Frigidaire FFGC3603LW Installation instructions

frigidaire.com
Drop-In Cooktop
FPEC3085K S 30" Electric
Signature Features
36" Gas
Drop-In Cooktop
FFGC3603L W
1When properly installed, meets the appliance
standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility
Guidelines as published by the United States
Access Board on June 23, 2004, as amended
August 5, 2005.
Burners
Right Front
Right Rear
Left Front
Left Rear
BTU
9,000
9,000
9,000
9,000
White
(W)
Product Dimensions
Width 36"
Depth 18-5/8"
Height 3-1/2"
More Easy-To-Use Features
Porcelain Cooktop Grates
Grates are durable and easy to clean.
LP Gas Conversion Option
A.D.A. Compliant1
Available in:
Spill Saver™ Drip Bowls
Cooktop features chrome drip bowls that
make cleaning up spills quick and easy.
Electronic Pilotless Ignition
Saves energy and can be ignited
manually when electricity is out.
Ready-Select™ Controls
Select options or control cooking
temperature with our easy-to-use
controls.
Color-Coordinated
Control Knobs
White cooktops come with matching
knobs.

Accessories information available
on the web at frigidaire.com
Granite Countertop
Installation Kit available.
USA
•
10200 David Taylor Drive • Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFGC3603L 08/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
Drop-In Cooktop
FFGC3603L W 36" Gas
Features
Controls
Surface Type
Grates
Right Front Element (BTU)
Right Rear Element (BTU)
Left Front Element (BTU)
Left Rear Element (BTU)
Control Location
Knob Color
Knob Type
Bowl Type
Certifications
A.D.A. Compliant1
Specifications
Power Supply Connection Location
Gas Supply Connection Location
LP Gas Conversion Kit
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts2
Amps @ 120 Volts
Minimum Circuit Required (Amps)
Approved for Electric Single Wall Oven
Combination Installation
Shipping Weight (Approx.)
Ready-Select™
Color-Coordinated
Porcelain
Steel Round with
Black Gloss Finish
9,000
9,000
9,000
9,000
Center Front
Color-Coordinated
Plastic
Chrome
Yes
Center Front
Center Front
Included
120V / 60V / 15A
.8
1.0
15
30 Lbs.
1When properly installed, meets the appliance standards in the Americans
with Disabilities Act and the Architectural Barriers Act Accessibility
Guidelines as published by the United States Access Board on June 23,
2004, as amended August 5, 2005.
2For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.
Product Dimensions
A - Width
B - Depth
C - Height
Cutout Dimensions
Width (Min.)
Width (Max.)
Depth (Min.)
Depth (Max.)
Height
34-1/4"
34-3/8"
16-5/8"
16-3/4"
5"
36"
18-5/8"
3-1/2"
NOTE: Always consult local and national electric and gas codes. Refer to Product
Installation Guide for detailed installation instructions on the web at frigidaire.com.
Drop-In Gas Cooktops
Frigidaire Baseline
AB
C
