Fracino PID 2 User manual

TO BE USED WITH FRACINO USER MANUAL AND INSTALLATION MANUAL
V1.1

DISPLAY AND KEYPAD
OVERVIEW
ToGR1 ToGR2 ToGR3
FRACINO ROMANO
MAX
MIN
HH:MM
DAY
ToBOILER
123
7
4
8
5
6
Display
Normal Operation
1. Group 1 Temperature oC
2. Group 2 Temperature oC
3. Group 3 Temperature oC
4. Steam Boiler Temperature oC
5. Time
6. Day
7. Steam boiler water level indicator
8. Scrolling menu bar
Keypad
Group 1
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K6GR1
K1GR1
K2GR1
K3GR1
K4GR1
K5GR1
K6GR1
PRIMARY FUNCTION SECONDARY FUNCTION
Single Espresso
Single Cappuccino
Double Espresso
Double Cappuccino
Manual Override
Hot Water Dispense
Scroll up when in program menu or technical menu
Scroll down when in program menu or technical menu
Select/enter when in program menu or technical menu
Enter program menu or techincal menu
1

Keypad
Group 2
K1GR2 K2GR2 K3GR2 K4GR2 K5GR2 K6GR2
K1GR2
K2GR2
K3GR2
K4GR2
K5GR2
K6GR2
PRIMARY FUNCTION SECONDARY FUNCTION
Single Espresso
Single Cappuccino
Double Espresso
Double Cappuccino
Manual Override
Steam Dispense*
Scroll up when in program menu
Scroll down when in program menu
Select/enter when in program menu
Enter program menu
*2 Group only, on a 3 group machines this is for hot water
Keypad
Group 3
K1GR3 K2GR3 K3GR3 K4GR3 K5GR3 K6GR3
K1GR3
K2GR3
K3GR3
K4GR3
K5GR3
K6GR3
PRIMARY FUNCTION SECONDARY FUNCTION
Single Espresso
Single Cappuccino
Double Espresso
Double Cappuccino
Manual Override
Steam Dispense
Scroll up when in program menu
Scroll down when in program menu
Select/enter when in program menu
Enter program menu
DISPLAY AND KEYPAD
OVERVIEW
2

START UP
Initial start up
1
1. On the initial start-up, immediatly after installation, turn the machine on using the
black rocker switch on the fornt panel behind the right hand steam tube, the blue light
should illuminate indicating the power is on. The display and keypads should illuminate.
20oC 20oC 20oC
FRACINO PID
MAX
MIN
09:00
MONDAY
20oC
2. After a second or two the boiler will begin to fill, this is indicated on the boiler water level
indicator on the display, the water level can also be observed on the sight glass on the left
hand side of the machine, it may take several minutes for the boiler to fill.
2
2
NOTE: The machine may time out during the filling, this will be indicated by a buzzer
and a “!” symbol on the display, turn the machine off using the mains on/off rocker switch,
wait 5seconds and turn on again - the machine will continue of fill.
NOTE: For installation instructions, refer to the Installation Manual supplied
with the machine
3

START UP
3. Immediatly after the boiler has filled press the star button on each group until water appears
from the bottom of the groups - this is to ensure the heat exchangers and group boilers are
full of water.
40oC 40oC 40oC
FRACINO ROMANO
MAX
MIN
09:00
MONDAY
35oC
4. After filling the boilers will start to heat, this is indicated on the groups by the heating element
symbol, which appears on the group temperature readout this symbol will appear when the group
heating element is on, as the group approaches its set temperature it will begin to pulse until the set
point is reached, it will then pulse to maintane the set point temperature.
3
4
5
5. The steam boiler temperature is indicated on the right hand side of the display. It is good practice
to open the steam valve by turning clockwise when the steam boiler is heating, this can be closed
when steam starts to appear from the steam tube. The steam pressure will build until it
reaches 1-1.2Bar.
5
6. It is advisable to leave the machine with the filer holders inserted in the groups for 10-15 minutes
to allow the groups to get hot and stabilize their temperature.
4

CLOCK AND
AUTO ON/OFF
Changing Clock
ToGR1 ToGR2 ToGR3
FRACINO PID
MAX
MIN
ToBOILER
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K6GR1
1
5 Seconds
1. To change the time on the clock, press and hold the star button for 5seconds to enter
the programming mode, remove finger from star button then press the star button for a
further 2 seconds, to enter the secondary programing mode, the display will show
“clock adjust”, as shown below
2 Seconds
1
clock adjust 1
2. Press the double espresso button to edit the time, the time and day should appear
with the hour flashing, use the single espresso (+) or single cappuccino (-) to
increase/decrease the hour respectively, press the double espresso button to scroll to
the minute adjust as required, press the double espress button to scoll to the day,
adjust as required
ToGR1 ToGR2 ToGR3
FRACINO PID
MAX
MIN
ToBOILER
clock adjust
HH:MM DAY
2
+ - Enter
3. Press the double espresso button to move to the Auto ON/OFF setting menu
5

CLOCK AND
AUTO ON/OFF
Auto ON/OFF
ToGR1 ToGR2 ToGR3
FRACINO PID
MAX
MIN
ToBOILER
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K6GR1
1
1. Press the double espresso button the hour should be flashing, use the espresso (+)
and Cappuccino (-) button to change to the require time, press the double espresso
button to scroll to the minute and adjust as required.
1
Auto ON/OFF
On : HH:MM
1
2. Press the double espresso to move to the OFF set time, set time as required using
the same proceedure as above.
ToGR1 ToGR2 ToGR3
FRACINO ROMANO
MAX
MIN
ToBOILER
clock adjust
HH:MM DAY
2
+ - Enter
ToGR1 ToGR2 ToGR3
FRACINO PID
MAX
MIN
ToBOILER
Auto ON/OFF
Off : HH:MM
2
NOTE: When using the Auto on/off the machine will go into stand-by mode and will not
isolate power from the machine.
ToGR1 ToGR2 ToGR3
FRACINO PID
MAX
MIN
ToBOILER
Closed on
day
3
3. The auto on/off can be programmed to skip a day in the week, i.e if Sunday is
selected the machine will turn off on Saturday, stay off on Sunday and turn back on
Monday. Use the single espresso and single Cappuccino to cycle through the days,
“-----------------” denotes that no day is selected.
6

PROGRAMMING
COFFEE MEASURES
Programming
Coffee Measures
ToGR1 ToGR2 ToGR3
DOSES SETTING SEL......
MAX
MIN
HH:MM
DAY
ToBOILER
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K6GR1
1. The coffee measures are programmed from the left hand keypad, when complete the
settings are stored on all groups. If required each group can be programmed individually
by using the same proceedure using the corresponding group and keypad.
1
2. Put a single shot of coffee (7-8grams) in to a single filter, insert filter in to the the left
hand group and place a shot pot or espresso cup under the group.
5 Seconds
3. Press and hold the star button for 5seconds until the scroll menu reads:
“doses setting select with in 30sec”
3
7

PROGRAMING
COFFEE MEASURES
Programming
Coffee Measures
ToGR1 ToGR2 ToGR3
DOSES SETTING SEL......
MAX
MIN
HH:MM
DAY
ToBOILER
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K6GR1
4. Press the single espresso button to start the brewing cycle, when the required
volume (approx. 30mL for a single espresso) has been dispensed press the single
espresso button to stop the brewing cycle.
5. Repeat the process to program the other buttons, using a single or double filter
as required, the programming must be done with in 30sec of each other, otherwise
it will timeout, if this happens press and hold the star button for 5 seconds as before
and continue from where you left off.
6. To exit the program you can either wait 30sec for the timeout or press and hold the
star button for 5seconds then press the star button to scroll through the menu until
the main display appears.
1
3. Press and hold the star button for 5seconds until the scroll menu reads:
“doses setting select with in 30sec”
4 6
8

PROGRAMING
HOT WATER MEASURES
Programming
Hot Water Measures
ToGR1 ToGR2 ToGR3
DOSES SETTING SEL......
MAX
MIN
HH:MM
DAY
ToBOILER
K1GR1 K2GR1 K3GR1 K4GR1 K5GR1 K6GR1
1. The duration of the hot water dispensing can be adjusted using the left hand key pad
1
2. Place a cup, teapot or measuring jug on the drip tray grid under the hot water
nozzle
5 Seconds
3. Press and hold the star button for 5seconds until the scroll menu reads:
“doses setting select with in 30sec”
2
WARNING: Do not hold the cup, teapot or measuring jug, the water from the hot
water nozzle is extremely hot which presents a risk of scalding.
3
