IMBARIMBA
The Imbarimba is a unique musical design combining the
element of two African instruments: the marimba and the
kalimba. The notes are arranged in the layout of the kalimba.
This allows both hands equal access to the upper and lower
notes. Coated fiberglass bars are entirely weatherproof
and withstand hard use and the elements.
(LH) C MAJOR / (RH) A MINOR PENTATONIC
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 1 OF 6
SCALE: 1:16
PRODUCT SHEET / INSTALLATION GUIDE
IMBARIMBA 2016

MOUNTING OPTION IDENTIFICATION:
This instrument is offered with various mounting options. Identify your option below and follow installation instructions on the following sheets.
Parts List:
Imbarimba Instrument
Assembly (1)
In-Ground Post (2)
1 1/4" Tamper-Resistant
Screw (10)
Security Driver (1)
Dual Drive #2 Screw (8)
Holster (2)
Weights:
Boxed Instrument Weight,60 lbs.
Boxed Post Weight,57 lbs.
Parts List:
Imbarimba Instrument
Assembly (1)
Surface Mount Post (2)
1 1/4" Tamper-Resistant
Screw (10)
Security Driver (1)
3/8" x 5" Anchor Bolt (8)
Plastic Anchor Cap (8)
Dual Drive #2 Screw (8)
Holster (2)
Weights:
Boxed Instrument Weight,60 lbs.
Boxed Post Weight,35 lbs.
Recycled Post In-Ground
Sheet 3 of 6
Recycled Post Surface Mount
Sheet 4 of 6
Steel Post Surface Mount
Sheet 4 of 6
Steel Post In-Ground
Sheet 3 of 6
Parts List:
Imbarimba Instrument
Assembly (1)
In-Ground Post (2)
1" Tamper-Resistant
Screw (10)
10-24 Tap (1)
11/64" Drill Bit (1)
Security Driver (1)
Dual Drive #2 Screw (8)
Holster (2)
Weights:
Boxed Instrument Weight,60 lbs.
Boxed Post Weight,72 lbs.
Parts List:
Imbarimba Instrument
Assembly (1)
Surface Mount Post (2)
1" Tamper-Resistant
Screw (10)
10-24 Tap (1)
11/64" Drill Bit (1)
Security Driver (1)
3/8" x 3 3/4" Anchor
Bolt (8)
Plastic Anchor Cap (8)
Dual Drive #2 Screw (8)
Holster (2)
Weights:
Boxed Instrument Weight,60 lbs.
Boxed Post Weight,40 lbs.
Parts List:
Imbarimba Instrument
Assembly (1)
Portable Post (2)
1 1/4" Tamper-Resistant
Screw (10)
Security Driver (1)
3/8" x 12" Stake (4)
Dual Drive #2 Screw (8)
Holster (2)
Weights:
Boxed Instrument Weight,60 lbs.
Boxed Post Weight,45 lbs.
Recycled Post Portable
Sheet 5 of 6
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 2 OF 6
SCALE: 1:24
PRODUCT SHEET / INSTALLATION GUIDE
IMBARIMBA 2016

30" On
Center
Frost Depth
Finished Height
Post Length
10" Excavated
Hole W/Concrete
Fill
FINISHED HEIGHT GUIDELINE
Ages 3-5, 22"
Ages 5-7, 27"
Ages 7-11, 32"
Adult, 36"
RECYCLED AND STEEL POST IN-GROUND INSTALLATION PROCEDURES
Step 1:
Excavate two 10" diameter hole, 36" deep, and 30" on center at the installation location. Contractor can modify post to desired height.
Post Length = Frost Depth (36" Recommended) + Finished Height (Refer to Height Guideline)
Step 2:
Lower the posts into the excavated holes.
Step 3:
Refer to sheet 6 for installation of instrument to posts.
Step 4:
Verify the correct placement, levelness, plumbness, and finished height
of the instrument. Also check for sufficient clearance around the instrument.
A 36" radius is recommended around the instrument for wheelchair accessibility,
however this is not required for instrument function. Instrument may be installed
next to a wall or in a variety of different configurations.
Step 5:
Last pour concrete around the posts. It is recommended to brace the instrument
to hold it rigid while the concrete cures. Leave to set according to the concrete
manufacturers guidelines. Approximately (4) 80lb. bags will be needed.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 3 OF 6
SCALE: 1:14
PRODUCT SHEET / INSTALLATION GUIDE
IMBARIMBA 2016

6" min.
30" On
Center
Surface Mounted
Post
4" min.
Anchor Bolt
RECYCLED AND STEEL POST SURFACE MOUNT INSTALLATION PROCEDURES
Step 1:
Determine installation location. Verify concrete footing is a minimum of 6" thick. If the concrete pad is at an angle, steel washers are required to act
as shims. (Shims not provided)
Step 2:
Stand the surface mount post upright onto the concrete pad with a 30" offset on center. Mark the center of the holes on the surface mount plates.
After you have made your marks, set aside the posts in order to drill for anchor holes. With a hammer or rotary drill, drill through the concrete at
marked locations. Drill to a minimum depth of 4". ( A 3/8" masonry drill bit will be needed )
Step 3:
Place the surface mounted posts back over the drilled out holes. Insert provided anchor bolts into aligned holes. Position anchor nut so that it is flush
with the top of the bolt. Pound anchor bolts into the hole until the anchor washer is flush with the post base. Tighten anchor bolts until they are snug.
Cover remaining bolt sections with provided plastic caps.
Step 4:
Refer to sheet 6 for installation of instrument to posts.
Step 5:
Verify the correct placement, levelness, plumbness, and finished height of the instrument. Also check for sufficient clearance around instrument.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 4 OF 6
SCALE: 1:13
PRODUCT SHEET / INSTALLATION GUIDE
IMBARIMBA 2016

Imbarimba Instrument
Assembly
Portable Post
3/8" x 12" Stake
6"
TYP
Holster
Portable Brace
T25 2" Screw
RECYCLED POST PORTABLE INSTALLATION PROCEDURES
Step 1:
With Holsters installed onto the Instrument (see sheet 6 for Holster installation instructions) place the Portable Posts to a 30" offset on center.
Step 2:
Place the Instrument Assembly onto the Portable Posts. Verify correct placement, levelness, and plumbness of posts.
Step 3:
Refer to sheet 6 for installation of instrument to posts.
Step 4:
Install the Portable Posts Brace 6" below the backside of the Holsters. Fasten down using the provided T25 2" Screws.
Step 5:
Screw heads should be flush with the outer surface of the Brace when properly installed. Drive screws in slowly to prevent stripping.
Step 6:
3/8" x 12" Stakes are provided and can be installed through the feet of the Portable Posts to prevent Instrument from moving around during use.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 5 OF 6
SCALE: 1:15
IMBARIMBA 2016
PRODUCT SHEET / INSTALLATION GUIDE

Holster
Dual Drive
#2 Screw
Instrument Back
W/ Predrilled Holes
Tamper-Resistant Screw
Instrument Post
Imbarimba Instrument
Assembly
Holster
HOLSTER AND INSTRUMENT TO POST INSTALLATION PROCEDURES
Step 1:
Align Holsters to the instrument back with the corresponding arrows and letters. Fasten Holster to back with the provided dual drive screws.
Backs are predrilled. Screw heads should be flush with the Holster surface when properly installed. Holster must also be flush along the back.
An extended square drive or Phillips will be needed. Drive screws in slowly to prevent stripping.
Step 2: (Recycled Post Only)
With two people, situate the instrument onto the posts. Predrill 1/8" pilot holes into the posts through the existing holes on the
instrument holster. Fasten the instrument to the posts with the provided 1 1/4" tamper-resistant screws and security driver.
(Steel Post Only)
With two people, situate the instrument onto the posts. Predrill 11/64" pilot holes into the posts through the existing holes on the
instrument holster. Next tap the holes with the provided 10-24 Tap, the Tap may be used with a cordless drill. Last fasten the instrument to the posts with
the provided 1" tamper-resistant screws and security driver.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
FREENOTES HARMONY PARK. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
FREENOTES HARMONY PARK IS
PROHIBITED.
FREENOTES HARMONY PARK
194 BODO DRIVE, UNIT F
DURANGO CO 81303
TEL: [phone]
FAX: [phone]
EMAIL: [email protected]
WWW.FREENOTESHARMONYPARK.COM
SHEET 6 OF 6
SCALE: 1:5
PRODUCT SHEET / INSTALLATION GUIDE
IMBARIMBA 2016
