Frient Entry Sensor Pro User manual

ba
<5mm
Frame Window/
Door
a.
b.
c.
d.
e.
f.
3. Release the button while the LED is ashing
numerous times in a row.
4. Afteryou release the button, the LED shows
one long ash, and the reset is completed.
eng
Modes
ACTIVATION MODE
A single green ash means that the sensor
and the magnet are moving either away from
or towards each other.
SEARCHING GATEWAY MODE
Red ashes every second for a longer period,
means that the device is searching for a gate-
way.
LOST CONNECTION MODE
When the red LED ashes 3 times, it means
that the device has failed to connect to a
gateway.
LOW-BATTERY MODE
Two consecutive red LED ashes every 60
seconds, means that the battery should be
replaced.
• There are many ways to mount the sensor
and magnet, as windows and doors vary
greatly. The most important consideration
is for the magnet to be placed as near to
the point on the sensor indicated by the
grey arrow.
• The sensor and magnet may be placed on
separate three dimensional planes, though
this does aect the maximum distance
allowed. The magnet may also be placed
either facing the side of the sensor or sitting
parallel to it.
Other information
Note local regulations about information to
your insurance company regarding installed
entry sensors.
Resetting
Resetting is needed if you want to connect
your entry sensor to another gateway or if you
need to perform a factory reset to eliminate
abnormal behavior.
STEPS FOR RESETTING
1. Press and hold down the reset button for
approximately 14-16 seconds.
2. While you are holding the button down, the
LED rst ashes once, then two times in a
row, and nally numerous times in a row.
Mounting
• Clean the surface before mounting.
• The entry sensor (a) should be mounted
to the frame using the double stick tape,
already applied on the back of the sensor
and magnet. Press rmly to secure sensor.
Testing
You can test if the positioning of the sensor
and magnet are correct by checking whether
the green light on the entry sensor is ashing
when you open or close the window/door.
Placement
• Place the sensor indoors at a temperature
between 0-50°C.
• The magnet has to be placed on that side
of the sensor which is marked with a small
triangle.
• The magnet and sensor also have to be
aligned/centered thickness-wise on as
similar level as possible.
• In case of a weak or a bad signal, change the
location of the entry sensor or strengthen
the signal with a smart plug.
SEE PAGE 2 FOR ILLUSTRATIONS
• When removing cover for battery change -
electrostatic discharge can harm electronic
components inside.
• Always mount indoors as the sensor is not
waterproof.
• Do not place the sensor close to magnetic
or electromagnetic elds. This device
includes a magnet. The magnet creates
a magnetic eld that may cause damage
to computer hard drives, magnetic cards,
data storage devices, hearing aids and
speakers e.g. Therefore, we strongly advise
you to never position the magnet close to
electronic devices.
Getting started
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
Product description
The entry sensor detects and reports opening
and closing of doors and windows. Easily
installed on any door or window, the sensor
triggers a signal when parted. This lets you
know when a room is entered, if a window or a
door has been left open, etc.
Entry Sensor/Pro
Fault nding
• If the entry sensor does not work when the
window or door is parted, the probable
cause is a faulty battery. Replace the
batteries if they are worn out.
• In case of a bad or weak signal, change the
location of the entry sensor. Otherwise you
can relocate your gateway or strengthen
the signal with a smart plug.
• If the search for a gateway has timed out, a
short press on the button will restart it.
Battery replacement
CAUTION: RISK OF EXPLOSION IF BATTERIES
ARE REPLACED BY AN INCORRECT
TYPE. DISPOSE OF THE BATTERIES IN
ACCORDANCE WITH INSTRUCTIONS.
2. Insert the enclosed batteries into the
device, respecting the polarities
3. Close the casing
4. The entry sensor will now start searching
(up to 15 minutes) for a Zigbee network to
join.
5. Make sure that the Zigbee network is open
for joining devices and will accept the entry
sensor.
6. While the entry sensor is searching for
a Zigbee network to join, the red LED is
ashing.
Disposal
Dispose the product and battery properly at
the end of life. This is electronic waste which
should be recycled.
Precautions
• The magnet (b) should be mounted on the
door or window no further than 5mm away
from the arrow on the sensor.
7. When the red LED stops ashing, the entry
sensor has successfully joined the Zigbee
network.
CAUTION: When removing cover for battery
change - Electrostatic Discharge (ESD) can
harm electronic components inside
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
2. Replace the batteries respecting the
polarities. The entry sensor uses 2xAAA
batteries.
3. Close the casing.
4. Test the entry sensor.
INSTALLATION MANUAL
Version 1.4
The reset button is marked with the small ring
on the front of the sensor.
Placement Examples - Top View
• The most benecial distance between the
sensor and the magnet is 0.2-0.5 cm.
• Be aware that on magnetic surface (e.g.
metal door), the distance between the
sensor and the magnet has to be 0.1-0.3
cm.

ba
<5mm
Frame Window/
Door
a.
b.
c.
d.
e.
f.
3. Release the button while the LED is ashing
numerous times in a row.
4. Afteryou release the button, the LED shows
one long ash, and the reset is completed.
eng
Modes
ACTIVATION MODE
A single green ash means that the sensor
and the magnet are moving either away from
or towards each other.
SEARCHING GATEWAY MODE
Red ashes every second for a longer period,
means that the device is searching for a gate-
way.
LOST CONNECTION MODE
When the red LED ashes 3 times, it means
that the device has failed to connect to a
gateway.
LOW-BATTERY MODE
Two consecutive red LED ashes every 60
seconds, means that the battery should be
replaced.
• There are many ways to mount the sensor
and magnet, as windows and doors vary
greatly. The most important consideration
is for the magnet to be placed as near to
the point on the sensor indicated by the
grey arrow.
• The sensor and magnet may be placed on
separate three dimensional planes, though
this does aect the maximum distance
allowed. The magnet may also be placed
either facing the side of the sensor or sitting
parallel to it.
Other information
Note local regulations about information to
your insurance company regarding installed
entry sensors.
Resetting
Resetting is needed if you want to connect
your entry sensor to another gateway or if you
need to perform a factory reset to eliminate
abnormal behavior.
STEPS FOR RESETTING
1. Press and hold down the reset button for
approximately 14-16 seconds.
2. While you are holding the button down, the
LED rst ashes once, then two times in a
row, and nally numerous times in a row.
Mounting
• Clean the surface before mounting.
• The entry sensor (a) should be mounted
to the frame using the double stick tape,
already applied on the back of the sensor
and magnet. Press rmly to secure sensor.
Testing
You can test if the positioning of the sensor
and magnet are correct by checking whether
the green light on the entry sensor is ashing
when you open or close the window/door.
Placement
• Place the sensor indoors at a temperature
between 0-50°C.
• The magnet has to be placed on that side
of the sensor which is marked with a small
triangle.
• The magnet and sensor also have to be
aligned/centered thickness-wise on as
similar level as possible.
• In case of a weak or a bad signal, change the
location of the entry sensor or strengthen
the signal with a smart plug.
SEE PAGE 2 FOR ILLUSTRATIONS
• When removing cover for battery change -
electrostatic discharge can harm electronic
components inside.
• Always mount indoors as the sensor is not
waterproof.
• Do not place the sensor close to magnetic
or electromagnetic elds. This device
includes a magnet. The magnet creates
a magnetic eld that may cause damage
to computer hard drives, magnetic cards,
data storage devices, hearing aids and
speakers e.g. Therefore, we strongly advise
you to never position the magnet close to
electronic devices.
Getting started
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
Product description
The entry sensor detects and reports opening
and closing of doors and windows. Easily
installed on any door or window, the sensor
triggers a signal when parted. This lets you
know when a room is entered, if a window or a
door has been left open, etc.
Entry Sensor/Pro
Fault nding
• If the entry sensor does not work when the
window or door is parted, the probable
cause is a faulty battery. Replace the
batteries if they are worn out.
• In case of a bad or weak signal, change the
location of the entry sensor. Otherwise you
can relocate your gateway or strengthen
the signal with a smart plug.
• If the search for a gateway has timed out, a
short press on the button will restart it.
Battery replacement
CAUTION: RISK OF EXPLOSION IF BATTERIES
ARE REPLACED BY AN INCORRECT
TYPE. DISPOSE OF THE BATTERIES IN
ACCORDANCE WITH INSTRUCTIONS.
2. Insert the enclosed batteries into the
device, respecting the polarities
3. Close the casing
4. The entry sensor will now start searching
(up to 15 minutes) for a Zigbee network to
join.
5. Make sure that the Zigbee network is open
for joining devices and will accept the entry
sensor.
6. While the entry sensor is searching for
a Zigbee network to join, the red LED is
ashing.
Disposal
Dispose the product and battery properly at
the end of life. This is electronic waste which
should be recycled.
Precautions
• The magnet (b) should be mounted on the
door or window no further than 5mm away
from the arrow on the sensor.
7. When the red LED stops ashing, the entry
sensor has successfully joined the Zigbee
network.
CAUTION: When removing cover for battery
change - Electrostatic Discharge (ESD) can
harm electronic components inside
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
2. Replace the batteries respecting the
polarities. The entry sensor uses 2xAAA
batteries.
3. Close the casing.
4. Test the entry sensor.
INSTALLATION MANUAL
Version 1.4
The reset button is marked with the small ring
on the front of the sensor.
Placement Examples - Top View
• The most benecial distance between the
sensor and the magnet is 0.2-0.5 cm.
• Be aware that on magnetic surface (e.g.
metal door), the distance between the
sensor and the magnet has to be 0.1-0.3
cm.

ba
<5mm
Frame Window/
Door
a.
b.
c.
d.
e.
f.
3. Release the button while the LED is ashing
numerous times in a row.
4. Afteryou release the button, the LED shows
one long ash, and the reset is completed.
eng
Modes
ACTIVATION MODE
A single green ash means that the sensor
and the magnet are moving either away from
or towards each other.
SEARCHING GATEWAY MODE
Red ashes every second for a longer period,
means that the device is searching for a gate-
way.
LOST CONNECTION MODE
When the red LED ashes 3 times, it means
that the device has failed to connect to a
gateway.
LOW-BATTERY MODE
Two consecutive red LED ashes every 60
seconds, means that the battery should be
replaced.
• There are many ways to mount the sensor
and magnet, as windows and doors vary
greatly. The most important consideration
is for the magnet to be placed as near to
the point on the sensor indicated by the
grey arrow.
• The sensor and magnet may be placed on
separate three dimensional planes, though
this does aect the maximum distance
allowed. The magnet may also be placed
either facing the side of the sensor or sitting
parallel to it.
Other information
Note local regulations about information to
your insurance company regarding installed
entry sensors.
Resetting
Resetting is needed if you want to connect
your entry sensor to another gateway or if you
need to perform a factory reset to eliminate
abnormal behavior.
STEPS FOR RESETTING
1. Press and hold down the reset button for
approximately 14-16 seconds.
2. While you are holding the button down, the
LED rst ashes once, then two times in a
row, and nally numerous times in a row.
Mounting
• Clean the surface before mounting.
• The entry sensor (a) should be mounted
to the frame using the double stick tape,
already applied on the back of the sensor
and magnet. Press rmly to secure sensor.
Testing
You can test if the positioning of the sensor
and magnet are correct by checking whether
the green light on the entry sensor is ashing
when you open or close the window/door.
Placement
• Place the sensor indoors at a temperature
between 0-50°C.
• The magnet has to be placed on that side
of the sensor which is marked with a small
triangle.
• The magnet and sensor also have to be
aligned/centered thickness-wise on as
similar level as possible.
• In case of a weak or a bad signal, change the
location of the entry sensor or strengthen
the signal with a smart plug.
SEE PAGE 2 FOR ILLUSTRATIONS
• When removing cover for battery change -
electrostatic discharge can harm electronic
components inside.
• Always mount indoors as the sensor is not
waterproof.
• Do not place the sensor close to magnetic
or electromagnetic elds. This device
includes a magnet. The magnet creates
a magnetic eld that may cause damage
to computer hard drives, magnetic cards,
data storage devices, hearing aids and
speakers e.g. Therefore, we strongly advise
you to never position the magnet close to
electronic devices.
Getting started
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
Product description
The entry sensor detects and reports opening
and closing of doors and windows. Easily
installed on any door or window, the sensor
triggers a signal when parted. This lets you
know when a room is entered, if a window or a
door has been left open, etc.
Entry Sensor/Pro
Fault nding
• If the entry sensor does not work when the
window or door is parted, the probable
cause is a faulty battery. Replace the
batteries if they are worn out.
• In case of a bad or weak signal, change the
location of the entry sensor. Otherwise you
can relocate your gateway or strengthen
the signal with a smart plug.
• If the search for a gateway has timed out, a
short press on the button will restart it.
Battery replacement
CAUTION: RISK OF EXPLOSION IF BATTERIES
ARE REPLACED BY AN INCORRECT
TYPE. DISPOSE OF THE BATTERIES IN
ACCORDANCE WITH INSTRUCTIONS.
2. Insert the enclosed batteries into the
device, respecting the polarities
3. Close the casing
4. The entry sensor will now start searching
(up to 15 minutes) for a Zigbee network to
join.
5. Make sure that the Zigbee network is open
for joining devices and will accept the entry
sensor.
6. While the entry sensor is searching for
a Zigbee network to join, the red LED is
ashing.
Disposal
Dispose the product and battery properly at
the end of life. This is electronic waste which
should be recycled.
Precautions
• The magnet (b) should be mounted on the
door or window no further than 5mm away
from the arrow on the sensor.
7. When the red LED stops ashing, the entry
sensor has successfully joined the Zigbee
network.
CAUTION: When removing cover for battery
change - Electrostatic Discharge (ESD) can
harm electronic components inside
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
2. Replace the batteries respecting the
polarities. The entry sensor uses 2xAAA
batteries.
3. Close the casing.
4. Test the entry sensor.
INSTALLATION MANUAL
Version 1.4
The reset button is marked with the small ring
on the front of the sensor.
Placement Examples - Top View
• The most benecial distance between the
sensor and the magnet is 0.2-0.5 cm.
• Be aware that on magnetic surface (e.g.
metal door), the distance between the
sensor and the magnet has to be 0.1-0.3
cm.

ba
<5mm
Frame Window/
Door
a.
b.
c.
d.
e.
f.
3. Release the button while the LED is ashing
numerous times in a row.
4. Afteryou release the button, the LED shows
one long ash, and the reset is completed.
eng
Modes
ACTIVATION MODE
A single green ash means that the sensor
and the magnet are moving either away from
or towards each other.
SEARCHING GATEWAY MODE
Red ashes every second for a longer period,
means that the device is searching for a gate-
way.
LOST CONNECTION MODE
When the red LED ashes 3 times, it means
that the device has failed to connect to a
gateway.
LOW-BATTERY MODE
Two consecutive red LED ashes every 60
seconds, means that the battery should be
replaced.
• There are many ways to mount the sensor
and magnet, as windows and doors vary
greatly. The most important consideration
is for the magnet to be placed as near to
the point on the sensor indicated by the
grey arrow.
• The sensor and magnet may be placed on
separate three dimensional planes, though
this does aect the maximum distance
allowed. The magnet may also be placed
either facing the side of the sensor or sitting
parallel to it.
Other information
Note local regulations about information to
your insurance company regarding installed
entry sensors.
Resetting
Resetting is needed if you want to connect
your entry sensor to another gateway or if you
need to perform a factory reset to eliminate
abnormal behavior.
STEPS FOR RESETTING
1. Press and hold down the reset button for
approximately 14-16 seconds.
2. While you are holding the button down, the
LED rst ashes once, then two times in a
row, and nally numerous times in a row.
Mounting
• Clean the surface before mounting.
• The entry sensor (a) should be mounted
to the frame using the double stick tape,
already applied on the back of the sensor
and magnet. Press rmly to secure sensor.
Testing
You can test if the positioning of the sensor
and magnet are correct by checking whether
the green light on the entry sensor is ashing
when you open or close the window/door.
Placement
• Place the sensor indoors at a temperature
between 0-50°C.
• The magnet has to be placed on that side
of the sensor which is marked with a small
triangle.
• The magnet and sensor also have to be
aligned/centered thickness-wise on as
similar level as possible.
• In case of a weak or a bad signal, change the
location of the entry sensor or strengthen
the signal with a smart plug.
SEE PAGE 2 FOR ILLUSTRATIONS
• When removing cover for battery change -
electrostatic discharge can harm electronic
components inside.
• Always mount indoors as the sensor is not
waterproof.
• Do not place the sensor close to magnetic
or electromagnetic elds. This device
includes a magnet. The magnet creates
a magnetic eld that may cause damage
to computer hard drives, magnetic cards,
data storage devices, hearing aids and
speakers e.g. Therefore, we strongly advise
you to never position the magnet close to
electronic devices.
Getting started
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
Product description
The entry sensor detects and reports opening
and closing of doors and windows. Easily
installed on any door or window, the sensor
triggers a signal when parted. This lets you
know when a room is entered, if a window or a
door has been left open, etc.
Entry Sensor/Pro
Fault nding
• If the entry sensor does not work when the
window or door is parted, the probable
cause is a faulty battery. Replace the
batteries if they are worn out.
• In case of a bad or weak signal, change the
location of the entry sensor. Otherwise you
can relocate your gateway or strengthen
the signal with a smart plug.
• If the search for a gateway has timed out, a
short press on the button will restart it.
Battery replacement
CAUTION: RISK OF EXPLOSION IF BATTERIES
ARE REPLACED BY AN INCORRECT
TYPE. DISPOSE OF THE BATTERIES IN
ACCORDANCE WITH INSTRUCTIONS.
2. Insert the enclosed batteries into the
device, respecting the polarities
3. Close the casing
4. The entry sensor will now start searching
(up to 15 minutes) for a Zigbee network to
join.
5. Make sure that the Zigbee network is open
for joining devices and will accept the entry
sensor.
6. While the entry sensor is searching for
a Zigbee network to join, the red LED is
ashing.
Disposal
Dispose the product and battery properly at
the end of life. This is electronic waste which
should be recycled.
Precautions
• The magnet (b) should be mounted on the
door or window no further than 5mm away
from the arrow on the sensor.
7. When the red LED stops ashing, the entry
sensor has successfully joined the Zigbee
network.
CAUTION: When removing cover for battery
change - Electrostatic Discharge (ESD) can
harm electronic components inside
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
2. Replace the batteries respecting the
polarities. The entry sensor uses 2xAAA
batteries.
3. Close the casing.
4. Test the entry sensor.
INSTALLATION MANUAL
Version 1.4
The reset button is marked with the small ring
on the front of the sensor.
Placement Examples - Top View
• The most benecial distance between the
sensor and the magnet is 0.2-0.5 cm.
• Be aware that on magnetic surface (e.g.
metal door), the distance between the
sensor and the magnet has to be 0.1-0.3
cm.

ba
<5mm
Frame Window/
Door
a.
b.
c.
d.
e.
f.
3. Release the button while the LED is ashing
numerous times in a row.
4. Afteryou release the button, the LED shows
one long ash, and the reset is completed.
eng
Modes
ACTIVATION MODE
A single green ash means that the sensor
and the magnet are moving either away from
or towards each other.
SEARCHING GATEWAY MODE
Red ashes every second for a longer period,
means that the device is searching for a gate-
way.
LOST CONNECTION MODE
When the red LED ashes 3 times, it means
that the device has failed to connect to a
gateway.
LOW-BATTERY MODE
Two consecutive red LED ashes every 60
seconds, means that the battery should be
replaced.
• There are many ways to mount the sensor
and magnet, as windows and doors vary
greatly. The most important consideration
is for the magnet to be placed as near to
the point on the sensor indicated by the
grey arrow.
• The sensor and magnet may be placed on
separate three dimensional planes, though
this does aect the maximum distance
allowed. The magnet may also be placed
either facing the side of the sensor or sitting
parallel to it.
Other information
Note local regulations about information to
your insurance company regarding installed
entry sensors.
Resetting
Resetting is needed if you want to connect
your entry sensor to another gateway or if you
need to perform a factory reset to eliminate
abnormal behavior.
STEPS FOR RESETTING
1. Press and hold down the reset button for
approximately 14-16 seconds.
2. While you are holding the button down, the
LED rst ashes once, then two times in a
row, and nally numerous times in a row.
Mounting
• Clean the surface before mounting.
• The entry sensor (a) should be mounted
to the frame using the double stick tape,
already applied on the back of the sensor
and magnet. Press rmly to secure sensor.
Testing
You can test if the positioning of the sensor
and magnet are correct by checking whether
the green light on the entry sensor is ashing
when you open or close the window/door.
Placement
• Place the sensor indoors at a temperature
between 0-50°C.
• The magnet has to be placed on that side
of the sensor which is marked with a small
triangle.
• The magnet and sensor also have to be
aligned/centered thickness-wise on as
similar level as possible.
• In case of a weak or a bad signal, change the
location of the entry sensor or strengthen
the signal with a smart plug.
SEE PAGE 2 FOR ILLUSTRATIONS
• When removing cover for battery change -
electrostatic discharge can harm electronic
components inside.
• Always mount indoors as the sensor is not
waterproof.
• Do not place the sensor close to magnetic
or electromagnetic elds. This device
includes a magnet. The magnet creates
a magnetic eld that may cause damage
to computer hard drives, magnetic cards,
data storage devices, hearing aids and
speakers e.g. Therefore, we strongly advise
you to never position the magnet close to
electronic devices.
Getting started
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
Product description
The entry sensor detects and reports opening
and closing of doors and windows. Easily
installed on any door or window, the sensor
triggers a signal when parted. This lets you
know when a room is entered, if a window or a
door has been left open, etc.
Entry Sensor/Pro
Fault nding
• If the entry sensor does not work when the
window or door is parted, the probable
cause is a faulty battery. Replace the
batteries if they are worn out.
• In case of a bad or weak signal, change the
location of the entry sensor. Otherwise you
can relocate your gateway or strengthen
the signal with a smart plug.
• If the search for a gateway has timed out, a
short press on the button will restart it.
Battery replacement
CAUTION: RISK OF EXPLOSION IF BATTERIES
ARE REPLACED BY AN INCORRECT
TYPE. DISPOSE OF THE BATTERIES IN
ACCORDANCE WITH INSTRUCTIONS.
2. Insert the enclosed batteries into the
device, respecting the polarities
3. Close the casing
4. The entry sensor will now start searching
(up to 15 minutes) for a Zigbee network to
join.
5. Make sure that the Zigbee network is open
for joining devices and will accept the entry
sensor.
6. While the entry sensor is searching for
a Zigbee network to join, the red LED is
ashing.
Disposal
Dispose the product and battery properly at
the end of life. This is electronic waste which
should be recycled.
Precautions
• The magnet (b) should be mounted on the
door or window no further than 5mm away
from the arrow on the sensor.
7. When the red LED stops ashing, the entry
sensor has successfully joined the Zigbee
network.
CAUTION: When removing cover for battery
change - Electrostatic Discharge (ESD) can
harm electronic components inside
1. Open the casing of the device by pushing
the fastening on top of the device to
remove the front panel from the back cover.
2. Replace the batteries respecting the
polarities. The entry sensor uses 2xAAA
batteries.
3. Close the casing.
4. Test the entry sensor.
INSTALLATION MANUAL
Version 1.4
The reset button is marked with the small ring
on the front of the sensor.
Placement Examples - Top View
• The most benecial distance between the
sensor and the magnet is 0.2-0.5 cm.
• Be aware that on magnetic surface (e.g.
metal door), the distance between the
sensor and the magnet has to be 0.1-0.3
cm.

Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a) Magnet (b)
Sensor (a)
Magnet (b)
Sliding Door
Sensor (a)
Magnet (b)
g.
h.
i.
Placement Examples - Doors
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy vibra-
tions.
• The sensor and magnet should be
mounted on the side opposite from the
hinge/pivot point.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
Placement Examples - Windows
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy
vibrations.
• The sensor and magnet should be mounted
on the side opposite from the hinge/pivot
point.
• Alternatively, if the window slides open, the
sensor and magnet may be mounted in
many positions, however the sensor should
always be placed on the frame.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
frient assumes no responsibility for any
errors, which may appear in this manual.
Furthermore, frient reserves the right to alter
the hardware, software, and/or specications
detailed herein at any time without notice,
and frient does not make any commitment
to update the information contained herein.
All the trademarks listed herein are owned by
their respective owners.
Distributed by frient A/S
Tangen 6
8200 Aarhus N
Denmark
www.frient.com
Copyright © frient A/S
All rights reserved.
Other certications
• Zigbee Home Automation 1.2 certied.
CE certication
The CE mark axed to this product conrms
its compliance with the European Directives
which apply to the product and, in particular,
its compliance with the harmonized standards
and specications.
Frame
Frame
Frame
Frame
Frame
Window
Frame
Frame
Frame
Door
Window
Sensor (a)
Sensor (a)
Sensor (a)
Magnet (b)
Magnet (b)
Magnet (b)
Door
IN ACCORDANCE WITH THE DIRECTIVES
• Radio Equipment Directive (RED)
2014/53/EU
• RoHS Directive 2015/863/EU amending
2011/65/EU
IC statement
ISED statement
Innovation, Science and Economic
Development Canada ICES-003 Compliance
Label: CAN ICES-3 (B)/NMB-3(B).
ISED statement
Français
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de
brouillage;
2. L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
English
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
This equipment complies with IC RSS-102
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20 cm between the
radiator and your body.
Cet équipement est conforme aux limites
d’exposition aux radiations IC CNR-102
établies pour un environnement non
contrôlé. Cet équipement doit être installé et
utilisé avec une distance minimale de 20 cm
entre le radiateur et votre corps.
FCC statement
Changes or modications to the equipment
not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment o and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The antenna used for this
transmitter must be installed to provide a
separation distance of at least 20 cm from
all persons and must not be co-located
or operating in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interfer-
ence, and
2. this device must accept any interference
received, including interference that may
cause undesired operation.

Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a) Magnet (b)
Sensor (a)
Magnet (b)
Sliding Door
Sensor (a)
Magnet (b)
g.
h.
i.
Placement Examples - Doors
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy vibra-
tions.
• The sensor and magnet should be
mounted on the side opposite from the
hinge/pivot point.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
Placement Examples - Windows
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy
vibrations.
• The sensor and magnet should be mounted
on the side opposite from the hinge/pivot
point.
• Alternatively, if the window slides open, the
sensor and magnet may be mounted in
many positions, however the sensor should
always be placed on the frame.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
frient assumes no responsibility for any
errors, which may appear in this manual.
Furthermore, frient reserves the right to alter
the hardware, software, and/or specications
detailed herein at any time without notice,
and frient does not make any commitment
to update the information contained herein.
All the trademarks listed herein are owned by
their respective owners.
Distributed by frient A/S
Tangen 6
8200 Aarhus N
Denmark
www.frient.com
Copyright © frient A/S
All rights reserved.
Other certications
• Zigbee Home Automation 1.2 certied.
CE certication
The CE mark axed to this product conrms
its compliance with the European Directives
which apply to the product and, in particular,
its compliance with the harmonized standards
and specications.
Frame
Frame
Frame
Frame
Frame
Window
Frame
Frame
Frame
Door
Window
Sensor (a)
Sensor (a)
Sensor (a)
Magnet (b)
Magnet (b)
Magnet (b)
Door
IN ACCORDANCE WITH THE DIRECTIVES
• Radio Equipment Directive (RED)
2014/53/EU
• RoHS Directive 2015/863/EU amending
2011/65/EU
IC statement
ISED statement
Innovation, Science and Economic
Development Canada ICES-003 Compliance
Label: CAN ICES-3 (B)/NMB-3(B).
ISED statement
Français
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de
brouillage;
2. L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
English
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
This equipment complies with IC RSS-102
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20 cm between the
radiator and your body.
Cet équipement est conforme aux limites
d’exposition aux radiations IC CNR-102
établies pour un environnement non
contrôlé. Cet équipement doit être installé et
utilisé avec une distance minimale de 20 cm
entre le radiateur et votre corps.
FCC statement
Changes or modications to the equipment
not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment o and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The antenna used for this
transmitter must be installed to provide a
separation distance of at least 20 cm from
all persons and must not be co-located
or operating in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interfer-
ence, and
2. this device must accept any interference
received, including interference that may
cause undesired operation.

Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a) Magnet (b)
Sensor (a)
Magnet (b)
Sliding Door
Sensor (a)
Magnet (b)
g.
h.
i.
Placement Examples - Doors
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy vibra-
tions.
• The sensor and magnet should be
mounted on the side opposite from the
hinge/pivot point.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
Placement Examples - Windows
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy
vibrations.
• The sensor and magnet should be mounted
on the side opposite from the hinge/pivot
point.
• Alternatively, if the window slides open, the
sensor and magnet may be mounted in
many positions, however the sensor should
always be placed on the frame.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
frient assumes no responsibility for any
errors, which may appear in this manual.
Furthermore, frient reserves the right to alter
the hardware, software, and/or specications
detailed herein at any time without notice,
and frient does not make any commitment
to update the information contained herein.
All the trademarks listed herein are owned by
their respective owners.
Distributed by frient A/S
Tangen 6
8200 Aarhus N
Denmark
www.frient.com
Copyright © frient A/S
All rights reserved.
Other certications
• Zigbee Home Automation 1.2 certied.
CE certication
The CE mark axed to this product conrms
its compliance with the European Directives
which apply to the product and, in particular,
its compliance with the harmonized standards
and specications.
Frame
Frame
Frame
Frame
Frame
Window
Frame
Frame
Frame
Door
Window
Sensor (a)
Sensor (a)
Sensor (a)
Magnet (b)
Magnet (b)
Magnet (b)
Door
IN ACCORDANCE WITH THE DIRECTIVES
• Radio Equipment Directive (RED)
2014/53/EU
• RoHS Directive 2015/863/EU amending
2011/65/EU
IC statement
ISED statement
Innovation, Science and Economic
Development Canada ICES-003 Compliance
Label: CAN ICES-3 (B)/NMB-3(B).
ISED statement
Français
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de
brouillage;
2. L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
English
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
This equipment complies with IC RSS-102
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20 cm between the
radiator and your body.
Cet équipement est conforme aux limites
d’exposition aux radiations IC CNR-102
établies pour un environnement non
contrôlé. Cet équipement doit être installé et
utilisé avec une distance minimale de 20 cm
entre le radiateur et votre corps.
FCC statement
Changes or modications to the equipment
not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment o and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The antenna used for this
transmitter must be installed to provide a
separation distance of at least 20 cm from
all persons and must not be co-located
or operating in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interfer-
ence, and
2. this device must accept any interference
received, including interference that may
cause undesired operation.

Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a) Magnet (b)
Sensor (a)
Magnet (b)
Sliding Door
Sensor (a)
Magnet (b)
g.
h.
i.
Placement Examples - Doors
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy vibra-
tions.
• The sensor and magnet should be
mounted on the side opposite from the
hinge/pivot point.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
Placement Examples - Windows
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy
vibrations.
• The sensor and magnet should be mounted
on the side opposite from the hinge/pivot
point.
• Alternatively, if the window slides open, the
sensor and magnet may be mounted in
many positions, however the sensor should
always be placed on the frame.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
frient assumes no responsibility for any
errors, which may appear in this manual.
Furthermore, frient reserves the right to alter
the hardware, software, and/or specications
detailed herein at any time without notice,
and frient does not make any commitment
to update the information contained herein.
All the trademarks listed herein are owned by
their respective owners.
Distributed by frient A/S
Tangen 6
8200 Aarhus N
Denmark
www.frient.com
Copyright © frient A/S
All rights reserved.
Other certications
• Zigbee Home Automation 1.2 certied.
CE certication
The CE mark axed to this product conrms
its compliance with the European Directives
which apply to the product and, in particular,
its compliance with the harmonized standards
and specications.
Frame
Frame
Frame
Frame
Frame
Window
Frame
Frame
Frame
Door
Window
Sensor (a)
Sensor (a)
Sensor (a)
Magnet (b)
Magnet (b)
Magnet (b)
Door
IN ACCORDANCE WITH THE DIRECTIVES
• Radio Equipment Directive (RED)
2014/53/EU
• RoHS Directive 2015/863/EU amending
2011/65/EU
IC statement
ISED statement
Innovation, Science and Economic
Development Canada ICES-003 Compliance
Label: CAN ICES-3 (B)/NMB-3(B).
ISED statement
Français
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de
brouillage;
2. L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
English
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
This equipment complies with IC RSS-102
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20 cm between the
radiator and your body.
Cet équipement est conforme aux limites
d’exposition aux radiations IC CNR-102
établies pour un environnement non
contrôlé. Cet équipement doit être installé et
utilisé avec une distance minimale de 20 cm
entre le radiateur et votre corps.
FCC statement
Changes or modications to the equipment
not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment o and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The antenna used for this
transmitter must be installed to provide a
separation distance of at least 20 cm from
all persons and must not be co-located
or operating in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interfer-
ence, and
2. this device must accept any interference
received, including interference that may
cause undesired operation.

Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a)
Magnet (b)
Sensor (a) Magnet (b)
Sensor (a)
Magnet (b)
Sliding Door
Sensor (a)
Magnet (b)
g.
h.
i.
Placement Examples - Doors
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy vibra-
tions.
• The sensor and magnet should be
mounted on the side opposite from the
hinge/pivot point.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
Placement Examples - Windows
• Be sure to mount the sensor on the frame,
to protect the electronics from heavy
vibrations.
• The sensor and magnet should be mounted
on the side opposite from the hinge/pivot
point.
• Alternatively, if the window slides open, the
sensor and magnet may be mounted in
many positions, however the sensor should
always be placed on the frame.
• Pay careful attention to the arrow printed on
the sensor. This should be oriented to face
the magnet. The distance between the two
should not exceed 5mm.
frient assumes no responsibility for any
errors, which may appear in this manual.
Furthermore, frient reserves the right to alter
the hardware, software, and/or specications
detailed herein at any time without notice,
and frient does not make any commitment
to update the information contained herein.
All the trademarks listed herein are owned by
their respective owners.
Distributed by frient A/S
Tangen 6
8200 Aarhus N
Denmark
www.frient.com
Copyright © frient A/S
All rights reserved.
Other certications
• Zigbee Home Automation 1.2 certied.
CE certication
The CE mark axed to this product conrms
its compliance with the European Directives
which apply to the product and, in particular,
its compliance with the harmonized standards
and specications.
Frame
Frame
Frame
Frame
Frame
Window
Frame
Frame
Frame
Door
Window
Sensor (a)
Sensor (a)
Sensor (a)
Magnet (b)
Magnet (b)
Magnet (b)
Door
IN ACCORDANCE WITH THE DIRECTIVES
• Radio Equipment Directive (RED)
2014/53/EU
• RoHS Directive 2015/863/EU amending
2011/65/EU
IC statement
ISED statement
Innovation, Science and Economic
Development Canada ICES-003 Compliance
Label: CAN ICES-3 (B)/NMB-3(B).
ISED statement
Français
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences
et Développement économique Canada
applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de
brouillage;
2. L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
English
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference,
including interference that may cause
undesired operation of the device.
This equipment complies with IC RSS-102
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20 cm between the
radiator and your body.
Cet équipement est conforme aux limites
d’exposition aux radiations IC CNR-102
établies pour un environnement non
contrôlé. Cet équipement doit être installé et
utilisé avec une distance minimale de 20 cm
entre le radiateur et votre corps.
FCC statement
Changes or modications to the equipment
not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment o and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The antenna used for this
transmitter must be installed to provide a
separation distance of at least 20 cm from
all persons and must not be co-located
or operating in conjunction with any other
antenna or transmitter.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interfer-
ence, and
2. this device must accept any interference
received, including interference that may
cause undesired operation.
