0English
7612982151170 .........Remote Control
Please refer to the graphics in the German Installation and Operating Instructions.
0Table of Contents
1. Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Description of Product
3. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5. User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation, Function and Commissioning
6. Switching the Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7. Activating the Fitting for Remote Control . . . . . . . . . . . . . . . . . . . 4
8. Functions for Wash Fittings and Urinals. . . . . . . . . . . . . . . . . . . . 5
9. Wash Fitting Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
10. Settings for Hygiene Unit and Hygiene Kit . . . . . . . . . . . . . . . . . . 11
11. Settings for AQUACONTACT. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12. Urinal Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
13. Additional Settings for the Urinal . . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance
14. Changing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1. Warranty
Liability is accepted according to the General Terms and Conditions of Business and
Supply.
2. Important Notes
Give these instructions to the operator.
All rights reserved to make technical alterations.
3. Application
Remote control for wash fittings and flush valves of the PROTRONIC,
PROTRONIC-C, PROTRONIC-S, PROTRONIC T, hygiene unit, hygiene kit (fittings
unit) and AQUA CONTACT series, for setting the function parameters.
EN

4
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
4. Dimensions
5. User Interface
A: Range
B: Time
C: Functions:
on/off: depending on fitting
D: Additional combination keys
E: LED
"Auto repeat" function
When the buttons for setting the range and the extension of flow duration are contin-
ually pressed, the command is sent again at regular intervals.
6. Switching the Mode
The fittings operate with different baud rates. The remote control must be set on the
fitting before activation.
6.1 Press and hold the "Reset" key.
6.2 Press the "–" ( ) key.
• Protronic-C, Protronic-T
The LED in the remote control flashes 2 times slowly.
• Protronic-S, Hygiene unit, Hygiene set, AQUACONTACT
The LED in the remote control flashes 4 times rapidly.
7. Activating the Fitting for Remote Control
☞Perform the following with the remote activation before each adjustment:
• Washbasin fittings: Trigger the valve.
• AQUACONTACT: Trigger the valve. Stop the valve.
• Urinal fittings: Place an object at the sensor for at least 5 s.
7.1 Direct the remote control (b) vertically towards the sensor (a) of the fitting at the
specified distance (d) and press a key.
☞When the key is pressed properly, the LED (c) in the remote control flashes 2 times.
If the LED does not flash, this means either that the keys were not pressed properly
or that the battery in the remote control is empty (see chapter 14.).

5
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
7.2 When a remote command is accepted, the LED in the sensor (d) of the fitting
flashes. The flashing intervals are described in the relevant functional description.
• Each time that a remote command is accepted, the fitting remains in remote
control mode for a further 60s.
• This does not apply for cleaning switch-off.
☞A flashing LED in the sensor (d) of the fitting is only visible at sensor height on the
Protronic-S series of products.
8. Functions for Wash Fittings and Urinals
Test Mode = simulation without water
In Test Mode, the sensor range can be tested and adjusted without flowing water.
8.1 Press the TEST key.
• Test mode is activated.
• The LED in the sensor of the fitting flashes:
– 4 × short, break, 4 × short
• The LED in the sensor of the fitting lights up when a hand or object is detected.
8.2 Adjust the range.
8.3 Exit the adjustment mode.
• Press the TEST key.
or
• Wait 60 seconds.
• The LED in the sensor of the fitting flashes:
– 4 × short, break, 4 × short
• The LED in the sensor of the fitting is off.
Setting the Range
8.4 Use the + and – keys ( ) to adjust the range in individual steps.
• The LED in the sensor of the fitting flashes:
– 4 × short for each adjustment by one step
– 2 x long when the respective end setting is reached

6
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Adjusting the extension of the flow duration/flushing time
8.5 Use the + and – ( ) keys to adjust the extension of the flow duration in individual
steps.
• The LED in the sensor of the fitting flashes:
– 4 × short for each adjustment by one step
– 2 x long when the respective end setting is reached
Switching off the fitting
8.6 Press the OFF key.
• The fitting is now permanently closed.
• The LED in the sensor of the fitting flashes:
– 3 × short, break, 3 × short, break, ...
8.7 Press the OFF key again.
• The fitting is ready for operation.
9. Wash Fitting Settings
Setting for continuous flow
For continuous flow, a time of 3.5 min or 11 min can be set (default 3.5 min).
9.1 Press the TEST key.
9.2 Press the OFF key repeatedly until the required mode has been set.
• The time for the continual flow is set.
• The LED in the sensor of the fitting flashes:
– 2 × long = 11 min continual flow time
– 4 × short = 3.5 min continual flow time
9.3 Exit the adjustment mode.
• Press the TEST key.
or
• Wait 60 seconds.
☞This function is not available for products manufactured before 1 June 2003. Press
the corresponding buttons to switch the fitting off.

7
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Activating continual flow (thermal disinfection)
9.4 Turn the mixing lever of the fitting to the hot water limit stop (see instructions for the
fitting).
9.5 Press the ON key.
• Continual flow is started (solenoid valve opens).
☞Continuous flow can be prematurely terminated by pressing the ON key again.
Setting the automatic safety shut-off.
When an object is continuously detected for 60s, water flow stops automatically.
9.6 Press and hold the RESET key.
9.7 Additionally press the OFF key within 2s.
• The LED in the sensor of the fitting flashes.
9.8 Use the + and – ( ) keys to adjust the switch-off time in individual steps.
• The LED in the sensor of the fitting flashes:
– 4 × short for each adjustment up to 60s by one step (5 s)
– 8 × short for each adjustment from 60s by one step (60 s)
– 2 x long when the respective end setting is reached
9.9 Wait 10 seconds.
• The system exits from the setting mode.
Activating/deactivating Hygiene Flushing
The "Hygiene flushing" function ensures water hygiene when the fitting is not used
for a prolonged period. After a certain adjustable interval on non-use, water flow is
activated for a selectable time.
Caution!
• When the “Hygiene Flushing” function is used, it must be ensured that the water
can flow away properly.
• When the "Hygiene flushing" function is to be used for both the hot and cold water
lines, the mixer lever of the fitting should be in the mixed-water position.
☞This function is not available for products manufactured before 1 May, 2002. When
the respective keys are pressed, the LED in the sensor of the fitting does not flash.
☞Important!
Protronic-C, Protronic-T: When the "Hygiene flushing" function is active, this state is
indicated by an LED within 3 minutes after the voltage supply is interrupted and
reconnected for object detection.
☞The factory default setting for "Hygiene Flushing" is deactivated.

8
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
9.10 Press and hold the RESET key.
9.11 Additionally press the OFF key within 2s.
• The LED in the sensor of the fitting flashes every second.
9.12 Release the RESET button.
9.13 Press the OFF key within 10 s.
• The LED in the sensor of the fitting flashes:
– 4 x short: The "Hygiene flushing" function is switched on.
– 2 × long: The "Hygiene flushing" function is switched off.
9.14 Wait 10 seconds.
• The system exits from the setting mode.
Setting the Flushing Interval
9.15 Press the TEST key.
9.16 Press the ON key repeatedly until the required mode has been set.
• The LED in the sensor of the fitting flashes:
9.17 Exit the adjustment mode.
• Press the TEST key.
or
• Wait 60 seconds.
Protronic-C, Protronic-T Protronic-S
– 2 × long = 1 day – 1 × short = 8 h
– 4 × short = 3 days – 2 × short = 24 h
– 3 × short = 48 h
– 4 × short = 72 h
☞The flushing interval is
factory-set to 3 days.
☞The flushing interval is
factory-set to 24 h.

9
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Adjusting flushing duration – Protronic C, Protronic T
The flushing duration can be set at one minute intervals from 1 to 10 minutes.
☞The flushing duration is factory-set to 5 minutes.
9.18 Press the TEST key.
9.19 Use the + and – ( ) keys to adjust the flushing duration in individual steps.
• The LED in the sensor of the fitting flashes:
– 4 × short = adjustment by one stage (approx. 1 minute).
– 2 × long = End setting reached.
9.20 Exit the adjustment mode.
• Press the TEST key.
or
• Wait 60 seconds.
Adjusting flushing duration – Protronic S
The flushing duration can be set as follows:
–10s
–30s
–60s
–2min
–3min
–5min
–7min
–10min
☞The flushing duration is factory-set to 10 seconds.
9.21 Press the TEST key.
9.22 Use the + and – ( ) keys to adjust the flushing duration in individual steps.
• The LED in the sensor of the fitting flashes:
– 4 × short = Adjust by one step.
– 2 × long = End setting reached.
9.23 Exit the adjustment mode.
• Press the TEST key.
or
• Wait 60 seconds.

10
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Resetting default factory settings (Reset)
9.24 Press the RESET key for at least 3 s.
• The system now has the factory settings again.
• The LED in the sensor of the fitting flashes:
– 4 × short, 3 × short, 3 x short
Changing the type of detection (only for on-wall washbasin mixer installation)
Water flow should start/stop when a hand approaches/moves away from the
sensor (3-7 cm).
9.25 Press the " –" key repeatedly until the minimum sensor range is reached.
• The LED in the sensor of the fitting flashes:
– 2 × long
9.26 Press the " –" key again.
• The type of detection has been changed. The sensor only responds when a hand
approaches/moves away. The range can be adjusted (see chapter 8.).
• The LED in the sensor of the fitting flashes:
– 5 × long, 3 × short
Water flow should start/stop when a person approaches/moves away from the
sensor (>35 cm).
9.27 Press the " +" key repeatedly until the maximum sensor range is reached.
• The LED in the sensor of the fitting flashes:
– 2 × long
9.28 Press the " +" key again.
• The type of detection has been changed. The sensor only responds when a
person approaches/moves away. The range can be adjusted (see chapter 8.).
• The LED in the sensor of the fitting flashes:
– 5 × long, 3 × short
Resetting the type of detection to the default factory setting
9.29 Press the RESET key.

11
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
10. Settings for Hygiene Unit and Hygiene Kit
Normal Mode
Start solenoid valve test
Warning!
When opening the solenoid valve cartridge for hot water, there is the risk of scalding.
10.1 Press the ON key.
• One by one, the solenoid valve cartridges open briefly.
Hygiene Mode
Start hygiene flushing
10.2 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
10.3 Press the ON key.
• Water flows for the set flushing time or until hygiene flushing is cancelled.
Stop hygiene flushing
10.4 Press the OFF key.
• Water stops.
• The fitting goes into Normal Mode.

12
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Setting the flushing interval
10.5 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
10.6 Use the + and – ( ) keys to adjust the flushing interval in individual steps.
• The LED in the sensor flashes.
Setting the flushing duration
10.7 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
10.8 Use the + and – ( ) keys to adjust the flushing duration in individual steps.
• The LED in the sensor flashes.
– 1 x short = Hygiene flushing off
– 2 × short = 8 h
– 3 × short = 24 h
– 4 × short = 48 h
– 5 × short = 72 h
☞The flushing interval is factory-set to 24 h.
– 1 x short = 10 s – 5 x short = 3 min
– 2 x short = 30 s – 6 x short = 5 min
– 3 x short = 60 s – 7 x short = 7 min
– 4 x short = 2 min – 8 x short = 10 min
☞The flushing duration is factory-set to 3 min.

13
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Reconfiguring the solenoid valve controller
☞By default, the solenoid valve controller is set so that at the start of hygiene flushing
both solenoid valve cartridges are opened.
10.9 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
10.10 Press the OFF key.
• The LED in the sensor flashes.
– Short = only the solenoid valve cartridge for cold water opens.
– Long = both solenoid valve cartridges open.
Exiting from Hygiene Mode
☞After a hygiene flushing cycle has completed, the fitting automatically switches to
Normal Mode.
10.11 Press the TEST key.
• The LED in the sensor flashes 4 × briefly.
or
Wait 60 seconds.
• The LED in the sensor does not flash.
TD Mode
Starting thermal disinfection
Warning!
Protective measures for persons (scald-protection) must be provided during thermal
disinfection, e.g. closing off sanitary rooms.
Failure to observe can cause bodily harm due to scalding.
10.12 Press and hold the RESET key.
10.13 Additionally press the OFF key within 2s.
• The LED flashes 4 × briefly.
• The fitting switches to Normal Mode.
• The LED flashes twice with a 1s interval.
10.14 Press the ON key.
• The LED flashes with 2s intervals.
• Thermal disinfection is started.

14
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
The process of thermal disinfection
• Start thermal disinfection
•Startdelay
The solenoid valve opens only after the set start delay.
Hot water starts to flow 10s after the start of thermal disinfection.
• Treatment time
Hot water flows for 2 min.
After 2 min, the water starts flowing in a pulsating mode for the remainder of the
set time (exposure phase).
• Safety window
During this time the water in the circulation line is to cool down to the preset
temperature.
• Cooling down phase
The remainder of the hot water in the fitting is flushed out.
Setting the parameters
☞The parameters for exposure time and cooling time cannot be set independently of
each other.
10.15 Press and hold the RESET key.
10.16 Additionally press the OFF key within 2s.
• The LED flashes 4 × briefly.
• The fitting switches to Normal Mode.
• The LED flashes twice with a 1s interval.
10.17 Use keys + and - ( ) to set the code for the desired pair of parameters.
☞By default, the parameter is set to code 7.
• The LED in the sensor confirms the code that was entered
– LED flashes briefly = unit digit
– LED flashes long = tens digit
Example: The LED flashes 2 x long and 1 x short = Code 21 was set. The exposure
time is 3 min. The cooling time is 60s
Cooling time 0 10s 20s 30s 60s
Exposure time 3 min 16111621
5 min 2 7 12 17 22
10 min 3 8 13 18 23
15 min 4 9 14 19 24
20 min 5 10152025

15
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Stopping thermal disinfection
10.18 Press and hold the RESET key.
10.19 Additionally press the OFF key within 2s.
• The LED in the sensor flashes with 1s intervals
• If the fitting is in the exposure phase, the cooling phase starts immediately.
• If the fitting is in the cooling phase, the solenoid valves are closed immediately.
Thermal disinfection emergency-stop
10.20 Press key OFF 2 times.
• The LED in the sensor does not flash.
Exiting from TD Mode
10.21 Press keys RESET and OFF.
• The LED flashes 4 × briefly.
or
if thermal disinfection is being performed, wait for the end of the disinfection process.
Resetting default factory settings (Reset)
10.22 Press the RESET key for at least 3 s.
• The system now has the factory settings again.
• The LED flashes briefly 4 × short (2 × in succession).
11. Settings for AQUACONTACT
☞Important!
Activate the fitting for remote control (see chapter 7.).
Normal Mode
Start solenoid valve test
Warning!
When opening the solenoid valve cartridge for hot water, there is the risk of scalding.
11.1 Press the ON key.
• One by one, the solenoid valve cartridges open briefly.

16
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Setting the range for the body reflection function
☞When the flow duration is set to 3s, the fitting is in the Body Reflection Mode.
The range can be set in 24 steps.
– Range 1: 18 cm
– Range 24: about 50 cm
11.2 Use the + and – keys ( ) to adjust the range in individual steps.
• The LED in the sensor confirms the range that was entered
– LED flashes briefly = unit digit
– LED flashes long = tens digit
Switching off the fitting
11.3 Press the OFF key.
• The LED in the sensor flashes 4 × briefly.
• The fitting has been switched off.
• The LED in the sensor flashes with 3s intervals
Switching on the fitting
11.4 Press the OFF key.
• The LED in the sensor flashes 2 × long.
• The fitting has been switched on.
• The LED in the sensor does not flash.
Adjusting flow duration
11.5 Use the + and – keys ( ) to adjust the flow duration in individual steps.
• The LED in the sensor of the fitting flashes:
– 1 x short = 3 s – 7 x short = 1 mins
– 2 x short = 10 s – 8 x short = 2 min
– 3 x short = 20 s – 9 x short = 3 min
– 4 x short = 30 s – 1 x long = 4 min
– 5 x short = 40 s – 1 x long , 1 x short = 5 min
– 6 x short = 50 s
☞The flow duration is factory-set to 30s.

17
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Hygiene Mode
Start hygiene flushing
11.6 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
11.7 Press the ON key.
• Water flows for the set flushing duration.
Setting the Flushing Interval
11.8 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
11.9 Use the + and – ( ) keys to adjust the flushing interval in individual steps.
• The LED in the sensor of the fitting flashes:
Setting the Flushing Time
11.10 Press the TEST key.
• The LED flashes 4 × briefly.
• The fitting goes into Hygiene Mode.
• The LED flashes at 1 second intervals.
11.11 Use the + and – ( ) keys to adjust the flushing duration in individual steps.
• The LED in the sensor of the fitting flashes:
– 1 x short = Hygiene flushing off
– 2 × short = 2 h – 5 × short = 24 h
– 3 × short = 8 h – 6 × short = 48 h
– 4 × short = 12 h – 7 × short = 72 h
☞The flushing interval is factory-set to 24 h.
– 1 × short = 10 s – 5 × short = 3 min
– 2 × short = 30 s – 6 × short = 5 min
– 3 × short = 1 min – 7 × short = 7 min
– 4 × short = 2 min – 8 × short = 10 min
☞The flushing duration is factory-set to 10s.

18
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Exiting from Hygiene Mode
☞After a hygiene flushing cycle has completed, the fitting automatically switches to
Normal Mode.
11.12 Press the TEST key.
• The LED in the sensor flashes 4 × long.
or
Wait 60 seconds.
• The LED in the sensor does not flash.
TD Mode
Starting thermal disinfection
Warning!
Protective measures for persons (scald-protection) must be provided during thermal
disinfection, e.g. closing off sanitary rooms.
Failure to observe can cause bodily harm due to scalding.
11.13 Press and hold the RESET key.
11.14 Additionally press the OFF key within 2s.
• The LED flashes 4 × briefly.
• The fitting switches to Normal Mode.
• The LED flashes twice with a 1s interval.
11.15 Press the ON key.
• The LED flashes with 2s intervals.
• Thermal disinfection is started.
The process of thermal disinfection
• Start thermal disinfection
•Startdelay
The solenoid valve opens only after the set start delay.
Hot water starts to flow, at the earliest 10s after the start of thermal disinfection.
• Treatment time
Hot water flows for 2 min.
After 2 min, the water starts flowing in a pulsating mode for the remainder of the
set time (exposure phase).
• Safety window
During this time the water in the circulation line is to cool down to the preset
temperature.
• Cooling down phase
The remainder of the hot water in the fitting is flushed out.

19
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
Setting the parameters
☞The parameters for exposure time and cooling time cannot be set independently of
each other.
11.16 Press and hold the RESET key.
11.17 Additionally press the OFF key within 2s.
• The LED flashes 4 × briefly.
• The fitting switches to Normal Mode.
• The LED flashes twice with a 1s interval.
11.18 Use keys + and – ( ) to set the code for the desired pair of parameters.
☞By default, the parameter is set to code 6.
• The LED in the sensor of the fitting confirms the entered code
– LED flashes briefly = unit digit
– LED flashes long = tens digit
Example: The LED flashes 2 x long and 1 x short = Code 21 was set. The exposure
time is 3 min. The cooling time is 10 min.
☞The parameters for safety window and start delay cannot be set independently of
each other.
11.19 Press and hold the RESET key.
11.20 Additionally press the OFF key within 2s.
• The LED flashes 4 × briefly.
• The fitting switches to Normal Mode.
• The LED flashes twice with a 1s interval.
11.21 Use keys + and – ( ) to set the code for the desired pair of parameters.
Cooling time 0 1 min 3 min 5 min 10 min
Treatment time 3 min 1 6 11 16 21
5 min 2 7 12 17 22
10 min 3 8 13 18 23
15 min 4 9 14 19 24
20 min 510152025

20
ZMI_001_2000101087-ZAQUA091_#SEN_#AQU_#V5.fm
☞By default, the parameter is set to code 1.
• The LED in the sensor of the fitting confirms the entered code
– LED flashes briefly = unit digit
– LED flashes long = tens digit
Stopping thermal disinfection
11.22 Press the OFF key.
• The LED in the sensor flashes with 1s intervals
• If the fitting is in the exposure phase, the cooling phase starts immediately.
• If the fitting is in the cooling phase, the solenoid valves are closed immediately.
Thermal disinfection emergency-stop
11.23 Press key OFF 2 times.
• The LED in the sensor does not flash.
Exiting from TD Mode
11.24 Press and hold the RESET key.
11.25 Additionally press the OFF key within 2s.
• The LED flashes 4 × briefly.
or
if thermal disinfection is being performed, wait for the end of the disinfection process.
Resetting default factory settings (Reset)
11.26 Press the RESET key for at least 3 s.
• The system now has the factory settings again.
• The LED flashes briefly 4 × short (2 × in succession).
Safety time-window 0 h 0.5 h 1 h 2 h 4 h
Start delay 10 sec 16111621
30 sec 2 7 121722
1 min 3 8 131823
2 min 4 9 141924
3 min 5 10152025
