Owner’s
Guide
Gas
Cooktop
P/N 318200650 (0005) Rev. D

2
© 2000 White Consolidated Industries
All rights reserved
Product Registration
Contents 3-4 ImportantSafetyInstructions
5 GroundingInstructions
5 Liquefied Petroleum (Propane) Gas Conversion
5 Flame Size
6 ProperBurner Adjustments
6 SettingSurfaceControls
6 Selecting Surface Cooking Utensils
7 Specialty Pans & Trivets
7 CanningTips& Information
General Cleaning
8 CleaningVariousPartsof Cooktop
9 ForModelWith OpenBurner
10-11 For Model With Sealed Burner
12 Avoid Service Checklist
13-14 Warranty
Note: TheinstructionsappearinginthisOwner'sGuidearenotmeanttocoverevery
possible condition and situation that may occur. Common sense and caution must
be practiced when installing, operating and maintaining any appliance.
Register Your Product
ThePRODUCT REGISTRATION CARD
should be filled in completely, signed
and returned to Frigidaire Company.
Thank you for choosing this appliance. The information contained within this
Owner's Guide will instruct you on how to properly operate and care for your
cooktop. Please read through the information contained in your literature pack to
learn more about your new appliance.
Record Your Model and Serial Numbers
Recordinthespaceprovidedbelowthemodelandserialnumbersfoundunderneath
or inside the cooktop.
ModelNumber: _____________________________________________________
SerialNumber:______________________________________________________
DateofPurchase: ___________________________________________________
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Donottouchanyelectricalswitch;donotuseany phone
in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installationandservicemustbeperformedbyaqualified
installer, servicer or the gas supplier.
If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
This Owner's Guide contains general
operating instructions for your cooktop
andfeatureinformationforseveralmodels.
Your cooktop may not have all the
describedfeatures.
Versión en español
Sidesea obtenerunacopiaenespañol de
esteManualdel Usuario,sírvaseescribira
ladirecciónqueseincluyeacontinuación.
Solicite la P/N318201100.
SpanishOwner'sGuides
FrigidaireCompany
P. O. Box 9061
Dublin,Ohio 43017-0961

3
This guide contains important safety symbols and instructions. Please pay special attention to these symbols and follow all
instructions given. Here is a brief explanation of the use of these symbols.
This symbol will help alert you to situations that may cause serious bodily harm, death or property damage.
This symbol will help alert you to situations that may cause bodily injury or property damage.
• Remove all tape and packaging wrap before using the
cooktop. Destroy the carton and plastic bags after
unpacking the cooktop. Never allow children to play with
packaging material. Do not remove the model/serial plate
attached to the cooktop.
•ProperInstallation—Besureyourapplianceisproperly
installed and grounded by a qualified technician in
accordancewiththeNationalFuelGasCodeANSIZ223.1
latest edition in the United States, or in Canada CAN/
CGA B149.1, and CAN/CGA B149.2, and the National
Electrical Code ANSI/NFPA No. 70—latest edition in
United States, or in Canada CSA Standard C22.1,
Canadian Electrical Code, Part 1, and local code
requirements. Install and/or adjust only per installation
instructions provided in the literature package for this
cooktop.
Ask your dealer to recommend a qualified technician and an
authorizedrepairservice.Knowhowtoshutoffgassupplyatthe
meteranddisconnecttheelectricalpowertothecooktopatthe
circuit breaker or fuse box in case of an emergency.
• UserServicing—Donotrepairorreplaceanypartofthe
appliance unless specifically recommended in the
manuals. All other servicing should be done only by a
qualified technician. This may reduce the risk of personal
injury and damage to the cooktop.
• Never modify or alter the construction of a cooktop by
removing panels, wire covers, or any other part of the
product.
Stepping or leaning on this cooktop can
result in serious injuries and may also cause damage to
thecooktop.Donotallowchildrentoclimborplayaroundthe
cooktop.
• Storage on Appliance—Flammable materials should
notbestoredonthecooktop,nearsurfaceburners.This
includes paper, plastic and cloth items, such as cookbooks,
plasticwareandtowels, aswellasflammableliquids. Donot
store explosives, such as aerosol cans, on the cooktop.
Flammable materials may explode and result in fire or
propertydamage.
Do not store items of interest to children
in the cabinets above the cooktop.
• Do not leave children alone—Children should not be
leftaloneorunattendedintheareawhereanappliance
isinuse.Theyshouldneverbeallowedtositorstandonany
part of the appliance.
• DONOTTOUCHSURFACEBURNERS,GRATES,ORAREAS
NEAR THESE BURNERS. Surface burners may be hot even
thoughtheflamesarenotvisible.Areasnearsurfaceburners
may become hot enough to cause burns. During and after
use,donottouchorletclothingorotherflammablematerials
touchtheseareasuntiltheyhavehadsufficienttimetocool.
Amongtheseareas are thecooktopand the surfacesfacing
thecooktop.
• Wear Proper Apparel—Loose-fitting or hanging
garments should never be worn while using the
appliance.Donotletclothingorotherflammablematerials
contacthotsurfaces.
Never use your appliance for warming or
heating the room.
• Do Not Use Water or Flour on Grease Fires—Smother
the fire with a pan lid, or use baking soda, a dry
chemical or foam-type extinguisher.
•When heating fat or grease, watch it closely. Fat or
grease may catch fire if allowed to become too hot.
•Use Only Dry Pot holders—Moist or damp pot holders
onhot surfaces mayresultin burnsfromsteam.Donot
let the pot holders touch the flame or burners. Do not use a
towel or other bulky cloth instead of a pot holder.
•Do Not Heat Unopened Food Containers—Buildup of
pressure may cause container to burst and result in
injury.
•Knowwhichknobcontrolseachsurfaceburner.Always
turntheknobtotheLITEpositionwhenignitingtheburners.
Visually check that the burner has lit. Then adjust the flame
so it does not extend beyond the edge of the utensil.
UseProper Flame Size—Adjustflamesize
soitdoesnotextendbeyondtheedgeoftheutensil.The
use of undersized utensils will expose a portion of the burner
flame to direct contact and may result in ignition of clothing.
Proper relationship of utensil to flame will also improve
efficiency.
IMPORTANT SAFETY INSTRUCTIONS
Readallinstructionsbeforeusingthisappliance.
Savetheseinstructionsforfuturereference.

4
IMPORTANT SAFETY INSTRUCTIONS (continued)
Donotuse stovetopgrills onyoursealed
gas burners. If you use a stove top grill on a sealed gas
burner, it will cause incomplete combustion and can result in
exposuretocarbon monoxide levelsaboveallowable current
standards. This can be hazardous to your health.
• Useproperpansize—Thisapplianceisequippedwithone
or more surface burners of different sizes. Select utensils
havingflatbottomlargeenoughtocoverthesurfaceburner.
The use of undersized utensils will expose a portion of the
surfaceburnertodirectcontactandmayresultinignitionof
clothing.Properrelationshipofutensiltothesurfaceburner
will also improve efficiency.
• Utensil Handles Should Be Turned Inward and Not
Extend Over Adjacent Surface Burners—Toreducethe
riskofburns, ignition of flammable materials,and spillage
duetounintentionalcontactwiththeutensil,thehandleof
theutensil shouldbe positionedso thatitisturnedinward,
and does not extend over adjacent surface burners.
• NeverLeaveSurfaceBurnersUnattendedatHighHeat
Settings—Boilovers cause smoking and greasy spillovers
that may ignite, or a pan that has boiled dry may melt.
• ProtectiveLiners—Donotusealuminumfoiltolinesurface
burnerpans.Protectivelinersoraluminumfoilmayinterfere
withheatandairdistribution,andcombustion.Damageto
the cooktop or personal injury may result.
SAVE THESE INSTRUCTIONS
• Glazed Cooking Utensils—Only certain types of glass,
glass/ceramic, ceramic, earthenware, or other glazed
utensilsaresuitableforcooktopservicewithoutbreakingdue
to the sudden change in temperature. Check the
manufacturer'srecommendationsforcooktopuse.
• DoNotUseDecorativeSurfaceBurnerCovers.Ifaburner
is accidentally turned on, the decorative cover will become
hot and possibly melt. You will not be able to see that the
burner is on. Burns will occur if the hot covers are touched.
Damagemayalsobedonetothecooktoporburnersbecause
the covers may cause overheating. Air will be blocked from
theburner andcause combustionproblems.
TEMPERED-GLASS COOKTOPS (some models):
• Do Not Operate or Clean a Broken Cooktop Glass—If
glasstopshouldbreak,cleaningsolutionsandspilloversmay
penetrate the broken cooktop and create a risk of electric
shock. Contact a qualified technician immediately.
• Clean Cooktop Glass with Caution—If a wet sponge or
cloth is used to wipe spills on a hot cooking area, be careful
to avoid a steam burn. Some cleaners can produce harmful
fumes if applied to a hot surface.
• DoNot PlaceHotCookware on theCooktop Glass. This
could cause glass to break.
• Avoidscratchingthecooktopglasswithsharpobjects.

5
Grounding Instructions(electric ignition models only)
IMPORTANT: READANDSAVETHESEINSTRUCTIONS.
Thisapplianceisequippedwitha3pronggroundingplugforyour
protection against shock hazard and should be plugged directly into a properly
groundedreceptacle.DONOTcutorremovethegroundingprongfromthisplug.
Forpersonalsafety,thiscooktopmustbeproperlygrounded. Formaximumsafety,
the power cord must be plugged into a 120V—60 Hz. outlet that is correctly
polarizedandproperlygrounded.
If a two-prong wall receptacle is the only available outlet, it is the personal
responsibilityoftheconsumertohaveitreplacedwithaproperlygroundedthree-
prong wall receptacle installed by a qualified electrician.
DO NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE THIRD ROUND
GROUNDING PRONG FROM THE POWER CORD PLUG. SEE THE INSTALLATION
INSTRUCTIONSPACKAGEDWITHTHISCOOKTOPFORCOMPLETEINSTALLATION
AND GROUNDING INSTRUCTIONS. DO NOT OPERATE THE COOKTOP USING A
TWO-PRONG ADAPTER OR AN EXTENSION CORD.
LiquefiedPetroleum(Propane)GasConversion
Severe shock or damage to the cooktop may occur if the cooktop is not installed by a qualified installer or
electrician.
This appliance can be used with Natural Gas and Propane Gas. It is shipped from the factory for use with natural gas.
If you wish to convert your cooktop for use with Liquefied Petroleum (propane) gas, for some models you should order the
conversion kit from your local dealer or from an authorized service agency (see Warranty). See the installation instructions for
the conversion kit number (for models with sealed burners only).
Forothermodels theconversion kitisincluded inthe packaging,ifyou wishto convert yourcooktop forusewith propanegas,
usethesuppliedfixedorificeslocatedinthepackagecontainingtheinstallationinstruction,inabagmarked"FORLP/PROPANE
GAS CONVERSION". Follow the instructions packaged with the orifices (for models with sealed burners only).
Formodels withopen burners,seetheinstallationinstructionsguidefor theconversion instructions.
The conversion must be performed by a qualified service technician in accordance with the manufacturer's instructions and all
codesandrequirementsoftheauthorityhavingjurisdiction.Failuretofollowtheinstructionscouldresultinseriousinjuryorproperty
damage. The qualified agency performing this work assumes responsibility for the conversion.
Flame Size
For most cooking,starton thehighestcontrol settingandthen turntoa loweroneto complete
theprocess.Use thechart below asa guide fordetermining properflamesize forvarioustypes of
cooking. The size and type of utensil used and the amount of food being cooked will influence
the setting needed for cooking.
For deep fat frying,use a thermometer and adjust the surface control knob accordingly. If the
fatistoo cool, thefood will absorbthe fat andbegreasy. If thefat is toohot,the foodwillbrown
so quickly that the center will be undercooked. Do not attempt to deep fat fry too much food at
once as the food will neither brown nor cook properly.
* These settings are based on using medium-weight aluminum pans with lids. Settings
may vary when using other types of pans.
Avoid fire hazard or
electrical shock. Do not use an adaptor
plug, an extension cord, or remove
grounding prong from electrical power
cord. Failure to follow this warning can
cause serious injury, fire or death.
Do not, under any
circumstances, cut,
remove, or bypass
the grounding prong.
Power supply cord with
3-prong grounding plug
Grounding
type wall
receptacle
*Flame Size
High Flame
Medium Flame
Low Flame
Type of Cooking
Start most foods; bring water to a boil; pan broiling
Maintain a slow boil; thicken sauces, gravies; steam
Keep foods cooking; poach; stew
Never extend the flame
beyond the outer edge of
the utensil. A higher flame
simply wastes heat and
energy, and increases your
risk of being burned by the
flame.
RIGHT
WRONG

6
Proper Burner Adjustments
Thecoloroftheflameisthekeytoproperburneradjustment.Agoodflameisclear,blueandhardlyvisibleinawell-lightedroom.
Each cone of flame should be steady and sharply defined. Adjust or clean burner if flame is yellow-orange. To clean burner, see
instructionsunderGeneralCleaning.Eachburnerlightsautomaticallyfromanelectricignitoreachtimeacontrolknobisturned
to the LITE position.
Setting Surface Controls
To operate the surface burner:
1. Place cooking utensil on burner.
2. Pushin andturnthe SurfaceControl knobtoLITE.Note: All electronicignitors willclick
at the same time. However, only the burner you are turning on will ignite.
3. Visually check that the burner has lit.
4. Aftertheburnerlights,turnthecontrolknobtothedesiredflamesize.Thecontrolknobs
donothavetobesetataparticularmark.Usetheguidesandadjusttheflameasneeded.
DO NOT cook with the control knob in the LITE position. (The electronic ignitor will
continue to click if left in the LITE position.)
5. To turn the burner off, turn the control knob as far as it ill go, to the OFF position.
ElectricIgnitionModels
In the event of an electrical power outage, the surface burners can be lit manually. To light a surface burner, hold a lit match to
the burner head, then slowly turn the surface control knob to LITE. Use caution when lighting surface burners manually.
Surface burner in use when an electrical power failure occurs will continue to operate normally.
Do notoperatethe burnerforan extendedperiodof timewithoutcookware onthegrate.Thefinishon
the grate may chip without cookware to absorb the heat.
Do not place plastic items such as salt and pepper shakers, spoon holders or plastic wrappings on top
ofthecooktopwhenitisinuse.Theseitemscouldmeltorignite.Potholders,towelsorwoodspoonscouldcatchfireifplaced
too close to a flame.
Selecting Surface Cooking Utensils
For best results and energy conservation, choose cooking utensils that have these characteristics:
Pansshould haveflat bottoms.Check for
flatnessby rotatingaruleracrossthebot-
tom. There should be no gaps between
the pan and ruler.
Note:Always useautensil forits intend-
ed purpose. Follow manufacturer's in-
structions.Someutensils werenot made
tobe usedin theovenoronthecooktop.
*Specialty pans such as lobster pots, griddles and pressure cookers may be used
butmustconform to the aboverecommendedcookware requirements.
Note:Do notuse griddleover morethan
one burner. That can damage your
cooktop and that can result in exposure
to carbon monoxide levels above allow-
ablecurrentstandards. Thatcanhazard-
ous to your health.
*GOOD
Flat bottom and straight sides.
Tight fitting lids.
Weight of handle does not tilt
pan. Pan is well balanced.
Pan sizes match the amount
of food to be prepared.
Made of a material that
conducts heat well.
Easy to clean.
POOR
Curved and warped pan bottoms.
Pan overhangs unit by more than
one inch or 2.5 cm.
Heavy handle tilts pan.
Flame extends beyond unit

7
DO NOT use a wok if it is equipped
with a metal ring that extends
beyond the burner unit. Because this
ring traps heat, the surface unit and
cooktop surface could be damaged.
Specialty Pans & Trivets Woks with flat bottoms suitable for
use on your cooktop are available in
most cookshop or hardware stores.
Round-bottomed woks (with a
support ring that does not extend
beyond the burner unit) may also be
used. The metal ring was designed to
support the wok safely when it is
filled with large amounts of liquids
(soup making) or fat (frying).
Wire trivets: Donot usewire trivets. Cookwarebottoms mustbe indirect contact
withthegrates.
DO NOT use two burner units to heat one large pan such as a
roaster or griddle, or allow cooking utensils to boil dry. The bottom surface of the
panineither ofthesesituations couldcausediscoloring orcrazingof theappliance
cooking surface, and damage to the grates and burner units.
Canning Tips &
Information 1. Use tested recipes and follow instructions carefully. Check with your local
Cooperative Agricultural Extension Service or a manufacturer of glass jars for
thelatestcanning information.
2. Use flat-bottomed canners only. Heat is spread more evenly when the
bottomsurfaceis flat.
3. Center canner on the burner grate.
4. Start with hot water and a high heat setting to reduce the time it takes to
bring the water to a boil; then reduce the heat setting as low as possible to
maintain a constant boil.
5. It is best to can small amounts and light loads.
Prevent damage to cooktop and burner grates:
1. Do not use water bath or pressure canners that extend more than one inch
beyond the edge of the burner grate.
2. Do not leave water bath or pressure canners on high heat for an extended
amount of time.
3. Alternate surface units between each batch to allow the units and
surrounding surfaces to cool down. Try to avoid canning on the same burner
unit all day.
Safe canningrequires that harmfulmicro-organisms aredestroyed
and the jars are sealed completely. When canning in a water bath canner, a gentle
but steady boil must be maintained continuously for the required time.
Canning can generate
largeamountsofsteam.Useextremecau-
tion to prevent burns. Always raise the
lid to vent steam away from you.

8
Surfaces
Aluminum (Trim Pieces) &
Vinyl
Glass, Painted and Plastic
Control Knobs, Body
Pieces, and Decorative Trim
Control Panel
Stainless Steel, Chrome
Decorative Trim
Porcelain Enamel
BurnerGrates,Burner Pans
(somemodels),Burner Rings
(some models), Cooktop
Surface
Surface Burners
How to Clean
Use hot, soapy water and a cloth. Dry with a clean cloth.
For general cleaning, use hot soapy water and a cloth. For more difficult soils and built-up
grease, apply a liquid detergent directly onto the soil. Leave on soil for 30 to 60 minutes.
Rinse with a damp cloth and dry. DO NOT use abrasive cleaners on any of these materials;
they can scratch.
Beforecleaningthe controlpanel,turnall controlsto OFF andremovethecontrolknobs. To
remove, pull each knob straight off the shaft. Clean using hot, soapy water and a cloth. Be
sure to squeeze excess water from the cloth before wiping the panel; especially when
wiping around the controls. Excess water in or around the controls may cause damage to
the appliance. To replace knobs after cleaning, line up the flat sides of both the knob and
the shaft; then push the knob into place.
Gentlescouringwith asoapynylon padwill remove mostspots. Rinsewitha 1:1solutionof
clean water and ammonia. Cover difficult spots with an ammonia soaked paper towel for
30minutes,scrub witha nylonpadand rinsewithclean water. Cleanersmade especially for
stainless steel or chrome are recommended. Bluish stains on these materials are caused by
overheating and cannot be removed. Remove all cleaners or the finish may be damaged
during future heating. DO NOT use spray oven cleaners on the cooktop.
Clean burner grates in the dishwasher and dry upon removal. If soils are not removed,
followthecooktop cleaninginstructions below.
Gentlescouringwith asoapynylon padwill remove mostspots. Rinsewitha 1:1solutionof
clean water and ammonia. If necessary, cover difficult spots with an ammonia-soaked
paper towel for 30 to 40 minutes. Rinse with clean water and damp cloth, then scrub with
a soap-filled scoring pad. Rinse and wipe dry with a clean cloth. Remove all cleaners or the
porcelain may become damaged during future heating. DO NOT use spray oven cleaners
onthecooktop.
The holes in the burners of your cooktop must be kept clean at all times for proper ignition
and a complete, even flame. Clean the burner holes routinely with a small gauge wire or
needle and especially after bad spillovers which could clog these holes.
To remove and replace burner units per your model, see instructions under General
Cleaning. To clean, soak the burners in a 1:1 solution of ammonia and water for 30 to 40
minutes. For stubborn stains, scrub with soap and water or a mild abrasive cleanser and
dampcloth.Dry theburners thoroughlyina warmovenfor 30minutes. Thenreplacethem,
making sure they are seated and level. DO NOT wash burner units in the dishwasher.
General Cleaning
Cleaning Various Parts of Your Cooktop
Before cleaning any part of the cooktop, be sure all controls are turned OFF and the cooktop is COOL. Remove spillovers and
heavy soiling as soon as possible. Regular cleaning will reduce the number of major cleaning later.

9
General Cleaning(continued)
For Models with Open Burners (some models)
To Raise and Lower the Top for Cleaning
Thecooktopis hingedand can beraised to cleanthe areaunderneath.Be sureallcooktop controlsareturned toOFF and burner
grates are cool.
1. Remove controls knobs, burner grates and spillover bowls. Set aside.
2. Grasp the front of the cooktop and lift. Some models have a swing-up rod to support the cooktop in its raised position.
3. Clean under the cooktop.
4. Lower the top gently after lowering the support rod (some models).
5. Replace bowls, grates and control knobs.
When lowering thetop,grasp thesideswith fingertipsonly.Becareful notto pinch fingers.Also, DO NOT drop
or bend the cooktop when raising or lowering. This could damage the surface.
DO NOT turnon theburners whenthe cooktopisraisedforcleaning.Besurethatthetopis completelylowered
and securely in place before turning on the burners.
To Remove and Replace Burners
The burners on your cooktop maybe removed for cleaning. Be sure all controls are turned to OFF and burner grates are cool
beforeremoving cooktopburnerunits.
To Remove Burners
1. Removetheshipping screwsfrom thesupportbracket. Seeillustrations forlocationof
screws.
2. Graspthe burnerhead andtilt ittotherighttoreleasethetabfromtheburnersupport
(A in Figure 1).
3. Lift the end of the burner assembly. Then pull away from the front of the cooktop to
free the air shutter from the gas valve orifice (B in Figure 1).
If your cooktop is equipped with a standing gas pilot, use caution when removing burner.
The flash tube may be hot because it is located near the pilot.
Check the lighter and burner ports (Figure 2). If they are clogged, use a wire or needle to
clear them.
To remove burned-on food, soak the burners in a vinegar and water solution for
20-30minutes.For stubbornstains,scrub withsoapand waterora mildabrasivecleanser
and a damp cloth. Do not wash burners in a dishwasher.
To Replace Burners
1. Slide the air shutter over the gas valve orifice (Figure 1).
2. Lower the burner assembly and hook the tab in the slots in the burner support. Make
sure it is properly seated and level.
3. Be sure both tabs are in the correct slots, the burner sits level and straight, and the
flash tube forms a straight line from the igniter to the burner (Figure 2).
4. Replace shipping screws if desired. These screws are not necessary for the operation
of the burner. They stabilize the burner during shipping of the appliance. Retain the
screws for later use in the event the range is moved.
Figure1
Figure2

10
General Cleaning(continued)
For Models with Sealed Burners (some models)
Unlike the standard gas range, THIS COOKTOP IS NOT REMOVABLE. Do not attempt to remove or lift the cooktop.
Before cleaning the cooktop, be sure the controls are turned to OFF and the cooktop is COOL.
To Clean the Cooktop
The cooktop is designed to make cleaning easier. Because the four burners are sealed, cleanups are easy when spillovers are cleaned up
immediately. To clean, wipe with a clean, damp cloth and wipe dry.
Tempered-glass Cooktop (some models)
Correct and consistent cleaning is essential to maintaining your heat-resistant glass top. Spills and
spatters should be wiped up using a clean paper towel and sudsy water. This should be done either
as soon as possible after spill occurs, after cooking is completed, or at the latest, before using the
cooktopagain.Usecautionifthecooktopishot.Forheavyspills,spatterorburned-onmaterials,use
razorblade scraper.Holdtherazorblade scraperat a30°angle andremove foodspillsorburnedon
foodresidue.
Finish the cleaning process by applying a recommended heat- resistant glass cooktop cleaning
cream.Apply cleanerwith clean,damppapertowel.Rinsewithapapertowel dampenedwith clean
water and wipe dry. Always wipe the cooktop thoroughly to avoid heating any cleaner residue.
Do NOT use the following on the heat-resistant glass cooktop:
- Abrasive plastic, nylon, metal scouring or cloth pads. They may scratch the cooktop and make it
moredifficulttocleanlater.Alwaysuseanew,cleanpapertowelwhencleaningtheheat-resistant
glasstop.
- Anything that may melt (plastics, aluminum foil, sugar or food with a high sugar content).
- Heavy duty cleansers, rust or stain removers.
- Chlorine bleach, ammonia, hydrofluoric acid or any other kind of chemical cleaners. They may etch or discolor the cooktop.
- Sponges,clothsor dishtowels.Alwaysuseanew,cleanpapertowelwhencleaningthecooktop.Lintorsoilremainingon the
cooktop from a cloth or sponge can burn and cause discoloration.
To Clean the Burner Grates, Contoured Burner Pans, Burner Cap and Burner Base
Theburnergrates,contouredburnerpans,burnercapsandburnerbaseshouldberoutinelycleaned.Keepingtheburnerportsclean
will prevent improper ignition and an uneven flame. See instructions below.
To Clean the Burner Grates
Be sure burners and grates are cool before you place your hand, a pot holder,
cleaningclothsorothermaterialonthem.Thecastironburnergratescanbewashed
inhotsoapywater.Rinsethoroughlyanddrythegrateswithacloth-don'tputthem
on the cooktop while still wet. Be sure the grates are positioned securely over the
burners.
To remove burned on food, place the grates in a covered container or plastic bag.
Add 1/4 cup ammonia and soak for 30 minutes. Wash, rinse well and dry. An
abrasive cleaner can be used for stubborn stains.
To Clean the Contoured Burner Pans
The burner pans are attached to the cooktop and are not removable. The burner pan forms a recessed well area located around
each burner unit. If spill occurs in one of the well areas, blot up spill with an absorbent cloth. Rinse with a clean, damp cloth and
wipe dry.
Heavy
burned-on
spills can be removed
with a razor blade scraper. Use
caution to avoid damaging
surface.
Burner grate can appear in different shapes.

11
General Cleaning (continued)
For Models with Sealed Burners (some models) (continued)
To Clean the Burner Cap
Remove burner cap. Use soap-filled pad or mild abrasive cleanser to clean burner
caps.Ifnecessary, coverstubborn spots withan ammonia-soakedpapertowel for
30minutes.Rubgentlywithamixtureofcleanwaterandvinegar.Wipedry.Remove
all cleaners or the porcelain may become damaged during future heating.
To Clean the Removable Burner Base and Gas Opening (some models)
Theports(orslots)aroundtheburnerbase mustberoutinely cleaned.Usea small-
gauge wire or needle to clean small slots or holes.
Note: If the electrode is damaged or broken, the surface burner will not light
because it will not spark. Manual lighting with a match is still possible.
Forproperflow ofgasand ignition ofthe burner -DO NOT ALLOWSPILLS, FOOD,
CLEANING AGENTS OR ANY OTHER MATERIAL TO ENTER THE GAS OPENING
TUBE.Gasmustflowfreelythroughthesmallholeinthebrassorificefortheburners
tolightproperly.Ifthe gasopeningorificebecomessoiled orclogged,use asmall-
gaugeorneedletoclean.ALWAYSkeeptheburnercapinplacewheneverasurface
burner is in use.
To Replace the Burner Base and the Burner Cap
Make sure the pieces are thoroughly dry before placing back.
1.Replace burner base and burner cap at there place. Make sure each burner cap
and burner base are properly aligned and leveled.
2. Replace the burner grate.
3. Turn the burner on to determine if it light. If the burner does not light after
cleaning, contact an authorized servicer. Do not service the sealed burner
yourself.
Gas
Opening
Burner Cap
Burner
Base
Electrode
Sealed Burner

OCCURRENCE
Surface burners do not light.
Surface burner flame burns half way
around.
Surface burner flame is orange.
POSSIBLE CAUSE/SOLUTION
Surface Control knob has not been completely turned to LITE. Push in and turn the
Surface Control knob to LITE until burner ignites and then turn control to desired
flame size.
Be sure gas supply valve is open.
Gas-airmixtureneedsastraight lineto travel.Besure burneris properlyseatedin its
support(modelswith openburners only).
Burner ports or slots are clogged. With the burner off, use a small-gauge wire or
needle to clean ports or slots.
Power cord is disconnected from outlet (electric ignition models). Be sure cord is
pluggedsecurelyinto outlet.
Electrical power outage (electric ignition models). Burners can be lit manually. See
Setting Surface Controls in this Owner'sGuide.
Burner ports or slots are clogged. With the burner off, clean ports with a small-
gauge wire or needle to clean ports or slots.
Moistureis presentaftercleaning. Lightlyfan theflame andallow burnertooperate
untilflameis full.Drythe burnersthoroughlyfollowing instructionsunderGeneral
Cleaning.
Dust particles in main line. Allow the burner to operate a few minutes until flame
turnsblue.
In coastal areas, a slightly orange flame is unavoidable due to salt air.
12
Avoid Service Checklist
Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not
the result of defective workmanship or materials in this appliance.

FRIGIDAIRE COOKTOP WARRANTY
Your Frigidaire product is protected by this warranty (for United States)
FULLONE-YEAR
WARRANTY
LIMITEDWARRANTY
(Applicabletothe
StateofAlaska)
WARRANTY
PERIOD
One year from original
purchasedate.
Timeperiodlistedabove.
FRIGIDAIRE,THROUGHITSAUTHORIZED
SERVICERS,WILL:
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship.
All of the provisions of the full warranty above and the
exclusions listed below apply.
THECONSUMERWILLBE
RESPONSIBLEFOR:
CostsofservicecallsthatarelistedunderNORMAL
RESPONSIBILITIESOFTHECONSUMER.*
Costsofthetechnician'straveltothehomeandany
costs for pick up and delivery of the appliance
required because of service.
Your appliance is warranted by Frigidaire Home Products, a division of White Consolidated Industries, Inc. We authorize no person to change
or add to any of our obligations under this warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire
Home Products Consumer Services or an authorized Frigidaire servicer.
This warranty applies only to products in ordinary household use, and the consumer is responsible for the
items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which
are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation
or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by persons other than authorized Frigidaire servicers; use of parts other than
Frigidaire Home Products Genuine Renewal Parts; obtained from persons other than such servicers; or external causes
such as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keepyour billofsale,deliveryslip, orsomeotherappropriatepayment record. Thedateonthebill establishesthewarranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This
written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under
this warranty must be obtained by following these steps, in order:
1. Contact Frigidaire Home Products Consumer Services or an authorized Frigidaire servicer.
2. If there is a question as to where to obtain service or parts, call or write our Consumer Relations Department at:
Frigidaire Home Products Consumer Relations
P.O. Box 212378
Augusta, Georgia 30917-2378
[phone]
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made
by White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IFYOUNEED
SERVICE

WARRANTY (for Canada)
GAS COOKTOP
For service under this warranty, contact your local dealer/
retailer, authorized FRIGIDAIRE PARTS AND SERVICE depot
or:
FRIGIDAIRE PARTS AND SERVICE
7075 Ordan Drive
Mississauga, Ontario, L5T 1K6
Tel: [phone]
Fax: [phone]
WARRANTOR WILL, THROUGH ITS
AUTHORIZED SERVICE DEPOT:
Pay all costs to repair or replace defective parts.
Pay cost (excluding service and labour charge) to replace
defective burners.
WARRANTOR:
FRIGIDAIRE HOME PRODUCTS
7075 Ordan Drive
Mississauga, Ontario
L5T 1K6
This cooktop is a branded product of Frigidaire Home
Products.
WARRANTY PERIOD:
For the first year after purchase by the original owner.
For the second, third, fourth and fifth years after purchase
by the original owner.
WARRANTY APPLIES TO:
a) Products purchased and installed in Canada for personal single family household use.
b) Defects resulting or arising out of the manufacturing process.
c) Products bearing legible manufacturer's model and serial number.
d) Replacements parts only for the remainder of the original warranty.
WARRANTY DOES NOT APPLY TO:
a) Transportation damage.
b) Supply and replacement of porcelain, fuses and glass.
c) Parts and service supplied or obtained from other than FRIGIDAIRE PARTS AND SERVICE or FRIGIDAIRE PARTS AND
SERVICE authorized depots.
d) Damage or failure as the result of the abuse, improper or commercial use.
CONSUMER/OWNER RESPONSIBILITY:
a) To provide proof of the original date of purchase by means of a bill of sale verifying purchase date.
b) To pay all costs to make the appliance readily accessible for service.
c) To ensure proper power supply and connection of the appliance to the same.
d) Proper installation, control setting and care of finish.
This warranty is in addition to any statutory warranties contained in any applicable legislation. The terms and conditions of this
warranty are not intended to exclude or limit your rights under those statutes. The warrantor however reserves the right to
charge transportation and travelling costs for distances in excess of 48 kilometers (30 miles) from the nearest FRIGIDAIRE PARTS
AND SERVICE authorized service depot.
This warranty plus the statutory warranties mentioned are the only warranties given to the consumer/owner for this product.

Guide de
l'utilisateur
Table de cuisson
à gaz
P/N 318200650 (0005) Rev. D

2
© 2000 White Consolidated Industries
Tous droits réservés
Enregistrement de
l'appareil
Contenu 3-4 Mesures importantes desécurité
5 Instructions de mise à la terre
5 Conversion au gaz propane
5 Dimension de la flamme
6 Bonréglagedes brûleurs
6 Commandes des brûleurs de surface
7 Choix des ustensiles de cuisine pour la cuisson sur les brûleurs
8 Casserolesetsous-plats particuliers
8 Conseils et renseignements sur la mise en conserve
Nettoyage Général
9 Nettoyage des diverses parties de votre table de cuisson
10 Pour les modèles avec brûleurs ouverts
11-12 Pour les modèles avec brûleurs scellés
13 Liste des vérifications préventives
14 Garantie
Remarque: Les instructions données dans ce guide ne couvrent pas toutes les
conditions et situations possibles. Usez de bon sens et de prudence lors de
l'installation, de l'emploi et de l'entretien de tout appareil ménager.
Enregistrez votre appareil
LaCARTE D'ENREGISTREMENTdoit
être remplie avec soin, puis signée et
retournée à la compagnie Frigidaire.
Nous vous remercions d'avoir choisi cet appareil. Les informations contenues
dansceguidedel'utilisateurvousindiquerontcommentutilisercorrectementvotre
appareiletcommentenprendresoin.Veuillezliretouslesrenseignementscontenus
dans votre documentation pour mieux connaître votre nouvel appareil.
Enregistrezlesnumérosdemodèleetdesériedevotreappareil
Écrivez ci-dessous ces numéros que vous trouverez sous la table de cuisson ou à
l'intérieur de celle-ci.
Numéro de modèle: _________________________________________________
Numéro de série:____________________________________________________
Date de l'achat: _____________________________________________________
POUR VOTRE SÉCURITÉ:
n'entreposez pas ou n'utilisez pas de l'essence ou tout autre
vapeurouliquideinflammableauvoisinagedecetappareiloude
tout autre appareil ménager.
— QUE FAIRE SI VOUS DÉTECTEZ UNE ODEUR DE GAZ:
• Ne mettez pas d'appareil en marche.
• Ne touchez pas à un commutateur électrique; ne vous servez
pas du téléphone dans le bâtiment.
• Allez chez le voisin et appelez immédiatement le fournisseur
de gaz. Suivez ses instructions.
• S'iln'estpaspossibled'appelerlefournisseurdegaz,appelez
les pompiers
L'installation et l'entretien doivent être réalisés par un
installateur qualifié, un technicien de service après-vente ou le
fournisseur de gaz.
Si l'information contenue dans ce guide n'est
pasexactementsuivie,ilpourraitenrésulterunfeuouuneexplosion
entraînant des dommages matériels, blessures ou même la mort.
Ce guide contient des instructions
générales pour votre table de cuisson et
desrenseignementss'appliquantàplusieurs
modèles.Votretable de cuissonpeut ne
pas avoir toutes les caractéristiques
décrites.

3
Ceguide contientdesinstructionsetsymbolesdesécurité importants.Veuillez faireparticulièrementattentionàces symboleset
suivre les instructions données. Voici une brève explication de ces symboles.
Ce symbole vous prévient des situations qui risquent d'entraîner de graves blessures, la mort ou des
dommages matériels.
Ce symbole vous prévient des situations pouvant entraîner des blessures ou dommages matériels.
• Enleveztoutlerubanetlematériaud'emballageavant
d'utiliserlatabledecuisson.Détruisezlecartonnageet
lessacsenplastiqueaprèsledéballagedel'appareil.Ne
laissezjamaislesenfantsjoueraveclematériaud'emballage.
•Installation—Assurez-vous que l'appareil est
correctementinstalléetmisàlaterreparuntechnicien
qualifié, conformément à la dernière édition de la
normeANSIZ223.1duNationalFuelGazCodeauxÉtats
Unis,ouauCanada,conformémentauxnormesB149.1
etB149.2CAN/ACGetaussiconformémentàladernière
édition de la norme n° 70 ANSI/NFPA du National
ElectricalCodeauxÉtatsUnis,ouauCanada,àlanorme
C22.1del'ACNOR,codecanadiendel'électricité,partie
1, ainsi qu'aux codes de la région. N'installez l'appareil
que selon les instructions d'installation fournies dans la
documentation.
Demandez à votre marchand de vous recommander un
technicien qualifié ainsi qu'un centre de réparation autorisé.
Sachez comment couper le gaz au compteur et couper le
courant électrique de la table de cuisson à la boîte de fusibles
ou au coupe-circuit en cas d'urgence.
• Entretienparl'usager—Neréparezpasouneremplacez
pas des pièces de l'appareil à moins d'une
recommandation précise dans les guides. Toutes les
réparationsdoiventêtrefaitesparuntechnicienqualifié,afin
deréduirelesrisquesdeblessureetdedommageàl'appareil.
• Ne modifiez jamais l'appareil, que ce soit en enlevant
des panneaux, protège-fils, ou toute autre pièce.
Il peut être dangereux pour les
personnes ou dommageable pour la table de cuisson de
monter ou de s'appuyer dessus. Ne laissez pas les enfants
grimper sur l'appareil ou jouer autour.
• Rangementsurl'appareil—Nerangezpassurlatablede
cuisson ou près des brûleurs de surface, des matériaux
inflammables. Ceci inclus des papiers, plastiques, tissus,
livresdecuisine,objetsenplastiqueettorchons,ainsiquedes
liquides inflammables. N'y posez pas des produits explosifs
comme bombes aérosol. Les produits inflammables
pourraient exploser et allumer un feu ou causer des
dommages matériels.
Ne rangez pas des articles pouvant
intéresser les enfants dans les armoires au-dessus de
l'appareil.
• Nelaissezpaslesenfantssanssurveillancedansunlieu
où un appareil fonctionne. Ne les laissez jamais s'asseoir
ou se tenir debout sur une pièce quelconque de l'appareil.
• NE TOUCHEZ PAS AUX BRÛLEURS DE SURFACE, AUX
GRILLES OU AUX ZONES À PROXIMITÉ DE CEUX-CI. Les
brûleursdesurfacepeuventêtresuffisammentchaudsmême
silesflammesnesontpasvisibles.Leszonesprèsdesbrûleurs
peuvent devenir suffisamment chaudes pour causer des
brûlures.Pendantetaprèstouteutilisation,netouchezpaset
nelaissezpasvosvêtementsouautresproduitsinflammables
venir en contact avec ces zones à moins qu'elles aient eu le
temps de se refroidir. Ces zones comprennent la surface de
cuisson et les surface orientées vers elle.
• Portezdesvêtementsappropriés—Neportezjamaisde
vêtementamplesouflottantsenutilisantcetappareil.
Ne laissez pas les matériaux inflammables et les vêtements
venir en contact avec les surfaces chaudes.
N'utilisez jamais votre appareil
pour réchauffer ou chauffer une pièce.
• N'éteignezpaslesfeuxdefritureavecdel'eauoudela
farine—Étouffez les feux avec un couvercle ou du
bicarbonate de soude, ou avec un extincteur à poudre
sèche ou à mousse.
•En chauffant de l'huile ou de la graisse, restez près de
l'appareil. La graisse ou l'huile peuvent prendre feu si elles
devenaienttropchaudes.
•N'utilisez que des gants isolants secs—Des gants
isolants mouillés ou humides en contact avec des
surfaces chaudes peuvent causer des brûlures par la
vapeur.Nelaissezpaslesgantsisolantstoucherlesbrûleurs
ou la flamme. Ne vous servez pas de torchon ni de chiffon à
la place d'un gant isolant.
•Ne réchauffez pas des contenants non ouverts—
L'accumulation de pression peut faire exploser le
contenantet blesser.
Mesures importantes de sécurité
Lisezcesinstructionsavantd'utiliserl'appareil.
Conservercesdirectivespourréférencefuture.

4
MESURES IMPORTANTES DE SÉCURITÉ(suite)
•Vous devez savoir quel bouton commande chacun des
brûleursdesurface. Tournezleboutonàlaposition"LITE"
(ALLUMAGE) pour mettre les brûleurs en marche. Vérifiez
que le brûleur est allumé puis réglez la flamme pour qu'elle
ne dépasse pas de l'ustensile.
Bonne dimension de la flamme—
Réglezla flammepour qu'ellene dépassepasdu bordde
l'ustensile. Avecdesustensilesdedimensioninsuffisante,une
partie de la flamme du brûleur sera exposée et risquera de
mettre la feu aux vêtements. Un bon contact entre l'ustensile
et la flamme améliore aussi l'efficacité.
N'utilisezpas desgrilles de réchaud
sur vos brûleurs à gaz scellés. Sinon, la combustion serait
incomplète et il pourrait en résulter un dégagement de mo-
noxydedecarbone àdesdoses supérieuresauxniveaux admis,
ce qui serait dangereux pour votre santé.
• Utilisez la grosseur de casserole appropriée—Cet
appareil est équipé d'un ou plusieurs brûleurs de surface de
différentes grosseurs. Choisissiez les ustensiles ayant un
dessous plat, assez large pour recouvrir le brûleur. Si vous
utilisezdesustensilestroppetits,unepartie dubrûleurseraà
découvert, et les vêtements entrant directement en contact
aveclebrûleursontsusceptiblesdeprendrefeu. L'utilisation
d'ustensiles d'une taille proportionnelle au brûleur améliore
aussi le rendement.
• Les poignées d'ustensiles doivent être tournées vers
l'intérieur, sans surplomber les brûleurs adjacents, afin
de réduire les risques de brûlure, de combustion et de
renversements causés par le contact involontaire avec un
ustensile.
• Ne laissez jamais les brûleurs de surface sans
surveillance à des réglages élevés—Les débordements
causent de la fumée, les éclaboussures de graisse sont
susceptibles de prendre feu et les ustensiles dont le contenu
s'est évaporé peuvent fondre.
• Protecteurs—N'utilisez pas de papier d'aluminium pour
recouvrir les cuvettes des brûleurs de surface ou toute autre
partiede l'appareil. Utilisezseulement lepapier d'aluminium
pour recouvrir la nourriture durant la cuisson au four. Toute
autre utilisation de protecteurs ou de papier aluminium est
susceptibledecauser unchocélectrique, un feuou un court-
circuit.
• Ustensile vitrifiés—Enraisonde brusqueschangementsde
température,onnepeututiliseraveclasurfacedecuissonque
certains ustensiles en verre, en vitrocéramique ou en terre
cuite, ou autres ustensiles vitrifiés, sans risquer qu'ils se
fendent. Vérifiez les recommandations du fabricant quant à
leur utilisation sur une surface de cuisson.
• N'utilisez pas de couvercle de brûleur décoratif. Si un
brûleur est accidentellement allumé, le couvercle risque de
chauffer et éventuellement de fondre. Vous risquez de vous
brûler en touchant le couvercle. Aussi, il y a risque
d'endommagementdelasurfacedecuissonetdesbrûleurss'il
y a surchauffe du couvercle. L'air sera aussi bloqué, ce qui
entraîneradesproblèmes de combustion.
SURFACE EN VERRE TREMPÉ (certains modèles):
• Nenettoyezpasetnefaitespasfonctionnerunetablede
cuisson avec une vitre cassée—Si le verre de la surface est
fissuré, les solutions de nettoyage et produits renversés
pourraient pénétrer à l'intérieur de la surface de cuisson et
entraîner un risque de décharge électrique. Prenez contact
immédiatement avec un technicien qualifié.
• Nettoyezprudemmentleverredelasurfacedecuisson—
Si vous utilisez un linge ou une éponge humide pour enlever
lesproduitsrenverséssurunesurfacedecuissonchaude,faites
attentionànepasvousbrûlerparlavapeur. Certainsproduits
de nettoyage peuvent dégager des vapeurs dangereuses s'ils
sont appliqués sur une surface chaude.
• Neplacezpasd'ustensilesdecuisine chauds sur leverre
de la table de cuisson. Ceci pourrait le casser.
• Éviter de gratter le verre de la table de cuisson avec des
objets pointus.
CONSERVEZ CES INSTRUCTIONS

5
Instructions de mise à la terre
(modèles à allumage électrique seulement)
IMPORTANT: LIRE ET CONSERVER CES INSTRUCTIONS.
Cet appareil est équipé d'une fiche à trois broches avec
mise à la terre pour assurer votre protection contre les chocs électriques. Cette
fichedoitêtrebranchéedirectement dansuneprisecorrectementmiseàlaterre.
Ne coupez PAS, n'enlevez pas la broche de mise à la terre de cette fiche.
Pour des raisons de sécurité personnelle, cette table de cuisson doit être
correctement mise à la terre. La fiche doit être branchée dans un prise
correctement polarisée et mise à la terre, de 120 volts, 60 hertz.
Si une prise murale à deux alvéoles est la seule prise à votre disposition, il vous
revientdedemanderàunélectricienqualifiédelaremplacerparuneprisemurale
à trois alvéoles correctement mise à la terre.
EN AUCUN CAS, IL NE FAUT COUPER OU ENLEVER LA BROCHE DE MISE À LA
TERRE DE CETTE FICHE. CONSULTEZ LES INSTRUCTIONS D'INSTALLATION
EMBALLÉESAVECCETAPPAREILPOURYTROUVERTOUSLESRENSEIGNEMENTS
SUR L'INSTALLATION ET LA MISE À LA TERRE. VOUS NE DEVEZ JAMAIS VOUS
SERVIR DE L'APPAREIL AVEC UN CORDON PROLONGATEUR OU D'UNE FICHE
D'ADAPTATION À DEUX BROCHES.
Conversion au gaz propane
Unchocélectriqueoudesdommagesàlatabledecuissonpeuventseproduiresicelle-cin'estpasinstallé
par un électricien ou installateur qualifié.
Cet appareil peut être utilisé avec le gaz naturel ou le gaz propane. Il est expédié de l'usine pour fonctionner au gaz naturel.
Sivousdésirezconvertirvotretabledecuissonpourqu'ellefonctionneaugazpropane,pourcertainsmodèles,consultezlefeuillet
d'installationpoursavoirquelestlenumérodukitdeserviceconversionàcommander(Modèlesavecbrûleursscellésseulement).
Pour d'autres modèles, le kit de service conversion est fourni avec l'appareil, servez-vous des orifices fournis dans l'enveloppe
portant l'inscription "POUR LA CONVERSION AU GAZ PROPANE" qui se trouve dans la pochette des documents. Suivez les
instructions d'installation se trouvant dans l'enveloppe (Modèles avec brûleurs scellés seulement) .
Pourlesmodèlesavecbrûleursouverts,suivezlesinstructionsdeconversionquisetrouventdanslefeuilletinstructionsd'installation.
Laconversiondoitêtreréaliséparuntechnicienqualifiéconformémentauxinstructionsdufabricantetdetouslescodesetexigences
des autorités ayant juridiction. Sinon, il pourrait en résulter de graves blessures ou des dommages matériels. L'agence qualifiée
réalisant ces travaux assume la responsabilité de la conversion.
Dimension de la flamme
Pour presque tous les types de cuisson, commencez par le réglage le plus élevé, puis tournez
sur un réglage plus faible pour terminer la cuisson. Suivez le tableau ci-dessous pour déterminer
labonnedimension delaflamme correspondantauxdifférents typesdecuisson. Ladimension et
letype d'ustensilesutilisés ainsiquelaquantitéd'alimentsàcuireinfluencentle réglagenécessaire
pourlacuisson.
Pour la grande friture,servez-vousd'unthermomètre etréglezla commandeenconséquence.
Si la graisse est trop froide, la nourriture absorbe la graisse. Si la graisse est trop chaude, la
nourriture brunit rapidement et le centre n'est pas cuit. N'essayez pas de frire à un feu élevé une
trop grande quantité à la fois, la nourriture risquant de brunir ou de ne pas cuire correctement.
* Certains réglages sont basés sur l'utilisation de casseroles en aluminium de poids moyen avec couvercle. Les
réglages peuvent varier avec d'autres types de casseroles.
Éviter tout risque
de feu ou de choc électrique. Ne pas utiliser
de cordon prolongateur ni de fiche
d'adaptation. Ne pas enlever la broche de
mise à la terre du cordon électrique. Si cet
avertissement n'était pas suivi, il pourrait en
résulter de graves blessures, la mort ou un
incendie.
Ne jamais couper,
enlever ou mettre
hors circuit la broche
de mise à la terre de
cette fiche.
Cordon
d'alimentation
muni d'une fiche
à trois broches
avec mise à la
terre.
Prise murale
mise à la
terre
Ne laissez jamais la flamme
dépasser du bord extérieur
de l'ustensile. Une flamme
plus haute gâche chaleur et
énergie et augmente les
risques de brûlure.
Dimension de la flamme
FLAMME HAUTE ("HI")
FLAMME MOY ("MED")
FLAMME BASSE ("LO")
Type de cuisson
Pourdébuterlacuisson,pourfairebouillirdel'eau,pourfairegrillerde la viande
Maintiend'uneébullitionlente;épaississement des sauces;cuissonàlavapeur
Mijotage,pochage,continuationdelacuisson

6
Bon réglage des brûleurs
La couleur de la flamme est la clé d'un bon réglage. La flamme doit être transparente, bleue, et à peine visible dans une pièce
bien éclairée. Le cône doit être uniforme, aux contours précis. Réglez ou nettoyez le brûleur si la flamme est jaune-orange. Pour
nettoyer le brûleur, voyez les instructions à la section Nettoyage général.
Commandes des brûleurs de surface
Emploi du brûleur de surface:
1. Placez l'ustensile sur le brûleur.
2. Appuyez sur le bouton de commande et tournez-le sur "LITE" (ALLUMAGE).
3. Vérifiez que le brûleur est bien allumé.
4. Aprèsallumagedubrûleur,tournezleboutonjusqu'àl'obtentiondeladimensiondelaflamme
voulue.Leboutonpeutalorsêtretournéàdroiteouàgauchesansavoiràêtrepoussé.Lesboutons
n'ont pas à être réglés à un repère particulier. Servez-vous des guides et réglez la flamme au
besoin. Ne cuisez PAS avec le bouton à la position "LITE" (ALLUMAGE), vous risquez d'user
l'électrode de l'allumeur.
5. Pour arrêter le brûleur, tournez le bouton de commande le plus loin possible à droite jusqu'à "OFF" (ARRÊT).
Modèles avec allumeur électrique
Encasdepannedecourant,lesbrûleurspeuvents'allumeràlamain.Pourcefaire,approchezuneallumettede latêtedubrûleur
puis tournez lentement la commande sur "LITE" (ALLUMAGE). Ensuite, tournez le bouton à la dimension de la flamme voulue.
Soyez prudent lorsque vous allumez manuellement les brûleurs.
Les brûleurs de surface en cours d'utilisation lors d'une panne de courant continuent de fonctionner normalement.
Ne faites pas fonctionner le brûleur pendant une période de temps prolongée sans casserole sur la
grille. Le fini de la grille pourrait s'écailler si aucune casserole n'absorbe la chaleur.
Ne placez pas de salière et poivrière en plastique, de porte-cuillère ou d'emballage plastique sur le
dessusdela table decuissonencoursd'utilisation.Cesarticlespeuventfondreous'enflammer.Gantsisolants,torchonsou
cuillères en bois peuvent prendre feu s'ils sont placés trop près d'une flamme.
