Introduction
This document provides a description of how to upgrade the standard DSP56362EVM
Evaluation Module to the DSPD56362 and related components. After the upgrade is complete
the EVM system will be capable of autodectect/autoswitching of PCM, Dolby DigitalTM,
DTSTM and MPEG bitstreams in addition to various post decoder functions. The user interface
of the upgraded EVM is also described.
