Fred's Royal WEEDER STJ-150A/10.8 User manual

For questions or comments, please call 541-708-6606
USER GUIDE
Retired organic gardener and inventor
of the Royal Weeder.
Happy Gardening, Fred

2
Fellow Gardeners,
Thank you for purchasing Fred’s Royal Weeder, the lightest electric tiller
on the gardening market.
A bit of background on the creation of Fred’s Royal Weeder might inter-
est you.
Once upon a time, my wife, Ilona, and I had a farm in Northern California
where we grew organic asparagus. At the time, I was not a big asparagus
fan, however, a neighbor up the road told us that deer do not eat aspar-
agus. This convinced us that we could successfully grow asparagus and,
after months of preparation, we planted 15 acres.
Ilona and I also cultivated a good sized vegetable garden which we
would till and prepare for planting each year. However, after the garden
was tilled with a large, gas rototiller, I would look at the small budding
plants and think, if I had a small electric tiller, I could get in between
those delicate plants and keep those rascally weeds from taking over!
I looked around to purchase a lightweight, battery powered tiller and
couldn’t nd anything - not at garden supply stores or even Amazon. So,
with the help of knowledgeable folks in the tool world, I worked on my
vision for a lightweight, cordless tiller that could weed between those
tender plants.
It took a year of trial and error, but persistence paid o and resulted in
the tiller you’ve just purchased - Fred’s Royal Weeder. I came up with
the name for the weeder when I was in England visiting the gardens at
Hampton Court Palace. I asked ‘Vicky’, a gardener there, if she had any
weed problems and she rolled her eyes and laughed. So, when I received
the rst shipment of weeders, I went back to England to present Vicky
with two Fred’s Royal Weeders - another happy gardener.
We are proud of our small, but mighty, Fred’s Royal Weeder and are
condent you will enjoy using it in your garden, too.
Thank you again for your purchase, may your garden thrive and produce
many bountiful crops of fresh produce and owers!
Happy Gardening!
Fred

3
2
Contents & Product Specications
Letter from the inventor...................2
Product Specications .....................3
Package Contents.............................4
Parts & intended Use ........................5
Safety Information........................ 6-7
MODEL STJ-150A/10.8
Battery voltage 10.8 V
Blade speed 200 rpm/Minimum
Blade size 6 inches / 150 mm
Net weight 3.2 Lbs
Battery type Lithium-ion
Battery capability 2.0 Ah
Charging time 1 hour
Operating time (no load) 55 minutes (20-35 minutes with load)
Charging unit 100-240 V~/ 50-60 Hz
Charging current 2A
PRODUCT SPECIFICATIONS
Assembly Instructions................8-12
Care & Maintenence........................13
Charging the Battery ......................14
Troubleshooting..............................15
Warranty ..........................................15
The Royal Weeder® is a trademark of
Royal Weeder, Inc. All rights reserved

4
1
2
5
7
8
9
10
12
13
14
6
3
4
11
1. Rechargeable battery
2. Main handle
3. On-o switch
4. Switch lock
5. Adjustable handle
6. Adjustable handle lock
7. Upper telescope shaft
8. Height adjustment knob
9. Lower telescope shaft
10. Telescope tube plug
11. Motor cover
12. Shield /Guard
13. Tiller blade
14. Nut and washer
10.8 V cordless
WEEDER/TILLER
MODEL STJ-150A/10.8

5
4
Parts and Intended Use
1 Adjustable Auxilary Handle
2 Unit with Motor
3 Plastic shield /guard
4 2-ST3.5x13 screws
5 Tiller blade
6 Washer
7 M8 nut
8 Wrench
9 Rechargeable battery
10 Battery charger/ charger pedestal
INTENDED USE
• The Royal Weeder®is designed for weeding, loosening soil in garden and blending
additives.
• The weeder may be used only for the tasks it is designed to handle. Any other use
is deemed to be a case of misuse. The user/operator and not the manufacturer will
be liable for any damage or injuries of any kind resulting from such misuse.
• Please note that The Royal Weeder® has not been designed for use in commercial,
trade or industrial applications. Our warranty will be voided if the appliance is used
in commercial, trade or industrial businesses or for equivalent purposes.
2
134567 8 9 10

6
Safety Information
SYMBOLS
Warning of risk of personal injury or damage to the weeder
Read this instruction manual
Always wear safety goggles while using the weeder
Wear boots and gloves when using the weeder
Risk of electrical shock
IMPORTANT INFORMATION AND WARNINGS
• When using The Royal Weeder®always observe all safety instructions.
• For your own safety please read the entire manual carefully before
using the weeder.
• Keep this user manual for reference.
• If you transfer ownership of the machine, please provide the instruction
and safety manual to receiver as well.
• We can’t accept any responsibility for damage or accident due to failure
to comply with these instructions and safety information.
• Non-compliance with safety rules and instructions may cause damage
to the motor, or serious injury.
• Clean and store the machine in a secure dry place for later use.
• This appliance is not intended for use by persons (including children)
w ith reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
UNPACKING
• Open the packaging and remove the weeder and parts with care.
• Check to see if all items are supplied.
• Inspect the weeder and accessories for transport damage.
• If possible, please keep the packaging until the end of the Warranty period.
• Do not let children play with plastic bags, foils or small parts. There is a
danger of swallowing or suocating!

7
6
Safety Information
SAFETY FOR HANDS AND FEET
• Always operate the weeder using both hands.
• Wear gloves and boots when using this tool.
SAFETY FOR EYES
• Always wear safety glasses when operating the weeder.
• The operation of any power tool can result in foreign objects being
thrown into your eyes which can result in severe eye damage. Before
beginning tool operation, always wear safety goggles or safety
glasses with side shields. Always use eye protection which is marked
to comply with ANSI Z87.1.
ELECTRICAL SAFETY
• Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
WORK AREA SAFETY
• Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious
personal injury.
• Use personal protective appliance. Always wear eye prtection.
Protective appliance such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
• Prevent unintentional starting. Ensure the switch is in the o-
position before connecting to power source and/or battery pack,
picking up or carrying the tool.
• Do not carry power tools with your nger on the power switch.
• Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
• Keep proper footing and balance at all times and do not overreach.
This enables better control of the power tool in unexpected situations.
• Dress properly—do not wear loose clothing or jewelry. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewelry or long hair can be caught in moving parts.

8
Safety Information
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your
application.The correct power tool will do the job better and safer at
the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and o.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
• Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
• Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may aect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
• Use the power tool, accessories and tool bits, etc. in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
dierent from those intended could result in a hazardous situation.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specied by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk
of re when used with another battery pack.
• Use power tools only with specically designated battery packs.
Use of any other battery packs may create a risk of injury and re.
• When battery pack is not in use, keep it away from other metal
objects like paper clips, coins, keys, nails, screws or other small metal
objects that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a re.
• Under abusive conditions liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
• Do not crush, drop or damage the battery. Do not use a battery or
charger that has been dropped or received a sharp blow. A damaged
battery is subject to leakage or explosion.
ADDITIONAL SAFETY INSTRUCTIONS FOR DISPOSAL
• The battery must be removed from the weeder before it is disposed
of safely.

9
8
Assembly Instructions
1. CONNECT THE HANDLE TO THE MOTOR:
• To connect the main handle and shaft to the motor part (g.1-a) and (g.1-b):
Coil the lead cord into the opening on top of the motor, then insert the main
handle and shaft into the opening. The shaft will click into place. (g.1-b).
gure 1-a gure 1-b
IMPORTANT - READ INSTRUCTIONS BEFORE
ASSEMBLING
2
2
1
• Read this instruction manual and carefully follow instructions for assembling
or adjusting the weeder.
• Remove the battery while assembling the weeder.
• Read and understand the battery charging instructions on page 13.
• Wear gloves to protect your hands.
Note: See our YouTube channel if you need help connecting the handle to the motor:
https://www.youtube.com/channel/UClhRIoJQyPfRFc5MdNYCmjQ/videos

10
Assembly Instructions
3. MOUNT THE BLADE
• Remove the nut and washer from the motor shaft. Mount the tiller blade on the
motor shaft (g. 3a), then tighten the M8 nut on washer with wrench supplied
( g.3-b).
2. MOUNT THE SHIELD/GUARD
• Mount the clear plastic guard to the weeder (g.2-a).
• Fasten the guard with two ST3.5*13 screws using a phillips screwdriver (g.2-b).
Note: Put a small amount of oil on the screws before screwing in.
gure 2-a gure 2-b
gure 3-a gure 3-b
WARNING: Always remove the battery before inserting or removing
the tiller blade.
1
2
2
1

11
10
Assembly Instructions Assembly Instructions
4. MOUNT THE ADJUSTABLE HANDLE
Press the lock button on aluminum shaft (1) on opposing sides, and at the same time
insert the handle (2) tting one side rst, then allowing the other side of the handle
to snap into place.(g.4-a)
1
2
1gure 4-a
gure 4-b
gure 4-c
When handle is in position, the lock button will lock the handle in place
automatically. (g.4-b)
Press and hold the lock button (1), then adjust the handle. When it is in desired
position (2), release the lock button. (g.4-c)
1
1
1
2

12
Assembly Instructions
5. ADJUST THE LENGTH OF THE WEEDER (g.5-a)
• Loosen the lower half of the knob located in the middle of aluminum shaft by
turning it clockwise.
• Pull the lower shaft up or down to adjust to desired height.
• Tighten the knob by turning counter clockwise.
gure 5-a
WARNING : It is important to adjust the weeder to a comfortable
height before starting the motor.
1
2
2
3
1
2
Care and Maintenence

13
12
Care and Maintenence
WARNING
Remove the battery before performing maintenance to the weeder
• Keep the weeder battery and handle away from dirt and water.
• Clean after use with a wet cloth.
• Do not use harsh detergents or other solvents on plastic parts.
• Only external parts need to be cleaned after use.
• Recharge the battery for next use.
STORAGE:
• Do not store in sunlight, in an excessively warm place, or near a furnace.
The battery life will be shortened.

14
Charging the Battery
6. CHARGING THE BATTERY
• The charger includes two parts: the adapter (a) and the charger pedestal (c).
• Do NOT use any other type of charger. This charger is only for use for this type
of battery.
• Please observe the specied voltage, the voltage must be the same as that
marked on the rating plate of the battery charger:100-240 V50-60 Hz
WARNING
The battery must be fully charged before your rst usage. Insert the battery in
the charging pedestal and allow the battery to charge for a full ve hours before you
use it for the rst time. DO NOT ALLOW WATER TO COME IN CONTACT WITH THE
CHARGING UNIT.
Note: If the weeder doesn’t work when pressure is applied to the trigger, this
means the battery is not charged - return it to the charging pedestal and continue
charging.
HOW TO CHARGE THE BATTERY (g. 6-a)
1. Check that your voltage is the same as that marked on the rating plate of the
battery charger. Insert the power plug of the adapter (a) into an electrical wall
socket. The LED (b) on the adapter will turn green.
2. Insert the battery pack into the charger pedestal (c) .The LED will turn red at
once indicating that the charger is working.
3. When fully charged, the LED will turn green.
4. Remove the battery from the charging pedestal when it is fully charged.
ATTENTION:
Please remove the battery from the charger pedestal after it is fully charged. Do
not store the battery in the charging pedestal.
gure 6-a
a
b
c
Troubleshooting & Warranties
3-prong
battery
ts the
2-prong
charger

15
14
Troubleshooting & Warranties
If you still have questions or an unresolved issue after going through this
troubleshooting guide, or if you’d like to speak to our customer service, please
email: [e-mail] or call 541-708-6606.
Problem Possible Cause Corrective Action
Weeder runs at a
sluggish speed
Battery is not fully
charged
Remove battery and place in
charging pedestal. Charge for
30 minutes.
Motor fails to start
when switch trigger is
depressed
Battery is not
secure
Battery is not
charged
To secure the battery, make sure the
latches on the battery compartment
snap into place.
Charge the battery according to the
instructions included in this guide.
Motor runs but tiller
does not move
The weeder is
damaged
Do not use The Royal Weeder®.
Email to: [e-mail]
Weeder smokes during
operation
The weeder is
damaged
Do not use The Royal Weeder®.
Email to: [e-mail]
30-DAY MONEY-BACK GUARANTEE
You may return The Royal Weeder®for any reason, for a full refund within 30 days
of date of purchase. Email [e-mail] to notify us of your intention to
return. Package and ship the product along with receipt or proof of purchase to:
Royal Weeder, Inc., 415 Williamson Way #7, Ashland, OR 97520
2-YEAR HASSLE-FREE WARRANTY
• This Royal Weeder® is warranted to the original purchaser from the original pur-
chase date for two (2) years subject to the warranty coverage described herein.
• The Royal Weeder® is warranted for the original user to be free from defects in
material and workmanship.
• If you believe The Royal Weeder® is defective at any time during the specied
warranty period, simply return the weeder along with proof of purchase to the
place of purchase for a free
replacement or refund, or email [e-mail] for warranty service.
This warranty is void if defects in materials or workmanship or damages result
from repairs or alterations which have been made or attempted by others or the
unauthorized use of nonconforming parts; the damage is due to normal wear,
damage is due to abuse (including overloading of the tool beyond capacity),
improper maintenance, neglect or accident; or the damage is due to the use of the
tool after partial failure or use with improper accessories or unauthorized repair or
alteration.
For questions or comments, please call 541-708-6606.

Purchase date ____________________
Purchased from___________________
Attach receipt here
Questions, problems, missing parts?
Email our Customer Service Department at:
541-708-6606
or email
[e-mail]
The Royal Weeder®
Royal Weeder, Inc.
415 Williamson Way #7
Ashland, OR 97520 USA
www.royalweeder.com
