Frigidaire FRA156MT1 Installation instructions

frigidaire.com
Product Dimensions
Height 17-1/16"
Width 23-5/8"
Depth 25-3/8"
More Easy-To-Use Features
Energy and Cost Savings
The unit operates at a low voltage –
conserving energy and saving you money.
Multi-Speed Fan
Features three different fan speeds, for
more cooling flexibility.
Sleep Mode
Quiet operation keeps you cool without
keeping you awake. Plus, Sleep Mode
gradually increases room temperature
after being activated.
Quickly Cools
Comfort Control Design
Easily control the direction of your cool air,
wherever your unit is.
Eortless™ Restart
Automatically resumes operating at its
previous settings when power is restored
to your unit.
Clean Filter Alert
Power Cord
Comes with an extra long three-prong
cord that makes extension cords
unnecessary.
SpaceWise® Adjustable Design
Optional Side Panels extend so you can
adjust your unit to fit your window.
24 Hour On/O Timer
ENERGY STAR®
Signature Features
Ready-Select™ Controls
Easily select options with the touch of a
button.
Eortless™ Clean Filter
Our anti-microbial filter cleans the air,
removing harmful bacteria.
Remote Control
Allows you to precisely control the
temperature and fan speed from across
the room.
Eortless™ Remote
Temperature Control
A themostat located on your air
conditioner’s remote control precisely
maintains preset room temperature, so
you will remain comfortable at all times. Performance
Cool
BTUs
15,100
Home Comfort
FRA156MT1
Median
Air Conditioner

Specifications
subject to change.
Product Dimensions
A - Height
B - Width
C - Depth
17-1/16"
23-5/8"
25-3/8"
Window Dimensions
D - Height (Min.)
E - Width (Min. / Max.)
Wall Cutout Dimensions
F - Max. Wall Thickness
Height
Width
18-1/2"
26-1/2" / 40-1/2"
8"
18"
23-5/16"
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
RAC Median Models
Frigidaire Baseline
C
B
A
E
D
F
Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FRA156MT1 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
*Plug Type (NEMA)
(A) 5-15P
Home Comfort
FRA156MT1 Median Air Conditioner
Performance
BTU (Cool)
Dehumidification (Pints / Hour)
Cool Area (Sq. Ft.)
Energy Eciency Ratio
Electrical
Volts
Amps (Cool)
Watts (Cool)
Length of Power Cord (Min. / Max.)
Plug Type (NEMA)*
Features
Electronic Controls
Fan Speeds (Cool / Fan)
Low Voltage Start-Up
Auto Cool Function
Energy Save
Sleep Mode
Filter Check
24 Hour On / O Timer
Clean Air Ionizer
Remote Control
Air CFM (High / Med / Low)
Air Direction Control
Fresh Air / Exhaust Vent / Closed
Filter Type
Filter Access
Slide-Out Chassis
Cabinet Louvers
Rear Grille
Window Mounting Kit (Included)
Certifications
ENERGY STAR®
Performance
Specifications
Refrigerant
Shipping Weight (Approx.)
15,100
3.8
900
10.7
115
12.0
1,410
5' / 6'
LCDI (A)
Ready-Select™ Controls
3 / 3
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Full-Function Remote T’Stat
362 / 317 / 282
4-Way
Yes / Yes / Yes
Antimicrobial Mesh
Tilt-Out
Yes
Yes
Yes
Pleated Quick Mount
Yes
AHAM
R410a
112 Lbs.
