PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
FGC26C3AUB FGC26C3A 3775411141042 black/bisque North America
FGC26C3AWB FGC26C3A 3775411141012 black/white North America
Publication No.
5995365920
020214
-EN/SERVICE /ECL
377
GAS
COOKTOP
Model No.
FGC26C3A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318047105
OWNER’S GUIDE - # 318200658
INSTALLATION INSTRUCTIONS - # 318201452
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

02/02 2
Publication No. FGC26C3A
5995365920
COOK TOP

# = Functional Parts 3 02/02
* = Non-Illustrated Parts
FGC26C3A Publication No.
5995365920
COOK TOP
A = FGC26C3A (FGC26C3AWB)
B = FGC26C3A (FGC26C3AUB)
POS. NO PART NO DESCRIPTION
3 5303305547 A B Channel,top stiffener
16 318159105 A - Panel,main top ,white
16 318159107 - B Panel,main top ,bisque
17 3016817 A B Rod,maintop support
18 318074310 A B Hinge,maintop ,(2)
19 318067300 A B Pan,burner ,(4)
20 316040807 A B Grate,black ,(4)
23 318021400 A B Panel,control
43 318196144 A B Knob,control ,black
45A 3201437 A B Strain relief
46 318077303 A B Burner Box
47 # 5303311311 A B Cord,electric power
74 318101508 A B Plate,control ,LF
75 318101509 A B Plate,control ,RF
76 318101510 A B Plate,control ,LR
77 318101511 A B Plate,control ,RR
78 318075802 A B Nameplate,Frigidaire
97 5303300265 A B Screw,8-18 x 0.500 ,chrome
98 5303326255 A B Screw grommet
99 5303324192 A B Self nut
100 5303325982 A B Nut,Keps ,10-32
183 5304410665 A B Screw,10-32 x 5/8
* 5303311532 A B Screw,6-32 x 1/4" ,back

02/02 4
Publication No. FGC26C3A
5995365920
BURNER

# = Functional Parts 5 02/02
* = Non-Illustrated Parts
FGC26C3A Publication No.
5995365920
BURNER
A = FGC26C3A (FGC26C3AWB)
B = FGC26C3A (FGC26C3AUB)
POS. NO PART NO DESCRIPTION
1 318177402 A B Manifold
2 # 318087012 A B Valve,top burner
2* 5303323141 A B Screw,valve mtg ,1/4-20 x 5/16
3 # 316032001 A B Switch,ignitor ,(4)
8 # 316135700 A B Module,spark
8* 318024201 A B Bracket,spark module
9 5303311307 A B Nut,angle ,4-20
10 # 318176300 A B Burner Assy,front
10A# 318176301 A B Burner Assy,back
11 # 318148502 A B Ignitor,top burner
11A# 318148503 A B Ignitor,top burner
12 3016993 A B Retainer,ignitor
14 # 5308007974 A B Regulator,pressure
33 5303294764 A B Channel,burner support
35 318146300 A B Bushing
66 5303294765 A B Angle,manifold pipe ,mtg
84 5303294763 A B Bracket,support
* 08016432 A B Screw,truss head ,8-18 x 0.375
* 5303311306 A B Screw,8-18 x 0.375

02/02 6
Publication No. FGC26C3A
5995365920
WIRING DIAGRAM
