FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
918-419e09/12/07
EUROPA 75
IMPORTANT: Save these Instructions.
Owners & Installation Manual
WARNING:
Improper installation, adjustment, alteration, service
or maintenance can cause injury, property damage,
or loss of life. Refer to this manual. For assistance or
additional information consult an authorized installer
or service agency.
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.

GreenFire GF75-1 BioEnergy Stove
2
GF75-1
TO THE NEW OWNER
Congratulations! You are the owner of a state-of-the-art stove by FPI.
Thank-you for purchasing a
FPI FIREPLACE PRODUCT.
The pride of workmanship that goes into each of our products will give you years of trouble-free
enjoyment. Should you have any questions about your product that are not covered in this manual,
please contact the FPI DEALER in your area.
Keep those FPI FIRES burning.
Safety Note: If this stove is not properly installed, a house fire may result. For your safety,
follow the installation instructions, contact local building, fire officials, or authority having jurisdiction
about restrictions and installation inspection requirements in your area.
The authority having jurisdiction should be consulted before installation to determine the need to
obtain a permit.

GreenFire GF75-1 BioEnergy Stove 3
TABLE OF CONTENTS
GREENFIRE BIOENERGY STOVE
Safety Label ..................................................................4
INSTALLATION
Important: Save These Instructions...............................5
Before You Start ............................................................5
Important Safety Information .......................................5
Unit Location .................................................................5
What is Included with the GF75-1 .................................5
Chimney Installation ......................................................6
Venting System......................................................6
Type Of Chimney .................................................6
Mobile Home Installation ......................................6
High Elevation .......................................................6
Negative Pressure in the House............................6
Pressure Reducer Plate.........................................6
12 Volt Battery ...............................................................6
First Fire ........................................................................6
Clearances ....................................................................7
Unit Dimensions ............................................................7
Vent Termination Requirements ....................................8
Horizontal Termination...................................................9
Side View.......................................................................9
Outside Vertical Termination........................................10
Vertical Termination ..................................................... 11
Existing Class "A" Chimney.........................................12
Existing Masonry Chimney..........................................13
OPERATING INSTRUCTIONS
GF75-1 Start Up Procedure .......................................14
Control Panel Functions ..............................................16
Heat Level Settings..............................................16
Combustion Fan Adjustment................................16
Ash Extraction......................................................16
Display A..............................................................16
Display B..............................................................16
Fuel Selection Icons ............................................16
Stop Button..........................................................16
Convection Fan....................................................16
Operation Guidelines For Burning Corn And Wheat ...17
Initial Use of GF75-1 for Burning Corn & Wheat..17
Starting Procedures.....................................................17
To Start Your Stove..............................................17
Clinker Prevention ...............................................18
MAINTENANCE
Maintenance................................................................19
Maintenance Schedule Using Wood Pellets........19
Maintenance Schedule Using Corn or Wheat......19
Tools Required.....................................................20
Maintenance of the Combustion Chamber ..........20
Maintenance of the Burn-pot ...............................20
Maintenance on the Convection Fan...................21
Maintenance on the Fuel Feeding System ..........21
Maintenance of the Ash-extraction System .........21
Maintenance on the Combustion Fan
(Connected to the Chimney)................................21
Inspection of the Seals ........................................22
Information on How to Clean the Chimney..........22
Maintenance of the Battery System.....................22
Type of Cleaning Product To Use For The
Windows ..............................................................22
GF75-1 Technical Data................................................23
TROUBLESHOOTING
Troubleshooting ..........................................................24
Electrical Diagram (12 Volts) .......................................25
WARRANTY
GF75-1 Model Manufacturers Warranty ......................27

GreenFire GF75-1 BioEnergy Stove
4
SAFETY LABEL
This is a copy of the label that accompanies
each GF75-1. We have printed a copy of the
contents here for your review. The safety label
is located on the back panel of the stove.
NOTE: FPI units are constantly being
improved. Check the label on the unit and
if there is a difference, the label on the unit
is the correct one.
DO NOT REMOVE THIS LABEL /
NE PAS ENLEVER CETTE
ÉTIQUETTE
Serial No./ No de serie
918-418d
Made in Canada / Fabrique au Canada
Duplicate S/N
CONTACT YOUR LOCAL BUILDING OR FIRE OFFICIAL ABOUT RESTRICTIONS AND
INSTALLATION INSPECTION IN YOUR AREA.
CONTACTEZ VOTRE BUREAU DE CONSTRUCTION OU D’INCENDIE AU SUJET DES
RESTRICTIONS ET DE L’INSPECTION D’INSTALLATION DANS VOTRE QUARTIER.
Listed Room Heater, Pelletized Fuel Type
Also Suitable for Mobile Home Installation Pursuant to (UM) 84-HUD
Manufactured by/Manufacturé par: FPI Fireplace Products International Ltd., Delta, BC, Canada
Install and use only in accordance with
manufacturer's installation instructions and
your local building codes.
Model :GF75-1
Tested to :ASTM E1509, ULC C1482,
ULC S627
Type of Fuel : Corn or Pelletized Wood or
Agricultural BioEnergy refer to
Manual.
Electrical Rating : 120V, 4 Amps, 60 Hz
Input Rating : 8,500 to 34,000
BTU TYPICAL
NOTE: Replace glass only with 5mm ceramic.
Components required for residential and mobile home
installation: Listed Pellet Vent.
Risk of electrical shock. Disconnect power
before servicing unit. Do not route power cord beneath
heater.
DANGER:
“PRÉVENTION DES FEUX DE MAISON”
Installez et utilisez seulement en accord avec
les instructions d’installation du manufacturier
et des codes locaux.
Modèle : GF75-1
Testé à : ASTM E1509, ULC C1482,
ULC S627
Type de Gaz : Granules de Bois et Mais
Évaluation Électrique : 120V, 4 Amps, 60 Hz
Évaluation Énergetique: 8,500 à 34,000
BTU Typique
NOTE:
DANGER:
Remplacez la vitre avec de la céramique de
5mm seulement.
Produits exigés pour l’installation dans la maison
résidentielle et mobile: Ventilation pour granules de
bois cataloguée.
Il y a risque de choc électrique. Débranchez
avant d’essayer de faire le service sur cet appareil. Ne
pas faire passer la corde électrique en dessous de la
fournaise.
Pieces Catalogue; Type - Poele a Granule
Peut Etre Utilisee Pour l’Installation Dans la Maison Mobile Sous (UM) 84-HUD
“PREVENT HOUSE FIRES”
NOTE: REGARDLESS OF THE STOVE CLEARANCE, VENT PIPE MUST ALWAYS
HAVE A 3” CLEARANCE.
CHIMNEY AND CONNECTOR:3” LISTED PELLET VENT ONLY.
FLOOR PROTECTOR MUST BE 3/8” MINIMUM THICKNESS NON-COMBUSTIBLE
MATERIAL OR EQUIVALENT, EXTENDING BENEATH HEATER AND TO THE
FRONT/SIDES/REAR AS INDICATED.
**SIDE WALL TO UNIT : 6 in. / 152 mm
MAX. ALCOVE DEPTH : 30 in. / 762 mm
BACK WALL TO UNIT : 6 in. / 152 mm
CORNER TO UNIT : 8 1/2 in. / 216 mm
**Unit to sidewall requires 8” clearance for access to controls.
NOTE: PEUT IMPORTE L’ESPACE LIBRE DU POÊLE, LE TUYAU DE VENTILATION
DOIT TOUJOURS AVOIR 3” D’ESPACE LIBRE
CHEMINÉE ET CONNECCTEUR : VENTILATION DE GRANULE DE BOIS CATALOGUÉ
DE 3” SEULMENT.
LE PROTECTEUR DE PLANCHER DOIT ÊTRE DE3/8” D’ÉPAISSEUR MINIMUM DE
MATÉRIEL NON-COMBUSTIBLE OU L’ÉQUILVALENT , S’ÉTENDANT EN DESSOUS DE
LA FOURNAISE ET AU DEVANT/CÔTÉS/ARRIÈRE COMME INDIQUÉ.
**MUR DU CÔTÉ À L’APPAREIL : 6 pouces / 152 mm
MUR ARRIERE À L’APPAREIL : 6 pouces / 152 mm
PROFONDEUR MAXIMUM DE L’ALCOVE : 30 pouces / 762 mm
COIN À L’APPAREIL : 8 1/2 pouces / 216 mm
**De l’appareil au mur exige 8” d’espace libre d’accès aux contrôles.
U.S. ENVIRONMENTAL PROTECTION AGENCY
Certified to comply with July 1990 particulate emission standards.
Distributed by: FPI Fireplace Products International Ltd., Delta, BC, Canada
DATE OF MANUFACTURE / DATE DU MANUFACTURIER
2006
2007 2008 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC
AGENCE DE PROTECTION ENVIRONNEMENTALE DES ETATS-UNIS
Certifie d’etre conforme avec les standards d’emission de Juillet 1990
HOT WHILE IN OPERATION. DO
NOT TOUCH. CONTACT MAY
CAUSE SKIN BURNS. KEEP CHILDREN, CLOTHING AND
FURNITURE AWAY. SEE NAMEPLATE AND
INSTRUCTIONS. DO NOT OVERFIRE. IF HEATER OF
CHIMNEY CONNECTOR GLOWS, YOU ARE OVERFIRING.
INSPECT AND CLEAN CHIMNEY AND CONNECTOR
FREQUENTLY. UNDER CERTAIN CONDITIONS OF USE, FLYASH BUILDUP
MAY OCCUR RAPIDLY. MOVING PARTS MAY CAUSE INJURY.
WARNING:
RISK OF SMOKEAND FLAME SPILLAGE. KEEP VIEWING
ANDASH REMOVALDOORS TIGHTLY CLOSED DURING OPERATION.
CAUTION:
CAUTION:
OPERATE THIS UNIT ONLY WITH THE FUEL HOPPER
LID CLOSED. FAILURE TO DO SO MAY RESULT IN EMISSIONS OF
PRODUCTS OF COMBUSTION FROM THE HOPPER UNDER CERTAIN
CONDITIONS. MAINTAIN HOPPER SEAL IN GOOD CONDITION. DO NOT
OVERFILLTHE HOPPER.
CHAUD LORSQU’EN OPÉRATION. NE TOUCHEZ PAS.
TOUT CONTACT PEUT CAUSER DES BRÛLURES ÀLA
PEAU. GARDEZ LES ENFANTS, LES VÊTEMENTS, LES MEUBLES À UNE
DISTANCE CONSIDÊRABLE. LISEZ L’ÉTIQUETTE ET LES
INSTRUCTIONS. NE PAS SURCHAUFFEZ. SI LA FOURNAISE OU LE
TUYAU DE CHEMINÉE ROUGISSENT, C’EST QUE VOUS SURCHAUFFEZ.
INSPECTEZ ET NETTOYEZ LA CHEMINÉE ET LE TUYAU FRÉQUEMMENT.
SOUS CERTAINES CONDITIONS D’USAGE, LE RÉSIDU DE CENDRE
PEUT SE FAIRE RAPIDEMENT. TOUTE PIECE MOBILE PEUVENT CAUSER
DES BLESSURES.
ATTENTION:
IL Y A RISQUE DE FUMÉE ET DE FLAMME.
GARDEZ LA PORTE DE VUE ET CELLE DES CENDRES FERMÉES
HERMÉTIQUEMENT DURANT L’OPERATION.
AVIS:
OPÉREZ CETAPPAREILAVEC LE COUVERCLE DE LA TRÉMIE
FERMÉ. SINON IL PEUT EN RÉSULTER DES ÉMISSIONS DES PRODUITS
DE COMBUSTION DE LA TRÉMIE SOUS CERTAINES CONDITIONS.
MAINTENEZ LE COUVERCLE DE LA TRÉMIE EN BONNE CONDITION. NE
REMPLISSEZ PAS LA TRÉMIE TROP PLEINE.
CAUTION: Special methods are required when
passing chimney through a wall or ceiling.
Follow the pipe manufacturer's instructions and
local building codes for the clearance to
combustibles required for the installation of the
vent pipe being used. Do not pass chimney
connector through a combustible surface. Do
not connect this unit to a chimney flue serving
another appliance.
WARNING: (MOBILE HOME) An outside air
inlet must be provided for combustion and be
unrestricted while unit is in use.
NOTE: Outside air is required.
AVIS:Des méthodes spéciales sont exigées
lorsqu’une cheminée passe à travers un mur ou
un plafond. Suivez les instructions du
manufacturier du tuyau et les codes locaux de
construction pour l’espace libre des
combustibles exigé pour l’installation du tuyau
connecteur de cheminée à travers une surface
combustible. Ne connectez pas cet appareil à
un tuyau de cheminee servant un autre
appareil.
ATTENTION: (MAISON MOBILE) Un tuyau
extérieur d’air doit être fourni pour la
combustion et doit être sans restriction lorsque
l’appareil est en usage.
NOTE: A besoin d’air de l’extérieur
286
286
Report No./Rapport Nu.: 120-S-01-2
STOVE STOVE
STOVE
BACKWALL
SEE
NOTE
SIDEWALL
3” 6”
8”** **6”
30”
MAX.
SEE
NOTE
8½”
3”
SIDEWALL
ADJACENT WALL
FLOOR PROTECTOR
FRONT
6”
6”
6”
6”
AVIS:

GreenFire GF75-1 BioEnergy Stove 5
INSTALLATION
IMPORTANT:
SAVE THESE
INSTRUCTIONS
The GF75-1 Stove must be installed in
accordance with these instructions. Carefully
read all the instructions in this manual first.
Consult the building authority having jurisdiction
to determine the need for a permit prior to starting
the installation.
NOTE: Failure to follow the instructions could
cause a malfunction of the heater which could
result in death, serious bodily injury, and/or
property damage. Failure to follow these
instructions may also void your fire insurance
and/or warranty.
BEFORE YOU START
It is very important to ensure that the stove is
installed in a safe manner. Be aware of fire
prevention rules and laws in your area. All
applicable National and Local codes must be
met and complied with.
We recommend that you call an accredited
professional or a dealer trained by FPI to guide
you to install your stove.
Please note the battery back-up comes shipped
inside the Ash pan. Please remove the battery
before start-up.
The stove’s electrical connection is to a standard
grounded wall socket. Special care should be
taken so the connection cable is not damaged
in any way.
It is strongly recommended to install a smoke
detector as well as an ABC type extinguisher
near the stove. A power surge bar is also
highly recommended to protect the electrical
component.
If the stove is installed by an uncertified installer,
FPI will not be held responsible for any faulty
operation including poor performance of the
stove.
IMPORTANT SAFETY
INFORMATION
Only use approved fuels in multi-fuel burning
appliances. Failure to comply with this may
create a hazardous situation and will void all
warranties.
In order to start your stove, always use a specified
and approved fire starter material. Never use
a flammable liquid like gasoline, barbecue fire
starter or alcohol.
INSTALLATION
Never attempt to re-start your stove until it has
fully cooled down. Never start the stove with a
gel when the burn-pot is hot. This could generate
serious burns.Always wait until the stove is cold
before re-starting it.
Never use or store flammable products close to
the stove while it’s in use, or at any other time.
Manual feed (Icon 11) is only used to prime the
auger when Hopper is empty. Do not use the
manual feeding procedures to start-up your stove
as these will create smoke in your house.
Ensure that the ash pan door is securely
closed at all times when the stove is in use. Air
pressure could ignite the gas accumulated in the
burn-pot creating an overdraft condition in the
combustion chamber altering the performance
of the burn-pot.
The GF75-1 model will not feed fuel if the main
door is not fully closed and the firebox in a
negative pressure situation. This is a safety
function of the appliance.
IMPORTANT:
Stove must be cold before any attempt to
clean the glass is made. Do not use detergent
containing abrasives to clean the windows
or any other parts of the stove. Use only
recommended products found at your local
hearth shop for this type of cleaning.
IMPORTANT:
When cleaning the stove, always remove
ashes into a steel container and place outside
the residence. Use gloves to handle or to
empty the ash pan.
Never use a vacuum cleaner to remove ashes
from the stove, unless you can be sure the
stove is fully cooled down.
IMPORTANT:
Before servicing the electrical panel, make
sure that all electrical source is turned off
to the stove.
UNIT LOCATION
1. For optimum benefit from your appliance,
speak to your professional for help with your
location.
2. The location you choose for your appliance
can be a factor in how it will perform. Choose
an interior location where the vent will not
be affected by any external interference,
i.e. trees, bushes, walls or fencing (refer to
"Vent Termination Requirements" section).
Make sure, at the time of the installation,
that there is the least possible interference
with the existing components of the house.
Install a non flammable covering when
necessary. Place the stove according to
recommendations made on "Clearances"
section or according to the safety label fixed
on the stove.
3. You can use the wall behind the stove to pass
the chimney system or simply join the stove
to an existing chimney or a metal chimney,
with the use of an approved liner.
4. Ensure that all clearances to combustibles
are met as per the safety label and the
diagrams on "Clearances" section.
5. This appliance does not need outside air
unless there is a negative pressure within
the room where the installation takes place.
Make sure that the outside air supply for the
burn-pot does not come from a garage, an
attic or any restricted non-ventilated space.
Air must come from the outside of the house
directly into the room where the stove is
installed.
6. This stove is not approved to be installed
into a bedroom under any circumstances.
7. The flooring under the stove must be made
of a non-combustible material, i.e. cement,
ceramics, etc, and must extend at least 6"
(152mm) all around the stove. Refer to the
diagrams on "Clearances" section.
WHAT IS INCLUDED
WITH THE GF75-1
Qty Description
1 pc User Manual
1 pc AC Power Inlet
1 pc Measuring 2 1/2 Cup Plastic
1 pc Alligator Clip Black
1 pc Alligator Clip Red
1 pc Pipe Adapter Gasket
(for Pressure Reducer Plate)
1 pc Pressure Reducer Plate 1-1/4 ID
1 pc Pressure Reducer Plate 1-5/8 ID
1 pc Poker
1 pc 12-V Battery
1 pc Battery Cage

GreenFire GF75-1 BioEnergy Stove
6
INSTALLATION
CHIMNEY
INSTALLATION
Important: Always use an approved 3”
(76mm) PL type vent system which is
approved for venting while burning corn.
Using a different size vent will result in poor
performance or eventual malfunction of your
appliance which is not covered under warranty.
Never exceed 3" diameter pipe.
Venting System
In order to get optimum performance from your
appliance a good venting system and positive
air supply is essential.
Type Of Chimney
Since this is a BioEnergy stove, it is advisable to
use only venting recommended and approved
for the burning of corn or other agricultural
fuels. Regular pellet vent cannot withstand the
continued use of these BioEnergy fuels and will
deteriorate over time. Using recommended corn
vent will prolong the lifetime of your system.
Never use a non-approved pipe for the venting
system. i.e. Dryer vent, "B" vent for gas vent,
PVC/plastic pipe or single wall chimney
system.
It is very important to take note that for horizontal
venting that the vent length shall not exceed 48"
(1219mm) chimney on an installation.
Always vent exhaust air to the outside atmosphere
and never into enclosed spaces, i.e. garage, car
port etc. Vent systems can become hot to touch,
warn children of them to avoid the risk of burn.
Mobile Home Installation
The GF75-1 model is approved for installation
in a mobile home of type (UM) 84-HUD. The
outside air connection must always go directly
to the atmosphere outside the building (refer to
Diagram 2 in "Unit Dimensions" section).
High Elevation
High altitude (6000' / 1828m and more) reduces
the air velocity which is drawn into the burn-pot.
To help increase the air velocity, the chimney
must have a minimum of 6' (1.82m) of vertical
vent outside the house to help create a natural
draught.
Negative Pressure In The House
The use of a bathroom fan, dryer, cooking hood
fan, etc. can cause negative pressure, especially
in new air tight homes. Combined these fans
consume an average of 200 cfm, which is
more powerful than the combustion fan on the
GF75-1, creating negative pressure around the
stove. To overcome this negative pressure, we
recommend to install an outside air intake from
the atmosphere directly to the 1" connector on
the back of the stove. (refer to Diagram 2 in
"Unit Dimensions" section).
Pressure Reducer Plate
There are 2 Pressure Reducer Plates, one with
a 1-1/4” and one with a 1-5/8" opening. These
are sometimes needed in longer chimney runs
or in high altitude installations. The Pressure
Reducer Plate is designed to slow down the
draft in your chimney in such situations.
1. Remove the 4 nuts & washers from the bolts
(see Diagram 9 below) from the combustion
exhaust outlet.
INSTALLATION
Diagram 9
BOLTS
2. Install the desire pressure reducer plate to
the combustion exhaust outlet, ensuring that
gaskets are replaced on both sides of the
pressure reducer plate. One gasket is placed
on each side of the pressure reducer plate.
3. Reverse step 1.
NOTE: Only 1 of the pressure reducer plates
is used (not both). It is recommended to try
the reducer plate with the 1-5/8" opening
first.
12 VOLT BATTERY
A 12 volt battery is included with this stove.
This standard battery back-up will ensure
uninterupted operation of your stove in the event
of unexpected loss of electrical power. Note
that this does not replace the regular 120 volt
power supply to the stove. The battery is only a
backup. The battery will generally last 7-9 hours
on a full charge (depending on feed rate). Refer
to "Electrical Diagram" section for details. It is
recommended to have your battery connected at
all times. The battery will trickle charge whenever
electrical power is restored and will continue to
charge througout the process.
If there is no battery connected, a power
interruption in excess of 5 seconds, will cause
the stove to go into shutdown mode once power
is restored with an error code of E5 or E6 in
Display B. A power interruption of less than 5
seconds will result in the stove picking up where
it left off upon restoration of power.
To facilitate the installation of a larger 12 volt
battery we include, in the manual package,
extension alligator clip leads.
Note: 12 volt batteries should never sit on
stone or concrete.
The FIRST FIRE in your stove is part of the
paint curing process. To ensure that the paint
is properly cured, it is recommended that you
burn your fireplace for at least four (4) hours the
first time you use it with the fan on.
When first operated, the unit will release an
odour caused by the curing of the paint and
the burning off of any oils remaining from
manufacturing. Smoke detectors in the house
may go off at this time. Open a few windows to
ventilate the room for a couple of hours. The
glass may require cleaning.
NOTE: When the glass is cold and the appliance
is lit, it may cause condensation and fog
the glass. This condensation is normal
and will disappear in a few minutes as
the glass heats up.
DO NOT ATTEMPT TO CLEAN THE
GLASS WHILE IT IS STILL HOT!
FIRST FIRE
DO NOT BURN THE APPLIANCE
WITHOUT THE GLASS FRONT IN
PLACE.
HOW TO INSTALL THE BATTERY:
1) Remove battery cage and battery from ash
pan.
2) Attach red positive wire to battery.
3) Attach black negative wire to battery.
4) Place battery into cage facing up.
5) Slide battery cage with battery inside over
four screws and tighten.
6) Attach red battery wire to red wire from
unit.
7) Attach black battery wire to black wire from
unit.
Children should be kept away from the hot
stove. For all other questions contact your
local dealer.
IMPORTANT
Battery cage, non-spillable battery and
packaging materials shipped inside bottom
door. Please remove contents before start-
up. See back panel for installation.

GreenFire GF75-1 BioEnergy Stove 7
INSTALLATION
INSTALLATION
Corner Installation Alcove Installation Minimum Hearth Requirement
ADJACENT WALL
STOVE
8 1/2”(152mm)
3”
(76mm)
F
3”
(76mm)
BACKWALL
F
STOVE
6” (152mm)
30”
MA
X
(762m
m
8”
(203mm)
6”
(152mm)
F
BACKOFSTOVE
STOVE
6” (152mm)
6”
(152mm)
6”
(152mm)
6” (152mm)
UNIT DIMENSIONS
25-1/4” (641mm)
40-1/2”
(1029mm)
26-1/2” (673mm)
19-3/8”
(492mm)
6” (152mm)
Vent Center Line
8” (203mm)
10-5/8” (270mm)
Outside Air
Center Line
Height and Depth Width
Diagram 1 Diagram 2
CLEARANCES
See the safety label on the back of the stove to know the exact distances to follow when installing the stove.

GreenFire GF75-1 BioEnergy Stove
8
INSTALLATION
INSTALLATION
VENT TERMINATION REQUIREMENTS
1. Do not terminate the vent in any enclosed or semi-enclosed areas that can build up a concentration of fumes.
2. Vent surfaces can become extremely hot. Keep children away from such areas. Non-combustible shielding or guards may be required.
3. Termination must exhaust above the inlet elevation. It is recommended to have a short vertical run which will help in the event of total power
failure.
4. If the unit is incorrectly vented or the air to fuel mixture is out of balance, a slight discoloration of the exterior of the house might occur. Since
these factors are beyond the control of FPI we grant no guarantee against such incidents.
5. When installing into an existing masonry chimney, you will probably need a short horizontal section to clear the lintel and allow the hopper lid to
open. See diagram on page 13 for more details.
6. Do not terminate a vent underneath a veranda porch or deck unless fully open on a minimum of two sides beneath the floor.
NOTES:
- Vent terminations shall not be recessed into walls or siding.
- A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings
and serves both dwellings.
- If the vent termination is accessible, a certified guard shall be installed.
- Local codes or regulations such as CAN / CSA B365 or USA NFPA 211 may require different clearances. Check with your local
authorities.
IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER.
The diagram below references all horizontal applications. For vertical applications refer to B365 for Canada and NFPA 211 for the US
along with pages 10 to 13 in this manual.
Min. Clearance Description
A 84" (2134mm) Above public walkway, sidewalk or street.
B 72" (1829mm) Within any gas regulator vent or mechanical air inlet to a building.
C 36" (914mm) Within a building opening, air inlet of another appliance, an oil tank vent or property boundry
D 36" (914mm) Horizontally of the vertical centerline of a gas meter/regulator and within height of 15ft. (4.5m) above.
E 12" (305mm) Above grade level or any non-combustible surface such as cement or gravel.
F 36" (305mm) To any building projection, adjacent wall or any combustible materials such as grass, trees, fencing, etc.
G 48" (1219mm) From beside/below any door or window that may be opened.
H 12" (305mm) Above any door or window that may be opened.
I 12" (305mm) To inside or outside corner.
J 24" (610mm) Below any eave or roof overhang.
Diagram 3

GreenFire GF75-1 BioEnergy Stove 9
INSTALLATION
INSTALLATION
HORIZONTAL TERMINATION
Top View
Side View
Diagram 4

GreenFire GF75-1 BioEnergy Stove
10
INSTALLATION
OUTSIDE VERTICAL TERMINATION
INSTALLATION
6” Min
6” Min
Hearth Pad
Outside Air
Tee with
cleanout
Support
bracket
3” (76 mm)
Clearance
Flashing
Rain cap
24” (610mm)
Side View
Diagram 5
