Foxtech Halo-6000 User manual

Halo-6000
EFI Generator for Hybrid Drone
User Manual
V1.0 2021.12

Contents
Safety Code 1
Description of Halo-6000 1
Preface 1
Functions and Technical Difficulties 2
Main Technical Parameters 2
Before Operation 4
Wiring Diagram 4
Operation 6
Usage and Operation 6
Maintenance 14
Maintenance 14
Faults and Maintenance Method 15
Others 18
Transport and Storage 18
Unpacking Instructions 18
Appendix 19
List of Accessories 19
List of wearing parts and maintenance 20

1©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Safety Code
Before using this product, please read this manual carefully and be familiar with the
meaning. Only by correctly operating and maintaining the product can we ensure its safe and
effective operation. In case of any irresistible accidents such as disability, death, fire and so on
due to improper use, it has nothing to do with the product and the manufacturer. If the user
refits, all irresistible accidents after refitting have nothing to do with the manufacturer.
General Safety Precautions
● When disassembling the motor and control system, cut off the power supply first.
● The motor shall be kept clean and free from obstacles. All dirt on the motor shall be
cleaned regularly to keep the motor clean and dry.
● Exhaust gas discharged by the engine has certain toxicity, and do not inhale or contact
engine exhaust gas.
This manual is an important part of the system. Without written approval, it is strictly
forbidden to copy any content of this manual.
Description of Halo-6000
Preface
First of all, thank you for your trust in our brand! Welcome to use the aviation hybrid system
(UAV) provided for you. Please read this manual before you use it.
This manual provides guidance on the use, troubleshooting and maintenance of Halo-6000.
This manual does not provide maintenance guide for electrical components. When it is
determined that the electrical components have failed, please do not repair them. The whole
assembly must be replaced. Other damage may be caused by trying to repair the faulty
electrical components.
Please read the safety rules in this manual carefully and follow all the requirements and
precautions in this manual.

2©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Functions and Technical Features
According to the requirements of multi-rotor UAV, the developed Halo-6000 is 58V (14S Li
battery).
The engine uses two cylinder and two stroke gasoline as fuel. It adopts 32-bit MCU of
vehicle gauge level, precise injection ignition, adaptive plateau correction, intelligent
self-learning, and has passed the environment and EMC tests. Besides, it has the
characteristics of high output power and low fuel consumption. The motor adopts the heuristic
integrated external rotor motor, which is integrated with the engine, makes the hybrid system
having the advantages of small volume, light weight, low noise and high power-mass ratio.
The controller has the protection functions of over voltage, undervoltage, over temperature
and overspeed.
Halo-6000 has excellent quality, strong power source, long-term high-power output, and
long service life.
Main Technical Parameters
No. Items Unit Parameter Index Remarks
1 Rated Voltage VDC 58
2 Rated Power kW 6.0@ Sea Level
3
Weight kg 9.2
Include: radiators, water pipe,
water pump, fuel pump etc;
Not include: coolant,
gasoline, fuel tank
4Dimension（L x W x H) mm 312×288×206
5 Average Fuel
Consumption
L/h 5.7
6 Applicable Models Multi-rotor
7 Applicable Power
Voltage
VDC multi-rotor UAV, VTOL fixed
wing aircraft
8 Altitude m ≤2000
9 Operating Ambient
Temperature
°C -20 ~ 50
10 Start Mode - One Key Starting
11 Mixing Ratio of
Lubricating Oil and
Gasoline
- 1:25 Please use the brand oil
suggested by the
manufacturer.

3©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Tab. 1 Main Technical Parameters of Halo-6000
Caution:
1. We suggest you to use 25L gasoline to run in the generator for the first time of using
the Halo-6000 at the ratio of 25:1(gasoline:engine oil). For everyday use, a ratio of
40:1(gasoline: engine oil)is suggested.
2.Please confirm that the technical parameters of UAV match the parameters of this
hybrid system before use, so as to meet the operational performance of UAV, Prevent
damage caused by improper configuration.
3.Failure to use the oil and engine-fuel ratio suggested by the manufacturer will cause
engine damage. The manufacturer will not be liable for any consequences caused by
using oil not suggested by the manufacturer.
Engine Model 247AI
Type Double cylinder, two-stroke, EFI engine, water-cooling system
Displacement（mL）124
Rated Power（kW）@7000 r/min 7.3
Rated Speed（r/min）7000
Rated Max. Speed（r/min）7500
Idle Speed r/min 5000
Oil Jaso FC or iso-l-egc and higher 2T oil
Gasoline Label Number 95# gasoline is required
Tab. 2 Main technical parameters of engine configuration

4©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Before Operation
Wiring Diagram（System Controller and PMU）
Please wire in strict accordance with Fig. 1 and Fig. 2. If the connection is wrong, the
system components may be damaged.
1.1 The wiring between engine harness and electrical parts is shown in Figure 1：
Fig. 1
Plug in instructions:
The red and black end connector is connected with the "+"
pole on the oil pump;
The blue and red end connector is connected with the
upper "-" pole of the oil pump
C
y
linder block Tem
p
erature Sensor
Oil Pump
Water Pump
Connecting aircraft CAN cable
Red: fault indicator
Connect the fan

5©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
The wiring of electrical wiring harness and electrical parts is shown in Figure 2：
Fig.2
XT150(Receptacle)
Serial port
Connect to engine CAN
Connect to aircraft CAN
red：fault indicator
green：operation indicator
connect to the receiver
4）Power Cord
The connector shall be selected
according to the battery
configured by the customer or
welded by the customer
3）connect to the receiver
connector ：3PIN 2.54mmDuPont row
plastic shell（receptacle）
yellow line：receiver signal line
1）connect the aircraft CAN
Connector：
2JST-02T-JWPF-VSLE
（Plug）
White line：CAN_L
Blue line：CAN_H
Green line: Serial port
PMU(for
water&fuel
p
um
p
)
system
controller
Rectifier bridge
2）Serial port
connector：5264（receptacle）
Motor temperature sensor
DC-12-IN
Controller power supply harness
Steering gear harness
Ignition coil harness
XT90H male
connector
Connect with
ignition coil
harness of system
controller
Motor
Controller
Relay

6©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Operation
Usage and Operation
1. Halo-6000 is configured as shown in Fig. 3：
2. The installation dimension of Halo-6000 is given in Fig. 4：
Fig. 3
Fig. 4

7©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Water jacket
Water jacket
radiator
radiator
system assembly
①
②
①②
②
②
②
3. Installation Method
3.1 Install the hybrid system to the appropriate position of UAV. The damping pad is
connected with the aircraft mounting mount, as shown in Figure 5 below：
Fig. 5
Caution ：The factory default is hoisting, other installation methods will cause shock
vibration damper damage
3.2 Cooling system installation and water pipe connection is shown in Figure 6 below：
3.2.1 Install the fixed water-cooling radiator.
3.2.2 Installation of fixed water jacket: the water jacket must be placed at the highest point
of the cooling system.
3.2.3 Installation of fixed water pump.
3.2.4 Connect the water pipe.
Water pipe of ①：Ø8 * Ø12；
Water pipe of ②：Ø12 * Ø16；
The red arrow marks the direction
of the coolant circulation flow, and the
distribution clamp is used at the end of
each inlet and outlet.
3.2.5 Precautions for filling water
Water injection is required before starting the water pump,
After the water pump is started, fill the water between the high and low scales of the
Water jacket.
图
4
Vibration Damper
Vibration Damper
Vibration Damper
Vibration Damper
Fig. 6

8©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
3.2.6 Precautions for use of coolant
a) Unscrew radiator cap,
b) Slowly fill the coolant into the water jacket. Be careful not to let the water bubble.
c) After supplying coolant, tighten the water jacket cap.
d) Check the connector of the cooling water rubber hose for looseness, damage or other
faults. If the sealing performance of the water pipe is poor, the cooling water may be consumed
excessively.
The radiator shall be installed under the propeller. If it is installed in other positions, the
forced air cooling fan shall be added, and the fan power supplied by ECU shall be less than
100W.
3.3 The oil pump installation and oil pipe connection are shown in Figure 7 below：
3.4 Operation method of engine fuel pipe exhaust
When the engine is started for the first time or the oil return pipe is not filled with oil,
exhaust treatment shall be carried out before starting the engine. The specific operation
methods are as follows: connect the gasoline bubble in series at the end of the oil return pipe,
press it several times to exhaust the air in the pipe, so that the fuel fills the whole oil supply
pipeline. At this time, remove the oil bubble and start the engine normally.
4. Preparation method of gasoline and lubricating oil
Use 95# or higher grade gasoline, Jaso FC grade or iso-l-egc grade or higher 2T engine
oil (Mott 710 is recommended), and use a proportioning pot to prepare according to the engine
fuel ratio of 1:40 (engine oil: gasoline). It is strictly prohibited to use vehicle 4-stroke engine oil.
Oil outlet Filling port
Oil inlet pipe
Oil return pipe
Oil inlet pipe
Oil pump
System assembly
Fuel tank
Gasoline bubble
Fig. 7

9©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
The specific preparation steps are shown in Figure 8 below.
5. Inspection items before use
5.1 Check whether the connectors of the range extender and controller are connected
and installed in place.
5.2 Make sure there is enough fuel in the fuel tank and the fuel pipe is installed correctly.
5.3 Spark plugs shall be checked before use. Spark plugs with excessive carbon and oil
stains shall be replaced or cleaned.
5.4 Check the steering gear mechanism, check whether the steering gear rod ball head
is flexible, and repair it if it is stuck.
5.5 Check the position of steering gear and throttle, and check whether the steering gear
operates normally and whether the throttle position is correct.
5.6 Check the motor to see if it rotates normally.
5.7 Check the oil pipe. The oil pipe shall not directly contact with heat sources such as
engine or motor. Meanwhile, excessive bending of oil pipe shall be avoided.
5.8 The ignition coil head should be pressed firmly to check whether the connector is
loose.
5.9 There is no obvious bubble in the tubing.
5.10 Check the anti loosening mark of the connecting bolt, and there shall be no
dislocation.
Check whether the exhaust funnel is loose. In case of shaking, be sure to tighten the
fixing bolts of the exhaust funnel.
6. Precautions for starting engine
6.1 Before starting the engine for the first time, the air in the oil inlet pipe needs to be
Fig. 8
①Add 95# or
higher gasoline to
the marking line
② Add lubricating oil
to the marking line
③ Mix the fuel in the inverted
proportional barrel.

10©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
discharged to make the oil inlet pipe full of oil and free of bubbles；
6.2 For the first using, the generator should be power on before adding coolant. After
power on, the electrical water pump will continue to run for about 100s. If the water jacket
is not full within 100s, the generator shall be re-powered on. Repeat until the air in the pipe
line is drained. The pipe lines can be squeezed properly until there is no obvious bubble
up welling in the water jacket; Generally, this operation is not needed during subsequent
startup, just observe the liquid level of water jacket, and add coolant when it is too low.
6.3 After each power on, the steering gear will execute the self-learning program for
about 8s. Operate the remote control to make the system indicator light normally on (the
remote control needs to be unlocked).
6.4 The engine must be idle for 30 seconds after starting, so that the crankshaft, piston
and connecting rod can be more fully lubricated.
6.5 Multiple start failures may cause the spark plug to be flooded. In this case, replace or
dry the spark plug and try to start again.
7. Function description of monitoring software
7.1 Software installation instructions
①Open the software installation package
with an installation package attached.
②Find setup.exe, double click to open, enter
the installation interface as shown in the figure
and wait until the loading is completed.
③After loading, the directory selection
interface will be displayed. In this interface,
you can select the software storage location,
and click "next" to install until it is completed.
④The installation is complete.

11©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
7.2 Software operation instructions
Find “GX_6. exe” on desktop and double click to enter the operation interface.
If the connection fails, check whether the serial port cable is correct, restart the
software and system, and try again.
First supply power to the system and connect the serial port harness. When
usin
g
the software, do not click other buttons before o
p
enin
g
the serial
p
ort.

12©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
8. Running
8.1 System controller receiver signal pulse width definition：
1) Receiver transmission pulse width,
1.1ms (reserved), 1.5ms (start) and 1.9ms (shutdown),
with a cycle of 20ms；
2) The remote controller is equipped with a three
position switch (1.1ms is idle and not used).
8.2 To start the Halo-6000, please first confirm whether the three position switch of the
remote control is normal；
8.3 Turn the three position control switch of the remote control to the "bid winning" (as
shown in Figure 9) position for operation,
Observe the bus voltage, ensure that the drone voltage is stable at 57V ±
2V；
8.4 Observe the drone voltage and operate stably for about one minute to warm up the
engine；
Fig. 9
Superscript：
1.1ms reserved
subscript：
1.9ms stop
Middlescript
1.5ms start
1. Start or idle：
First, turn the three position switch of the remote control to
the "superscript" position, then turn it from the "superscript"
position to the "subscript" position, pause for 2 seconds, and
then turn the three position switch of the remote control to the
"bid winning" position to start the range extender (if it is not
started, repeat the above methods).
2. Power generation operation：
After the engine is ignited and idling, the range extender does not need any manual operation, and the
system automatically enters the power generation state.
3. Stop Running：
When the range extender is in operation, turn the three position switch of the remote control from the
"bid winning" position to the "subscript" position to stop, and the system will stop automatically.

13©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
8.5 In case of maneuver or gust during flight, the bus voltage will drop, which is a normal
phenomenon.
If the drone voltage drops rapidly and continuously and is lower than 53V, special attention
shall be paid, and it shall be immediately lowered for maintenance if necessary;
8.6 Running out of fuel will cause serious damage to Halo-6000r. Optionally, use the oil
level sensor to monitor the remaining fuel to ensure that the operation is stopped before
running out of fuel.
9. Stop Running
9.1 After continuous flight, Halo-6000 needs to be cooled. Therefore, after landing,
maintain idle speed for 30s. After the engine is shut down, do not turn off the power supply
and keep the water pump running for 3min.
9.2 After the booster runs, some parts are at high temperature. After the booster
stops running, please do not touch the booster to avoid scalding.
Gasoline is a volatile flammable and explosive liquid. At the end of the
day or during long-distance transportation.The remaining fuel in the
oil tank shall be drained and properly stored in the oil drum to avoid
danger!

14©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Fig. 8
Maintenance
Maintenance
1. For routine maintenance items (after each operation), the warranty will not be given if
the maintenance manual is not followed
1.1 Check whether the plug of the controller circuit is in good contact, and check
whether the oil pipe and water pipe are loose or leaking.
1.2 Check if the controller is damp and keep it dry.
1.3 Check the motor for dirt and moisture, remove dirt and keep it clean and dry.
1.4 Check the air filter, remove the dirt, and keep clean（to prevent foreign matters or
dust from entering the engine inlet）.
1.5 Check whether the fixing bolts are loose, and no loose bolts are allowed.
1.6 Check whether the steering gear rod ball is stuck. If it is stuck, oil can be applied
temporarily and replaced later.
2. Regular Maintenance(Carry out regular maintenance and parts replacement according
to Appendix 3)
2.1 After the Halo-6000 runs for 50h, check the carbon deposit on the spark plug. If the
carbon deposit is serious, remove the carbon deposit or replace the spark plug.
2.2 Check whether the fuel pipe has aging, hardening and cracks. If so, be sure to replace
it to avoid potential safety hazards.
2.3 Check the motor for dirt, remove sundries and keep it clean and dry.
Remove carbon deposit
Remove the spark plug

15©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
3. Maintenance Before Long-Term Shutdown
it is necessary to carry out comprehensive maintenance for the Halo-6000 before
storage, if the system is out of service and will not be used for a long time. This can
avoid some parts failure caused by long-term shutdown and maintain the system
performance.
Caution: The manufacturer shall not be responsible for the system damage
caused by untimely maintenance.
Faults and Maintenance Methods
1 Common faults and maintenance methods are shown in Table 3 below：
No. Description Check Item Cause of Failure Maintenance Method
1
System
cannot be
started.
Air filter Under heavy working condition Clean the filter with fuel
2
Oil Supply
System
Wrong lubricating oil model Use the original lubricating oil
3 Tubing bubble or no oil
Press the oil bubble several times
to absorb oil
4 Wire Harness Poor contact of connector
Check the circuit and connect it
again
5 Spark Plug yellow or weak light change the spark plug
6
Reed valve
failure
Damaged reed valve diaphragm Replace reed valve
7
Speed
fluctuation,
voltage
fluctuation,
smoke
Spark Plug The spark plug is loose. Tighten the spark plug
8 Fuel
Water in fuel or fuel quality
Poor quality, fuel storage more
than 2 months
Change the fuel
9 Lubricating Oil Poor quality of lubricating oil
Change to the original
lubricating oil
10 Oil Way
The oil supply is not smooth,
there are bubbles in the yellow
oil pipe, or the oil filter in the oil
tank has not been replaced for
more than 50 hours.
Drain the air from the oil inlet
pipe. Open the filler cap to
make the top of the fuel filter
close to the top of the oil level.
Power on and drain the air. In
some cases, tilt the fuel tank
properly.

16©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
11 Control Circuit
The control circuit or sensor is
damaged. Contact the manufacturer.
12
Insufficient
Power Output
It's time for maintenance. Contact the manufacture.
13 Air Filter The air filter element is too dirty.
Clean the filter element with
gasoline.
14 Spark Plug
Remove the spark plug and press
it in the red coil. Contact the
ignition head of the spark plug
with the engine block, and turn the
starting head. If the ignition light is
yellow or weak, replace the spark
plug.
15
The voltage
drops rapidly
after take-off
Battery Low battery voltage
Before takeoff, turn the
three-position-switch to "run"
and wait for about 1 minute.
16 miscellaneous Mechanical parts are damaged. Contact the manufacturer.
Tab. 3
Caution: This system does not support low power consumption. When the
system is not in use, please remove the battery or set a switch to cut off the
electrical connection between the battery and the system. The system does not
support hot plug. The controller will be damaged by hot plug in case of use and
maintenance.
2. Controller Indicator Definition
2.1 Red indicator light: The light is not on in normal state, and is always on in case of
system failure
The fault list of the red fault indicator is shown in Table 4 below：
Failure Fault light mode
1. Sensor Failure
1. throttle position —— -
2. liquid level sensor —— - -
3. water temperature sensor —— - - -
4. motor temperature —— - - - -
5. atmospheric pressure sensor —— - - - - -

17©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
2. ignition failure —— —— -
3. speed failure ——
4. voltage failure -
5. power failure on
Tab. 4
Note：”——“ represents that the red fault light flashes slowly by 0.5s every
time，”-“ represents that the red fault light flashes rapidly by 0.2s every time.
2.2 Green indicator light: It is a running indicator light, and its working state is divided into
fast flash (100ms) → slow flash (500ms) → constant light.
Flash: system initialization process;
Slow flash: after initialization, wait for receiving the start command;
Light on: after receiving the start command, you can start the engine through the starter.

18©2021 FOXTECH All Rights Reserved
Halo-6000 EFI Generator User Manua
l
Others
Transportation and Storage
Handle it lightly during loading and unloading. During transportation, it is strictly forbidden
to bump and scratch to prevent rain. The booster shall be stored in a clean, ventilated,
moisture-proof and moisture-proof place.
In idle or for a long-time storage：
1. Please put the booster in a clean, ventilated, moisture-proof and moisture-proof
place.
2. Disconnect the power cord of the controller from the battery.
3. The motor rotor needs to be covered to prevent dust and foreign objects from
entering.
Unpacking Instructions
Note: operate with care.
When unpacking, the extender shall be placed in the upright direction according to the
label of the outer package.
After unpacking, check the packing list and the items (including certificate, operation and
maintenance manual, products, etc.) according to the packing list.
Carefully check whether it is consistent with the real object.
