Freedom9 freeView IP 800 User manual

freeView IP 800
IP KVM Rackmount
Remote Access Device
freeView IP 800 > 8-Port IP KVM Rackmount
Remote Access Device
Specifications
The freeView IP 800 defines a new class of remote KVM access
devices. It combines digital remote KVM access via IP networks
through comprehensive and integrated systems management.
The freeView IP 800 offers convenient remote control and
access via IP LAN or Internet.
It captures, digitizes, & compresses the video, keyboard &
mouse signals and transmits them via IP to and from a remote
computer. It provides a truly non-intrusive solution for remote
access and control.
The access & control software runs on its embedded proces-
sors, not on mission-critical computers. Thus, there is no
interference with server operation or impact on network
performance.
Host Connections
Connector Type
Console Connections
Keyboard/Mouse PS/2
Video VGA
LAN Port RJ-45
Model Numbers
Model Name freeView IP 800
Description Remote System Management
Part Number KVM-08IA
Revision 2.0 Specifications are subject to change without notice. Copyright 2007 Freedom9 Inc.
• Manage servers around the world
• KVM access over IP, ISDN or analog
telephone line
• BIOS level access
• SSL encryption
• No impact on server or network
performance
• Automatically senses video resolution for
best possible screen capture
• High-performance mouse tracking and
synchronization
www.freedom9.com
1-888-998-9189
Keyboard/Mouse
Video
8
1-to-3 (HD)
PS/2
VGA
1
Features:
• Port to connect a user console for direct
analog access to KVM switch
• Local mouse suppression (only when using
Sun’s Java Virtual Machine)
• Virtual Media allows for file transfers
between local and remote computers
Serial Port DB-9 (Male)
LED Yes
Hot Plug Yes
Scan Intervals 5-99 Sec
VGA Resolution Local: 1920x1440
Remote: 1600x1200
Power Supply DC 5V, 2.5A
Housing Metal
Dimensions (H x W x D) 1.7” x 16.9” x 8.7” in (44 x 430 x 220 mm)
• Low Density CAT5 cable to eliminate
cable clutter at the rack
Daisy Chain Port 3-to-3
