Freescale Semiconductor MPC566EVB User manual

MPC566EVBUM
Rev. 1.2, 3/2003
MPC566EVB User's Manual
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Revision History
Version
Number Revision Date Description of Changes
1.1 11/2002 Initial Version
1.2 3/2003 Fixed typos. Added appendix describing dBUG ethernet configu-
ration. Added appendix for emulating the MPC53X parts.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

© Motorola Inc., 2002. All rights reserved.
DigitalDNA and Mfax are trademarks of Motorola, Inc.
IBM PC and IBM AT are registered trademark of IBM Corp.
All other trademark names mentioned in this manual are the registered trade mark of respective owners
No part of this manual and the dBUG software provided in Flash ROM’s/EPROM’s may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise. Use of the program or any
part thereof, for any purpose other than single end user by the purchaser is prohibited.
Motorola reserves the right to make changes without further notice to any products herein. Motorola makes no warranty,
representation or guarantee regarding the suitability of its products for any particular purpose, nor does Motorola assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation
consequential or incidental damages. “Typical” parameters which may be provided in Motorola data sheets and/or specifications can
and do vary in different applications and actual performance may vary over time. All operating parameters, including “Typicals” must
be validated for each customer application by customer’s technical experts. Motorola does not convey any license under its patent
rights nor the rights of others. Motorola products are not designed, intended, or authorized for use as components in systems
intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in
which the failure of the Motorola product could create a situation where personal injury or death may occur. Should Buyer purchase or
use Motorola products for any such unintended or unauthorized application, Buyer shall indemnify and hold Motorola and its officers,
employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable
attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or
unauthorized use, even if such claim alleges that Motorola was negligent regarding the design or manufacture of the part. Motorola
and are registered trademarks of Motorola, Inc. Motorola, Inc. is an Equal Opportunity/Affirmative Action Employer.
How to reach us:
USA/EUROPE/Locations Not Listed: Motorola Literature Distribution; P.O. Box 5405, Denver, Colorado 80217. 1–303–675–2140
or 1–800–441–2447
JAPAN: Motorola Japan Ltd.; SPS, Technical Information Center, 3–20–1, Minami–Azabu. Minato–ku, Tokyo 106–8573 Japan.
81–3–3440–3569
ASIA/PACIFIC: Motorola Semiconductors H.K. Ltd.; Silicon Harbour Centre, 2 Dai King Street, Tai Po Industrial Estate, Tai Po, N.T.,
Hong Kong. 852–26668334
Technical Information Center: 1–800–521–6274
HOME PAGE: http://www.motorola.com/semiconductors
Document Comments: FAX [phone], Attn: RISC Applications Engineering
World Wide Web Addresses: http://www.motorola.com/PowerPC
http://www.motorola.com/NetComm
http://www.motorola.com/ColdFire
Axiom Manufacturing: http://www.axman.com
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Cautionary Notes
Axiom Manufacturing (http://www.axman.com) reserves the right to make changes without
further notice to any products to improve reliability, function or design. Axiom does not
assume any liability arising out of the application or use of any product or circuit described
herein; neither does it convey any license under patent rights or the rights of others. Axiom
products are not designed, intended, or authorized for use as components in systems
intended for surgical implant into the body, or other applications intended to support or sus-
tain life, or for any other application in which failure of the Axiom product could create a
situation where personal injury or death may occur. Should Buyer purchase or use Axiom
manufacturing products for any such unintended or unauthorized application, Buyer shall
indemnify and hold Axiom Manufacturing and its officers, employees, subsidiaries, affili-
ates, and distributors harmless against all claims, costs, damages, and expenses, and reason-
able attorney fees arising out of, directly or indirectly, any claim of personal injury or death
associated with such unintended or unauthorized use, even if such claim alleges that Axiom
Manufacturing was negligent regarding the design or manufacture of the part or system.
EMC Information on MPC566EVB
1. This product as shipped from the factory with associated power supplies and cables,
has been tested and meets with requirements of EN5022 and EN 50082-1: 1998 as a
CLASS A product.
2. This product is designed and intended for use as a development platform for hard-
ware or software in an educational or professional laboratory.
3. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
4. Anti-static precautions must be adhered to when using this product.
5. Attaching additional cables or wiring to this product or modifying the products oper-
ation from the factory default as shipped may effect its performance and also cause
interference with other apparatus in the immediate vicinity. If such interference is
detected, suitable mitigating measures should be taken.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

WARNING
This board generates, uses, and can radiate radio frequency energy and, if not installed
properly, may cause interference to radio communications. As temporarily permitted by
regulation, it has not been tested for compliance with the limits for class a computing devices
pursuant to Subpart J of Part 15 of FCC rules, which are designed to provide reasonable
protection against such interference. Operation of this product in a residential area is likely
to cause interference, in which case the user, at his/her own expense, will be required to
correct the interference.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Contents
Paragraph
Number Title Page Number
MOTOROLA MPC564EVB User’s Manual i
Chapter 1
MPC566 EVB Board
1.1 Processor.............................................................................................................. 1-3
1.2 System Memory................................................................................................... 1-4
1.2.1 External Flash .................................................................................................. 1-4
1.2.2 SRAM.............................................................................................................. 1-5
1.2.3 Internal SRAM................................................................................................. 1-5
1.2.4 Internal Flash ................................................................................................... 1-5
1.2.5 MPC566EVB Memory Map............................................................................1-5
1.2.5.1 Memory Device / Bank Selection and Configuration.................................. 1-6
1.2.5.2 Memory Bank Chip Select Configuration................................................... 1-7
1.2.5.3 Reset Vector Mapping.................................................................................. 1-7
1.3 Support Logic ...................................................................................................... 1-8
1.3.1 Reset Logic ...................................................................................................... 1-8
1.3.2 Clock Circuitry ................................................................................................ 1-8
1.3.3 Watchdog Timer............................................................................................... 1-8
1.3.4 Exception Sources............................................................................................ 1-8
1.3.5 TA Generation.................................................................................................. 1-9
1.3.6 User’s Program ................................................................................................ 1-9
1.3.7 Power Oak K/I/S Hardware Options .............................................................1-10
1.4 Communication Ports ........................................................................................ 1-11
1.4.1 COM1 - COM4.............................................................................................. 1-11
1.4.2 CAN PORTs and Options .............................................................................. 1-13
1.4.3 10/100T Ethernet Port.................................................................................... 1-14
1.4.4 BDM and NEXUS Development Ports ......................................................... 1-15
1.4.4.1 BDM Port Options..................................................................................... 1-15
1.4.4.2 Nexus Connector ....................................................................................... 1-16
1.5 Connectors and User Components.....................................................................1-19
1.5.1 Keypad........................................................................................................... 1-19
1.5.2 LCD Port........................................................................................................ 1-19
1.5.3 User Components........................................................................................... 1-21
1.5.4 MPC566EVB Hardware Options................................................................... 1-22
1.5.5 Signals Available on Board............................................................................ 1-22
1.5.5.1 IRQ PORT ................................................................................................. 1-22
1.5.5.2 BUS_PORT................................................................................................ 1-22
1.5.5.3 TPU_PORTs .............................................................................................. 1-24
1.5.5.4 CONTROL_PORT .................................................................................... 1-24
1.5.5.5 MIOS_PORT ............................................................................................. 1-25
1.5.5.6 QADC_PORTs........................................................................................... 1-26
1.5.5.7 QSM_PORTs ............................................................................................. 1-27
1.5.5.8 MICTOR 1 – 3 PORTs...............................................................................1-28
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Contents
Paragraph
Number Title Page Number
ii MPC564EVB User’s Manual MOTOROLA
1.6 Reference Documents........................................................................................ 1-28
1.7 Software Development ...................................................................................... 1-28
Chapter 2 Initialization and Setup
2.1 System Configuration .......................................................................................... 2-1
2.2 Installation And Setup .........................................................................................2-3
2.2.1 Unpacking........................................................................................................ 2-3
2.2.2 Preparing the Board for Use ............................................................................ 2-3
2.2.3 Providing Power to the Board.......................................................................... 2-3
2.2.4 Selecting Terminal Baud Rate .........................................................................2-5
2.2.5 The Terminal Character Format....................................................................... 2-5
2.2.6 Connecting the Terminal.................................................................................. 2-5
2.2.7 Using a Personal Computer as a Terminal....................................................... 2-6
2.3 MPC566EVB Jumper and Switch Setup.............................................................2-6
2.3.1 Reset Configuration Word and Configuration Switch (CONFIG_SW) .......... 2-8
2.3.2 Memory Configuration (MAP_SW).............................................................. 2-10
2.4 System Power-up and Initial Operation............................................................. 2-10
Chapter 3
Using the Monitor/Debug Firmware
3.1 What Is dBUG?.................................................................................................... 3-1
3.2 Operational Procedure ......................................................................................... 3-2
3.2.1 System Power-up............................................................................................. 3-2
3.2.2 System Initialization ........................................................................................ 3-4
3.2.2.1 Hard RESET Button....................................................................................3-5
3.2.2.2 Non-Maskable Interrupt Button................................................................... 3-5
3.2.2.3 Software Reset Command. .......................................................................... 3-5
3.3 Command Line Usage .........................................................................................3-6
3.4 Commands ........................................................................................................... 3-6
3.5 System Call Functions.......................................................................................3-39
3.5.1 OUT_CHAR.................................................................................................. 3-39
3.5.2 IN_CHAR...................................................................................................... 3-39
3.5.3 IN_STAT........................................................................................................ 3-40
3.5.4 ISR_REGISTER............................................................................................ 3-40
3.5.5 ISR_REMOVE .............................................................................................. 3-40
3.5.6 EXIT_TO_dBUG........................................................................................... 3-41
Appendix A
MPC535/536 Emulation
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Contents
Paragraph
Number Title Page Number
MOTOROLA MPC564EVB User’s Manual iii
Appendix B
Configuring dBUG for Network Downloads
B.1 Required Network Parameters.............................................................................B-1
B.2 Configuring dBUG Network Parameters.............................................................B-1
B.3 Troubleshooting Network Problems....................................................................B-2
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Contents
Paragraph
Number Title Page Number
iv MPC564EVB User’s Manual MOTOROLA
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

Chapter 1. MPC566EVBBoard 1-1
Chapter 1
MPC566 EVB Board
The MPC566EVB is an MPC566-based evaluation board that can be used for the development and
test of microcontroller systems1(see Figure 1-1). The MPC566 is a member of the Motorola
MPC500 RISC microcontroller family. It is a 32-bit processor with a 32-bit internal address bus
and 32 lines of data.
The evaluation board is a development and test platform for software and hardware for the
MPC5661. The system provides for development of target applications for the similar MPC561,
MPC562, or MPC563 microcontrollers also. It can be used by software and hardware developers
to test programs, tools, or circuits without having to develop a complete microcontroller system
themselves. All special features of the MPC5661are supported.
The heart of the evaluation board is the MPC566. The MPC566EVB has 1Mbyte (256K x 32)
external SRAM for development or application memory, 2Mbyte (512K x 32) external Flash
memory, and numerous hardware expansion possibilities. The MPC566EVB board also provides
an Ethernet interface (10/100BaseT), TouCAN, and RS232 interface in addition to the built-in I/O
functions of the MPC5661device for programming and evaluating the attributes of the micropro-
cessor. To support development and test, the evaluation board can be connected to debuggers and
emulators produced by different manufacturers.
The MPC566EVB provides for low cost software testing with the use of a ROM resident debug
monitor, dBUG, programmed into the external Flash device. Operation allows the user to load
code in the on-board RAM, execute applications, set breakpoints, and display or modify registers
or memory. After software is operational, the user may program the MPC566 Internal Flash
EEPROM or the on-board FLASH memory for dedicated operation of new software application.
No additional hardware or software is required for basic operation. For high level debug, exten-
sive third-party tools are available for the MPC500 series. The Nexus and BDM debug ports are
available to connect the tool sets.
Specifications
Clock: 56 MHz Maximum, 4Mhz reference
Operating temperature: 0°C to +70°C
Power requirement: 6 – 26V DC @ 300 ma Typical
Power output: 5.8V @ 1.5A output with 5V, 3.3V, and 2.6V regulated supplies
Board Size: 7.00 x 7.60 inches, 8 layers
1The MPC566EVB can be used to emulate the MPC535and MPC536. See Appendix A and MPC566 Electrical
Spec for limitations.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

1-2 MPC566EVB User’s Manual
•Memory Devices:
1M Byte (256K x 32) Sync. SRAM
2M Byte (512K x 32) Sync. FLASH
1M Byte FLASH internal to MPC566 device
36K Byte SRAM internal to MPC566 device
•POWER OAK (PC33394 P2.6) regulated power supply for 5V, 3.3V and 2.6V supplies.
•MAP Switch – provides easy assignment of chip selects and memory mapping.
•CONFIG Switch – Basic necessary Reset Word Configuration options.
•COM1 - SCIA1 with RS232 type DB9-S Connection
•COM2 - SCIA2 with RS232 type DB9-S Connection, TX / RX polarity option.
•COM3 & 4 - SCIB1 and SCIB2 with RS232 type DB9-S Connection, 10 pin IDC ribbon header
connectors.
•CAN Ports1– 3 CAN transceiver interfaced ports, 1 x 4 headers.
•10/100T Ethernet Port – LAN91C111 based MAC+PHY, memory mapped.
•DEVELOPMENT Ports – Nexus 50 pin and dual voltage BDM Port.
•LCD Port - LCD Module Interface Connector w/ Contrast Adjust, Buffered and Memory
Mapped
•KEYPAD Port1- 16 Key passive interface, applies QADC_B channels for operation.
•BUS Port – 32 data and 24 address lines on 60 pin header.
•CONTROL Port - Bus Controls with 40 pin header.
•QSM Ports – 2 Serial I/O ports with 16 pin socket headers.
•MIOS Port - MDA, PWM, and MGPIO ports with 34 pin socket header.
•TPU Ports1- 3 Timing Processor I/O ports with 20 pin socket headers.
•QADC Ports1- 2 Analog I/O ports, one 20 pin and one 24 pin socket header.
•IRQ Port – Interrupt or MPC566 port I/O with 10 pin socket header.
•POWER Port – Primary and standby power supply access port, no header.
•I/O Connectors in .1 grid, pin headers for bus and control provide easy ribbon cable connection
for external connections. Socket headers provide easy wire connection to breadboard prototype
area with 22ga solid wire.
•Large Prototyping Area with +5V and ground connection grids.
•Mictor Logic Probe connectors for the Address and Data bus (Not installed default)
•Breadboard Prototyping area (2.5 x 1.5 inch) for easy installation of test connections.
•System Indicators – Reset Indicator, Supply voltage indications for 5V, 3.3V, and 2.6V supplies
•Reset Switches – POReset, Hard, Soft reset buttons.
•User Components – 4 user LEDs (one with debounce), 4 user Switches, 1 user Potentiometer
with socket header for I/O connection.
1The MPC535/6 has limited or no functionality for this module. See Appendix A
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MPC566EVB User’s Manual 1-3
Processor
Figure 1-1. MPC566 EVB top view
1.1 Processor
The microprocessor used on the MPC566EVB is the highly integrated Motorola PowerPC
MPC566 32-bit microcontroller. The MPC566 implements a PPC ISA core with 1MByte UC3F
flash, four UART channels, three Timing Processor Units (TPUs)1, 36 KBytes of SRAM plus
4KBytes DECRAM, a QSPI (Queued Serial Peripheral Interface) module, three TouCAN
modules1, 12 PWMs and 6 counter submodules in the MIOS, enhanced QADC64E, PPM module1,
a Nexus debug interface port, and 6KByte DPTRAM1. This processor communicates with external
devicesovera32-bitwidedatabus,D[0:31].TheMPC566canaddressa 32 bit address range. Only
24 bits are available on the bus however. There are internally generated chip selects to allow the
full 32 bit address range to be selected. There are regions that can be decoded to allow superviser,
user, instruction, and data each to have the 32-bit address range. All the processor's signals are
available through the expansion connector (BUS_PORT). Refer to the schematic for their pin
assignments.
The MPC566 processor has the capability to support both an IEEE-ISTO 5001-1999 NEXUS port
and a BDM debug port. These ports are multiplexed and can be used with third party tools to allow
the user to download code to the board. The board is configured to boot up in the normal/BDM
mode of operation. The BDM signals are available at the port labeled BDM_PORT. The NEXUS
connector is near the reset switches on the board. It is the 2002 50 pin standard I/O connections and
connector. The BDM and NEXUS ports can not be used at the same time.
1The MPC535/6 has limited or no functionality for this module. See Appendix A.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

1-4 MPC566EVB User’s Manual
System Memory
Figure 1-2 shows the MPC566 block diagram.
Figure 1-2. MPC5661Block Diagram
1.2 System Memory
1.2.1 External Flash
One on-board Flash ROM (U4) is used in the system. The Am29BDD160G device contains
16Mbits of non-volatile storage (1 M x 16-bit/512 K x 32-bit) giving a total of 2MBytes of Flash
memory. This device requires a 32 bit wide port and must be written in 32 bit word size data. It
may be read inbytes, half words, or words. Wait states are required to access inasynchronous mode
and the same wait state delay is required during the first cycle of a burst type access. Refer to the
specific device data sheet for configuring the flash memory. User should note that the debug
monitor firmware is installed in this flash device. Development tools or user application programs
1See Appendix A for block diagram of MPC535/6
E-BUS
MPC5xx
Core
L-BUS
U-BUS
IMB3
Flash
512 Kbytes
+
FP
USIU
Flash
512 Kbytes
L2U
I/F
UIMB
QSMCM
MIOS14
DPTRAM
6 Kbytes
Nexus
JTAG
TPU3
QADC64E
QSMCM
TPU3 DPTRAM
4 Kbytes
TPU3 Tou
J1850
32K CALRAM_A
4-Kbyte Overlay
4-Kbyte CALRAM_B
4-Kbyte Overlay
CAN Tou
CAN Tou
CAN
w/AMUX
QADC64E
w/AMUX
Buffer
Burst
Controller 2
DECRAM
(4Kbytes)
28 Kbytes SRAM
No Overlay
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MPC566EVB User’s Manual 1-5
System Memory
may erase or corrupt the debug monitor. If the debug monitor becomes corrupted and it’soperation
is desired, the firmware must be programmed into the flash by applying a development port tool
such as BDM or Nexus. User should use caution to avoid this situation. The upper 1 MByte is used
to store the MPC566EVB dBUG debugger/monitor firmware (0x0090_0000 to 0x009F_FFFF).
1.2.2 SRAM
The MPC566EVB has two 512 KByte device on the board (U2). It’s starting address is
0xFFF0_0000.
The synchronous SRAM Memory Bank is composed of two128K x 32 memory devices. These
memory devices are connected in linear order from U2 to U3 if more than one is available, so that
the low order address of the memory bank will access U2 and the high order addresses of the
memory bank will access U3. This memory bank must be configured as a 32 bit wide port but is
byte, half word, and word accessible for read or write operations.
Also see Section 1.2.5, “MPC566EVB Memory Map”.
1.2.3 Internal SRAM
The MPC566 processor has 36-KBtyes of internal memory which may be used as data or
instruction memory. This memory is mapped to 0x003F_8000 and configured as data space but is
not used by the dBUG monitor except during system initialization. After system initialization is
complete, the internal memory is available to the user. The memory is relocatable to any 32-KByte
boundary.
1.2.4 Internal Flash
The MPC566 has a U-bus CDR3 flash EEPROM module (UC3F). The primary function of the
UC3F flash EEPROM module is to serve as electrically programmable and erasable non-volitle
memory (NVM) to store program instructions and/or data. The MPC566 flash EEPROM array has
1 Mbytes of NVM that is divided into sixteen 64-Kbyte array blocks. If the flash array is disabled
in the IMMR register (FLEN=0), then neither the UC3F array or the UC3F control registers are
accessible. This feature allows the MPC566 to emulate the MPC561/562.
Please refer to the MPC566 User’s Manual for more details.
1.2.5 MPC566EVB Memory Map
Interface signals to support interface to external memory and peripheral devices are generated by
the memory controller. It supports four regions on four chip-select pins. The general purpose
chip-selects are available on lines CS[0] through CS[3]. CS[0] also functions as the global (boot)
chip-select for booting out of external flash.
Since the MPC566 chip selects are fully programmable, the memory banks can be located at any
location in the MPC5xx memory space.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

1-6 MPC566EVB User’s Manual
System Memory
Following is the default memory map for this board as configured by the Debug Monitor located
in the external flash bank. The internal memory space of the MPC566 is detailed further in the
MPC565-6 Users Manual. Chip Selects 0-3 can be changed by user software to map the external
memory in different locations but the chip select configuration such as wait states and transfer
acknowledge for each memory type should be maintained.
Possible Chip Select usage:
Synchronous SRAM Memory Bank CS0 or CS1 default CS1, MAP SW. 1,2
Synchronous FLASH Memory Bank CS0 or CS2 default CS0, MAP SW. 3,4
10/100T / LCD Port CS3 default CS3, MAP SW. 6,7
MPC566 Internal Flash N/A MAP_SW. 8, may effect mem-
ory map of chip selects
The MPC566EVB Default Memory Map shows the MPC566EVB memory map.
1.2.5.1 Memory Device / Bank Selection and Configuration.
The MPC566EVB board has one internal memory bank, two external memory banks and a
Peripheral memory bank that provide:
•36KByte Internal SRAM
•MPC566 512K byte Internal FLASH Memory (U1)
•256K x 32bit (1MByte) Synchronous Static RAM (U2/3).
Table 1-1. The MPC566EVB Default Memory Map
Address Range Signal and Device
0x0000_0000 - 0x0007_FFFF 1MB UC3F Flash
0x0010_0000 - 0x002F_7FFF Reserved for Flash
0x002F_8000 - 0x002F_8FFF BBC DECRAM 4 KBytes
0x002F_9000 - 0x002F_9FFF Reserved for BBC
0x002F_A000 - 0x002F_BFFF BBC Control
0x002F_C000 - 0x002F_FFFF USIU & Flash Control
0x0030_0000 - 0x0030_7FFF UIMB I/F & IMB Modules 32KBytes
0x0030_8000 - 0x0037_FFFF Reserved for IMB
0x0038_0000 - 0x0038_007F CALRAM/READI Control
0x0038_0080 - 0x0038_3FFF Reserved (L-bus Control)
0x0038_4000 - 0x003F_6FFF Reserved (L-bus Memory)
0x003F_7000 - 0x003F_FFFF CALRAM (internal SRAM)
0x0080_0000 - 0x00A0_0000 External Flash 2MByte (0x0090_0000 -
0x00A0_0000 reserved for dBUG)
0x0100_0000 - 0x0108_0000 Ethernet
0xFFF0_0000 - 0xFFFF_FFFF External SRAM 1MB
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MPC566EVB User’s Manual 1-7
System Memory
•512K x 32bit (2MByte) Synchronous Flash EEPROM (U4)
•Peripherals 10/100T Ethernet and LCD Port
Each external RAM or Flash memory bank can be configured individually to operate from the
MPC566 chip selects. Caution should be used not to place more than one memory bank on the CS0
chip select and to properly configure the chip select to control the memory devices provided in the
memory bank correctly. Failure to observe precautions may render the external memory bus
inoperable.
The MAP Switch (MAP_SW) connects MPC566 chip selects to the different external memory
banks. If memory access problems occur, the settings of these options and the associated chip
select configurations should be reviewed with some detail. Information to configure the chip
selects and memory is detailed in the following section.
1.2.5.2 Memory Bank Chip Select Configuration
Application software that executes on Reset must configure each memory bank chip select
properly for correct operation. Chip Select Memory Options shows the default memory settings
programmed by the dBUG ROM monitor and may be applied for most user applications:
Table 1-2. Chip Select Memory Options
1.2.5.3 Reset Vector Mapping
After reset, the processor attempts to execute at physical address 0x0000_0100 if the hard reset
configuration word IP bit is cleared to 0 or physical address 0xFFF0_0100 if the hard reset
configuration word IP bit is set to 1. This requires the board to have a non-volatile memory device
in this range with the correct information stored in it. The MPC566 processor chip-select zero
(CS0) responds to any accesses after reset until the OR0 is written. Since CS0 (the global chip
select) is connected to the Flash ROM (U6), the Flash ROM initially appears at address
0xFFF0_0000. The initialization routine then programs the chip-select logic, locates the Flash
Memory Bank Reg. Default Value Notes
CS1 = SRAM BR1 0xFFF0_0003 Base Address = 0xFFF0_0000, Port width = 32 bit *Default
CS1 = SRAM, asynchro-
nous access mode OR1 0xFFF0_0000 MemoryRange = 0xFFF0_0000 > 0xFFFF_FFFF, wait state = 0.
CS0 = FLASH BR0 0x0080_0003 Base address 0x0080_0000, Port width = 32 bit *Default
CS0 = FLASH, asynchro-
nous access mode OR0 0xFFE0_0030 Memory range = 0x0080_0000 > 0x009F_FFFF, wait state = 3, asynchronous operation 40Mhz clock, 95ns device.
Note U4 = 2M bytes and will mirror 2x with this setting.
Usable range = 0x0080_0000 > 0x008F_FFFF (dBUG mon-
itor is in upper half starting at 0x0090_0000)
CS3 = Peripheral BR3 0x0100_0807 Base address = 0x0100_0000, Port width = 16 bit *Default
External TA* generation provided.
CS3 = Peripheral, asyn-
chronous OR3 0xFFFF_80F0 Memory Range 0x0100_0000 > 0100_7FFF, wait state = External Terminate (TA*) *Default Note Peripheral memory
map.
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

1-8 MPC566EVB User’s Manual
Support Logic
ROM to start at 0x0080_0000 and configures the rest of the internal and external peripherals.
Please refer to the MPC565 user’s manual (Global (Boot) Chip-Select Operation) for more
information.
1.3 Support Logic
1.3.1 Reset Logic
The reset logic provides system initialization. Reset occurs during power-on or via assertion of the
signal RESET which causes the MPC566 to reset. HRESET is triggered by the reset switch (SW1)
which resets the entire processor/system.
dBUG configures the MPC566 microprocessor internal resources during initialization. The
contents of the exception table are copied to address 0xFFF0_0000 in the SDRAM. The Software
Watchdog Timer isdisabled, the Bus Monitor is enabled, and theinternal timers are placed in astop
condition. A memory map for the entire board can be seen in Table 1-1., “The MPC566EVB
Default Memory Map”.
RW0 – 30: External Reset Configuration Word (RCW) Options
RW0, RW2, RW4 – 18, RW23 – 30 provide the user access to external Reset Configuration Word
(RCW) bits not normally required for default MPC566EVB operation. The RW0 – 30 designations
reflect the data bus D0 – D30 bit effected when the RCW word is enabled externally. All RW0 –
30 option bits are defaulted to the logic low value during external RCW word operation. The user
may apply a wire jumper between the 2 pad positions of each RW0 – 30 option to provide a logic
high level on the respectivebit position during external RCW operation. Refer tothe MPC566 user
manual Reset chapter for the respective RCW bit definitions.
1.3.2 Clock Circuitry
The MPC566EVB board uses a 4MHz crystal (Y1 on the schematics) to provide the clock to the
on-chip oscillator of the MPC566. In addition to the 4MHz crystal, there is also a 25MHz oscillator
(Y3) which feeds the Ethernet chip (U20).
1.3.3 Watchdog Timer
The duration of the Watchdog is selected by the SWT[1:0] bits in the System Protection and
Control Register (SYPCR), SWT[1:0] = 0b11 gives a maximum timeout period of 228/System
frequency. The dBUG monitor initializes these bits with the value 0b11, which provides the
maximum time-out period, but dBUG does NOT enable the watchdog timer via the SYPCR
register SWE bit.
1.3.4 Exception Sources
The MPC500 family of processors can receive exceptions as a result of external signals, errors,
interrupts, or unusual conditions arising in the execution of instructions. When the processor
receives an exception, information about the state of the processor is saved and, after switching to
supervisor mode, the processor begins handling the exception based on instructions in the
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

MPC566EVB User’s Manual 1-9
Support Logic
Exception Vector Table in memory. Exceptions are handled in program order based on PowerPC
architecture requirements. When an exception occurs that was caused by an instruction, any
unexecuted instructions that appear earlier in the instructionstream are required to complete before
the exception is taken. Exceptions no associated with a specific instruction (asynchronous
exceptions) are recognized when they occur. Exception handlers should save the information in
SRR0 and SRR1 soon after the exception is taken to prevent this information from being lost due
to another exception being taken.
The processor goes to an exception routine via the exception table. This table is stored in the Flash
EEPROM. The address of the table location is set by the IP bit (switch 5 of MAP_SWITCH). The
dBUG ROM monitor writes a copy of the exception table into the RAM starting at 0xFFF0_0000.
To set an exception vector, the user places the address of the exception handler in the appropriate
vector in the vector table located at 0xFFF0_0000.
The MPC566’s interrupt controller supports up to 8 external interrups (0 - 7), eight levels for all
internal USIU interrupt sources and 32 levels for internal peripheral modules. It has an enhanced
mode of operation, which simplifies the MPC566 interrupt structure and speeds up interrupt
processing.
NOTE:
No interrupt sources should have the same level and priority as
another. Programming two interrupt sources with the same level and
priority can result in undefined operation.
The MPC566EVB hardware uses IRQ[0]/SGPIOC[0] to support the ABORT (Non Maskable
Interrupt) function using the ABORT switch (SWITCH1 when BRK_EN jumper is inserted). This
switch is used to force a non-maskable interrupt if the user's program execution should be aborted
without issuing a RESET.
Refer to MPC566 User’s Manual for more information about the interrupt controller.
1.3.5 TA Generation
The TA signal is driven by the slave device from which the current transaction was addressed. It
indicates that the slave has received the data on the write cycle or returned data on the read cycle.
If the transaction is a burst, TA should be asserted for each one of the transaction beats. The
MPC566 drives TA when the slave device is controlled by the on-chip memory controller or when
an external master initiated a transaction to an internal slave module. TA is used to indicate the
completion of the bus cycle. It also allows devices with different access times to communicate with
the processor properly (i.e. asynchronously) like the Ethernet controller. The internal TA generator
is used for all external memories. External TA is only used for Ethernet/LCD.
1.3.6 User’s Program
Switch 5 on the MAP_SW bank of switches allows users to test code from boot/PORESET without
having to overwrite the ROM Monitor. The user’s code will boot from internal flash
(0x0000_0000) needs to contain the start of the Exception Vector Table).
When the switch is ON (IP is set), the behavior of the system is normal, dBUG boots and then runs
from 0x0090_0000.
Procedure:
Freescale Semiconductor, I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
nc...

1-10 MPC566EVB User’s Manual
Support Logic
1. Compile and link as though the code was to be placed at the base of the internal flash, but
setup so that it will download to the SRAM starting at address 0xFFF0_8000. The user
should refer to their compiler documentation for this,since it will depend upon the compiler
used.
2. Set IP bit (Switch 5 ON).
3. Download to SRAM (If using serial or ethernet, start the ROM Monitor first.If using BDM
via a wiggler cable, download first, then start ROM Monitor by pointing the program
counter (PC) to 0x0090_0100 and run.)
4. In the ROM Monitor, execute the 'upuser' command.
5. Turn off IP bit (Switch 5 OFF). User code should now be running from reset/POR.
1.3.7 Power Oak K/I/S Hardware Options
Several hardware options surround the Power Oak supply to allow the user access to many of the
features. The options are sorted by leading character to indicate functionality. ‘K’ designated
options refer to VKAM and MPC566 back-up supply options. ‘I’ designated options refer to
Interrupt operation options. ‘S’ designated options refer to MPC566 Reset or I/O signal connection
options. Following is the summary table (also refer to MPC566EVB schematic):
Table 1-3. K/I/S Option Table
Option
Designator Power Oak Signal MPC566 signal Associated
Option1Default Connection
K0 VKAM KAPWR K1 Closed, Note: REV B
board has 0 ohm resistor
installed
K1 2.6V KAPWR K0 Open
K2 VKAM VDDSRAM1 K3 Closed
K3 2.6V VDDSRAM1 K2 Open
K4 VKAM VDDSRAM2 K5 Closed
K5 +2.6V VDDSRAM2 K4 Open
K6 VKAM VDDSRAM3 K7 Closed
K7 2.6V VDDSRAM3 K6 Open
K8 VKAM VDDSYN K9 Open
K9 2.6V VDDSYN K8 Closed
K10 VKAM VDDRTC K11 Closed
K11 2.6V VDDRTC K10 Open
I0 WAKEUP IRQ4 Open
I1 WAKEUP IRQ0 I2 Open
I2 PRERESET IRQ0 I1 Open
