Frigidaire FEC30S6A User manual

FEC30S6A.eps L21C0005.eps L21T0002.eps 318046807-1.eps 318046807-2.eps
8"
"
Product No. FEC30S6ABE FEC30S6ASE
3805422351065 3805423351015
Series 30" elec 30" elec
Color black white
Market North America North America
Wiring Diagram 318046807 318046807
Owner's Guide 318200612 318200612
Installation Instructions 318201410 318201410
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995434262
05/04/13
(EN/SERVICE/ECL)
377
ELECTRIC COOK-TOP
RANGE
Model No.
FEC30S6A
Copyright ©2005 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995434262 FEC30S6A
04/05 2
CONTROL PANEL

FEC30S6A Publication No: 5995434262
# Functional Parts 3 04/05
* Non-Illustrated Parts
CONTROL PANEL
Model Index: AFEC30S6A (FEC30S6ASE)
BFEC30S6A (FEC30S6ABE)
POS. NO PART NO. DESCRIPTION
16 318096327 A B Box, instrument mtg
36 318196633 A - Knob, control, white
36 318196634 - B Knob, control, black
51 # 318044820 A - Light, indicator, red
51 # 318044822 - B Light, indicator, clear
54 # 318220071 A B Switch, surface unit, small
54A# 318220072 A B Switch, surface unit, large
69 5303323134 A B Screw, 8-32 x 0.188
74 318148900 A B Bushing, switch
* 5303300265 A B Screw, 8-18 x 0.500, chrome, (3)
* 5303323140 A B Screw, ground, 10-32 x 0.375

Publication No: 5995434262 FEC30S6A
04/05 4
MAIN TOP/SURFACE UNITS

FEC30S6A Publication No: 5995434262
# Functional Parts 5 04/05
* Non-Illustrated Parts
MAIN TOP/SURFACE UNITS
Model Index: AFEC30S6A (FEC30S6ASE)
BFEC30S6A (FEC30S6ABE)
POS. NO PART NO. DESCRIPTION
15 # 318198817 A B Element, surface, small/6", 1200 W
15A# 318198818 A B Element, surface, large/8", 2200 W
15B# 318198819 A B Element, surface, 9", 2500 W
16 318079347 A - Main Top, white
16 318079348 - B Main Top, black
20 318121902 A B Bracket, retainer
23 318194703 A B Panel, service, black
46 318077232 A B Burner Box
52 318122007 A B Spring, element mtg, large
52A 318122010 A B Spring, element mtg, 1000W/2500W
52B 318122006 A B Spring, element mtg, small
159 318125113 A B Deflector
163 318014110 A B Spacer, (2)
* # 318078525 A B Box & wires assy
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303323129 A B Screw, 8 X 0.750

Publication No: 5995434262 FEC30S6A
04/05 6
WIRING DIAGRAM

FEC30S6A Publication No: 5995434262
# Functional Parts 7 04/05
* Non-Illustrated Parts
WIRING DIAGRAM
