frasch WAFL BAFL User manual

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
These installation suggestions consists of common process for WAFL BAFL installation. Installers
should rely upon their own professional experience and understanding of their unique requirements to
ensure a successful install.
You Will Need
Items Included
frasch.co | 682.200.3005
frasch.com
Cable Cutter Drill
(2) A Sides (2) B Sides
(2) Small Ribs
(2) Medium Ribs
(2) Large Ribs
4’
Aircraft Cable
(4) Griplock (12)
1/4-20 2” thread
forming screws
9mm Spike
Bracket
Screwdriver
(4) Conecta
Hardware*
(* Patent Pending)
01 of 07
rev. 4-2022

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
frasch.co | 682.200.3005
frasch.com
1. Connect (1) A side and (1) B side together using (1) extrusion.
Slide the extrusion from the top into the opening.
A Side Panel
A Side Panel
B Side Panel
B Side Panel
Extrusion goes into
opening
02 of 07
rev. 4-2022

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
frasch.co | 682.200.3005
frasch.com
2. Slide the center ribs into the two connected sides following the diagram below.
Slide ribs into
openings
Insert ribs following the diagram
as shown.
Small Rib
Small Rib
Medium Rib
Medium Rib
Large Rib
Large Rib
03 of 07
rev. 4-2022

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
frasch.co | 682.200.3005
frasch.com
4. Connect (1) B side panel to the ribs followng the diagram below.
3. Connect (1) A side panel to the ribs following the diagram below.
A Side
B Side
04 of 07
rev. 4-2022

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
frasch.co | 682.200.3005
frasch.com
5. Slide in (3) extrusions from the top to connect the remaining sides together.
6. Lift up 2 trap doors from each center rib. Use included screws to fasten through the ribs into the side
pieces. They will screw through into the wood in the side pieces.
B
Find and lift open
trap doors
05 of 07
rev. 4-2022

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
frasch.co | 682.200.3005
frasch.com
8. Connect the griplock to the saddle bracket.
7. Insert and lock the aircraft cable into the Griplock.
1. Unscrew safety cap.
2. Press down to insert cable
3. Screw down safety cap.
06 of 07
rev. 4-2022

WAFL BAFL NON-LIT INSTALLATION
Acoustical Box Ba
frasch.co | 682.200.3005
frasch.com
9. Slide the (1) saddle bracket onto the center of each side.
Note: This can be moved depending on location of mounting.
10. Mount to ceiling.
A
Locate where spike bracket
should be placed. Slide spike
brackets from the top in
between layers until they grip
the center layer of material.
11.02in
280.00mm
191.97in
4876.00mm
191.97in
4876.00mm
609 112th Street, SUite A
Arlington, TX 76011
682.200.3005
www.frasch.com
CUSTOMER NAME
PROJECT NAME
PROJECT ADDRESS
DESIGN PROPOSAL
DRAWN BY
XX
XX/XX/XXXX
DATE
X
VERSION
1:33.3
SCALE SHEET
1 of 1
PROPOSAL IS TO CONFIRM DESIGN INTENT ONLY. NOT FOR CONSTRUCTION. FINAL DETAILS AND
HARDWARE SUBJECT TO CHANGE DURING SUBMITTALS AND ENGINEERING DEVELOPMENT.
CUSTOMER NAME
ORDER CONFIRMATION #
SXXX
07 of 07
rev. 4-2022
