Franke Frames FS TS 906 I XS User manual

FS TS 906 I XS
Cooker Hood T-Shape Island
Kochfeldabzugshaube Insel
Hotte aspirante en T îlot
Afzuigkap T-vorm eiland
Cappa aspirante a T, isola
Campana extractora en forma de T Isla
Exaustor em forma de T para ilhas
Απορροφητήρα σε σχήα Τ
Frithængende T-formet emhætte
T-formet avtrekksvifte til kjøkkenøy
Spisfläkt i T-form, köksö
EN User manual
DE Bedienungsanleitung
FR Manuel d‘utilisation
NL Gebruikershandleiding
IT Istruzioni per l‘uso
ES Manual del usuario
PT Manual do utilizador
EL Εγχειρίδιο χρήστη
DA Brugervejledning
NO Brukermanual
SV Bruksanvisning

FS TS 906 I XS
– 3 –
EN
Table of conTenTs
About this manual 4
Intended use 4
Safety information 5
Overview 6
Operation 7
Switching the control panel on 7
Selecting lighting and lighting level 7
Selecting the power level 7
Switching the ventilation off 7
Toggling the intensive mode 7
Ventilation mode 24h 7
Shutoff delay 7
AutoMode 8
Filter saturation alarm 8
Alarm messages 8
Hood to hob connection 8
Cleaning and care 9
Cleaning the surfaces of the hood 9
Odour filter 9
Grease filter 9
Lighting 9
Spare parts and accessories 10
Maintenance and repair 10
Disposal 10
Customer service 10
Technical data 10

FS TS 906 I XS
– 4 –
EN
abouT This manual
This user manual applies to several models of the
device. Thus it may be possible that some of the
described features and functions are not available on
your specific model.
 Carefully read the user manual before using the
device.
 Keep the user manual.
 Use the device described in this user manual only
according to the intended use.
Symbol Meaning
Warning symbol. Warning against risks
of injury.
 Actions in safety and warning notes to
avoid injury or damage.
 Action step. Specifies an action to be
done.
 Result. Result of one or more action
steps.
9Precondition that has to be fulfilled be-
fore performing the following action.
inTended use
The hood was developed exclusively for domestic
use to eliminate cooking vapours.
The hood, which is equipped with a grease filter,
removes vapours forming over a stove top via an air
circulation or an air exhaust system.

FS TS 906 I XS
– 5 –
EN
safeTy informaTion
The manufacturer can not be made liable for
possible damage which may occur due to incorrect
installation and incorrect, improper or unreasonable
use of the device.
The hood can not support heavy loads.
 Do not climb, stand or sit on the hood.
 Do not place heavy objects on the hood.
Children of 8 years or older and persons with
restricted physical, sensory or mental abilities, or
with limited experience or knowledge, may not use
or clean the device, except they are supervised and
instructed by a person responsible for their safety.
Children under 8 years may not use or clean the
device even if supervised.
This device is not a toy.
 Keep children away from the device and the
packaging material.
 Do not leave children near the device unattended.
 Do not let children play with the device.
 When using the hood, observe the manuals of
the stove top and of the cooking devices that
are used beneath the hood or while the hood is
running.
Fire hazard and risk of injury due to open flame!
Deposits in the grease filter may catch fire.
 Do not use open flames near the device (e.g.
flambéing).
 Always clean or change all filters at the specified
intervals.
When using deep fat fryers, overheated oil can burst
into flames.
 Continuously monitor fryers during use.
Risk of eye injury due to LED light!
The LED light is very bright and may damage the
eyes.
 Do not look directly into the LED light for a
prolonged time.
Risk of electric shock due to damaged device!
 Do not switch on a damaged device.
 Switch off the fuse in the fuse box.
 Contact the customer service.
Risk of electric shock due to entering liquid!
The device contains electrical components.
 Make sure that no liquid enters the interior of the
device.
 Do not use pressurised steam to clean the device.
 Do not use a wet cloth to clean the operating
elements.
Risk of burns due to hot surfaces!
Accessible metallic parts of the hood may become
very hot when used with cooking appliances, that
emit great amounts of heat (e.g. gas hobs).
 Do not touch hot surfaces.
 Be careful when opening or closing the fold-out
panel.
 Wear heat-resistant gloves.

FS TS 906 I XS
– 6 –
EN
overview
1
2
1 Control panel
2 Cover of the grease filter
Key Function
Control panel on/off
Ventilation off
Power level 1
Ventilation mode 24h
Power level 2
Power level 3
Intensive setting on/off
Shutoff delay on/off
Lighting on/off
Lighting level
Alarm „filter saturation“ active/inactive
AutoMode (reactivating)

FS TS 906 I XS
– 7 –
EN
operaTion
Switching the control panel on
 Press .
 All icons light up with half their intensity.
 If not used for 15 seconds it will revert to
standby status.
Selecting lighting and lighting level
Lighting at full intensity
 Briefly press .
Lighting at half the intensity
 Press for 2 seconds.
Selecting the power level
Level 1
 Press .
 The icon of the key lights up.
Level 2
 Press .
 The icon of the key lights up.
Level 3
 Press .
 The icon of the key lights up.
Switching the ventilation off
 Press .
Toggling the intensive mode
The intensive mode fights extensive odour and
smoke which may occur when cooking.
The intensive mode can be switched on at any
time, at any power level and when the ventilation
is switched off. The intensive ventilation runs for 6
minutes. At the end of the 6 minutes the originally
selected power level is reactivated.
Switching on
 Press .
 During the running time the icon in the key
blinks 1x per second.
Switching off
 Press or .
Ventilation mode 24h
The ventilation mode 24h switches the drive to power
level 1 (10 minutes on and 50 minutes off).
The ventilation mode 24h can not be selected while
the shutoff delay or the intensive mode is running.
Switching on
 Press and hold for 2 seconds.
 The icon of the key blinks.
Switching off
 Press and hold for 2 seconds or press .
Shutoff delay
The shutoff delay switches the ventilation off
automatically after 15 minutes and helps to remove
remaining odours. The shutoff delay can be selected
at any power level. The shutoff delay cannot be
selected while the intensive setting or the ventilation
mode 24h is running.
Switching on
 Press .
 The icon of the key lights up.
Switching off
 Press or .

FS TS 906 I XS
– 8 –
EN
AutoMode
The hood is designed to work automatically linked
with the hob.
The automode function is automatically set when
your are starting a cooking and the hob is operating.
The icon lights up and the lighting goes on. The
speed level will be increased automatically by the
hob.
If you manually choose a certain speed or switch the
ventilation off, the AutoMode function is deactivated.
After cooking and switching off the hob, the hood
waits roughly 60 seconds before switching off
(ventilation and lighting).
Reactivate the AutoMode
 Briefly press .
 The icon of the key lights up.
Filter saturation alarm
The alarm for cleaning the grease filter turns on after
100 hours of effective running time of the hood.
The alarm for changing the odour filter turns on after
200 hours of effective running time of the hood.
Activating the alarm „filter saturation“
 Press and hold for 2 seconds.
 All icons blink 2x. The alarm is activated.
Deactivating the alarm „filter saturation“
 Press .
 All icons blink 1x. The alarm is deactivated.
Resetting the „filter saturation“
 Press and hold for 2 seconds.
 All icons blink 3x. The alarm is reset.
Alarm messages
Alarm 1 „Grease filter saturation“
When alarm 1 occurs you have to clean the grease
filter.
The icons of the keys and are blinking.
 Clean the grease filter.
Alarm 2 „Odour filter saturation“
When alarm 2 occurs you have to change the odour
filter and clean the grease filter.
The icons ot the keys and are blinking.
 Change the odour filter.
 Clean the grease filter.
Hood to hob connection
Some models of this hood can be paired with
specific hobs to establish a hood-hob-connection.
When using for the first time, it may be neccessary
to establish the pairing of the hood with the hob.
Pairing of hood and hob
 Switch-on a new hood and a new hob within 1
minute one each other.
 The pairing procedure starts automatically.
 During pairing procedure hood will „beep“
periodically.
 After few minutes beeping pairing is completed
and the hood beeps with a specific sequence.
The hood and the hob are now able to re-connect to
their known partner each time they are switched on/
off.
Un-pairing of hood and hob
To un-pair hob or hood, repeat the following
sequence for each device.
 5 sec. switch-on, 5 sec. switch off for 5 times.
This procedure could be done for the hood and the
hob individually or for both devices.
 After un-pairing the hood will restart beeping
waiting for a hob to reconnect.
The pairing will not restart until hob and hood are
switched off.

FS TS 906 I XS
– 9 –
EN
cleaning and care
Before performing any cleaning and maintenance:
 Switch off the device.
 For cleaning and care details, refer to the manual
delivered with the filter.
Fire hazard! Risk of injury!
Deposits in the grease filter may catch fire.
Filters that are not cleaned or changed regularly
may catch fire if open flames or extensive heat
are handled beneath the hood.
 Always clean or change all filters at the specified
intervals.
Cleaning the surfaces of the hood
 Do not use any scouring agents or chemical
detergents, which could corrode or scratch the
durfaces of the device.
 Clean the hood using a damp cloth and a neutral
liquid detergent.
Odour filter
New odour filters (activated carbon filter) are
available in specialist stores.
 Do not wash or re-use an unwashable odour filter.
Refer to the manual for cleaning and care details.
 Change the odour filter after 4 months of
operation or earlier after intensive use.
 Dispose of the used odour filter in the domestic
waste.
Changing the odour filter
 Open the cover.
 Remove the grease
filter.
 Change the odour filter.
 Close the cover.
Grease filter
The grease filter can be cleaned in the dishwasher.
 For cleaning and care details, refer to the manual
delivered with the filter.
 Clean the grease filter after 2 months of operation
or earlier after intensive use.
Cleaning the grease filter
 Open the cover.
 Remove the grease
filter.
 Clean the grease filter.
 Put the grease filter back in place.
 Close the cover.
Lighting
 Make sure that the LED in the spotlights are
changed only by the customer service.

FS TS 906 I XS
– 10 –
EN
spare parTs and accessories
New odour and grease filters are available in
specialist stores.
Component Type, item no. Remark
Odour filter 112.0016.756
112.0174.992
not washable
long lasting, washable
Grease filter 133.0195.979 Casssette filter X 253x300
mainTenance and repair
Repairs if carried out incorrectly may cause serious
injury, damage to the device and fittings, as well as
affect the functioning of the device.
 Make sure that maintenance on electrical
components and on the smoke vent is carried out
only by the manufacturer or the customer service.
 Make sure that damaged cables are changed only
by the manufacturer or the customer service.
disposal
The symbol on the product or on the
packaging indicates that the device must
not be disposed of in the domestic waste.
By disposing of the device in a proper way you help
to avoid harmful consequences to environment and
health.
Further information about recycling the device is
available from the competent authority, the local
refuse disposal service or the vendor of the device.
 Dispose of the device, which is to be discarded,
via a specialised waste collection point for
electronic and electrical devices.
cusTomer service
 Refere to the contact address for your country on
the back page or www.franke.com
Technical daTa
 Refer to the type plate placed on the product.
Further information on technical data is available on:
www.franke.com
