Frigidaire FEC36S8HSB User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FEC36S8HSB 3805642599012 WHITE U.S.A.
FEC36S8HBB 3805642599062 BLACK U.S.A.
ELECTRIC - COOKTOP
Model No.
FEC36S8H
©2001 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
ELECTRIC COOKTOP
WIRING DIAGRAM # - 318047023
OWNER’S GUIDE # - 318200612
INSTALLATION SHEET # - 318201410
Publication No.
5995349189
010131
-EN/SERVICE
377
Gallery
WARMING ZONE
ELECTROLUX HOME PRODUCTS NORTH AMERICA
802, BOUL. L’ANGE-GARDIEN
L’ASSOMPTION, QC
CANADA, J5W 1T6
TEL.: [phone] (ENGLISH)
[phone] (FRANÇAIS)

Publication No. FEC36S8H
5995349189
01/01 2
CONTROL PANEL
69
36A 36A
36C
36
36 74
74
74
51
16
54
54A
54A
54C 54
69A
LA01CP80425-1

FEC36S8H Publication No.
5995349189
# = Functional Part 301/01
* = Non-Illustrated Part
CONTROL PANEL
POS. NO PART NO DESCRIPTION
16 318096320 A B Plate instrument mtg
36 318164500 AKnob-surface white
36 318164505 BKnob-surface black
36A 318164509 AKnob-surface white
36A 318164511 BKnob-surface black
36C 318016330 AKnob-surface white (warming-element)
36C 318016331 BKnob-surface black (warming-element)
51# 5303297484 A B Light-indicator,hot surface
54 # 318120505 A B Switch-surface unit,small
54A# 318191000 A B Switch surface unit
54C# 318078801 A B Switch-6” Element
69 5303323134 A B Screw, switch mtg. ,8-32 x 3/16
69A 5303305528 A B Screw, 8-32 X 1/4
74 5303321205 A B Bushing, (4)
*5303300265 A B Screw, 8-18 X ½ chrome
*5303323131 A B Screw, 8-32 X 7/16
*5303323140 A B Screw ground
A = FEC36S8H (FEC36S8HSB)
B = FEC36S8H (FEC36S8HBB)

FEC36S8H Publication No.
5995349189
01/01 4
MAINTOP/SURFACE UNITS
46
163
163
170
170
163
163
23
20
20
159
162
164
15A
15
52A
52
52D
52C
52B
15B
15D
15C
16
LA01CT80425-1

FEC36S8SH Publication No.
5995349189
# = Functional Part 501/01
* = Non-Illustrated Part
POS. NO PART NO DESCRIPTION
15# 318178102 A B Element-surface, 1700W
15A# 318050202 A B Element-surface,1000/1900W
15B# 318178000 A B Element-surface, 700/2100W
15C# 318178103 A B Element-warmer
15D# 318178100 A B Element-surface, 1200W
16 318079324 AGlass Maintop & frame assy
16 318079323 BGlass Maintop & frame assy
20 318121902 A B Bracket
23 5303297401 A B Panel-access
46 318077221 A B Box-burner
52 318122008 A B Spring-element mtg
52A 318122009 A B Spring-element mtg
52B 318122007 A B Spring-element mtg
52C 318122004 A B Spring-element mtg
52D 318122006 A B Spring-element mtg
159 318125121 A B Deflector
162 318125200 A B Deflector
163 08007817 A B Spacer
164 318125301 A B Plate-connection
170 318124900 A B Support-thermal
* # 318078514 A B Box & wires assy
*5303323129 A B Screw, 8 X ¾
*5303323140 A B Screw ground
*08016432 A B Screw, 8-18 X 3/8
*5303300265 A B Screw, 8-18 X ½ chrome
MAINTOP/SURFACE UNITS
A = FEC36S8H (FEC36S8HSB)
B = FEC36S8H (FEC36S8HBB)

FEC36S8H Publication No.
5995349189
01/01 6
WIRING DIAGRAM
