Freenotes Harmony Park Piper Operating and maintenance instructions

47" Adult
43" Ages 7-11
38" Ages 5-7
33" Ages 3-5
26
1
2
"
24
1
4
"
Main Features:
C Major Pentatonic •
Recycled HDPE Frame •
Coated Fiberglass Bars •
Anodized Aluminum Resonators •
Stainless Steel Hardware •
Contents:
SHEET 2 - Parts List and Instrument to Post Installation •
SHEET 3 - In Ground Installation •
SHEET 4 - Surface Mount Installation •
Weights:
Instrument Weight, 25lbs. •
Boxed Instrument Weight, 33lbs. •
Boxed Posts Weight,35-72lbs. •
PIPER
INSTALLATION GUIDE
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 1 OF 4
TITLE:
SCALE: 1:16
REVISION: B
DATE: 2/9/2018
DWG. NO.
Piper - Installation Guide
PIPR-INSTALL

1
DETAIL A
SCALE 1 : 4
2
8
DETAIL B
SCALE 1 : 4
9/10
Parts List:
Step 1: Start by mounting the Holsters to the Instrument Back with the provided #8 Flat Head Screws and Driver. The Back comes
predrilled. Screw heads should be flush with the Holster surface when properly installed. Holster should also be flush along the
back. Drive Screws slowly to prevent stripping.
Step 2: With two people, situate the Instrument with Holsters installed onto the Posts. Posts come predrilled and/or tapped. Fasten the
Instrument to the Posts with the provided #8 Button Head Screw for Recycled Posts or #10-24 Button Head Machine Screw for
Steel Posts. Drivers are provided.
ITEM NO. PART DESCRIPTION
In Ground -
Recycled Post/QTY.
In Ground -
Steel Post/QTY.
Surface Mount
Recycled Post/QTY.
Surface Mount -
Steel Post/QTY.
1 Piper Instrument Assembly 1 1 1 1
2 Small SS Holster 2 2 2 2
3 In Ground Recycled Post, 72"lg. 2 ---
4 In Ground Steel Post, 72"lg. - 2 - -
5 Surface Mount Recycled Post, 36"lg. - - 2 -
6 Surface Mount Steel Post, 36"lg. - - - 2
7 Surface Mount Base, For Recycled Post - - 2 -
8 #8 Flat Head Screw, 1.25"lg. SS, T15 tamp 8 8 8 8
9 #8 Button Head Screw, 1.25"lg. SS, T15 tamp 10 - 10 -
10 #10-24 Button Head Machine Screw, 1"lg. SS, T25 tamp - 10 - 10
11 5/16" Hex Head Lag Bolt, 5"lg. SS - - 4 -
12 3/8"-16 Wedge Expansion Anchor, SS - - 8 8
13 35/64" Hex Nut Cap - - 8 8
14 Security Driver 1 1 1 1
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 2 OF 4
TITLE:
SCALE: 1:16
REVISION: B
DATE: 2/9/2018
DWG. NO.
Parts List and Instrument to Post Installation
PIPR-INSTALL

Post Length
Frost Depth
Finished Post Height
Ground Level
133
4
" On
Center
3/4
1
Step 1: Excavate two 10" diameter holes, 36" deep, and 13.75" on center at the installation location. Contractor can modify Post to
desired height. Post Length = Frost Depth
(36" Recommended) + Finished Post Height
Finished Post Height Guideline: ( Ages 3-5, 22" ) ( Ages 5-7, 27" ) ( Ages 7-11, 32" ) ( Adult, 36" )
Step 2: With two people, lower the Posts with the Instrument attached into the excavated holes.
Step 3: Verify the correct placement, levelness, and finished height of the Instrument. Check for sufficient clearance around the
Instrument, a 36" perimeter around the Instrument is recommended for wheelchair accessibility.
Step 4: Last pour concrete around the posts. It is recommended to brace the Instrument to hold it rigid while the concrete cures.
Leave to set according to the concrete manufacturers guidelines. Approximately (6) 80lb. bags will be needed.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN
PERMISSION OF FREENOTES HARMONY
PARK IS PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
WWW.FREENOTESHARMONYPARK.COM
SHEET 3 OF 4
TITLE:
SCALE: 1:16
REVISION: B
DATE: 2/9/2018
DWG. NO.
In Ground Installation
PIPR-INSTALL

36"
24"
6"
5/6
1
Concrete Pad
DETAIL C
SCALE 1 : 6
3/8" Drill Diameter
to a Depth of 4"
12
13
Step 1: Standard height for Surface Mount Posts are 36". The Recycled Posts may be modified in the field to the following heights:
( Ages 3-5, 22" ) ( Ages 5-7, 27" ) ( Ages 7-11, 32" ) ( Adult, 36" )
The height of Surface Mount Steel Posts can not be adjusted.
Step 2: Determine installation location. Verify concrete footing is a minimum of 36" long x 24" wide x 6" thick. If the concrete pad is at
an angle, steel washers are required to act as shims (Shims not provided). If there is not already an existing pad, approximately
(5) 80lb. bags will be needed. Allow concrete to cure per concrete manufacturers guidelines.
Step 3 (Recycled Post Only): Install the Surface Mount Bases to the bottom of the Posts. Align the holes on the Bases with the holes on
the Posts. The Bases should fit snuggly around the Posts. Fasten them together with the provided
5/16" Hex Head Lag Bolt
s.
Step 4: With two people place the Instrument Assembly with Posts attached onto the concrete pad and mark the center of the holes
on the surface mount bases. After you have made your marks, set aside the Instrument in order to drill for anchor holes. With a
hammer or rotary drill, drill through concrete at marked locations. Drill to a minimum depth of 4". A 3/8" masonry drill bit will be
needed.
Step 5: Place the Instrument back over the drilled out holes. Insert provided anchor bolts into aligned holes. Position anchor nut so that
it is flush with the top of the bolt. Pound anchor bolts into the hole until the anchor washer is flush with the surface mount bases.
Tighten anchor bolts until they are snug. Cover remaining bolt sections with provided nut caps.
Step 6: Verify the correct placement, levelness, and finished height of the Instrument.
Check for sufficient clearance around the Instrument, a 36" perimeter around the
Instrument is recommended for wheelchair accessibility.
Step 7: If installing onto wet concrete, us the wet set anchor manufacturers guidelines
for installation procedures.
