Friedrich Uni-Fit UE08A13B User manual

• High eciency operation
saves on energy costs
• Residential/commercial
applications
• Mounts ush with the exterior
wall for a neat appearance
• A high eciency replace-
ment for 27" sleeves includ-
ing Fedders A and B*. Sleeve
measures 27" W x 16 3/4" H
• Ideal for thicker wall installa-
tions, where side ns don’t t
• Easy-to-reach, top mount
controls
• Three-speed fan
• Ecient rotary compressor
• Easy-to-clean lter
COOLING ONLY, HEAT PUMP & ELECTRIC HEAT
• 24 hour programmable timer
• Money Saver® setting saves energy by
cycling the fan with the compressor
• Smart Fan auto-adjusts fan speed to
maintain desired temperature
• Auto-memory backup
REMOTE CONTROL FEATURES
The Most Energy Efficient Solid-side Air Conditioner
Installs in existing 27” sleeves
Units are shown installed in WSC sleeve (sold and shipped separately)
Sleeve Dimensions
Friedrich
WSC Sleeve
Fedders
A Sleeve
Fedders
B Sleeve*
Height (inches) 16 3/4 16 3/4 16 3/4
Width (inches) 27 27 27
Depth (inches) 16 3/4 16 3/4 19 3/4
REMOTE
CONTROL
24-HOUR
TIMER
MONEY SAVER
FEATURE
SMART
FAN
*Installation in Fedders B sleeve requires a bae kit. See BAK accessory under accessories.
ANTIMICROBIAL
FILTER
FIVE EnergyStar models
Perfect for new construction,
retrots and remodeling
THRU-THE-WALL AIR CONDITIONERS
cool only | heat pumps | electric heat

• High eciency operation
saves on energy costs
• Residential/commercial
applications
• Mounts ush with the exterior
wall for a neat appearance
• A high eciency replace-
ment for 27" sleeves includ-
ing Fedders A and B*. Sleeve
measures 27" W x 16 3/4" H
• Ideal for thicker wall installa-
tions, where side ns don’t t
• Easy-to-reach, top mount
controls
• Three-speed fan
• Ecient rotary compressor
• Easy-to-clean lter
COOLING ONLY, HEAT PUMP & ELECTRIC HEAT
• 24 hour programmable timer
• Money Saver® setting saves energy by
cycling the fan with the compressor
• Smart Fan auto-adjusts fan speed to
maintain desired temperature
• Auto-memory backup
REMOTE CONTROL FEATURES
The Most Energy Efficient Solid-side Air Conditioner
Installs in existing 27” sleeves
Units are shown installed in WSC sleeve (sold and shipped separately)
Sleeve Dimensions
Friedrich
WSC Sleeve
Fedders
A Sleeve
Fedders
B Sleeve*
Height (inches) 16 3/4 16 3/4 16 3/4
Width (inches) 27 27 27
Depth (inches) 16 3/4 16 3/4 19 3/4
REMOTE
CONTROL
24-HOUR
TIMER
MONEY SAVER
FEATURE
SMART
FAN
*Installation in Fedders B sleeve requires a bae kit. See BAK accessory under accessories.
ANTIMICROBIAL
FILTER
FIVE EnergyStar models
Perfect for new construction,
retrots and remodeling

• High eciency operation
saves on energy costs
• Residential/commercial
applications
• Mounts ush with the exterior
wall for a neat appearance
• A high eciency replace-
ment for 27" sleeves includ-
ing Fedders A and B*. Sleeve
measures 27" W x 16 3/4" H
• Ideal for thicker wall installa-
tions, where side ns don’t t
• Easy-to-reach, top mount
controls
• Three-speed fan
• Ecient rotary compressor
• Easy-to-clean lter
COOLING ONLY, HEAT PUMP & ELECTRIC HEAT
• 24 hour programmable timer
• Money Saver® setting saves energy by
cycling the fan with the compressor
• Smart Fan auto-adjusts fan speed to
maintain desired temperature
• Auto-memory backup
REMOTE CONTROL FEATURES
The Most Energy Efficient Solid-side Air Conditioner
Installs in existing 27” sleeves
Units are shown installed in WSC sleeve (sold and shipped separately)
Sleeve Dimensions
Friedrich
WSC Sleeve
Fedders
A Sleeve
Fedders
B Sleeve*
Height (inches) 16 3/4 16 3/4 16 3/4
Width (inches) 27 27 27
Depth (inches) 16 3/4 16 3/4 19 3/4
REMOTE
CONTROL
24-HOUR
TIMER
MONEY SAVER
FEATURE
SMART
FAN
*Installation in Fedders B sleeve requires a bae kit. See BAK accessory under accessories.
ANTIMICROBIAL
FILTER
FIVE EnergyStar models
Perfect for new construction,
retrots and remodeling
COOLING ONLY & ELECTRIC HEAT
Universal Fit for Easy Replacement
Chassis installs into existing 26" sleeves
Sleeve Dimensions
Friedrich
USC Sleeve GE Amana Whirlpool/ Fedders Frigidaire
Height (inches) 15 17/32 15 5/8 15 5/8 15 3/4 15 7/16
Width (inches) 25 7/8 26 26 26 3/4 25 7/8
Depth (inches) 16 23/32 16 7/8 16 7/8 15 18
Units are shown without USC sleeve (USC sleeves sold and shipped separately)
REMOTE
CONTROL
12-HOUR
TIMER
MONEY SAVER
FEATURE
• Rotary compressors provide
quiet, dependable performance
• Six-way air ow control
• Stale air exhaust
• Auto re-start
• Washable/reusable lter
• Seacoast protection
HEAT/COOL MODELS feature mechanical controls,
two cooling speeds, two heating speeds, plus one
fan-only setting.
COOLING MODELS feature electronic controls
with remote control, Money Saver® setting that
saves energy by cycling the fan with the compres-
sor and three cooling/three fan-only speeds.
TWO EnergyStar models
• 12 hour programmable timer
• Money Saver® setting saves energy by
cycling the fan with the compressor
REMOTE CONTROL FEATURES (cool only models)
THRU-THE-WALL units mount ush with
exterior walls for a sleek appearance, as well as
unobstructed window views.
(Wallmaster WSC sleeve shown with architectural
grille. Uni-t grille has dierent appearance.)

USC Sleeve/Standard Grille USC Sleeve/Replacement Grille*
STANDARD GRILLE – Expanded aluminum
For use with USC sleeve. (Ships with USC sleeve).
*REPLACEMENT GRILLE – High-tech plastic
For use on existing sleeves without any grille. (Ships with
chassis).
IMPORTANT NOTE:
When installing into an existing sleeve, consult Installation
Section of your Installation/Operation Manual to determine
whether or not the grille needs to be replaced and/or a
bae adapter should be used.
Installation Accessories (WallMaster only)
DK / Drain Kit
Installed at the back of the unit and allows
for attachment to permanent condensate
disposal system, if disposal is necessary
or desired.
SB / Sub Base
Used as a base for the unit when
it is desired to place the cord and
receptacle within the installation, or
simply as a base for the unit when
mounted low in the wall.
BAK / Bae Adapter Kit
Necessary when installing in a sleeve
deeper than 16 3/4" deep, such as
Fedders B sleeve (19 3/4" deep).
IDK / Internal Drain Kit
New construction applications where
a condensate drain system has been
built into the wall interior.
16 3/4"
Fedders B
19 3/4”
IMPORTANT:
Operating the air conditioner
with incorrect rear grille or
without Bae Adapter Kit
(on 19 3/4” deep sleeve) will
recirculate discharge air and
cause compressor overload
to trip.
CORRECT Vertical Louvers
INCORRECT Horizontal Louvers
WSC Sleeve/Standard Grille WSC Sleeve/Optional Architectural Grille, AG
Model Height Width Depth
Depth
with
Front
Minimum
Extension
Into Room
Minimum
Extension
Outside
Thru-the-wall
Finished Hole
Height Width
WALLMASTER
WSC Sleeve
Chassis
16 3/4" 27" 16 3/4" 23" 7 1/2" 9/16" 17 1/4" 27 1/4"
15 3/4" 26 1/2" 21" – – – – –
UNI-FIT
USC Sleeve 15 1/2" 25 7/8" 16 3/4" 20 1/2" – 1/2" 15 3/4" 26 1/8"
US Chassis 14 3/8" 24" 20 1/8" 3 3/4" – – –
UE Chassis 14 3/8" 24 5/8" 19 5/8" 3 1/2" – – –
IMPORTANT:
• Sleeves are sold and shipped separately to accommodate
new construction and replacement requirements
Sleeve/Chassis Dimensions
Exterior Grilles
Exterior Grilles
When should you
install a solid side
sleeve?
SOLID SIDE wall sleeve
allows for installation in thick
exterior walls where the
installation of room air units
with side vents would eect
performance and may even
void the warranty.
Commercial
and residential
applications
ROOM AIR CONDITIONER
Blocked side vents restrict air ow
FRIEDRICH THRU-THE-WALL
Solid-side sleeve (no side vents)

USC Sleeve/Standard Grille USC Sleeve/Replacement Grille*
STANDARD GRILLE – Expanded aluminum
For use with USC sleeve. (Ships with USC sleeve).
*REPLACEMENT GRILLE – High-tech plastic
For use on existing sleeves without any grille. (Ships with
chassis).
IMPORTANT NOTE:
When installing into an existing sleeve, consult Installation
Section of your Installation/Operation Manual to determine
whether or not the grille needs to be replaced and/or a
bae adapter should be used.
Installation Accessories (WallMaster only)
DK / Drain Kit
Installed at the back of the unit and allows
for attachment to permanent condensate
disposal system, if disposal is necessary
or desired.
SB / Sub Base
Used as a base for the unit when
it is desired to place the cord and
receptacle within the installation, or
simply as a base for the unit when
mounted low in the wall.
BAK / Bae Adapter Kit
Necessary when installing in a sleeve
deeper than 16 3/4" deep, such as
Fedders B sleeve (19 3/4" deep).
IDK / Internal Drain Kit
New construction applications where
a condensate drain system has been
built into the wall interior.
16 3/4"
Fedders B
19 3/4”
IMPORTANT:
Operating the air conditioner
with incorrect rear grille or
without Bae Adapter Kit
(on 19 3/4” deep sleeve) will
recirculate discharge air and
cause compressor overload
to trip.
CORRECT Vertical Louvers
INCORRECT Horizontal Louvers
WSC Sleeve/Standard Grille WSC Sleeve/Optional Architectural Grille, AG
Model Height Width Depth
Depth
with
Front
Minimum
Extension
Into Room
Minimum
Extension
Outside
Thru-the-wall
Finished Hole
Height Width
WALLMASTER
WSC Sleeve
Chassis
16 3/4" 27" 16 3/4" 23" 7 1/2" 9/16" 17 1/4" 27 1/4"
15 3/4" 26 1/2" 21" – – – – –
UNI-FIT
USC Sleeve 15 1/2" 25 7/8" 16 3/4" 20 1/2" – 1/2" 15 3/4" 26 1/8"
US Chassis 14 3/8" 24" 20 1/8" 3 3/4" – – –
UE Chassis 14 3/8" 24 5/8" 19 5/8" 3 1/2" – – –
IMPORTANT:
• Sleeves are sold and shipped separately to accommodate
new construction and replacement requirements
Sleeve/Chassis Dimensions
Exterior Grilles
Exterior Grilles

Friedrich Air Conditioning Co. | P.O. Box 1540 | San Antonio, TX 78295-1540 | [phone] | fax [phone] | www.friedrich.com
TTW-08 Printed in USA
As an EnErgy Star®partner, Friedrich Air Conditioning Co.
has determined that the selected EnErgy Star®models ()
meet the EnErgy Star® guidelines for energy efciency.
Plug Face/ Circuit Rating
Specications  EnErgy Star®models
WALLMASTER HEAT PUMP
HEATING PERFORMANCE
Change-over from heat pump operation to resistance operation on models
indicated is automatic at a preset outside ambient temperature of approxi-
mately 35°F.
Calculate the heat loss of the space to be heated. As long as the heat loss does
not exceed the resistance heating capacity rating of the unit, the heating per-
formance will be satisfactory.
Note: all models will produce condensate. If condensate disposal is desired, an
optional drain kit is available.
DEFROST CONTROL: Initiated at 20°F (outdoor coil temperature) and termi-
nated at 43°F (outdoor coil temperature). During defrost, the compressor stops
and the electric heat starts, then operates with the fan to maintain indoor
comfort. Below 43°F, the unit remains in electric heat mode. During electric heat
mode, the unit will achieve the following ratings: 11000/9100 BTU/h, 16.0/14.7
amps, and 3550/2950 watts.
DEFROST DRAIN: Drain automatically opens at approximately 50°F to prevent
condensate from freezing inside drain pan.
Model
Cooling
Capacity
BTU/h
Heating
Capacity
BTU/h
Volts
Rated
Cooling
Amps
Cooling
Watts
Heating
Amps
Heating
Watts
Energy
Efficiency
Ratio
EER
Moisture
Removal
Pints/Hr.
Room
Side Air
Circulation
Net
Weight
Lbs.
WALLMASTER
WS08B10A 8000 — 115 6.8 762 — — 10.5 1.3 245 93
WS10B10A 10000 — 115 8.7 954 — — 10.5 2.4 245 103
WS14B10A 13500 — 115 12.0 1415 — — 9.5 3.3 295 112
WS10B30A 10000/10000 — 230/208 4.6/5.0 1005/996 — — 10.0/10.0 2.1 260 101
WS13B30B 12500/12000 — 230/208 6.3/6.7 1404/1379 — — 8.9/8.7 3.3 280 109
WS16B30A 15800/15000 — 230/208 7.8/8.5 1756/1705 — — 9.0/8.8 4.2 290 119
WE10B33C 10000/10000 11000/9100 230/208 4.6/5.0 1005/996 16.0/14.7 3550/2950 10.0/10.0 2.1 260 103
WE13B33C 12500/12000 11000/9100 230/208 6.3/6.7 1404/1379 16.0/14.7 3550/2950 8.9/8.7 3.3 280 111
WE16B33C 15800/15000 11000/9100 230/208 7.8/8.5 1756/1705 16.0/14.7 3550/2950 9.0/8.8 4.2 290 121
WY10B33C 10100/9800 8100/7800 230/208 4.6/4.8 1013/976 3.9/4.0 857/821 10.0/10.0 2.5 230 107
WY13B33C 12500/12100 10400/10000 230/208 6.4/6.8 1389/1352 5.4/5.7 1182/1136 9.0/9.0 3.2 280 116
UNI-FIT
US08B10A 8000 — 115 7.5 830 — — 9.6 2.2 260 73
US10B10A 9800 — 115 10.2 1110 — — 8.8 3.2 285 78
US10B30A 10000/9800 — 230/208 4.7/5.2 1060/1040 — — 9.4 3.2 285 78
US12B10A 11500 — 115 12.0 1310 — — 8.8 3.8 290 80
US12B30B 11500/11200 — 230/208 6.0/6.4 1310/1270 — — 8.8 3.8 290 80
US14B30A 13000/12600 — 230/208 7.0/7.5 1530/1480 — — 8.5 4.0 300 84
UE08A13B 8000 3850 115 7.5 830 10.7 1230 9.6 2.2 260 73
UE10A33B 10000/9800 11200/9200 230/208 4.7/5.2 1060/1040 15.3/14.0 3500/2900 9.4 3.2 285 78
UE12A33B 11500/11200 11200/9200 230/208 6.0/6.4 1310/1270 15.3/14.0 3500/2900 8.8 3.8 290 80
WallMaster
Model Number
Uni-Fit
Model Number
Circuit Rating
Breaker
or T-D Fuse
Plug Face
(NEMA#)
Wall
Outlet
Appearance
WS08B10A, WS10B10A,
WS14B10A
US08B10A, UE08A13B
US10B10A, US12B10A 125V - 15A 5 - 15P
WS10B30A, WS13B30A,
WS16B30A
US10B30A, US12B30B,
US14B30A 250V - 15A 6 - 15P
WE10, WE13, WE16
WY10, WY13 UE10A33B, UE12A33B 250V - 20A 6 - 20P
WallMaster Heat Pump heating information (shown in red) indicates heat pump heating performance. WallMaster Electric Heat heating information (shown in red)
indicates electric heat strip performance. For WallMaster Heat Pump electric heating performance refer to corresponding WallMaster Electric Heat model.
