Friedrich Uni-Fit UE08A13B User manual

Uni-Fit Thru-the-wall
Cooling only and electric heat
PURCHASER P.O. # DATE
PROJECT LOCATION
ENGINEER ARCHITECT
SUBMITTED BY FOR APPROVAL FOR REFERENCE
ITEM PLAN DESIGNATION QUANTITY COOLING BTU/H VOLTAGE FRIEDRICH MODEL
TTW_UNI-FIT_SUBMITTAL_08
Universal Fit for Easy Replacement
Chassis installs into existing 26" sleeves
COOLING ONLY & ELECTRIC HEAT
• Rotary compressors provide quiet,
dependable performance
• Six-way air ow control
• Stale air exhaust
• Auto re-start
• Washable/reusable lter
• Seacoast protection
HEAT/COOL MODELS feature mechanical controls, two cooling
speeds, two heating speeds, plus one fan-only setting.
COOLING MODELS feature electronic controls with remote con-
trol, Money Saver® setting that saves energy by cycling the fan
with the compressor and three cooling/three fan-only speeds.
• 12 hour programmable timer
• Money Saver® setting saves energy by
cycling the fan with the compressor
REMOTE CONTROL FEATURES (cool only models)
Units are shown without USC sleeve (USC sleeves
sold and shipped separately)
Sleeve Dimensions
Friedrich
USC
Sleeve
GE Amana Whirlpool/
Fedders Frigidaire
Height (inches) 15 17/32 15 5/8 15 5/8 15 3/4 15 7/16
Width (inches) 25 7/8 26 26 26 3/4 25 7/8
Depth (inches) 16 23/32 16 7/8 16 7/8 15 18
REMOTE
CONTROL
12-HOUR
TIMER
MONEY SAVER
FEATURE

Plug Face/ Circuit Rating
Specications  EnErgy Star®models
Model
Cooling
Capacity
BTU/h
Heating
Capacity
BTU/h
Volts
Rated
Cooling
Amps
Cooling
Watts
Heating
Amps
Heating
Watts
Energy
Efficiency
Ratio
EER
Moisture
Removal
Pints/Hr.
Room
Side Air
Circulation
Net
Weight
Lbs.
UNI-FIT
US08B10A 8000 — 115 7.5 830 — — 9.6 2.2 260 73
US10B10A 9800 — 115 10.2 1110 — — 8.8 3.2 285 78
US10B30A 10000/9800 — 230/208 4.7/5.2 1060/1040 — — 9.4 3.2 285 78
US12B10A 11500 — 115 12.0 1310 — — 8.8 3.8 290 80
US12B30B 11500/11200 — 230/208 6.0/6.4 1310/1270 — — 8.8 3.8 290 80
US14B30A 13000/12600 — 230/208 7.0/7.5 1530/1480 — — 8.5 4.0 300 84
UE08A13B 8000 3850 115 7.5 830 10.7 1230 9.6 2.2 260 73
UE10A33B 10000/9800 11200/9200 230/208 4.7/5.2 1060/1040 15.3/14.0 3500/2900 9.4 3.2 285 78
UE12A33B 11500/11200 11200/9200 230/208 6.0/6.4 1310/1270 15.3/14.0 3500/2900 8.8 3.8 290 80
Uni-Fit
Model Number
Circuit Rating
Breaker
or T-D Fuse
Plug Face
(NEMA#)
Wall
Outlet
Appearance
US08B10A, UE08A13B
US10B10A, US12B10A 125V - 15A 5 - 15P
US10B30A, US12B30B,
US14B30A 250V - 15A 6 - 15P
UE10A33B, UE12A33B 250V - 20A 6 - 20P
As an EnErgy Star®partner, Friedrich Air Conditioning Co.
has determined that the selected EnErgy Star®models ()
meet the EnErgy Star® guidelines for energy efciency.
