured while the stream is in UDP mode.
Stream Bitrate
Image transfer rate, which is in the unit of bps. The higher the stream
bitrate, the clearer the transferred image, yet the higher request to the
bandwidth of the image transmission system.The recommended
range is [2048~8192].
Output Resolution / Output FPS
Default as 1080P / 25FPS
Stream Mode
Stream Media / UDP / GB/T28181. Default as Stream Media. The
Stream Media is RTSP mode; it is necessary to con󽗉gure the UDP
target and UDP port in UDP mode; the GB/T28181 mode is unavailable
temporarily.
Encode Format
H.264 / H.265. Default as H.264.
Save Format
Default as MP4.
Save Stream Bitrate
Image storage rate, which is in the unit of bps. The higher the storage
bitrate, the clearer the storage image, yet the higher request to
the storage rate of the MicroSD card.The recommended range is
[2048~9216].
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 5

1. Connect the gimbal and the GCU with the gimbal control cable. Connect
the computer and the gimbal update port with the con󽗉g module. Power
on the devices.
2. Open GimbalCon󽗉g software. Choose the COM port corresponding to the
con󽗉g module. Click "Open Port" and con󽗉rm the software and the gimbal
are connected.
3. Click "Open Firmware" , choose the 󽗉rmware 󽗉le, click "Start Upgrade" and
wait for the updating complete.
Updating Firmware
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 6

Appendix Speci󽗉cations
General
Product Name SYK-10L AI
Dimensions 85.8*86*129.3 mm
Weight 429 g
Operating Voltage 14 ~ 53 VDC
Power 6.7 W(AVG, light off) / 55 W(Peak, light on)
Mounting Downward / Upward
Gimbal
Gimbal Type 3-axis Nonorthogonal Mechanical Stabilization
Angular Vibration Range ±0.01°
Controllable Range Pitch: -157°～ +80° , Yaw: ±360° constantly
Max Controllable Speed Pitch: ±200° /s, Yaw:±200° /s
Wide Camera
Image Sensor 1/2.8'' CMOS; E󽗈ective Pixels: 2.07M
Lens
Focal Length: 2.4 mm
HFOV：98.5°
VFOV：44.3°
DFOV：101.7°
Zoom Camera
Image Sensor 1/2.8'' CMOS; E󽗈ective Pixels: 2.07M
Lens
Focal Length: 4.7~47 mm
HFOV：61.3°～ 6.8°
VFOV：36.9°～ 3.9°
DFOV：68.4°～ 7.8°
Optical Zoom Rate 10X
Equivalent Digital Zoom Rate 3X
Min Illumination IRCUT o󽗈: 0.01Lux / F1.6
IRCUT on: 0.0015Lux / F1.6
Object Detection Distance Person: 709.4 m, Vehicle: 932.4 m
Object Identi󽗉cation Distance Person: 141.9 m, Vehicle: 186.5 m
Object Veri󽗉cation Distance Person: 70.9 m, Vehicle: 93.2 m
SYK-10L AI User Manual
© 2023 FOXTECH All Rights Reserved 7

Laser Night Vision
Wavelength 850±10 nm
E󽗈ective Illumination distance ≤ 200 m
Beam Angle 8°
Laser Safety Class 3B (IEC 60825-1:2014)
AI Multi-object Detection & Tracking
Object Size 16x16 ~ 128x128 px
Object Identi󽗉cation Delay ＜ 40 ms
Tracking Speed ±32 px / 󽗉eld
Tracking Deviation Refresh Rate 30 Hz
Tracking Deviation Output Delay ≤ 5 ms
Image & Video
Image Format JPEG
Image Resolution 1920 x 1080
EXIF * Shooting point coordinate
Video Format MP4
Video Resolution 1080P@25 fps
Stream Encode Format H.264, H.265
Stream Network Protocol RTSP, UDP
Storage
Supported SD Cards Supports a Speed Class 10 MicroSD card
with a capacity of up to 128GB
Supported File System HDD-FAT32
Environment
Operating Temperature -20℃～ 50℃
Storage Temperature -40℃～ 60℃
Operating Humidity ≤ 85%RH（Non-condensing）
* Not supported temporarily and will be supported by 󽗉rmware updating.
