Franke SMART SM 86 P User manual

SM 86 P
SMART
EN Installation and user manual Pyrolytic Oven
DE Installations- und Gebrauchsanweisung Pyrolyseofen
FR Manuel d‘installation et mode d‘emploi Four à pyrolyse
IT Manuale per l‘installazione e l‘uso Forni pirolitici
ES Manual de instalación y servicio Horno pirolítico
PT Manual de instalação e de assistência Forno com Sistema de Pirólise
NL Installatie- en gebruikershandleiding Pyrolytische oven
EL Εγκατάσταση και εγχειρίδιο συντήρησης Σύστημα πυρόλυσης

– 3 –
SM 86 P EN
ABOUT THIS MANUAL
This user manual applies toseveral models
ofthedevice. Thus itmay bepossible that
some ofthedescribed features and functions
are not available onyour specific model.
 Carefully read theuser manual before using
thedevice.
 Keep theuser manual.
 Use thedevice described inthis user
manual only according totheintended use.
Franke reserves theright tomake modifications
totheproduct without prior notice.
All information correct attime ofissuance.
Symbol Meaning
Warning symbol. Warning against risks ofinjury.
Actions insafety and warning notes toavoid injury ordamage.
Action step. Specifies anaction tobe done.
Result. Result ofone ormore action steps.
TABLE OF CONTENTS
About this manual 3
Intended use 4
Safety Information 4
Recommendations 6
Proper installation and placement 6
Proper use 7
Maintenance and cleaning 7
Repair 7
Taking out ofservice 8
Information for energy saving 8
Overview 8
Installation 9
Electrical connection 9
Switching onthefirst time 9
Operation 10
Control Panel 10
Cooking programs 12
Cleaning and care 13
Pyrolysis 13
Maintenance 14
Troubleshooting 16
Technical data 16
Support 16
Disposal 17

SM 86 P
– 4 –
EN
INTENDED USE
The oven was developed exclusively for non-
professional, domestic use inthehousehold.
theoven isdesigned tooffer professional
performance inthehousehold.
Itisa highly versatile appliance enabling
safe and easy selection ofdifferent cooking
methods.
SAFETY INFORMATION
 Read the user manual and
the safety information
carefully before using
theoven.
 Keep the manual for future
reference.
The manufacturer can not
be made liable for possible
damage which may occur
due to incorrect installation
and incorrect, improper or
unreasonable use of the device.
The electrical safety of the
oven is guaranteed only when
it is connected to an earthing
system in compliance with the
valid regulations.
To ensure safe and efficient
operation ofthis electrical
device:
 Only contact authorized
service centers.
 Do not modify any features
ofthedevice.
 This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be
made by children without
supervision.
 This device is not a toy.
 Do not leave children near
thedevice unattended.
 Do not let children play with
thedevice.
 Do not allow children
totouch thedevice orits
controls during and
immediately after using it.
 Ensure that the device
isinstalled in a way that
allows todisconnect itfrom
thepower supply, with
acontact opening distance
that ensures complete
disconnection incategory III
overvoltage conditions.

– 5 –
SM 86 P EN
 Means for disconnection
must be incorporated in the
fixed wiring in accordance
with the wiring rules.
 Only use the temperature
probe recommended for this
oven.
 The appliance shall not be
installed behind a decorative
door in order to avoid
overheating.
Risk of burns!
 During use the appliance
becomes hot. Care should
be taken to avoid touching
heating elements inside
theoven. Children less than
8years ofage shall be kept
away unless continuously
supervised.
WARNING: Accessible parts may
become hot during use. Young
children should bekept away.
CAUTION: in order to avoid
a hazard due to inadvertent
resetting of the thermal cut-
out, this appliance must not be
supplied through an external
switching device, such as a
timer, or connected to a circuit
that is regularly switched on
and off by the utility.
Risk of burns!
The end ofthedoor handle may
behotter due tohot air being
vented.
 Always make sure that
thecontrol knobs are
intheoff position when
theoven isnot inuse.
WARNING: Ensure that
theappliance isswitched off
before replacing thelamp
toavoid thepossibility
ofelectric shock.
 Do not use harsh abrasive
cleaners orsharp metal
scrapers toclean theoven
door glass/ theglass
ofhinged lids ofthehob (as
appropriate), since they can
scratch thesurface, which
may result inshattering
oftheglass.
 Do not use steam cleaners
ordirect jets ofwater.
 Excess spillage must
beremoved before
cleaning and shall specify
which utensils can beleft
intheoven during cleaning.
 During thepyrolytic cleaning
process, surfaces can heat
up more than usual, children
should therefore bekept
atasafe distance.
 If the supply cord is damaged,
it must be replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid a
hazard.

SM 86 P
– 6 –
EN
During cooking, moisture may condense inside
theoven cavity orontheglass ofthedoor. This
isa normal condition. toreduce this effect,
wait 10-15 minutes after turning onthepower
before putting food inside theoven. inany
case, thecondensation disappears when
theoven reaches thecooking temperature.
 Cook thevegetables inacontainer with
alid instead ofanopen tray.
 WARNING: before initiating theautomatic
cleaning cycle:
 Clean theoven door
 Remove large orcoarse food residues from
theinside oftheoven using adamp sponge.
Do not use detergents;
 Remove all accessories and thesliding rack
kit (where present);
 Do not place tea towels
 In ovens with meat probe itisnecessary,
before making thecleaning cycle, close
thehole with thenut provided. Always
close thehole with thenut when themeat
probe isnot used.
 Connect aplug tothesupply cable that
isable tobear thevoltage, current and load
indicated onthetag and having theearth
contact. thesocket must besuitable for
theload indicated onthetag and must
behaving theearth contact connected and
inoperation. theearth conductor isyellow-
green incolour. This operation should
becarried out byasuitably qualified
professional. incase ofincompatibility
between thesocket and theappliance
plug, ask aqualified electrician
tosubstitute thesocket with another
suitable type. theplug and thesocket
must beconformed tothecurrent norms
oftheinstallation country. Connection
tothepower source can also bemade
byplacing anomnipolar breaker between
theappliance and thepower source
that can bear themaximum connected
load and that isin line with current
legislation. theyellow-green earth cable
should not beinterrupted bythebreaker.
thesocket oromnipolar breaker used for
theconnection should beeasily accessible
when theappliance isinstalled.
 The type ofpower cable must
beH05V2V2-F.
 Failure tocomply with theabove can
compromise thesafety oftheappliance
and invalidate theguarantee.
 Any excess ofspilled material should
beremoved before cleaning.
 When you place theshelf inside, make
sure that thestop isdirected upwards and
intheback ofthecavity.
 The shelf must beinserted completely into
thecavity
 WARNING: Do not line theoven walls with
aluminum foil orsingle-use protection
available from stores. Aluminum foil
orany other protection, indirect contact
with thehot enamel, risk melting and
deteriorating theenamel oftheinsides.
 WARNING: Never remove theoven door seal.
Recommendations
After each use oftheoven, aminimum
ofcleaning will help keep theoven perfectly
clean.
In order toprevent excessive dirtying ofyour
oven and theresulting strong smokey smells,
we recommend not using theoven atvery
high temperature. Itisbetter toextend
thecooking time and lower thetemperature
alittle. Inaddition totheaccessories supplied
with theoven, we advise you only use dishes
and baking moulds resistant tovery high
temperatures.
Proper installation and placement
The manufacturers have no obligation tocarry
this out. If theassistance ofthemanufacturer
isrequired torectify faults arising from
incorrect installation, this assistance isnot
covered bytheguarantee. theinstallation
instructions for professionally qualified
personnel must befollowed. Incorrect
installation may cause harm orinjury topeople,
animals orbelongings. Themanufacturer
cannot beheld responsible for such harm
orinjury.
 Keep children away from thedevice and
thepackaging material.

– 7 –
SM 86 P EN
If theoven isto bepermanently connected
tothepower supply:
 Ensure that thedevice isinstalled only
bythecustomer service, anelectrician
ortrained personnel with theappropriate
knowledge/education.
 Ensure that thedevice isconnected
directly tothemains socket. Ensure that
no adapters, no multi-sockets and no
extension cables are used toconnect
thedevice.
 Ensure that thedevice isnot exposed
toatmospheric agents (rain, sun).
Risk ofdeath!
 Keep pets away from thedevice.
 Packaging materials, e.g. plastic film
and polystyrene, can bedangerous for
children.
 Keep packaging material away from
children.
Proper use
 Only use thedevice toprepare and cook
food.
 Use oven gloves when placing containers
intheoven orwhen taking containers out
oftheoven.
 Observe themanuals ofthecooking
devices that are used with theoven when
using thedevice.
 Do not place power cables ofother electric
appliances onhot parts oftheoven.
 Do not use flammable liquids near
theoven.
Risk ofoverheating and malfunction
oftheoven due toblocked ventilation!
 Do not block theventilation ofthefan
orthecooling openings above theoven
door.
Risk ofburns!
 When opening orclosing thedoor, always
hold thedoor handle inthemiddle.
Risk ofelectric shock due
todamaged device!
 Do not switch onadamaged device.
 Switch off thefuse inthefuse box.
 Contact thecustomer service.
Risk ofelectric shock!
 Do not touch thedevice with wet parts
ofyour body.
 Do not use thedevice when barefoot.
 Do not pull onthedevice orpower cable
tounplug itfrom thesocket.
Maintenance and cleaning
Before maintenance orcleaning:
 Disconnect thedevice from thepower
supply, e.g., switch off thefuse
inthefuse box.
Risk ofelectric shock due
toentering liquid!
The device contains electrical components.
 Make sure that no liquid enters theinterior
ofthedevice.
 Do not use pressurised steam toclean
thedevice.
 Do not use awet cloth toclean
theoperating elements.
Repair
 Do not allow anyone except qualified
personnel toinstall orrepair theappliance.
 Contact aservice centre authorised
bythemanufacturer orqualified personnel
inthefollowing cases:
– Immediately after unpacking, intheevent
ofdoubts regarding theintegrity
ofthedevice
– During installation (according
tothemanufacturer‘s instructions)
– Doubts regarding thecorrect operation
ofthedevice
– Malfunction orpoor operation
– Replacing thepower socket if incompatible
with thepower plug ofthedevice

SM 86 P
– 8 –
EN
Taking out ofservice
 If theoven isno longer tobe used, call
theservice centre orqualified personnel
todisconnect itfrom thepower supply.
Information for energy saving
Where possible, avoid pre-heating theoven
and always try tofill it. Open theoven door as
infrequently as possible, because heat from
thecavity disperses every time itisopened.
For asignificant energy saving, switch off
theoven between 5and 10 minutes before
theplanned end ofthecooking time, and
use theresidual heat that theoven continues
togenerate. Keep theseals clean and
inorder, toavoid any heat dispersal outside
ofthecavity. If you have anelectric contract
with anhourly tariff, the„delayed cooking“
programme makes energy saving more
simple, moving thecooking process tostart
atthereduced tariff time slot.
OVERVIEW
1
2
3
5
4
6
1. Control panel
2. Shelf positions (lateral wire grid if included)
3. Metal grill
4. Drip pan
5. Fan (behind thesteel plate)
6. Oven door
Accessories
Metal grill Drip pan
Holds baking trays and plates. Collects theresidues that drip during thecooking
offoods onthegrills.
Lateral wire grids

– 9 –
SM 86 P EN
INSTALLATION
The manufacturers have no obligation tocarry
this out. If theassistance ofthemanufacturer
isrequired torectify faults arising from
incorrect installation, this assistance isnot
covered bytheguarantee.
 The installation instructions for
professionally qualified personnel must
befollowed.
 Incorrect installation may cause harm
orinjury topeople, animals orbelongings.
 The manufacturer cannot beheld
responsible for such harm orinjury.
 The oven can belocated high inacolumn
orunder aworktop.
 Before fixing, you must ensure good
ventilation intheoven space toallow proper
circulation ofthefresh air required for
cooling and protecting theinternal parts.
 Make theopenings specified onlast page
according tothetype offitting.
Electrical connection
 ENSURE THAT ANELECTRICIAN
ORQUALIFIED TECHNICIAN MAKES
THEELECTRICAL CONNECTIONS.
 The power supply towhich theoven
isconnected must conform with thelaws
inforce inthecountry ofinstallation.
 The manufacturer accepts no responsibility
for any damage caused bythefailure
toobserve these instructions.
 The oven must beconnected
toanelectrical supply with anearthed
wall outlet oradisconnector with multiple
poles, depending onthelaws inforce
inthecountry ofinstallation.
 The electrical supply should beprotected
with suitable fuses and thecables used
must have atransverse section that can
ensure correct supply totheoven.
Connection
 The oven issupplied with apower
cable that should only beconnected
toanelectrical supply with 220-240 V,
50-60 Hz power between thephases
orbetween thephase and neutral.
Before theoven isconnected totheelectrical
supply, itisimportant tocheck:
9power voltage indicated onthegauge;
9the setting ofthedisconnector.
 The grounding wire connected totheoven‘s
earth terminal must beconnected
totheearth terminal ofthepower supply.
WARNING! Before connecting
theoven tothepower supply, ask aqualified
electrician tocheck thecontinuity ofthepower
supply‘s earth terminal. Themanufacturer
accepts no responsibility for any accidents
orother problems caused byfailure toconnect
theoven totheearth terminal orbyanearth
connection that has defective continuity.
Note: as theoven could require maintenance
work, itisadvisable tokeep another wall
socket available so that theoven can
beconnected tothis if itisremoved from
thespace inwhich itisinstalled. Thepower
cable must only besubstituted bytechnical
service staff orbytechnicians with equivalent
qualifications.
Switching onthefirst time
Preliminary cleaning
 Clean theoven before using for thefirst time.
 Wipe over external surfaces with adamp
soft cloth.
 Wash all accessories and wipe inside
theoven with asolution ofhot water and
washing up liquid.
 Set theempty oven tothemaximum
temperature and leave onfor about 1hour,
this will remove any lingering smells
ofnewness.

SM 86 P
– 10 –
EN
OPERATION
Control Panel
Key Function
1Timer/automatic mode 5LCD display adjustment controls
2Fan function 6Function selector knob
3Defrost mode 7Programme selector knob
4Temperature orclock display
Function How toactivate How todeactivate What itdoes Why itisneeded
SILENCE
MODE
Rotate theleft
function selector
totheposition „
Silence mode“
Rotate thefunction
selector
totheposition OFF.
Enables you toturn
off thesound
oftheminute
minder.
To turn off thesound
oftheminute minder
SET
THETIME
Rotate theleft
function selector
totheposition “Set
thetime”
Use thebuttons „
+ „ or„ - „ toset
thetime
Rotate thefunction
selector
totheposition OFF.
Enables you
toset thetime
which appears
onthedisplay
To set thetime
NB : Set thetime when
you first install your oven
orjust after ablack out (the
clock isshowing apulsating
12.00)
COOKING
DURATION
Turn theright
function selector
toacooking
function
Rotate theleft
function selector
totheposition
„Cooking Time
Duration”
Set thetime
ofcooking byusing
buttons „ + „ and
„ - „
Lighting Auto
appears
When thecooking
time has elapsed,
theoven switch
off automatically
and thealarm rings
for few seconds
tostop thecooking
functions early,
turn thefunction
control toOFF
orset thetime
on00.00; byrotating
thefunction selector
toCooking Time
Duration and
byusing thebuttons
„+ „ and „ - “
It allows topreset
thecooking time
required for
therecipe chosen.
When thecooking
time isset, turn
thefunction selector
toOFF togo back
toactual time.
To view thecooking
time selected, turn
theleft function
selector toCooking
Time duration.
For cooking thedesired
recipes.

– 11 –
SM 86 P EN
END of
COOKING
Turn theright
function selector
toacooking
function
Rotate theleft
function selector
totheposition „End
ofcooking“
Set theend time
ofcooking byusing
buttons „ + „ and
„ - „
Lighting Auto
appears
When thecooking
time has elapsed,
theoven switch off
automatically.
To stop thecooking
functions early, turn
thefunction control
toOFF
It allows topreset
theend ofcooking
time you want.
When thecooking
time isset, turn
thefunction selector
toOFF togo back
toactual time.
To view thecooking
time selected, turn
theleft function
selector toEnd
ofcooking Time
This function isnormally
used with theCOOKING
DURATION function
For example, thedesired
food needs tocook for 45
minutes and I want itto
beready for 12.30; inthis
case: attheend oftheset
time, theoven automatically
switches off and analarm
sounds. Select thedesired
cooking function. Set
thecooking duration to45
minutes (“-” “+”). Set
theend ofcooking to12:30
(“-” “+”). Cooking will
automatically begin at11:45
(12:30 minus 45 minutes),
attheend oftheset
cooking time, theoven will
automatically switch off.
WARNING: bysetting only
theend ofcooking time, and
not thecooking duration,
theoven will immediately
switch onand switch off
attheend oftheset cooking
time.
MINUTE
MINDER
Turn theleft
function selector
totheposition
Minute Minder.
Set thetime
ofcooking byusing
buttons
“+”and “-”
Set thetime
on00.00
byturning theleft
function selector
totheposition
Minute Minder, and
using thebutton „ - “
Emits anaudible
signal attheend
ofaset time.
During operation,
thedisplay shows
theremaining time.
Allow touse theoven as
alarm even if theoven
isswitch off
CHILD
SAFETY
LOCK
Turn theleft
function selector
totheposition Child
lock.
Press thebutton „ +
„ during 5seconds
Child lock
isavailable when
„ STOP „ appears
ondisplay
Turn back theleft
function selector
toChild lock and
press button „ + „
during
5 seconds.
Indication STOP
disappears.
The oven cannot
beused.
This function isuseful
when there are children
inthehouse.
WARNING! thefirst operation tocarry out
after installation, orafter apower cut, isto
set thetime ofday (a power cut has occured if
thedisplay isflashing 12:00).
200° - thetemperature LED “°” flashes until
thedisplayed temperature isreached.
HOT - When aprogramme finishes, if theoven
isstill hot, thedisplay shows „HOT“, alternating
with thetime, even if theknobs are positioned
toOFF.

SM 86 P
– 12 –
EN
COOKING PROGRAMS
Program T °C
default Description (depends ontheoven model)
LAMP
Turns ontheoven light.
40
DEFROST
When thedial isset tothis position. thefan circulates air atroom temperature around
thefrozen food so that itdefrosts inafew minutes without theprotein content ofthefood
being changed oraltered.
210
FAN COOKING*
We recommend you use this method for poultry, pastries, fish and vegetables. Heat
penetrates into thefood better and both thecooking and preheating times are reduced.
You can cook different foods atthesame time with orwithout thesame preparation inone
ormore positions. This cooking method gives even heat distribution and thesmells are not
mixed. Allow about ten minutes extra when cooking foods atthesame time.
220
CONVENTIONAL COOKING*
Both top and bottom heating elements are used. Preheat theoven for about ten minutes. This
method isideal for all traditional roasting and baking. For seizing red meats, roast beef, leg
oflamb, game, bread, foil wrapped food (papillotes), flaky pastry. Place thefood and its dish
onashelf inmid position.
210
FAN + LOWER ELEMENT
The bottom heating element isused with thefan circulating theair inside theoven. This
method isideal for juicy fruit flans, tarts, quiches and pâté.
It prevents food from drying and encourages rising incakes, bread dough and other bottom-
cooked food. Place theshelf inthebottom position.
200
FAN ASSISTED GRILL*
Use theturbo-grill with thedoor closed.
The top heating element isused with thefan circulating theair inside theoven. Preheating
isnecessary for red meats but not for white meats. Ideal for cooking thick food items, whole
pieces such as roast pork, poultry, etc. Place thefood tobe grilled directly ontheshelf
centrally, atthemiddle level. Slide thedrip tray under theshelf tocollect thejuices. Make
sure that thefood isnot too close tothegrill. Turn thefood over halfway through cooking.
L3
GRILL
Use thegrill with thedoor closed.
The top heating element isused alone and you can adjust thetemperature. Five minutes
preheating isrequired toget theelements red-hot. Success isguaranteed for grills, kebabs
and gratin dishes. White meats should beput atadistance from thegrill; thecooking time
islonger, but themeat will betastier. You can put red meats and fish fillets ontheshelf with
thedrip tray underneath.
L3 SUPER GRILL
Grill Super: 3000 W
ECO PYROLYSIS
*Tested in accordance with the CENELEC EN 60350-1.

– 13 –
SM 86 P EN
CLEANING AND CARE
The lifecycle oftheappliance can beextended
through regular cleaning.
 Wait for theoven tocool before carrying out
manual cleaning operations.
 Never use abrasive detergents, steel wool
orsharp objects for cleaning, so as tonot
irreparably damage theenamelled parts.
 Use only water, soap orbleach-based
detergents (ammonia).
Glass parts
 It isadvisable toclean theglass window
with absorbent kitchen towel after every
use oftheoven.
 To remove more obstinate stains, you can
use adetergent-soaked sponge, well wrung
out, and then rinse with water.
Oven window seal
 If dirty, theseal can becleaned with
aslightly damp sponge.
Accessories
 Clean accessories with awet, soapy sponge
before rinsing and drying them: avoid using
abrasive detergents.
Drip pan
 After using thegrill, remove thepan from
theoven.
 Pour thehot fat into acontainer and wash
thepan inhot water, using asponge and
washing-up liquid.
 If greasy residues remain, immerse thepan
inwater and detergent. Alternatively, you
can wash thepan inthedishwasher oruse
acommercial oven detergent.
 Never put adirty pan back into theoven.
Pyrolysis
The oven isequipped with apyrolyser cleaning
system, which destroys food residues athigh
temperature. theoperation iscarried out
automatically bymeans oftheprogrammer.
theresulting fumes are rendered “clean”
bypassing over aPyrolyser wich starts as soon
as cooking begins.
As very high temperatures are required
bythePyrolyser, theoven door isfitted with
asafety lock. thepyrolyser can bestopped
atany time. thedoor cannot beopened until
thesafety lock isdisplayed.
Note: If ahob has been fitted above theoven,
never use thegas burners ortheelectric
hot-plates while thePyrolyser isworking, this
will prevent thehob from overheating.
TWO PYROLYTIC CYCLE are pre-set:
–ECO PYROCLEAN: cleans amoderately
stained oven. Operates for aperiod of
90 minutes.
–SUPER PYROCLEAN: cleans aheavily
stained oven. Operates for aperiod of
120 minutes.
 Never use commercially available cleaning
products onaPyrolytic oven!
Note: Carrying out Pyrolytic cleaning
immediately after cooking allows you totake
advantage ofresidual heat, thus saving energy.
Before executing apyrolytic cycle
 Remove all theaccessories from
theoven because they are not able
totolerate thehigh temperatures used
during thepyrolytic cleaning cycle;
inparticular removing grids, side racks
and thetelescopic guides. inovens with
meat probe itisnecessary, before making
thecleaning cycle, close thehole with
thenut provided.
 Remove any large spillages orstains as
itwould take too long todestroy them.
 Also excessively large amounts ofgrease
could ignite when subject tothevery high
temperatures ofthePyrolytic cycle.
 Close theoven door.
 Excess spillage must beremoved before
cleaning.
 Clean theoven door.
 Remove large orcoarse food residues
from theinside oftheoven using adamp
sponge. Do not use detergents.
 Remove all accessories and thesliding
rack kit (where present).
 Do not place tea towels.

SM 86 P
– 14 –
EN
Using thepyrolytic cycle
 Rotate thefunction selector
totheposition .
 On thedisplay, appears theindication
„ECO„ or„SUP„.
 The preset time is90 min, this can
bevaried from 90 min (Eco mode) to
20 min (Sup mode) via the programmer
(setting button „ + „ or„ - „).
 If theoven isvery dirty, itisrecommend
o increase thetime to120 min, if
theoven ismoderately dirty reduce
thecleaning cycle time to90 min.
 It ispossible todefer thestart time
ofthepyroclean cycle bychanging theEND
time via theprogrammer.
 After few minutes, when theoven
reaches ahigh temperature, thedoor
locks automatically. thepyroclean cycle
can bestopped atany time byturning
thefunction selector back to‚0‘ (the word
OFF will bedisplayed for 3seconds).
 Once thepyroclean cycle isfinished,
thepyrolysis will switch off automatically.
 On thedisplay appears theindication
„END“ until thedoor islocked then
„0--n“.
 You can turn thefunction selector back
to„ 0„ but if thetemperaure isstill high,
the„0--n „ indication appears toinform that
thedoor islocked.
Use ofpyrolytic cycle inTouch Control
ovens
 Rotate thefunction selector into position
pyrolisys.
 The display will show either „ECO“
or„SUP“.
 The pre-set time is 90 minutes but it can be
varied from 90 min (Eco mode) to 120min
(Sup mode) using theprogrammer („ +“ or
„-“ key).
 If the oven is very dirty, the time
should be increased to 120 min, while
if the oven is only a slightly dirty,
reduce the cleaning cycle to 90 min.
Maintenance
Removal oftheoven window
 Open thefront window.
 Open theclamps ofthehinge housing
ontheright and left side ofthefront window
bypushing them downwards.
 Replace thewindow bycarrying out
theprocedure inreverse.
A
Removal and cleaning oftheglass door
 Open theoven door.
 Lock thehinges, remove thescrews and
remove theupper metal cover bypulling
itupwards.
 Remove theglass, carefully extracting
itfrom theoven door (note: inpyrolytic
ovens, also remove thesecond and third
glass (if present)).
 At theend ofcleaning orsubstitution,
reassemble theparts inreverse order.
 On all glass, theindication „Pyro“ must
belegible and positioned ontheleft
side ofthedoor, close totheleft-hand
lateral hinge. inthis way, theprinted label
ofthefirst glass will beinside thedoor.
Changing the bulb
 Disconnect theoven from themains supply.
 Undo theglass cover, unscrew thebulb and
replace itwith anew bulb ofthesame type.
 Once thedefective bulb isreplaced, replace
theglass cover.

– 15 –
SM 86 P EN
AB 1
2
3
7
5
3
1
2
4
6
Removal and cleaning oftheglass door
31
2 4
Changing thebulb

SM 86 P
– 16 –
EN
TROUBLESHOOTING
Problem Possible cause Solution
The oven does not heat up The clock isnot set Set theclock
The oven does not heat up The child lock ison Deactivate thechild lock
The oven does not heat up A cooking function and temperature
has not been set
Ensure that thenecessary settings
are correct
TECHNICAL DATA
Power supply voltage and frequency 220-240 V, 50-60 Hz
Total power and fuse rating 3000 W ~ 16 A
Power and heating elements
Upper 1000 W
Lower 1250 W
Grill 2250 W
Circular 2000 W
Fan 30 W
Tangential fan 15 W
Oven lamp 1 x 25 W
SUPPORT
In the event of any operation problems,
contact a Franke Technical Service Centre
(refer to the attached list).
Never use theservices ofunauthorised
technicians.
Specify:
– the type offault;
– the appliance model (Art./Cod.);
– the serial number (S.N.).
This information
isgiven
ontheappliance
dataplate
onthewarranty
certificate.

– 17 –
SM 86 P EN
DISPOSAL
Information for users
The symbol ontheproduct
oronthepackaging indicates that
thedevice must not bedisposed
ofin thedomestic waste.
By disposing ofthedevice inaproper way
you help toavoid harmful consequences
toenvironment and health.
Further information about recycling thedevice
isavailable from thecompetent authority,
thelocal refuse disposal service orthevendor
ofthedevice.
Dispose ofthedevice, which isto
bediscarded, via aspecialised waste collection
point for electronic and electrical devices.
In accordance with theDirective 2012/19/
EU, regarding thereduction ofthehazardous
substances used inelectrical and electronic
appliances, and waste disposal.
The barred dustbin symbol ontheappliance
indicates that attheend ofits working life
theproduct must not bedisposed ofas
household waste.
Consequently, when theappliance has reached
theend ofits working life theuser must take
itto asuitable recycling centre for electronic
and electrotechnical waste, orreturn itto
thedealer when purchasing anew appliance
ofequivalent type.
Proper separate waste collection
ofthescrapped appliance for subsequent
recycling, treatment and environmentally-
friendly disposal helps prevent apotentially
negative impact ontheenvironment and health
and facilitates recycling ofthematerials used
inappliance construction.
Information for test institutes
To calculate thevolume, remove theinternal
wire side runners, if present (according
tostandards 2009/60350-50304/EN).

SM 86 P
– 18 –
DE
ZU DIESER BEDIENUNGSANLEITUNG
Diese Bedienungsanleitung gilt für
verschiedene Modelle des Geräts. Auf
diese Weise ist es möglich, dass einige der
beschriebenen Merkmale und Funktionen an
Ihrem spezifischen Modell nicht verfügbar sind.
 Lesen Sie die Bedienungsanleitung durch,
bevor Sie das Gerät benutzen.
 Bewahren Sie die Bedienungsanleitung auf.
 Benutzen Sie das in dieser
Bedienungsanleitung beschriebene Gerät
nur gemäß der bestimmungsgemäßen
Verwendung.
Franke behält sich das Recht vor, Änderungen
am Produkt ohne vorherige Ankündigung
vorzunehmen. Alle Informationen waren zum
Zeitpunkt der Veröffentlichung korrekt.
Symbol Bedeutung
Warnzeichen. Warnung vor Verletzungsgefahren.
Maßnahmen in Sicherheits- und Warnhinweisen zur Vermeidung von Schäden und Verletzungen.
Handlung. Hier müssen Sie etwas tun.
Resultat. Ergebnis einer oder mehrerer Handlungen.
INHALTSVERZEICHNIS
Zu dieser Bedienungsanleitung 18
Bestimmungsgemäße Verwendung 19
Sicherheitshinweise 19
Empfehlungen 22
Korrekte Installation und Aufstellung 22
Richtige Verwendung 22
Pflege und Reinigung 23
Reparatur 23
Außerbetriebsetzung 23
Informationen zum Energiesparen 23
Überblick 23
Installation 24
Elektrischer Anschluss 24
Erstmaliges Einschalten 25
Bedienung 25
Bedienfeld 25
Garprogramme 28
Reinigung/Instandhaltung 29
Pyrolysefunktion 29
Pflege 31
Störungsbehebung 32
Technische Daten 32
Support 33
Entsorgung 33

– 19 –
SM 86 P DE
BESTIMMUNGSGEMÄSSE VERWENDUNG
Der Multifunktionsofen wurde ausschließlich
für den nicht gewerblichen, privaten Gebrauch
im Haushalt entwickelt. Der Ofen sorgt für
Profileistungen im Haushalt.
Mit diesem äußerst vielseitigen Gerät lassen
sich verschiedene Garmethoden sicher und
einfach auswählen.
SICHERHEITSHINWEISE
 Gebrauchsanweisung und
Sicherheitshinweise vor
der Verwendung des Ofens
aufmerksam lesen.
 Gebrauchsanweisung
sorgfältig aufbewahren,
um auch zu einem
späteren Zeitpunkt darauf
zurückgreifen zu können.
Der Hersteller haftet nicht für
etwaige Schäden, die durch
fehlerhafte Installation und
falschen, unsachgemäßen
oder unangemessenen
Gebrauch entstehen können.
Die elektrische Sicherheit des
Ofens ist nur gewährleistet, wenn
er an eine vorschriftsgemäße
Erdungsanlage angeschlossen ist.
Für den sicheren und
effizienten Betrieb dieses
Elektrogeräts:
 Nur autorisierte
Kundendienststellen
kontaktieren.
 Nehmen Sie keine
Änderungen an den
Gerätefunktionen vor.
 Dieses Gerät kann von
Kindern ab 8 Jahren
und von Personen mit
eingeschränkten physischen,
sensorischen oder geistigen
Fähigkeiten oder mangelnder
Erfahrung oder Kenntnisse
im Umgang mit dem Gerät
benutzt werden, wenn
sie vorher in die sichere
Verwendung des Geräts
eingewiesen wurden und die
damit verbundenen Gefahren
verstanden haben. Kinder
dürfen nicht mit dem Gerät
spielen. Unbeaufsichtigte
Kinder dürfen das Gerät
nicht reinigen oder warten.
 Dieses Gerät ist kein
Spielzeug.
 Lassen Sie Kinder in der
Nähe des Geräts nicht
unbeaufsichtigt.
 Kinder nicht mit dem Gerät
spielen lassen.
 Kinder dürfen das Gerät
oder die Bedienelemente
während des Betriebs oder
unmittelbar danach nicht
berühren.

SM 86 P
– 20 –
DE
 Das Gerät muss so
eingebaut werden, dass die
vollständige Trennung von
der Stromquelle mit einem
Kontaktöffnungsabstand
ermöglicht wird (gemäß
Überspannungskategorie III).
 Die Trennvorrichtung ist gemäß
den Verkabelungsvorschriften
in die feste Verkabelung
einzubinden.
 Nur das für diesen
Ofen empfohlene
Bratenthermometer
verwenden.
 Das Gerät sollte nicht
hinter einer Dekortür
installiert werden, um eine
Überhitzung zu vermeiden.
Verbrennungsgefahr!
 Während der Verwendung
wird das Gerät heiß. Es sollte
sorgfältig vermieden werden,
Heizelemente innerhalb des
Ofens zu berühren. Kinder
unter 8 Jahren dürfen sich
dem Gerät nur unter Aufsicht
nähern.
WARNUNG: Die zugänglichen
Teile können während der
Verwendung heiß werden. Kleine
Kinder sollten ferngehalten
werden.
VORSICHT: Damit es nicht
zu einer unbeabsichtigten
Rücksetzung des
Temperaturbegrenzers kommen
kann, darf das Gerät nicht
über ein externes Schaltgerät
wie eine Zeitschaltuhr mit
Strom versorgt oder an einen
elektrischen Stromkreis
angeschlossen werden, der
regelmäßig von der Anlage ein-
und ausgeschaltet wird.
Verbrennungsgefahr!
Der Türgriff kann aufgrund
austretender Heißluft zum Rand
hin heißer sein.
 Die Bedienknöpfe müssen
immer in ausgeschalteter
Position sein, wenn der Ofen
nicht benutzt wird.
WARNUNG: Vergewissern Sie
sich vor dem Auswechseln
der Lampe, dass das Gerät
ausgeschaltet ist, um die
Möglichkeit von Stromschlägen
auszuschließen.
 Verwenden Sie keine
scheuernden Reinigungsmittel
oder scharfen Metallschaber
zum Reinigen der Glastür
des Ofens/der Glasflächen
von Scharnierdeckeln des
Kochfelds (wenn zutreffend),
da diese die Oberfläche
zerkratzen und zum Glasbruch
führen können.
 Reinigen Sie das Gerät nicht
mit Dampfreinigern oder
direktem Wasserstrahl.
 Übermäßige Verschüttungen
müssen vor der Reinigung
