56F8013
Socket Board for Flash Programming
User Guide
56F8013SBUG
Rev. 0
04/2005

Document Revision History
Version History Description of Change
Rev. 0 Initial Release

TABLE OF CONTENTS
Table of Contents, Rev. 0
Freescale Semiconductor i
Preliminary
Preface v
Chapter 1
Introduction
1.1 56F8013 Socket Board Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Chapter 2
Technical Summary
2.1 32-Pin LQFP Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 32-Pin PDIP Socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.3 JTAG Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.4 Daughter Card Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.5 Power-On LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.6 Manual Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.7 Test Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Appendix A
56F8013 Socket Board Schematics
Appendix B
56F8013 Socket Board Bill of Material

56F8013 Socket Board User Guide, Rev. 0
ii Freescale Semiconductor
Preliminary

LIST OF FIGURES
List of Figures, Rev. 0
Freescale Semiconductor iii
Preliminary
1-1 Connecting the 56F8013 Socket Board & 56F8013 Demonstration Board . . . . . . . 1-1
1-2 Connecting the 56F8013 Socket Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

56F8013 Socket Board User Guide, Rev. 0
iv Freescale Semiconductor
Preliminary

Preface, Rev. 0
Freescale Semiconductor v
Preliminary
Preface
This reference manual describes the hardware on the 56F8013 Socket Board in detail.
Audience
This document is intended for application developers or a production team who wish to
program an application into the Flash memory on a Freescale 56F8013 part before it is
mounted on a printed circuit board.
Organization
This manual is organized into two chapters and two appendixes.
•Chapter 1, Introduction, provides an overview of the 56F8013 Socket Board and
its features.
•Chapter 2, Technical Summary, describes in detail the 56F8013 Socket Board’s
hardware.
•Appendix A, 56F8013 Socket Board Schematics, contains the schematics of the
56F8013 Socket Board.
•Appendix B, 56F8013 Socket Board Bill of Material, provides a list of the
materials used on the 56F8013 Socket Board.
Suggested Reading
More documentation on the 56F8013 part may be found at URL:
www.freescale.com

56F8013 Socket Board User Guide, Rev. 0
vi Freescale Semiconductor
Preliminary
Notation Conventions
This manual uses the following notational conventions:
Term or Value Symbol Examples Exceptions
Active High
Signals
(Logic One)
No special symbol
attached to the
signal name
A0
CLKO
Active Low
Signals
(Logic Zero)
Noted with an
overbar in text and
in most figures
WE
OE
In schematic drawings,
Active Low Signals may be
noted by a backslash: /WE
Hexadecimal
Values
Begin with a “$”
symbol
$0FF0
$80
Decimal Values No special symbol
attached to the
number
10
34
Binary Values Begin with the letter
“b” attached to the
number
b1010
b0011
Numbers Considered positive
unless specifically
noted as a negative
value
5
-10
Voltage is often shown as
positive: +3.3V
Blue Text Linkable on-line ...refer to Chapter 7, License
Bold Reference sources,
paths, emphasis
...see:
http://www.freescale.com/

Preface, Rev. 0
Freescale Semiconductor vii
Preliminary
Definitions, Acronyms, and Abbreviations
Definitions, acronyms and abbreviations for terms used in this document are defined below for
reference.
EOnCETM Enhanced On-Chip Emulation; a debug bus and port created to enable a
designer to create a low-cost hardware interface for a
professional-quality debug environment
JTAG Joint Test Action Group; a bus protocol/interface used for test and
debug
LED Light Emitting Diode
56F8013 A Freescale controller with motor control peripherals.
OnCETM On-Chip Emulation, a debug bus and port created to allow a means for
low-cost hardware to provide a professional-quality debug environment
PCB Printed Circuit Board
ZIF Zero Insertion Force
References
The following sources were referenced to produce this manual:
[1] DSP56800E Reference Manual, DSP56800ERM, Freescale Semiconductor, Inc.
[2] 56F8000 Peripheral Reference Manual, MC56F8000RM, Freescale Semiconduc-
tor, Inc.
[3] 56F8013 Technical Data, MC56F8013, Freescale Semiconductor, Inc.

56F8013 Socket Board User Guide, Rev. 0
viii Freescale Semiconductor
Preliminary

Introduction, Rev. 0
Freescale Semiconductor 1-1
Preliminary
Chapter 1
Introduction
The 56F8013 Socket Board provides a means to program the Flash memory in a 56F8013
controller, then allows the 56F8013 controller to be removed and placed onto another printed
circuit board.
Some packages are not available at publication.
1.1 56F8013 Socket Board Architecture
The 56F8013 Socket Board contains a Zero Insertion Force LQFP-32 socket and a Zero Insertion
Force PDIP-32 socket, as shown in Figure 1-1. This combination of sockets allows both
56F8013 package types to be easily supported. Additionally, the PCB includes a JTAG
connector, manual reset pushbutton switch and Daughter Card connector.
The 56F8013 Socket Board is designed to be used with a 56F8013 Demonstration Board. The
power supply and JTAG interface POD used with the 56F8013 Demonstration Board are needed
to provide an operational Flash programming platform.
P3
56F8013 Demonstration Board
J1
P1
P2
56F8013 Socket Board
P1
J1
RESET
POWER ON
U1
U2
JTAG
Figure 1-1. Connecting the 56F8013 Socket Board & 56F8013 Demonstration Board

56F8013 Socket Board User Guide, Rev. 0
1-2 Freescale Semiconductor
Preliminary
An interconnection diagram is shown in Figure 1-2, connecting the PC, the external +9.0V DC
power supply, the 56F8013 Socket Board and the 56F8013 Demonstration Board.
PC-compatible
Cable
Computer
Parallel Extension
56F8013
External
+9V
Power
J1
Connect cable
to Parallel/Printer port
with 2.1mm,
receptacle
connector
JTAG POD
P1
56F8013 Socket Board
Demonstration
Board
Figure 1-2. Connecting the 56F8013 Socket Board
Perform the following steps to connect the 56F8013 Socket Board:
1. Connect the 56F8013 Demonstration Board to the 56F8013 Socket Board by pressing the
two boards together, using P2 on the 56F8013 Demonstration Board and P1 on the
56F8013 Socket Board.
2. Connect the parallel extension cable to the Parallel port of the host computer.
3. Connect the other end of the parallel extension cable to the JTAG interface POD.
— Connect the ribbon cable from the JTAG interface POD to J1 on the 56F8013 Socket
Board, shown in Figure 1-2. This provides the connection which allows the host
computer to download code to the 56F8013 part on the 56F8013 Socket Board.
4. Make sure that the external +9.0V DC, 450mA power supply is not plugged into a
+120V AC power source.
5. Connect the 2.1mm output power plug from the external power supply into P1 on the
56F8013 Demonstration Board, shown in Figure 1-2.
6. Apply power to the external power supply. The green Power-ON LED on the 56F8013
Demonstration Board, LED7, and LED1 on the 56F8013 Socket Board will illuminate
when power is applied correctly.

Technical Summary, Rev. 0
Freescale Semiconductor 2-1
Preliminary
Chapter 2
Technical Summary
Some packages are not available at publication.
The 56F8013 Socket Board is designed to be combined with the 56F8013 Demonstration Board.
This combination provides a Flash programming platform for the 56F8013 part. The main
features of the 56F8013 Socket Board, with board and schematic reference designators, include:
• 32-Pin LQFP ZIF Socket, an open-top, press-down, spring-loaded Zero Insertion Force
socket by CTI/WELLS [U1]
• 32-Pin PDIP ZIF Socket, a lever-controlled Zero Insertion Force Socket by Aries [U2]
• JTAG interface connector [J1]
• Daughter Card connector, which allows the connection of the 56F8013 Demonstration
Board [P1]
• LED power indicator [LED1]
• Manual reset pushbutton [S1]
2.1 32-Pin LQFP Socket
The 56F8013 Socket Board uses a CTI/WELLS 32-pin LQFP Zero Insertion Force (ZIF) socket,
7007-032-1-07, designated as U1 on the board. Pin 1 of the package should be aligned with pin 1
of the socket, which is positioned where the U1 reference designator is located. The socket is
spring loaded, allowing the user to press down on the outer ring of the socket, forcing the contact
pins to pull away from the package well area. The user then places the part requiring Flash
memory programming into the socket’s package well area. When the user releases the outer ring
of the socket, the contact pins extend to press against the package pins, making an electrical
contact with the part.
NOTE: Parts should only be installed or removed from the LQFP-32 socket when power is not
present on the 56F8013 Socket Board. Also, only one socket should have a part present at one
time.

56F8013 Socket Board User Guide, Rev. 0
2-2 Freescale Semiconductor
Preliminary
2.2 32-Pin PDIP Socket
The 56F8013 Socket Board uses an ARIES 32-pin PDIP Universal Zero Insertion Force (ZIF)
socket, 32-6554-11, designated as U2 on the board. The locking action of the socket is controlled
by a lever arm on the side of the socket. When the lever arm is raised, the socket’s contact pins
are released, allowing the removal or insertion of the part. When the lever arm is lowered, the
socket’s contact pins press against the pins on the part, providing an electrical connection.
NOTE: Parts should only be installed or removed from the PDIP-32 socket when power is not
present on the 56F8013 Socket Board. Also, only one socket should have a part present at one
time.
2.3 JTAG Connector
The 56F8013 Socket Board provides a JTAG Connector, J1. This connector allows the PC to
communicate with a 56F8013 part in the LQFP-32 socket or in the PDIP-32 socket.
2.4 Daughter Card Connector
The 556F8013 Socket Board uses a Daughter Card Connector, P1. This connector provides
power to the 56F8013 Socket Board via the 56F8013 Demonstration Board. Power (+3.3V DC)
is present on pin 1 of P1 and the ground is present on pin 3 of P1.
2.5 Power-On LED
The 56F8013 Socket Board provides a Power-On LED, LED1, which illuminates when power is
applied to the 56F8013 Socket Board.
2.6 Manual Reset
The 56F8013 Socket Board provides a Manual Reset Pushbutton, S1, which allows the manual
generation of a reset signal to the 56F8013 part in either the U1 or U2 socket.
2.7 Test Points
The 56F8013 Socket Board provides two power monitoring test points, TP1 and TP2. TP1 is
connected to +3.3V and TP2 is connected to digital ground.

56F8013 Socket Board Schematics, Rev. 0
Freescale Semiconductor Appendix A-1
Preliminary
Appendix A
56F8013 Socket Board Schematics

A A
B B
C C
D D
E E
4 4 3 3
2 2
1 1
RESET PUSHBUTTON
JTAG Connector
/TRST
DSCO Design
ANGUILLA SOCKETS
ANGUILLAPROGRAMMER.DSN
1.0
12Monday, February 28, 2005
A
Digital Signal Controller Operation
2100 East Elliot Road Tempe, Arizona 85284
Title
Document Date:
Size
Designer: Sheet of
Rev.
Number
[phone] FAX: [phone]
/RESET TDI TDO TCK TMS
/RESET
/DE TDI TDO TCK
TMS GND GND GND
TMS
/RESET TDI TDO TCK TMS
/RESET
/DE
+3.3V +3.3V
+3.3V
+3.3V
+3.3V
+3.3V +3.3V
C1 2.2uF
U1
LQFP-32 SOCKET
17
12
11
10
5
6
9
19
4
16
7
8
27
13
20
18
22
32
30
14
1
3
24
23
29
28
21
2
25
26
31
15
PB2/MISO/T2
ANA0/PC0 ANA1/PC1
ANA2/VREFH/PC2
ANB0/PC4 ANB1/PC5
VSSA_ADC
PB4/T0/CLKO PB5/T1/FAULT3 PB3/MOSI/T3
ANB2/VREFL/PC6
VDDA_ADC
VSS_IO1 VSS_IO0
PA5/PWM5/FAULT2/T3 PA6/FAULT0 PA4/PWM4/FAULT1/T2 TDO/PD1 TDI/PD0 TCK/PD2 PB6/RXD/SDA/CLKIN PB7/TXD/SCL PA3/PWM3 PA2/PWM2 PA0/PWM0 PA1/PWM1 PB0/SCLK/SCL PB1/SS/SDA
VCAP1
VDD_IO
TMS/PD3 RESET/PA7/VPP
C2 2.2uF
U2
PDIP-32 SOCKET
13
8
7
6
1
2
5
15
32
12
3
4
23
9
16
14
18
28
26
10
29
31
20
19
25
24
17
30
21
22
27
11
PB2/MISO/T2
ANA0/PC0 ANA1/PC1
ANA2/VREFH/PC2
ANB0/PC4 ANB1/PC5
VSSA_ADC
PB4/T0/CLKO PB5/T1/FAULT3 PB3/MOSI/T3
ANB2/VREFL/PC6
VDDA_ADC
VSS_IO1 VSS_IO0
PA5/PWM5/FAULT2/T3 PA6/FAULT0 PA4/PWM4/FAULT1/T2 TDO/PD1 TDI/PD0 TCK/PD2 PB6/RXD/SDA/CLKIN PB7/TXD/SCL PA3/PWM3 PA2/PWM2 PA0/PWM0 PA1/PWM1 PB0/SCLK/SCL PB1/SS/SDA
VCAP1
VDD_IO
TMS/PD3 RESET/PA7/VPP
R2 10K
S1
KEY
J1
1 3 5 7 9 11 13
2 4 6
10 12 14
R3
10K
R4
47K
56F8013 Socket Board User Guide, Rev. 0
Appendix A-2 Freescale Semiconductor
Preliminary
Figure A-1. 32-Pin Sockets

A A
B B
C C
D D
E E
4 4 3 3
2 2
1 1
Daughter Peripheral Port Connector
RESET_b/PA7/VPP
PC0 PC1 ANA2/VREFH/PC2 PC4 PC5 VREFL/PC6 SS_b/SDA/PB1 SCLK/SCL/PB0 PA2 PA3 FAULT1/T2/PA4 FAULT2/T3/PA5
TMS/PD3
PB6/RXD/SDA/CLKIN
MISO/T2/PB2 PB7/TXD/SCL
FAULT0/PA6
TDI/PD0
MOSI/T3/PB3
PA0
T1/FAULT3/PB5
T0/CLKO/PB4
PA1
TDO/PD1 TCK/PD2
SCLK/SCL/PB0 SS_b/SDA/PB1
TEST POINT
GROUND
TEST POINT
+3.3V
POWER GOOD LED
DSCO Design
DAUGHTER CARD CONNECTOR
ANGUILLAPROGRAMMER.DSN
1.0
22Monday, February 28, 2005
A
Digital Signal Controller Operation
2100 East Elliot Road Tempe, Arizona 85284
Title
Document Date:
Size
Designer: Sheet of
Rev.
Number
[phone] FAX: [phone]
GND
+3.3V
+3.3V
+3.3V
+3.3V
P1
1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39
2 4 6 8
10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
+
C3 47uF 10VDC
TP2
1
TP1
1
R1 270
LED1
GREEN LED
56F8013 Socket Board Schematics, Rev. 0
Freescale Semiconductor Appendix A-3
Preliminary
Figure A-2. Daughter Card Connector

56F8013 Socket Board User Guide, Rev. 0
Appendix A-4 Freescale Semiconductor
Preliminary

56F8013 Socket Board Bill of Material, Rev. 0
Freescale Semiconductor Appendix B-1
Preliminary
Appendix B
56F8013 Socket Board Bill of Material
Qty Description Ref. Designators Vendor Part #
Sockets
132-Pin LQFP Socket U1 CTI/WELLS, 7007-032-1-07
132-Pin PDIP Socket U2 ARIES, 32-6554-11
Resistors
1270 Ω, 5%, 0805 R1 SMEC, RC73L2A271JT
210K Ω, 5%, 0805 R2, R3 SMEC, RC73L2A103JT
147K Ω, 5%, 0805 R4 SMEC, RC73L2A473JT
Switches
1Pushbutton Switch S1 Panasonic, EVQ-PAD07K
LEDs
1Green LED, 1206 LED1 Agilent, HSMG-C650
Capacitors
147µF, 16V DC,ELECT-C C1 Panasonic, ECE-V1CA470WR
Connectors
140x2 Header P1 SAMTEC, TSW-140-07-S-D
17x2 JTAG Header J1 SAMTEC, TSW-107-07-S-D
Test Points
1+3.3V Test Point TP1 KEYSTONE, 5000, RED
1GND Test Point TP2 KEYSTONE, 5001, BLACK
Miscellaneous
4Rubber Feet 3M SJ5018BLKC

56F8013 Socket Board User Guide, Rev. 0
Appendix B-2 Freescale Semiconductor
Preliminary
