About this Document
This document describes how to connect to the
MPC8572EAMC and verify its basic operation. Settings for
the switches and jumpers are shown, as well as instruction
for connecting peripheral devices. In addition, instructions
for connecting a debugger to the MPC8572EAMC, such as
Freescale’s CodeWarrior are included, but instructions for
working with this debugger are beyond the scope of this
document.
Required Reading
It is assumed that the reader is familiar with the MPC8572E
microprocessor and MPC8572E PowerQUICC™ III
Integrated Host Processor Family Reference Manual as well
as the content of the High Level Design Document for
MPC8572EAMC.
Document Number: MPC8572EAMCGSG
Rev. 1.0, 08/2008
Contents
1. Check Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Assemble and Connect the Board . . . . . . . . . . . . . . . . 6
3. Perform Initial Board Power Up and Check LEDs . . . 6
4. Connecting JTAG Debugging Tools to the Board . . . 8
5. Front Panel Connectivity . . . . . . . . . . . . . . . . . . . . . . 8
6. Module Management Support . . . . . . . . . . . . . . . . . . 9
7. Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MPC8572E Advanced Mezzanine Card
Hardware Getting Started Guide

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
2Freescale Semiconductor
Definitions, Acronyms, and Abbreviations
Table 1. Definitions, Acronyms, and Abbreviations
AdvancedMC Advanced mezzanine card
AMC Advanced mezzanine card
ATCA Advanced telecommunications computing platform
BDM Background debugging mode
CCB Core complex bus
COP Computer operating properly
CPLD Complex programmable logic device
DIP Dual in-line package
DSP Digital signal processor
DUART Dual universal asynchronous receive transmit
EEPROM Electrically erasable programmable read-only module
GETH Gigabit Ethernet
HW Hardware
I2C (bus) Inter-IC bus
MMC Module management controller
SRIO Serial RapidIO
UART Universal asynchronous receive transmit
USB Universal serial bus
μTCA micro telecommunications computing architecture

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
Freescale Semiconductor 3
Check Switches
Figure 1 illustrates the main header and switch locations on the top (processor) side of the
MPC8572EAMC. Users should follow this getting started guide prior to applying power to the card,
because incorrect board settings can cause permanent board damage.
Figure 1. MPC8572EAMC Primary Side Header Positions
1 Check Switches
1. DIP Switch settings should only be changed when power is NOT applied to the board.
2. The MPC8572EAMC board has three push button switches (SW1, SW2 and SW3), four Dual In
line Package (DIP) switches (SW4, SW5, SW500, and SW501), and eight jumper headers (J1–J7
and HD1). The default DIP switch positions provide Power On Reset configuration values for the
MPC8572EAMC board. Check the default positions and verify the board is operational before
changing the switches. The settings for the switches are shown in Figure 2, with their default
positions as described in Table 2. Table 6 gives a full list of all possible switch configurations.
3. Jumper headers J3, J6, and HD1 are reserved for factory test and are used to program the module
management controller and Reset/System CPLDs. Users should not attempt to reprogram the card
using these headers because this may result in permanent card damage. The jumpers should
remain in their default position as detailed in Table 3.

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
4Freescale Semiconductor
Check Switches
Figure 2. Secondary Side Switch Positions
Table 2. Default Switch Settings
Feature Default Settings
[OFF = 1, ON = 0) Comments
SW4
SW4.1 OFF Reserved
SW4.2 OFF Reserved
SW4.3 OFF Reserved
SW4.4 ON [SW4.4] = MMC H/W Select. ON—MMC present
SW5
SW5.1 ON [SW5.1:2] = ON:OFF. CCB:SYSCLK = 10:1 (666 MHz)
SW5.2 OFF
SW5.3 OFF [SW5.3:4] = OFF:ON. e500 Core #0:CCB = 2:1
SW5.4 ON

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
Freescale Semiconductor 5
Check Switches
SW5.5 OFF [SW5.5:6] = OFF:ON. e500 Core #1:CCB = 2:1
SW5.6 ON
SW5.7 OFF [SW5.7:8] = OFF:OFF. Boot ROM Location = 32-bit Local FLASH Memory
SW5.8 OFF
SW500
SW500.1 ON [SW500.1:3]=ON:ON:OFF.DDR Clock Ratio = 10:1 DDRCLK (666 MHz)
SW500.2 ON
SW500.3 OFF
SW500.4 OFF [SW500.4:5] = OFF:OFF. MPC8572E acts as the host processor
SW500.5 OFF
SW500.6 ON [SW500.6:8] = ON:ON:OFF. IO Port Selection = SRIO 125 MHz, 3.125 Gbps (x4)
SW500.7 ON
SW500.8 OFF
SW501
SW501.1 OFF [SW501.1] = OFF Boot Sequence Configuration = Boot Sequencer Disabled
SW501.2 OFF CPU Boot Config:
[SW501.2:3] = OFF:ON. E500 Core 0 allowed to boot, Core 1 in boot hold-off
SW501.3 ON
SW501.4 ON RIO System Size:
[SW501.4] = ON. Large system size, up to 65,536 devices
Table 3. Header Configuration/Availability
Feature Status Comments
J1 Available IEEE Std 1588™ header
J2 Available USB DUART Connection. Provides debug information from MPC8572E Core #0 /1.
J3 — MMC BDM Debug header. Reserved for factory use only.
J4 Available COP Debug Header
J6 — CPLD JTAG Select. Reserved for factory use only.
J7 Available Pin 1 = TxD, Pin 2 = RxD, Pin 3 = GND. Connect for console debug information from MMC only.
HD1 — CPLD Programming Header. Reserved for factory use only.
Table 2. Default Switch Settings (continued)
Feature Default Settings
[OFF = 1, ON = 0) Comments

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
6Freescale Semiconductor
Assemble and Connect the Board
2 Assemble and Connect the Board
1. The heat sink must be fitted to the processor at all times.
2. Freescale recommends running the AdvancedMC in an ATCA, microTCA, picoTCA chassis or
equivalent. This delivers the correct power and air flow to the board. The board should be inserted
into the carrier chassis as per the specific carrier instructions. Please ensure the card is inserted the
correct way. An example is shown in Figure 3.
Figure 3. Inserting the MPC8572EAMC into a Chassis
3 Perform Initial Board Power Up and Check LEDs
A complete list of all LEDs on the MPC8572EAMC is shown in Table 5.
1. Switch on the power to the chassis.
2. Check for the blue front panel LED and power good LEDs being illuminated (a full description of
the LED operation is given in Table 5).
Table 4. Push Switches
Feature Switch Function Comments
SW1 AdvancedMC hot swap Micro switch used to detect AdvancedMC handle position
SW2 Power cycle switch Push button switch used to power cycle the AdvancedMC
SW3 Reset switch Push button switch used for hard reset of the processor

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
Freescale Semiconductor 7
Perform Initial Board Power Up and Check LEDs
3. When powered up:
a) Blue front panel LED remains illuminated as long as power is applied to the board (via the
AdvancedMC backplane connector).
b) Ethernet port activity LEDs switch on to indicate any Ethernet link to the front or back planes.
c) The “System Status” LED, LD507, switches on, then goes off once system configuration is
complete. LED LD506 should stay on indicating the processor is “Ready.”
d) Any USB UART activity is shown on LEDs D507 and D508.
4. Pressing the power cycle button (SW2) power cycles the board and start the reset sequence.
5. Pressing the reset button (SW3) starts the reset sequence only.
Table 5. LED Operation
Description Ref Color LED On LED Off
MMC red LED LD1 Red MMC control Normal operation
MMC card power blue LED LD500 Blue Hot swap state Hot swap state
Port 0 AMC SERDES Ethernet Rx activity D500 Green Rx Ethernet activity No Rx Ethernet activity
Port 0 AMC SERDES Ethernet Tx activity D501 Yellow Tx Ethernet activity No Tx Ethernet activity
Port 0 AMC SERDES LOS D502 Orange Loss of signal No loss of signal
Port 1 AMC SERDES LOS D504 Orange Loss of signal No loss of signal
Port 1 AMC SERDES Ethernet Tx activity D505 Yellow Tx Ethernet activity No Tx Ethernet activity
Port 1 AMC SERDES Ethernet Rx activity D506 Green Rx Ethernet activity No Rx Ethernet activity
USB/UART 1 activity D507 Orange UART 1 activity No UART 1 activity
USB/UART 0 activity D508 Orange UART 0 activity No UART 0 activity
Front panel dual RJ45 Ethernet Rx activity P3:D1-2a Green Rx Ethernet activity No Rx Ethernet activity
Front panel dual RJ45 Ethernet Tx activity P3:D1-4a Yellow Tx Ethernet activity No Tx Ethernet activity
Front panel dual RJ45 Ethernet Rx activity P3:D1-2b Green Rx Ethernet activity No Rx Ethernet activity
Front panel dual RJ45 Ethernet Tx activity P3:D1-4b Yellow Tx Ethernet activity No Tx Ethernet activity
Front panel 10/100 RJ45 Ethernet Rx activity P1 Orange/
Green
Rx Ethernet activity No Rx Ethernet activity
Front panel 10/100 RJ45 Ethernet Tx activity P1 Yellow Tx Ethernet activity No Tx Ethernet activity
General debug system CPLD LD507 Green System CPLD
execution not
complete
System CPLD execution
complete
General debug system CPLD LD506 Green Ready signal POR config cycles
unsuccessful
General debug system CPLD LD505 Yellow Default on User debug #1
General debug system CPLD LD504 Yellow Default on User debug #2
General debug POR CPLD LD502 Green User config #1 User config #1

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
8Freescale Semiconductor
Connecting JTAG Debugging Tools to the Board
4 Connecting JTAG Debugging Tools to the Board
Figure 4 illustrates an example of how to connect a JTAG debugger to the MPC8572EAMC. The USB tap
debugging tool enables the CodeWarrior software IDE to work with the MPC8572EAMC board.
1. Connect the JTAG debugger unit to the JTAG 16-pin connector (J4).
2. Connect USB cable from Host PC (with CodeWarrior Power Architecture™ tools installed on it)
to CodeWarrior USB Tap. Figure 4 illustrates Freescale’s CodeWarrior debugger connected to the
MPC8572EAMC. Note the orientation of pin 1 (red edge of ribbon cable) with pin 1 on J4.
3. Switch on power to the board.
4. Check for completion of the reset sequence (see step 3) and power indicator on USB Tap.
5. Continue as per standard CodeWarrior instructions.
a) Contact your local FAE for the correct JTAG configuration file.
Figure 4. USB TAP Connection to Header J4
5 Front Panel Connectivity
Figure 5 shows the different front panel connections. P1 provides a RJ45 10/100 Ethernet port. The final
front panel connector P3 provides two high speed Gigabit Ethernet connections. Serial connectivity for
General debug POR CPLD LD501 Yellow User config #2 User config #2
General debug POR CPLD LD503 Yellow User config #3 User config #3
Table 5. LED Operation (continued)
Description Ref Color LED On LED Off

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
Freescale Semiconductor 9
Module Management Support
both dual cores is provided via USB serial connector J2. Users should note that USB drivers should be
installed onto the host PC before the serial terminal can be used. These can be downloaded from the
following URL: http://www.ftdichip.com/FTDrivers.htm
A serial terminal can be setup using a PC communication program such as Hyperterminal set to 115200
baud rate. If the USB session hangs the terminal then the communication link must be disconnected and
then reconnected.
Any board settings that users wish to make should be checked for validity against a recent version of the
MPC8572E PowerQUICC™ III Integrated Host Processor Family Reference Manual. Operating the
board, or MPC8572E device, beyond the recommended device operating conditions may cause permanent
board damage.
Figure 5. MPC8572EAMC Front Panel Connectivity
6 Module Management Support
The MPC8572EAMC contains a CorEdge™-enabled module management controller (MMC), which
meets the PICMG and intelligent platform management interface (IPMI) AdvancedMC specifications.
This enables the board to be hot swapped in or out of an MMC-compatible system. To hot swap a board,
complete the following steps:
Hot swapping in a board:
1. Set switch SW4.4 to ON to select the MMC present option.

MPC8572E Advanced Mezzanine Card Hardware Getting Started Guide, Rev. 1.0
10 Freescale Semiconductor
Module Management Support
2. Insert the AdvancedMC into the slot with the handle extracted. The BLUE LED switches ON once
it is inserted.
3. Close the handle. The BLUE LED flashes and then switches OFF. The board powers up.
Hot swapping out a board:
1. Extract the hot swap handle
2. The BLUE LED flashes and then stays ON.
3. When the BLUE LED is ON, the AdvancedMC can be removed from the chassis.
Figure 6. Hot Swapping in a Chassis
NOTE
While the chassis shown in Figure 6is MMC-compatible, thechassisshown
in Figure 3 is not.
Table 6 lists the complete switch settings.
Table 6. Complete Switch Settings
Feature Default Settings
[OFF = 1, ON = 0) Comments
SW4
SW4.1 OFF Reserved
SW4.2 OFF Reserved
SW4.3 OFF Reserved
SW4.4 ON [SW4.4] = MMC H/W Select. ON—MMC present1
[SW4.4] = MMC H/W Select. OFF—MMC not present
