The MPC8313E reference design board (RDB) is a system
featuring the PowerQUICC™ II Pro processor, which
includes a built-in security accelerator. This low-cost,
high-performance system solution consists of a printed
circuit board (PCB) assembly plus a software board support
package (BSP) distributed in a CD image. This BSP enables
the fastest possible time-to-market for development or
integration of applications including printer engines,
broadband gateways, no-new-wires home adapters/access
points, and home automation boxes.
This document describes the hardware features of the board
including specifications, block diagram, connectors,
interfaces, and hardware straps. It also describes the board
settings and physical connections needed to boot the
MPC8313E RDB. Finally, it considers the software shipped
with the platform.
When you finish reading this document, you should:
• Be familiar with the board layout
• Understand the default board configuration and your
board configuration options
• Know how to get started and boot the board
• Know about the software and further documentation
that supports the board
Document Number: MPC8313ERDBUG
Rev. 4, 02/2009
Contents
1. MPC8313E RDB Hardware . . . . . . . . . . . . . . . . . . . . 2
2. Board-Level Functions . . . . . . . . . . . . . . . . . . . . . . . . 7
3. Connectors, Jumpers, Switches, and LEDs . . . . . . . 19
4. Micro-Jumper/Resistor Options for eTSEC1 . . . . . . 27
5. MPC8313E RDB Board Configuration . . . . . . . . . . 38
6. Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7. MPC8313E RDB Software . . . . . . . . . . . . . . . . . . . . 46
8. Frequently Asked Questions (FAQs) . . . . . . . . . . . . 47
9. Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
WARNING
This is a class A product. In a domestic
environmentthisproductmaycauseradio
interference, in which case the user may
be required to take adequate measures.
PowerQUICC™ MPC8313E Reference
Design Board (RDB)

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
2Freescale Semiconductor
MPC8313E RDB Hardware
Use this manual in conjunction with the following documents:
•MPC8313E PowerQUICC™ II Pro Integrated Communications Processor Family Reference
Manual (MPC8313ERM)
•MPC8313E PowerQUICC II Pro Processor Hardware Specifications (MPC8313EEC)
• “Hardware and Layout Design Considerations for DDR Memory Interfaces” (AN2582)
NOTE
The normal function of the product may be disturbed by strong
electromagnetic interference. If so, simply reset the product to resume
normal operation by following the instructions in the manual. If normal
function does not resume, use the product in another location.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy. If it is
not installed and used in accordance with the instruction manual, it may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which case the user will be required to correct the interference at his or her
own expense.
1 MPC8313E RDB Hardware
This section covers the features, block diagram, specifications, and mechanical data of the MPC8313E
RDB.
1.1 Features
The board features are as follows:
• CPU: Freescale MPC8313E running at 333/166 MHz; CPU/coherent system bus (CSB)
• Memory subsystem:
— 128 Mbyte unbuffered DDR2 SDRAM discrete devices
— 8 Mbyte flash single-chip memory
— 32 Mbyte NAND flash memory
— 256 Kbit M24256 serial EEPROM
— SD connector to interface with the SD memory card in SPI mode
• Interfaces:
— 10/100/1000 BaseT Ethernet ports:
– eTSEC1, RGMII: five 10/100/1000 BaseT RJ-45 interfaces using Vitesse™VSC7385 L2
switch, orselectable one 10/100/1000BaseT RJ-45 interface using Marvell™88E1111 PHY
in REVC board

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 3
MPC8313E RDB Hardware
– eTSEC2, selectable RGMII or SGMII: one 10/100/1000 BaseT RJ-45 interface using
Marvell 88E1111 PHY
— USB 2.0 port: high-speed host/device
— USB interface: selectable on-chip PHY or external ULPI PHY interface by SMSC USB3300
USB PHY
— PCI: 32-bit PCI interface running at up to 66 MHz
– One 32-bit 3.3 V PCI slot connected to PCI bus
– One 32-bit 3.3 V miniPCI slot connected to PCI bus
— Dual UART ports:
– DUART interface: supports two UARTs up to 115200 bps for console display
• Board connectors:
— LCD connectors by GPIO
— ATX power supply connector
— JTAG/COP for debugging
• IEEE Std. 1588™ signals for test and measurement
• Real-time clock and thermal sensor on I2C bus
• Programmable LEDs for debug use
• 6-layer PCB routing (4-layer signals, 2-layer power and ground)

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
4Freescale Semiconductor
MPC8313E RDB Hardware
Figure 1 shows the MPC8313E RDB block diagram.
Figure 1. MPC8313E RDB Block Diagram
MPC8313E
eTSEC1 Vitesse
L2 Switch
RGMII/
ULPI/ SMSC
USB PHY
IEEE1588
eTSEC2 Marvell
PHY
RGMII/SGMII
Clock, pulse, etc.
On-Chip
USB
Dual
UART
USB
mini-AB
USB
mini-AB
SPI SD card
33/66 MHz
3.3 V 32-Bit
PCI Slot
3.3 V 32-Bit
miniPCI Slot PCI Bus
System Clock
and USB Clock
128 Mbyte
DDR2
8 Mbyte NOR
Flash Memory
32-Bit DDR2
Bus
32 Mbyte NAND
Flash Memory
LEDs/status
Buffers
16-Bit Local
Bus
DAC for
IEEE1588
Clock (optional)
I2C Bus
Real-Time
Clock
Thermal
Sensor
GPIO
LCD
Connectors
JTAG/COP
Header JTAG/COP
Power Supply
with Low Power
Mode
Test
Points
: selected by resistor options
---NOTE---
EEPROM
Marvell
PHY
RGMII/SGMII

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 5
MPC8313E RDB Hardware
1.2 Specifications
Table 1 lists the specifications of the MPC8313E RDB.
Table 1. MPC8313E-RDB Specifications
Characteristics Specifications
Power requirements (without add-on card): Typical Maximum
12 V DC 0A 0 A
5.0 V DC1 mA1.5 A
Communication processor MPC8313E running at 266 MHz
Addressing: Total address range
Flash memory (local bus)
DDR2 SDRAM
4 Gbyte (32 address lines)
8 Mbyte with one chip-select
128 Mbyte DDR2 SDRAM
Operating temperature 0o C to 70o C (room temperature)
Storage temperature –25oC to 85oC
Relative humidity 5% to 90% (noncondensing)
PCB dimensions:
Length
Width
Thickness
6693 mil (REVA and REVB) or 7692 mil (REVC)
6693 mil
62 mil

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
6Freescale Semiconductor
MPC8313E RDB Hardware
1.3 Mechanical Data
Figure 2 shows the MPC8313E RDB REVAx and REVB dimensions (in mil and [mm]). The board
measures 170 mm ×170 mm (6693 mil × 6693 mil) for integration in a mini-ITX chassis.
Figure 2. Dimensions of the MPC8313E RDB (REVAx and REVB)

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 7
Board-Level Functions
Figure 3 shows the MPC8313E RDB Rev C dimensions (in mil and [mm]). The board measures
195 mm ×170 mm (7692 mil ×6693 mil).
Figure 3. Dimensions of the MPC8313E RDB (REVC)
2 Board-Level Functions
The board-level functions are reset, external interrupts, clock distribution, DDR SDRAM controller, local
bus controller, I2C interfaces, SD memory card interface, USB interface, eTSEC1 10/100/1000 BaseT
interface, dual RS-232 ports, PCI bus, and COP/JTAG.

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
8Freescale Semiconductor
Board-Level Functions
2.1 Reset and Reset Configurations
The MPC8313E RDB reset module generates a single reset to the MPC8313E and other peripherals on the
board. The reset unit provides power-on reset, hard reset, and soft reset signals in compliance with the
MPC8313E hardware specification.
Figure 4 shows the reset circuitry. Note the following:
• Hard reset is generated either by the COP/JTAG port or the MPC8313E.
• Power-on reset is generated by the Maxim MAX811 device. When MR is deasserted and 3.3 V is
ready, the MAX811 internal timeout guarantees a minimum reset active time of 150 ms before
PORESET is deasserted. This circuitry guarantees a 150 ms PORESET pulse width after 3.3 V
reaches the right voltage level, which meets the specification of the PORESET input of
MPC8313E.
• COP/JTAG port reset provides convenient hard-reset capability for a COP/JTAG controller. The
RESET line is available at the COP/JTAG port connector. The COP/JTAG controller can directly
generate the hard-reset signal by asserting this line low.
• Push button reset interfaces using the MR signal with debounce capability to produce a manual
master reset of the RDB.
• Soft reset is generated by the COP/JTAG port. Assertion of SRESET causes the MPC8313E to
abort all current internal and external transactions and set most registers to their default values.
Figure 4. Reset Circuitry of the MPC8313E
MAX811
3.3 V
MR
Push Button
GND
HRESET from COP
SRESET from COP
TRST from COP
SRESET to MPC8313E
TRST to MPC8313E
PORESET to MPC8313E
NOR FLASH
L2 Switch
MPC8313E
Reset config logic
Marvell PHY

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 9
Board-Level Functions
2.2 External Interrupts
Figure 5 shows the external interrupts to the MPC8313E.
Figure 5. MPC8313E Interrupts
The following are descriptions of the interrupt signals shown in Figure 5:
• All external interrupt signals are pulled up by 4.7 KΩ resistors.
•IRQ0is connected to SD Card
•IRQ1is connected to PCI slot INTA.
•IRQ2is connected to and shared by the PCI slot’s INTB and the mini PCI slot INTA.
•IRQ3is connected to the L2 switch as well as to an external USB PHY (by an optional resistor).
•IRQ4is connected to the Marvell GBE PHY as wellas toRTC and LM75 (by an optional resistors).
IRQ0
IRQ2
IRQ3
IRQ4
MPC8313E
SD Card
IRQ1
PCI slot (AD15) INTA
Mini PCI (AD14) INTA and PCI slot (AD15) INTB
L2 Switch and ULPI external USB PHY (optional)
Marvell PHY, RTC (optional) and LM75 (optional)

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
10 Freescale Semiconductor
Board-Level Functions
2.3 Clock Distribution
Figure 6 and Table 2 show the clock distribution on the MPC8313E RDB.
Figure 6. MPC8313E-RDB Clock Scheme
MPC8313E
LCLKx (NC)
local bus
PLL
DDR
PLL
PCI
DIV
66.666 MHz
OSC
CLKIN
33/66 MHz
33/66 MHz
Mini PCI Slot
PCI Slot
OCCR
2
PCI_SYNC_OUT
PCI_SYNC_IN
System
PLL
M66EN
33/66 MHz
CFG_CLKIN_DIV
NC
48 MHz
OSC
25 MHz
OSC
USB
CLKIN
L2 Switch
GBE PHY GTX_CLK125
SD_REF_CLK
50 MHz OSC/
50 MHz VCXO
IEEE1588
TMR CLK
0
1
2
ULPI USB
GND GND
24 MHz
Crystal
PHY
Real-Time
GND GND
32.768 KHz
Crystal
Clock
DDR2 SDRAM
CLK
MCK
MCK#
133 MHz
PLL
125 MHz
LVDS
OSC
125MHz

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 11
Board-Level Functions
2.4 DDR2 SDRAM Controller
The MPC8313E processor uses DDR2 SDRAM as the system memory. The DDR2 interface uses the
SSTL2 driver/receiver and 1.8 V power. A Vref 1.8 V/2 is needed for all SSTL2 receivers in the DDR2
interface. For details on DDR2 timing design and termination, refer to the Freescale application note
entitled “Hardware and Layout Design Considerations for DDR Memory Interfaces” (AN2582). Signal
integrity test results show this design does not require terminating resistors (series resistor (RS) and
termination resistor (RT)) for the discrete DDR2 devices used. DDR2 supports on-die termination; the
DDR2 chips and MPC8313E are connected directly. The interface is 1.8 V provided by an on-board
Table 2. Clock Distribution
Clock Frequency Module Generated by Description
66.666 MHz MPC8313E CLKIN 66.666 MHz oscillator The MPC8313E uses CLKIN to generate the
PCI_SYNC_OUT clock signal, which is fed back
on the board through the PCI_SYNC_IN signal
to the internal system PLL. From the power-on
reset configuration, the CSB clock is generated
by the internal PLL and is fed to the e300 core
PLL for generating the e300 core clock. The
CFG_CLKIN_DIV configuration input selects
whether CLKIN or CLKIN/2 is driven on the
PCI_SYNC_OUT signal. The CFG_CLKIN_DIV
is tied to the M66EN input pin.
133 MHz DDR2 SDRAM MPC8313E The DDR memory controller is configured to use
the 2:1 mode CSB to DDR for the DDR interface
(DDR266). The local bus clock uses 1:1 local to
CSB clock, which is configured by hard reset
configuration or SPMR register.
33/66 MHz PCI 32-bit slot and MiniPCI
slot
MPC8313E The PCI module uses the PCI_SYNC_IN as its
clock source. The trace length of the
PCI_SYNC_IN to PCI_SYNC_OUT signal is
matched with all PCI clocks on the RDB.
25 MHz L2 Switch and GBE PHY 25 MHz oscillator The 25 MHz oscillator provides the clock for the
L2 switch and the GBE PHY
125 MHz eTSEC clock GBE PHY with PLL
(REVC), or
125 MHz oscillators
(REVB), or
GBE PHY (REVAx)
The GTX_CLK125 and SERDES (SGMII) clocks
are provided by external oscillators (or by GBE
PHY in REVAx and REVC boards).
48 MHz USB clock 48 MHz oscillator 48 MHz is provided for on-chip USB PHY of
MPC8313E
50 MHz IEEE1588 Clock (TMR_CLK) 50 MHz oscillator/50
MHz VCXO
50 MHz is used by the IEEE 1588 module. It can
be an ordinary oscillator or VCXO controlled by
SPI DAC.
24 MHz ULPI external USB PHY 24 MHz crystal 24 MHz crystal is used by the ULPI external
USB PHY
32.768 KHz Real-time clock 32.768 KHz crystal 32.768 KHz crystal is used by the real-time clock

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
12 Freescale Semiconductor
Board-Level Functions
voltage regulator. VREF, which is half the interface voltage, or 0.9 V, is provided by a voltage divider of
1.8 V for voltage tracking and lowcost. The MPC8313E providesa pair of clockpins, whichare connected
and shared by the two DDR2 devices.
Figure 7 shows the DDR2 SDRAM controller connection.
Figure 7. DDR2 SDRAM Connection
2.5 Local Bus Controller
The MPC8313E local bus controller has a 26-bit LAD[0–15] and LA[16–25] address that consists of
16-bit data multiplex bus and control signals. The local bus speed is up to 133 MHz. To interface with the
standard memory device, an address latch must provide the address signals. The LALE is used as the
latching signal. To reduce loading of the high speed local bus interface, a data buffer for all low-speed
devices is attached to the memory controller. The followings modules are connected to the local bus:
• 8 Mbyte NOR flash memory
• 32 Mbyte NAND flash memory
• LED/status buffers
2.5.1 NOR Flash Memory
Through the general-purpose chip-select machine (GPCM), the MPC8313E RDB provides 8 Mbyte of
flash memory using a chip-select signal. The flash memory is used with the 16-bit port size. Figure 8
DDR2 Device (512 Mbit, 16-Bit)
MPC8313E
DDR2
Controller
DDR2 Device (512 Mbit, 16-Bit)
MCS0
MCK, MCK, MCKE
MRAS, MCAS, MWE
MDM[0:3], MDQS[0:3]
A[0:14], BA[0:2]
MDQ[0:31]
ODT
VREF
1.8 V Reg
VREF

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 13
Board-Level Functions
shows the hardware connections for the flash memory. The starting address for the 8 Mbyte flash memory
is 0xFE00_0000 to 0xFE7F_FFFF.
Figure 8. NOR Flash Connection
2.5.2 NAND Flash Memory
The MPC8313E has native support for NAND Flash memory through its NAND Flash control machine
(FCM). The MPC8313E RDB implements an 8-bit NAND Flash with 32 Mbyte in size. Figure 9 shows
the NAND Flash connection.
Figure 9. NAND Flash Connection
MPC8313E
eLBC
Controller
NOR
Flash 16-Bit
NOR_CS
*NOTE: NOR_CS can be either CS0 or CS1
by DIP switch option, default is CS0
Latch
Buffer
LA[24:16] A[0:8]
A[9:21]
LBA[15:3]
LAD[15:0]
DQ[0:15]
LBD[15:0]
WE
OE
WE0
GPL2
MPC8313E
eLBC
Controller
NAND
Flash 8-Bit
NAND_CS
*NOTE: NAND_CS can be either CS0 or CS1
by DIP switch option; the default is CS1
CLE
ALE
WE
RE
R/B
WP
GPL0
GPL1
WE0
GPL2
GPL4
GPL3
LAD[0:7] IO[7:0]
*Buffer LBD0-7

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
14 Freescale Semiconductor
Board-Level Functions
2.5.3 LED/Status Buffers
The MPC8313E RDBhas an 8-bit read/write buffer. The read buffer returns information on M66EN, board
revision, boot device (NOR or NAND), and SD card status. The write buffer controls eight LEDs on the
board for status or debug indication. Figure 10 shows the hardware connection of the buffers.
Figure 10. LED/Status Buffers
2.6 I2C Interfaces
The MPC8313E has two I2C interfaces. On the MPC8313E RDB, I2C1 is used as master mode. It is
connected to the following three devices as shown in Figure 11.
• Serial EEPROM M24256 at address 0x50.
• Real-time clock DS1339U at address 0x68.
• Thermal sensor LM75 at address 0x48.
It may also be connected to the DAC AD5301 at address 0x0C, whose optional nature is represented in
Figure 11 by the dashed line.
The connection of the I2C bus is shown in Figure 11. The M24256 serial EEPROM can be used to store
the reset configuration word of the MPC8313E, as well as to store the configuration registers’ values and
user program if the MPC8313E boot sequencer is enabled. By default, the EEPROM is not used and the
hard reset configuration words are loaded from local bus flash memory. For details about how to program
MPC8313E
eLBC
Controller
WE0
GPL2
LAD[0:7] Buffer
LCS3
LCX373
LCX245
8x LEDs
Write Buffer
Read Buffer SD_INSERT
SD_PROTECT
RSVD0
BOOT0
RSVD1
M66EN
REV0
REV1
LBD[0:7]
OE

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 15
Board-Level Functions
the reset configuration word value in I2C EEPROM and the boot sequencer mode, refer to the MPC8313E
reference manual.
Figure 11. I2C Connection
2.7 SD Memory Card Interface
An SD memory card interface connects directlyto the SPI bus oftheMPC8313E. SD data mode and SDIO
mode are not supported. The SPI mode is the only SD operating mode supported by this connection. Hot
insertion and removal is not supported. See Figure 12 for the hardware connection.
For REVB boards, the SD card chip select signal is changed from GPIO31(SPISEL) to GPIO13(LA8)
because when using SPI as master mode, SPISEL cannot be set as GPIO (which is supposed to be used for
device select signal). In this case, another GPIO pin should be used. GPIO13 is implemented on this board
as an example.
I2C1-SCL
I2C EEROM
M24256
MPC8313E
SCL
SDA
I2C1-SDA
I
2
C Address = 0x50
I2C RTC
DS1339U
SCL
SDA
I
2
C Address = 0x68
I2C Sensor
LM75
SCL
SDA
I
2
C Address = 0x48
3.3 V
I2C DAC (Optional)
AD5301
SCL
SDA
I
2
C Address = 0x0C

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
16 Freescale Semiconductor
Board-Level Functions
CAUTION
Power down before inserting or removing the SD memory card.
Figure 12. SD Memory Card Connection
2.8 USB Interface
MPC8313E supportsa USB 2.0 high speedhost/device interface through its on-chip USB PHY orexternal
ULPI USB PHY. The MPC8313E RDB supports both options. By default, the on-chip USB PHY is used.
Figure 13 shows the USB connections.
Figure 13. USB Connections
MPC8313E
CS
DIN
DOUT
SCLK
INSERT
CONTACT
PROTECT
SD_CS
SPIMOSI
SPIMISO
SPICLK
SD_INSERT
SD_CONTACT
SD_PROTECT
LA8 (GPIO13)
SPIMOSI
SPIMISO
SPICLK
SD Memory Card Socket
Status Read
Buffer
Local Bus
MPC8313E
USB-DP
USB-DM
USB mini-AB
On-Chip
USB PHY
ULPI external
USB PHY Interface
USB3300
USB PHY
USB VBUS
Power Supply
USB mini-AB
USB-VBUS
Control
Control
**ULPI
IRQ3
**NOTE: Because ULPI is multiplexed with eTSEC1 RGMII, by default
on-chip PHY is used. A change of resistor option is needed to use
the external USB PHY interface.
OR

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 17
Board-Level Functions
2.9 eTSEC1 10/100/1000 BaseT Interface
eTESC1 is set to operate in RGMII mode. It connects to a VSC7385 5-port L2 switch, as shown in
Figure 14.
Figure 14. RGMII Interface Connection for L2 Switch
2.10 eTSEC2 10/100/1000 BaseT Interface
eTESC2 can be set to operate in RGMII mode (default) or SGMII mode. Figure 15 shows the hardware
connection for eTSEC.
Figure 15. eTSEC2 Connection
VSC7385
MPC8313E
RGMII
eTSEC1
Local Bus
LCS2#, GPCM 8bit data
RJ-45 ports
L2 switch
MPC8313E
RGMII
eTSEC2
88E1111
GBE PHY
SGMII
RJ-45 Port
NOTE: By default, RGMII is used and SGMII is optional
MDC, MDIO
MDIO PHY
Address = 4

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
18 Freescale Semiconductor
Board-Level Functions
2.11 Dual RS-232 Ports
Dual RS-232 ports are supported on the RDB. Figure 16 illustrates the serial port connection using a
MAX3232 3.3 V RS-232 driver to interface with a 9-pin D type female connector. This serial connection
runs at up to 115.2 Kbps.
Figure 16. RS-232 Debug Ports Connection
2.12 PCI Bus
The 32-bit PCI interface connects to a 32-bit 3.3 V PCI slot and a miniPCI slot (see Figure 17).
Figure 17. PCI Bus Connection
MPC8313E
UART1
RXD
RTS
TXD
CTS
UART2
RXD
RTS
TXD
CTS
MAX3232
TXD
RXD
CTS
RX
TX
TX
DO
DI
DI
RTS
Female DB-9
RS-232
Serial
Port
RX
DO 3
7
8
2
MAX3232
TXD
RXD
CTS
RX
TX
TX
DO
DI
DI RTS
Female DB-9
RS-232
Serial
Port
RX
DO 3
7
8
2
MPC8313E
32Bit PCI
PCI-AD[0:31]
PCI-CBE[0:3]
PCI-REQ0
PCI-GNT0
PCI-CTRL
32Bit 3.3 V
PCI Slot
32-Bit 3.3 V
MiniPCI Slot
PCI-REQ1
PCI-GNT1
[AD14]
[AD15]

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
Freescale Semiconductor 19
Connectors, Jumpers, Switches, and LEDs
2.13 COP/JTAG Port
The common on-chip processor (COP) is part of the MPC8313E JTAG module and is implemented as a
set ofadditional instructions and logic. This port can connect to a dedicated emulator for extensive system
debugging. Several third-party emulators in the market can connect to the host computer through the
Ethernet port, USB port, parallel port, RS-232, and so on. A typical setup using a USB port emulator is
shown in Figure 18.
Figure 18. Connecting MPC8313E-RDB to a USB Emulator
The 16-pin generic header connector carries the COP/JTAG signals and the additional signals for system
debugging. The pinout of this connector is shown in Figure 19.
Figure 19. MPC8313E RDB COP Connector
3 Connectors, Jumpers, Switches, and LEDs
Table 3 summarizes the connectors, jumpers, switches, and LEDs on the MPC8313E RDB and provides
the number of the section/page on which each is discussed. The rest of this section discusses each of these
in the order of its appearance in the table.
Table 3. Connectors, Jumpers, Switches, and LEDs
Reference Description Section/Page
Connectors
P1 14-pin COP/JTAG connector 3.1/Page 21
PC MPC8313E RDB
P1
USB
Emulator
USB Port
COP Port
TDI
Pull-up
TCK
TMS
SRESET
HRESET
CKSTP_OUT
GND
TRST
Pull-up
CKSTP_IN
NC
NC
NC
GND
1
TDO

PowerQUICC™ MPC8313E Reference Design Board (RDB), Rev. 4
20 Freescale Semiconductor
Connectors, Jumpers, Switches, and LEDs
P2 3.3 V PCI Slot [IDSEL - AD15] 3.2/Page 21
P3 MiniPCI Slot [IDSEL - AD14] 3.3/Page 22
P4 USB mini-AB Connector (on-chip PHY) 3.4/Page 22
P5 RJ-45 LAN connectors Enet4 (top), Enet5 (bottom). See Figure 23 3.5/Page 23
P6 RJ-45 LAN connectors Enet2 (top), Enet3 (bottom). See Figure 23
P7 RJ-45 LAN connectors Enet0 (top), Enet1 (bottom). See Figure 23
P8 USB mini-AB Connector (external ULPI USB PHY) 3.4/Page 22
P9 ATX type power supply connector. The board can be powered by an ATX power supply or
the power supply bundled with the mini-ITX case.
—
P10 IEEE 1588 connector (Optional) 3.9/Page 25
P11 Dual UART connector. UART1 (top), UART2 (bottom) 3.6/Page 24
U44 SD memory card socket 3.7/Page 24
BT1 RTC battery holder, CR2032 type. The real-time clock on the RDB requires a battery when
the board is powered off. When placing or replacing the battery, take care to ensure that the
polarity is correct.
—
J20 Connector for chassis connection (power on, power LED, reset) —
J21 LCD connector 3.8/Page 24
J22 LCD connector
J23 LCD backlight connector. A 2-pin header (J23) is provided for LCD backlight power. Pin1 is
5 V and pin 2 is GND.
—
J24 MCU programming connector. J24 is used for MCU programming on the RDB. It is reserved. —
Jumpers
J19 Open (Default)—Power ON controlled by switch; Close—Power is always ON —
Switches
S1 System reset button. Resets the MPC8313E RDB. (PORESET). Press once on the push
button reset switch on the RDB to cause a power-on reset (PORESET) to the board.
—
S2 Power ON button. Press once to power ON/OFF. —
S3 DIP switch. Selects the reset configuration source (RST_CFG_SRC) for the MPC8313E. 3.10/Page 26
S4 DIP switch. Board revision indicator and boot device selector. 3.11/Page 26
LEDs
D6 Enet5 Link 10 —
D7 Enet5 Link 100 —
D8 Enet5 Duplex —
D9 Enet5 RX —
D12 USB VBUS —
D10 On-chip USB PHY CTL0 —
Table 3. Connectors, Jumpers, Switches, and LEDs (continued)
Reference Description Section/Page
