Freenotes Harmony Park Aria User manual

43" Adult
39" Ages 7-11
34" Ages 5-7
29" Ages 3-5
31
7
8
"
15
3
4
"
Main Features:
C Major Pentatonic •
Steel Powder Coated Frame •
Anodized Aluminum Bars •
Stainless Steel Hardware •
Contents:
SHEET 2 - Parts List and Instrument to Post Installation •
SHEET 3 - In Ground Installation •
SHEET 4 - Surface Mount Installation •
Weights:
Instrument Weight, 35lbs. •
Boxed Instrument Weight, 44lbs. •
Boxed Post Weight, 28-36lbs. •
ARIA
INSTALLATION GUIDE
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 1 OF 4
TITLE:
SCALE: 1:16
REVISION: A
DATE: 2/9/2018
DWG. NO.
Aria - Installation Guide
ARIA-INSTALL

1
2/3
DETAIL A
SCALE 1 : 4
5
Parts List:
Step 1: The Steel Post Options do not require assembling the Instrument to the Post, as the Post and Instrument are one unit. If mounting
to a Recycled Post, follow the instructions below.
Step 2: With two people, situate the Instrument onto the Post. Predrill 5/32" pilot holes into the Posts through the existing holes on the
Instrument Frame. Fasten the Instrument to the Post with the provided #10 Button Head Screws and Security Driver.
ITEM NO. PART DESCRIPTION
In Ground -
Recycled Post/QTY.
In Ground -
Steel Post/QTY.
Surface Mount -
Recycled Post/QTY.
Surface Mount -
Steel Post/QTY.
1 Aria Instrument Assembly 1 1 1 1
2 In Ground Recycled Post, 68"lg. 1 - - -
3 Surface Mount Recycled Post, 32"lg. - 1 - -
4 Surface Mount Base, For Recycled Post - - 1 -
5 #10 Button Head Screw, 2"lg. SS, T25 tamp 4 - 4 -
6 5/16" Hex Head Lag Bolt, 5"lg. SS - - 2 -
7 3/8"-16 Wedge Expansion Anchor, SS - - 4 4
8 35/64" Hex Nut Cap - - 4 4
9 Security Driver 1 - 1 -
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 2 OF 4
TITLE:
SCALE: 1:16
REVISION: A
DATE: 2/9/2018
DWG. NO.
Parts List and Instrument to Post Installation
ARIA-INSTALL

Post Length
Frost Depth
Finished Post Height
Ground Level
1
Step 1: Excavate one 10" diameter hole, 36" deep, at the installation location. Contractor can modify Post to desired height.
Post Length = Frost Depth
(36" Recommended) + Finished Post Height
Finished Post Height Guideline: ( Ages 3-5, 20" ) ( Ages 5-7, 25" ) ( Ages 7-11, 30" ) ( Adult, 34" )
Step 2: With two people, lower the Post with the Instrument attached into the excavated hole.
Step 3: Verify the correct placement, levelness, and finished height of the Instrument. Check for sufficient clearance around the
Instrument, a 36" perimeter around the Instrument is recommended for wheelchair accessibility.
Step 4: Last pour concrete around the post. It is recommended to brace the Instrument to hold it rigid while the concrete cures.
Leave to set according to the concrete manufacturers guidelines. Approximately (3) 80lb. bags will be needed.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 3 OF 4
TITLE:
SCALE: 1:16
REVISION: A
DATE: 2/9/2018
DWG. NO.
In Ground Installation
ARIA-INSTALL

24"
24"
6"
1
Concrete Pad
DETAIL B
SCALE 1 : 6
3/8" Drill Diameter
to a Depth of 4"
7
8
Step 1: Standard height for Surface Mount Posts are 36". The Recycled Post may be modified in the field to the following heights:
( Ages 3-5, 20" ) ( Ages 5-7, 25" ) ( Ages 7-11, 30" ) ( Adult, 34" )
The height of Surface Mount Steel Posts can not be adjusted.
Step 2: Determine installation location. Verify concrete footing is a minimum of 24" long x 24" wide x 6" thick. If the concrete pad is at
an angle, steel washers are required to act as shims (Shims not provided). If there is not already an existing pad, approximately
(4) 80lb. bags will be needed. Allow concrete to cure per concrete manufacturers guidelines.
Step 3 (Recycled Post Only): Install the Surface Mount Base to the bottom of the Post. Align the holes on the Base with the holes on
the Post. The Base should fit snuggly around the Post. Fasten them together with the provided
5/16" Hex Head Lag Bolt
s.
Step 4: With two people place the Instrument Assembly with Post attached onto the concrete pad and mark the center of the holes
on the surface mount base. After you have made your marks, set aside the Instrument in order to drill for anchor holes. With a
hammer or rotary drill, drill through concrete at marked locations. Drill to a minimum depth of 4". A 3/8" masonry drill bit will be
needed.
Step 5: Place the Instrument back over the drilled out holes. Insert provided anchor bolts into aligned holes. Position anchor nut so that
it is flush with the top of the bolt. Pound anchor bolts into the hole until the anchor washer is flush with the surface mount base.
Tighten anchor bolts until they are snug. Cover remaining bolt sections with provided nut caps.
Step 6: Verify the correct placement, levelness, and finished height of the Instrument.
Check for sufficient clearance around the Instrument, a 36" perimeter around the
Instrument is recommended for wheelchair accessibility.
Step 7: If installing onto wet concrete, us the wet set anchor manufacturers guidelines
for installation procedures.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 4 OF 4
TITLE:
SCALE: 1:16
REVISION: A
DATE: 2/9/2018
DWG. NO.
Surface Mount Installation
ARIA-INSTALL
