Freenotes Harmony Park ARIA Operating and maintenance instructions

15"
31 7
8
"
15 3
4
"
ARIA
The sleek-looking 9 note Aria is a non-resonated instrument
with aluminum keys and a powder coated steel frame.
Mounted on just one post. This instrument sounds like a
delightful breath of fresh air.
C MAJOR PENTATONIC
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
PRODUCT SHEET / INSTALLATION GUIDE
SHEET 1 OF 5
ARIA 2016
SCALE: 1:14

Recycled Post Surface Mount
Sheet 4 of 5
Steel Post Surface Mount
Sheet 4 of 5
Recycled Post In-Ground
Sheet 3 of 5
Steel Post In-Ground
Sheet 3 of 5
MOUNTING OPTION IDENTIFICATION:
This instrument is offered with various mounting options. Identify your option below and follow installation instructions on the following sheets.
Parts List:
Aria Instrument Assembly (1)
In-Ground Post (1)
2" Tamper-Resistant Screw (5)
Security Driver (1)
Weights:
Boxed Instrument Weight, lbs.
Boxed Post Weight, 28 lbs.
Parts List:
Aria Instrument / Surface Mount
Post Assembly (1)
3/8" x 3 3/4" Anchor Bolt (4)
Plastic Anchor Cap (4)
Weights:
Boxed Instrument / Post
Weight, lbs.
Parts List:
Aria Instrument Assembly (1)
Surface Mount Post (1)
2" Tamper-Resistant Screw (5)
Security Driver (1)
3/8" x 5" Anchor Bolt (4)
Plastic Anchor Cap (4)
Weights:
Boxed Instrument Weight, lbs.
Boxed Post Weight, 28 lbs.
Parts List:
Aria Instrument / In-Ground
Post Assembly (1)
Weights:
Boxed Instrument / Post
Weight, lbs.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 2 OF 5
SCALE: 1:16
PRODUCT SHEET / INSTALLATION GUIDE
ARIA 2016

Frost Depth
Finished Height
Post Length
10" Excavated
Hole W/Concrete
Fill
RECYCLED AND STEEL POST IN-GROUND INSTALLATION PROCEDURES
Step 1:
Excavate one 10" diameter hole, 36" deep at the installation location. Contractor can modify post to desired height.
Post Length = Frost Depth (36" Recommended) + Finished Height (Refer to Height Guideline)
Step 2:
Lower the post into the excavated hole.
Step 3:
Refer to sheet 5 for installation of instrument to post.
( The Steel In-Ground option does not require assembling the instrument to
the post, as the post and instrument are one unit )
Step 4:
Verify the correct placement, levelness, plumbness, and finished height
of the instrument. Also check for sufficient clearance around the instrument.
A 36" radius is recommended around the instrument for wheelchair accessibility,
however this is not required for instrument function. Instrument may be installed
next to a wall or in a variety of different configurations.
Step 5:
Last pour concrete around the post. It is recommended to brace the instrument
to hold it rigid while the concrete cures. Leave to set according to the concrete
manufacturers guidelines. Approximately (2) 80lb. bags will be needed.
FINISHED HEIGHT GUIDELINE
Ages 3-5, 22"
Ages 5-7, 27"
Ages 7-11, 32"
Adult, 36"
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 3 OF 5
SCALE: 1:12
PRODUCT SHEET / INSTALLATION GUIDE
ARIA 2016

6" min.
Surface Mounted
Post
4" min.
Anchor Bolt
RECYCLED AND STEEL POST SURFACE MOUNT INSTALLATION PROCEDURES
Step 1:
Determine installation location. Verify concrete footing is a minimum of 6" thick. If the concrete pad is at an angle, steel washers are required to act
as shims. (Shims not provided)
Step 2:
Stand the surface mount post upright onto the concrete pad. Mark the center of the holes on the surface mount plate. After you have made your
marks, set aside the post in order to drill for anchor holes. With a hammer or rotary drill, drill through concrete at marked locations. Drill to a
minimum depth of 4". ( A 3/8" masonry drill bit will be needed )
Step 3:
Place the surface mounted post back over the drilled out holes. Insert provided anchor bolts into aligned holes. Position anchor nut so that it is flush
with the top of the bolt. Pound anchor bolts into the hole until the anchor washer is flush with the post base. Tighten anchor bolts until they are snug.
Cover remaining bolt sections with provided plastic caps.
Step 4:
Refer to sheet 5 for installation of instrument to post. ( The Steel Surface Mount option does not require assembling the instrument to the post, as the
post and instrument are one unit )
Step 5:
Verify the correct placement, levelness, plumbness, and finished height of the instrument. Also check for sufficient clearance around the instrument.
A 36" radius is recommended around the instrument for wheelchair accessibility, however this is not required for instrument function. Instrument may
be installed next to a wall or in a variety of different configurations.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 4 OF 5
SCALE: 1:6
PRODUCT SHEET / INSTALLATION GUIDE
ARIA 2016

Recycled Post
2" Tamper-Resistant Screw
Aria Instrument Assembly
INSTRUMENT TO POST INSTALLATION PROCEDURES
Step 1:
The Steel Post options do not require assembling the instrument to the post, as the post and instrument are one unit. Refer back to the final
steps on the previous sheets if this applies to you. If mounting to a recycled post, follow the instructions below.
Step 2:
With two people, situate the instrument onto the post. Predrill 5/32" pilot holes into the posts through the existing holes on the instrument. Fasten the
instrument to the post with the provided 2" tamper-resistant screws and security driver.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 5 OF 5
SCALE: 1:6
PRODUCT SHEET / INSTALLATION GUIDE
ARIA 2016
