Freescale Semiconductor M5407C3 User manual

M5407C3UM/D
Rev. 1.1, 8/2000
M5407C3 User's Manual
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

© Motorola Inc., 2000. All rights reserved.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...
Information in this document is provided solely to enable system and software
implementers to use Freescale Semiconductor products. There are no express or
implied copyright licenses granted hereunder to design or fabricate any integrated
circuits or integrated circuits based on the information in this document.
Freescale Semiconductor reserves the right to make changes without further notice to
any products herein. Freescale Semiconductor makes no warranty, representation or
guarantee regarding the suitability of its products for any particular purpose, nor does
Freescale Semiconductor assume any liability arising out of the application or use of
any product or circuit, and specifically disclaims any and all liability, including without
limitation consequential or incidental damages. “Typical” parameters which may be
provided in Freescale Semiconductor data sheets and/or specifications can and do
vary in different applications and actual performance may vary over time. All operating
parameters, including “Typicals” must be validated for each customer application by
customer’s technical experts. Freescale Semiconductor does not convey any license
under its patent rights nor the rights of others. Freescale Semiconductor products are
not designed, intended, or authorized for use as components in systems intended for
surgical implant into the body, or other applications intended to support or sustain life,
or for any other application in which the failure of the Freescale Semiconductor product
could create a situation where personal injury or death may occur. Should Buyer
purchase or use Freescale Semiconductor products for any such unintended or
unauthorized application, Buyer shall indemnify and hold Freescale Semiconductor
and its officers, employees, subsidiaries, affiliates, and distributors harmless against all
claims, costs, damages, and expenses, and reasonable attorney fees arising out of,
directly or indirectly, any claim of personal injury or death associated with such
unintended or unauthorized use, even if such claim alleges that Freescale
Semiconductor was negligent regarding the design or manufacture of the part.
How to Reach Us:
Home Page:
www.freescale.com
E-mail:
[email protected]
USA/Europe or Locations Not Listed:
Freescale Semiconductor
Technical Information Center, CH370
1300 N. Alma School Road
Chandler, Arizona 85224
[phone] or [phone]
[email protected]
Europe, Middle East, and Africa:
Freescale Halbleiter Deutschland GmbH
Technical Information Center
Schatzbogen 7
81829 Muenchen, Germany
[phone] (English)
[phone] (English)
[phone] (German)
[phone] (French)
[email protected]
Japan:
Freescale Semiconductor Japan Ltd.
Headquarters
ARCO Tower 15F
1-8-1, Shimo-Meguro, Meguro-ku,
Tokyo 153-0064
Japan
0120 191014 or [phone]
[email protected]
Asia/Pacific:
Freescale Semiconductor Hong Kong Ltd.
Technical Information Center
2 Dai King Street
Tai Po Industrial Estate
Tai Po, N.T., Hong Kong
[phone]
[email protected]
For Literature Requests Only:
Freescale Semiconductor Literature Distribution Center
P.O. Box 5405
Denver, Colorado 80217
1-800-441-2447 or 303-675-2140
Fax: [phone]
[email protected]

LIMITED WARRANTY
Matrix Design warrants this product against defects in material and workmanship for
a period of sixty (60) days from the original date of purchase.
This warranty extends
to the original customer only and is in lieu of all other warrants, including
implied warranties of merchantability and fitness.
In no event will the seller be
liable for any incidental or consequential damages. During the warranty period,
Matrix Design will replace, at no charge, components that fail, provided the product
is returned (properly packed and shipped prepaid) to Matrix Design at address below.
Dated proof of purchase (such as a copy of the invoice) must be enclosed with the
shipment. We will return the shipment prepaid via UPS.
This warranty does not apply if, in the opinion of Matrix Design, the product has been
damaged by accident, misuse, neglect, misapplication, or as a result of service or
modification (other than specified in the manual) by others.
Please send the board and cables with a complete description of the problem to:
Matrix Design & Manufacturing, Inc.
2914 Montopolis Drive #290
Austin, TX 78741
Phone: [phone]
Fax: [phone]
http://www.cadreiii.com
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

WARNING
This board generates, uses, and can radiate radio frequency energy and, if not installed
properly, may cause interference to radio communications. As temporarily permitted
by regulation, it has not been tested for compliance with the limits for class a
computing devices pursuant to Subpart J of Part 15 of FCC rules, which are designed
to provide reasonable protection against such interference. Operation of this product
in a residential area is likely to cause interference, in which case the user, at his/her
own expense, will be required to correct the interference.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

CONTENTS
Paragraph
Number Title Page
Number
Contents v
PRELIMINAR WITHOUT NOTICE
apps docs:ColdFire:5407:Eval Board UM NEW:5407C3UMTOC.fm 8/14/00
Chapter 1
M5407C3 Board
1.1 General Hardware Description ........................................................................... 1-1
1.2 System Memory.................................................................................................. 1-4
1.3 Serial Communication Channels......................................................................... 1-4
1.4 Parallel I/O Ports................................................................................................. 1-4
1.5 Programmable Timer/Counter............................................................................ 1-5
1.6 PCI Controller..................................................................................................... 1-5
1.7 On Board Ethernet .............................................................................................. 1-5
1.8 System Configuration ......................................................................................... 1-5
1.9 Installation And Setup......................................................................................... 1-7
1.9.1 Unpacking....................................................................................................... 1-7
1.9.2 Preparing the Board for Use ........................................................................... 1-7
1.9.3 Providing Power to the Board......................................................................... 1-8
1.9.4 Selecting Terminal Baud Rate........................................................................ 1-8
1.9.5 The Terminal Character Format ..................................................................... 1-8
1.9.6 Connecting the Terminal ................................................................................ 1-8
1.9.7 Using a Personal Computer as a Terminal...................................................... 1-8
1.10 System Power-up and Initial Operation............................................................ 1-11
1.11 M5407C3 Jumper Setup ................................................................................... 1-11
1.12 Using The BDM Port........................................................................................ 1-13
Chapter 2
Using the Monitor/Debug Firmware
2.1 What Is dBUG?................................................................................................... 2-1
2.2 Operational Procedure ........................................................................................ 2-3
2.2.1 System Power-up............................................................................................ 2-3
2.2.2 System Initialization....................................................................................... 2-4
2.2.2.1 Hard RESET Button. .................................................................................. 2-5
2.2.2.2 ABORT Button........................................................................................... 2-5
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

vi M5407C3 User’s Manual
CONTENTS
Paragraph
Number Title Page
Number
2.5 TRAP #15 Functions ........................................................................................ 2-39
2.5.1 OUT_CHAR................................................................................................. 2-39
2.5.2 IN_CHAR..................................................................................................... 2-39
2.5.3 CHAR_PRESENT........................................................................................ 2-40
2.5.4 EXIT_TO_dBUG.......................................................................................... 2-40
Chapter 3
Hardware Description and Reconfiguration
3.1 The Processor and Support Logic....................................................................... 3-1
3.1.1 Processor......................................................................................................... 3-1
3.1.2 Reset Logic..................................................................................................... 3-1
3.1.3 HIZ Signal....................................................................................................... 3-2
3.1.4 Clock Circuitry ............................................................................................... 3-2
3.1.5 Watchdog Timer............................................................................................. 3-2
3.1.6 Interrupt Sources............................................................................................. 3-2
3.1.7 Internal SRAM................................................................................................ 3-3
3.1.8 The MCF5407 Registers and Memory Map................................................... 3-4
3.1.9 Reset Vector Mapping.................................................................................... 3-5
3.1.10 TA Generation ................................................................................................ 3-5
3.1.11 Wait State Generator....................................................................................... 3-6
3.1.12 SDRAM DIMM.............................................................................................. 3-6
3.1.13 Flash ROM...................................................................................................... 3-7
3.1.14 JP15 Jumper and User’s Program................................................................... 3-7
3.2 Serial Communication Channels......................................................................... 3-7
3.2.1 MCF5407 UARTs........................................................................................... 3-7
3.2.2 I2C Module..................................................................................................... 3-8
3.3 Real-Time Clock................................................................................................. 3-8
3.4 Parallel I/O Port .................................................................................................. 3-8
3.5 On-Board Ethernet Logic.................................................................................... 3-8
3.6 Connectors and Expansion Bus ........................................................................ 3-11
3.6.1 Expansion Connectors - J1 and J2................................................................ 3-11
3.6.2 The Debug Connector J5 .............................................................................. 3-13
Appendix A
Configuring dBUG for Network Downloads
Appendix B
ColdFire to ISA, IRQ7 and Reset Logic Abel Code
Appendix C
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

CONTENTS
Paragraph
Number Title Page
Number
Contents vii
PRELIMINAR WITHOUT NOTICE
SDRAM MUX PAL Equation
Appendix D
Evaluation Board BOM
Appendix E Schematics
Appendix F
Errata
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

viii M5407C3 User’s Manual
PRELIMINAR WITHOUT NOTICE
CONTENTS
Paragraph
Number Title Page
Number
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

ILLUSTRATIONS
Figure
Number Title Page
Number
Illustrations ix
PRELIMINAR WITHOUT NOTICE
apps docs:ColdFire:5407:Eval Board UM NEW:5407C3UMLOF.fm 8/14/00
1-1 5407 Block Diagram.....................................................................................................1-3
1-2 Minimum System Configuration ..................................................................................1-6
1-3 Pin assignment for female P4 (Terminal) connector. ................................................... 1-9
1-4 Jumper Locations........................................................................................................1-10
2-1 Flow Diagram of dBUG Operational Mode. ................................................................2-4
3-1 The J5 Connector pin assignment...............................................................................3-14
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

ILLUSTRATIONS
Figure
Number Title Page
Number
x BookTitle
PRELIMINAR WITHOUT NOTICE
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

Tables xi
PRELIMINAR WITHOUT NOTICE
TABLES
Table
Number Title Page
Number
apps docs:ColdFire:5407:Eval Board UM NEW:5407C3UMLOT.fm 8/14/00
1-1 Power Supply Connections...........................................................................................1-8
1-2 Jumper Settings...........................................................................................................1-11
1-3 Jumper Settings...........................................................................................................1-13
1-4 Jumper Settings...........................................................................................................1-13
2-1 dBUG Command Summary..........................................................................................2-7
3-1 The M5407C3 Memory Map........................................................................................3-5
3-2 J1 Connector Pin Assignment.....................................................................................3-11
3-3 J2 Connector pin assignment......................................................................................3-12
D-1 MCF5407EVM_BOM................................................................................................. D-1
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

xii M5407C3 User’s Manual
PRELIMINAR WITHOUT NOTICE
TABLES
Table
Number Title Page
Number
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

Chapter 1. M5407C3Board 1-1
Chapter 1
M5407C3 Board
The M5407C3 is a versatile single board computer based on MCF5407 ColdFire®
Processor. It may be used as a powerful microprocessor based controller in a variety of
applications. With the addition of a terminal, it serves as a complete microcomputer for
reference, development/evaluation, training and educational use. The user need only
connect an RS-232 compatible terminal (or a personal computer with terminal emulation
software) and power supply to have a fully functional system.
Provisions have been made to connect this board to additional user supplied peripherals, via
the Microprocessor Expansion Bus connectors, to expand memory and I/O capabilities.
Additional peripherals may require bus buffers to minimize additional bus loading.
Furthermore, provisions have been made in the PC-board to permit configuration of the
board in a way, which best suits, an application. Options available are: upgrade to
512MBytes SDRAM, 512K SRAM, and commercially available slave PCI devices.
1.1 General Hardware Description
The M5407C3 board provides the RAM, Flash ROM, on board NE2000 compatible
Ethernet interface (10M bit/sec), RS232, and all the built-in I/O functions of the MCF5407
for learning and evaluating the attributes of the microprocessor. The MCF5407 is a member
of the ColdFire® family of processors. It is a 32-bit processor with 32-bit of address bus
and 32 lines of data. The processor has eight 32-bit data registers, eight 32-bit address
registers, a 32-bit program counter, and a 16-bit status register.
The MCF5407 has a System Integration Module referred to as the SIM. The module
incorporates many of the functions needed for system design. These include programmable
chip-select logic, System Protection logic, General purpose I/O, and Interrupt controller
logic. The chip-select logic can select up to eight memory banks and peripherals in addition
to two banks of DRAM’s. The chip-select logic also allows programmable number of
wait-states to allow the use of slower memory (refer to
MCF5407 User's Manual by
Freescale for detailed information about the SIM.). The M5407C3 uses four (CS[3:0]) of
the eight chip selects to access the Flash ROM’s (CS0), PCI bridge chip (CS1), SRAM
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

1-2 M5407C3 User’s Manual
General Hardware Description
to the user.
The M5407C3 will work with most PC100 SDRAM DIMMs with a few exceptions. The
MCF5407 supports up to two banks of SDRAM, but double-sided DIMMs require 4 bank
selects to access all of the chips. Therefore when using double-sided DIMMs only half of
the available memory will be accessible. Since DIMMs are manufactured primarily for use
in PCs the DQM signals on some DIMMS are routed so that the SDRAM can only be
accessed correctly as a 64-bit port so the M5407C3 will not be able to access the SDRAM
correctly.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

Chapter 1. M5407C3Board 1-3
General Hardware Description
Figure 1-1 shows the 5407 block diagram.
Figure 1-1. 5407 Block Diagram
External
Address
Bus
(1) RS232
drivers
(1) DB-9 Debug
Osc.
Davicom
10 Mb/sec
RJ45 Connector
External
Data
Bus
Control Signals
addr[31:0]
data[31:0] Control Signals
PCI slot
SDRAM
32bit 3.3V
Module
SDRAM
External
Mux (PAL)
(1) RS232
drivers
ColdFire® MCF5407 Bus Clk Drv
26-pin debug connector
512KB Sync
FSRAM
32 bit 3.3V
(not populated)
Flash
16 bit
1MB minimum
Osc.
PCI Interface
PAL
Expansion Connector#1
Expansion Connector#2
Osc.
EEPROM
(1) DB-9
Buffers
Osc.
Real TIme
Clock
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

1-4 M5407C3 User’s Manual
System Memory
1.2 System Memory
One on board Flash ROM (U12) is used to store the M5407C3 dBUG debugger/monitor
firmware in the lower 128 KBytes. The AM29PL160C-XX device is 16Mbits (16 bit by 1
MByte) giving a total of 2MBytes of Flash memory.
The PCI bridge chip provides the interface to the Universal 32-bit PCI on board connector
allowing the user to experiment and develop new applications to commercially available
slave PCI based peripherals products.
The MCF5407 has 4KBytes of internal SRAM organized as two independently
configurable 2 Kbyte blocks. each block can be configured for either data or instruction
space.
There is one 168-pin DIMM socket for SDRAM. System ships with 1M x 8 Bank x 16-Bits
SDRAM totaling 16M of volatile memory. Various SDRAM configurations are supported.
The internal caches of the MCF5407 are non-blocking. The data cache is 8 KByte, 4-way
set-associative with a 16-byte line size. The instruction cache is 16 KBytes, 4-way
set-associative with a 16-byte line size. The ROM Monitor currently does not utilize the
caches, but programs downloaded with the ROM Monitor can use the cache.
The M5407C3 evaluation board has a foot print for 512 KByte SRAM but is unpopulated.
1.3 Serial Communication Channels
The MCF5407 has 2 built-in UART’s (UART0 and UART1) with independent baud rate
generators. The signals of both channels are passed through external Driver/Receivers to
make the channel compatible with RS-232.An RS232 serial cable with DB9 connectors is
included. UART0 (P4) is used by the debugger for the user to access with a terminal. In
addition, the signals of both channels are available on the 120 pin expansion connector J2.
UART0 channel is the “TERMINAL” channel used by the debugger for communication
with external terminal/PC. The “TERMINAL’baud rate defaults to 19200.
1.4 Parallel I/O Ports
MCF5407 offers one 16-bit general-purpose parallel I/O port. Each pin can be individually
programmed as input or output. The parallel port bits PP[7:0] are multiplexed with
TT[1:0], TM[2:0], DREQ[1:0], and XTIP. The second set of parallel port bits PP[15:8] is
multiplexed with address bus bits A[31:24]. Both bytes of the parallel port are controlled
by the Pin Assignment Register (PAR). The pins are programmable on a pin by pin basis.
The setting of the multiplexed pins is determined by the configuration byte during reset.
After reset, PP[7:0] are configured as parallel port output pins and the PP[15:8] are
configured as A[31:24]. PP[7:4] are general purpose outputs and PP[3:0] are used by the
ROM Monitor to automatically configure the SDRAM address lines via the U27 mux.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

Chapter 1. M5407C3Board 1-5
ProgrammableTimer/Counter
1.5 ProgrammableTimer/Counter
The MCF5407 has two built in general purpose timer/counters. These timers are available
to the user. The signals for each timer are available on the 120 pin expansion connector J2.
1.6 PCI Controller
The MCF5407 connects to the PCI controller (U17) via the PCI host interface. The PCI
controller is configured for master mode. U18 contains the arbitration logic for the PCI bus.
This logic is such that the PCI controller (U17) defaults to allowing the 5407 bus
mastership. A PCI card wishing to arbitrate the bus away from the controller must use
signal REQ# to request the bus. U18 will then arbitrate the bus away from U17 and assert
GNT# to the PCI card to show that the card has been granted the bus. Similarly the
controller can arbitrate the bus back using signals /REQ and /GNT. By default the controller
currently has priority over the card in the equations in U18, if the user wanted to alter this
priority they could do so by editing file "ISA5407.abl" available on the ColdFire website
(www.mot.com/coldfire).
1.7 On Board Ethernet
The M5407C3 has an on board Ethernet (NE2000 compatible controller) operating at 10M
bits/sec. The on board dBUG ROM monitor is programmed to allow a user to download
files from a network to memory in different formats. The current compiler formats
supported are S-Record, COFF, ELF, or Image. Refer to Appenix A for details on how to
configure.
1.8 System Configuration
The M5407C3 board requires only the following items for minimum system configuration:
• The M5407C3 board (provided).
• Power supply, 7V to 14V DC with minimum of 1.0 Amp.
• RS-232C compatible terminal or a PC with terminal emulation software.
• RS-232 Communication cable (provided).
Refer to Section 2.2.2, “System Initialization” for initial setup.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

1-6 M5407C3 User’s Manual
System Configuration
Figure 1-2 displays minimum system configuration.
Figure 1-2. Minimum System Configuration
BDM
Connector
+7.0 to +14VDC
Input Power
dBUG>
RS-232 Terminal
Or PC
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

Chapter 1. M5407C3Board 1-7
Installation And Setup
1.9 Installation And Setup
The following sections describe all the steps needed to prepare the board for operation.
Please read the following sections carefully before using the board. When you are
preparing the board for the first time, be sure to check that all jumpers are in the default
locations. Default marking are on the board next to the individual jumpers and a master
jumper table is on the underside of the board. After the board is functional in its default
mode, you may use the Ethernet by following the instructions provided in Appendix A.
1.9.1 Unpacking
Unpack the computer board from its shipping box. Save the box for storing or reshipping.
Refer to the following list and verify that all the items are present. You should have
received:
• M5407C3 Single Board Computer
• M5407C3 User's Manual, this documentation
• One RS-232 communication cable
• One debug wiggler cable
• Programmers Reference Manual
• A selection of Third Party Developer Tools and Literature
NOTE:
Avoid touching the mos devices. Static discharge can and will
damage these devices.
Once you verified that all the items are present, remove the board from its protective jacket.
Check the board for any visible damage. Ensure that there are no broken, damaged, or
missing parts. If you have not received all the items listed above or they are damaged,
please contact Matrix Design immediately.
1.9.2 Preparing the Board for Use
The board as shipped is ready to be connected to a terminal and the power supply without
any need for modification. However, follow the steps below to insure proper operation from
the first time you apply the power. Figure 3 Jumper Table and Locations shows the
placement of the jumpers and the connectors, which you need to refer to in the following
sections. The steps to be taken are:
a) Connecting the power supply.
b) Connecting the terminal.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...

1-8 M5407C3 User’s Manual
Installation And Setup
1.9.3 Providing Power to the Board
The board accepts two means of power supply connections. Connector P6 is a 2.1mm
power jack and P3 lever actuated connector. The board accepts 7V to 14V DC at 1.5 Amp
via either one of the connectors.
1.9.4 SelectingTerminal Baud Rate
The serial channel of MCF5407 which is used for serial communication has a built in timer
used by the dBUG ROM monitor to generate the baud rate used to communicate with a
terminal.. It can be programmed to a number of baud rates. After the power-up or a manual
RESET, the dBUG ROM monitor firmware configures the channel for 19200 baud. After
the dBUG ROM monitor is running, you may issue the SET command to choose any baud
rate supported by the dBUG ROM monitor. Refer to Chapter 2 for the discussion of this
command.
1.9.5 The Terminal Character Format
The character format of the communication channel is fixed at the power-up or RESET.
The character format is 8 bits per character, no parity, and one stop bit. You need to insure
that your terminal or PC is set to this format.
1.9.6 Connecting theTerminal
The board is now ready to be connected to a terminal. Use the RS-232 male/female DB-9
serial cable to connect the PC to the M5407C3. The cable has a 9-pin female D-sub
terminal connector at one end and a 9-pin male D-sub connector at the other end. Connect
the 9-pin male connector to P4 connector on M5407C3. Connect the 9-pin female
connector to one of the available serial communication channels normally referred to as
COM1 (COM2, etc.) on the IBM PC’s or compatible. Depending on the kind of serial
connector on the back of your PC, the connector on your PC may be a male 25-pin or 9-pin.
You may need to obtain a 9-pin-to-25-pin adapter to make the connection. If you need to
build an adapter, refer to Figure 2 which shows the pin assignment for the 9-pin connector
on the board.
1.9.7 Using a Personal Computer as aTerminal
You may use your personal computer as a terminal provided you also have a terminal
emulation software such as PROCOMM, KERMIT, QMODEM, Windows 95/98/2000
Table 1-1. Power Supply Connections
Contact Number Voltage
1 +7–14V DC
2 Ground
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
nc...
