Frigidaire EC200WF User manual

Manual v1.2
Evaporative Air Cooler
and Tower Fan
EC200WF
Owner’s Manual

2
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online............................................................................... 3
Safety Information & Warnings ........................................................................... 4
Parts List............................................................................................................... 5
Features ............................................................................................................... 6
Operating Instructions ......................................................................................... 7
Cleaning And Maintenance................................................................................ 11
Limited Manufacturer’s Warranty ..................................................................... 12
SPECIFICATIONS
MODEL
NO
EC200WF
RATED VOLTAGE
120V
RATED FREQUENCY
60 Hz
RATED POWER
65W
NOISE
≤55dB
AIRFLOW
350 CFM
COVERAGE
250 square feet
DIMENSIONS
Depth: 12.7 in
Width: 12.8 in
Height: 31.4 in
Frigidaire is a registered trademark of Electrolux Home Products, Inc.
All rights reserved.
Manufactured under license by:
NewAir, LLC
6600 Katella Ave, Cypress, CA 90630
Comments/questions:
s[email protected] | 855-963-9247

3
REGISTER YOUR PRODUCT ONLINE
Register Your Frigidaire Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more
accurately
Recall Notifications
Stay up to date on safety notices, system updates, and recall
notifications
Special Promotions
Opt-in for NewAir promotions and offers.
Registering your product information online is safe & secure and takes
less than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your sales receipt below and
record the following information, which can be found on the manufacturer’s
nameplate on the back of the unit. You will need this information if it becomes
necessary to contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________
newair.com/register

4
SAFETY INFORMATION & WARNINGS
In order to use the product safely and to avoid any danger caused
by incorrect operation, please pay close attention to the warnings
and instructions in this manual.
•Please read all instructions carefully before using this product.
•Before use, please check whether the operating voltage matches the
voltage on the label of the unit.
•Cleaning and user maintenance should not be done by children without
adult supervision.
•WARNING: Unplug or disconnect the appliance from the power supply
before servicing or cleaning.
•The appliance is exclusively for household and indoor use.
•This appliance has a polarized plug with one blade that is wider than the
other. To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do
not attempt to override this safety feature.
•WARNING:To reduce the risk of fire or electric shock, do not use this fan
with any solid-state speed control device.
•WARNING: Chemical Burn Hazard. Keep batteries away from children.
•This product contains a lithium button/coin cell battery. If a new or used
lithium button/coin cell battery is swallowed or enters the body, it can
cause severe internal burns and can lead to death in as little as 2 hours.
Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove the
batteries, and store it away from children. If you think batteries might have
been swallowed or placed inside any part of the body, seek immediate
medical attention.

5
PARTS LIST
1. Top Cover
8. Remote Control Storage
2. Display Panel
9. Rear Case
3. Remote Control Sensor
10. Air Intake/Filter
4. Decorative Ring
11. Cord Storage Brackets
5. Fan Outlet
12. Water Tank
6. Front Shell
13. Power Cord
7. Casters

6
FEATURES
1. Four fan speeds: quiet, low, medium, high
2. Three fan modes: normal, nature, and sleep mode
3. Four timer settings: 1h, 2h, 4h, 8h
4. Low water protection function
5. Wide angle fan oscillation
6. Remote control (maximum range 6m, left/right 60° from sensor)
7. Fan-only mode
8. Power failure memory function
9. Touch screen controls
10. Automatic shutoff after 15 hours of continuous operation

7
OPERATING INSTRUCTIONS
Remove the product from the packaging and review the instructions and other
included accessories. The unit can be used immediately after being removed
and unpacked.
FILLING THE WATER TANK
We recommend filling your water tank first before operating the unit, so that
the evaporative cooling will be functional right away. The water tank can be
pulled out of the bottom of the back of the unit, and filled up to the max fill
line. Your unit comes with ice packs, which can be placed inside the tank on the
left side (there should be an icon indicating this location). These will help the
cooler put out even colder air.
Once the water tank is full, press the On/Off button. Then, press the
Cooler/Humidifer button to turn on the water pump. The water pump will
enable evaporative cooling, as it draws water up and runs it through the
cooling pad.
USING THE REMOTE CONTROL
One battery (CR2032 3V) is used in the remote control. Please insert the
battery into the remote control tightly based on the direction of the polarity. If
the remote will not be used for a long time, please remove the battery and
store safely.
Used batteries should be disposed of properly, and kept away from children.
Please note that even used batteries could be hazardous.

8
CONTROL & DISPLAY PANELS
1
On/Off
2 Timer setting: 1, 2, 4, 8 hours
3 Humidification, or evaporative cooling
4 Fan oscillation
5
Mode selection: Normal, nature ( ), sleep ( )
6 speed control: High, medium, low, silent

9
CONTROL PANEL USE
When the unit is first turned on with the On/Off button, it will beep twice, the
air outlet will rotate from the current angle to 0°, and the system enters the
standby state. If there is no button operation within 1 minute, the indicator
light will darken. If the button is pressed again, the indicator light will turn back
to full brightness.
The unit can be operated by pressing the button on the control panel. The
instructions are as follows:
ON/OFF CONTROL
Press the “On/Off” button for the first time to enter the normal fan
speed—this will cause the air outlet to automatically rotate out
toward the front. Press the “On/Off” button again to shut down—
this will cause the fan to stop running and hide the air outlet. At this point, the
fan is in standby mode. To completely turn off the fan, press the On/Off button.
Note: In order to extend the life of the product, it is recommended to
completely power off the product after each use
TIMER
Press the “Timer” button to select 1 hour, 2 hours, 4 hours or 8
hours. If the LED is off, it means that the timer function is not set.
After selecting the time, the LED indicator will display the set time
and will automatically shut down after the selected time has elapsed.
COOLER/HUMIDIFIER
Press the “Cooler/Humidifier” button to enable the water pump. If the water
pump is running, water will flow down through the cooling pad and offer cooler
air than the fan-only setting.

10
SWING FUNCTION
Press the “Swing” button to make the fan oscillate at a range of 50
degrees, and then press it again to stop the oscillation.
MODE SELECTION
Press the “Mode” button to select normal mode, nature mode or
sleep mode, and the LED indicator will light up accordingly: Nature
mode ( ), sleep mode ( ).
Nature mode: The fan is automatically set to match the air conditioner, and
will occasionally change speeds, mimicking a natural breeze.
Sleep mode:The fan speed changes at regular intervals to provide a
comfortable sleeping environment. In sleep mode, the high, medium, and low
speeds will all be cycled through.
Note: In nature mode, the fan speed button is not available, so the speed
indicator will not light up on the top control panel.
FAN SPEED SELECTION
After the power is turned on, the fan will begin in normal mode.
You can press the “Speed” button to change the fan speed to high,
medium, low, and silent. The LED indicator will light up accordingly:
High → Medium → Low → Quiet
Note: If you select the low speed, the motor will start at medium speed for a
few seconds and then switch to low speed.
When the fan is turned on in standby state, all functions except timer and
sleep mode have memory settings.

11
CLEANING AND MAINTENANCE
1. When cleaning, use ordinary detergent and a soft brush. Do not use chemical
agents for cleaning.
2. Always unplug the power cord before cleaning the device to prevent possible
electrocution.
3. If dust accumulates on the outer surface of the unit, please wipe with a damp
soft cloth. Use a water and a soap mixture to clean the exterior.
4. Remove the cooling pad from the unit and check to make sure the cooling pad
is in good condition. If the pad is cracked, it will need to be replaced. Wipe the
interior clean with a damp soft cloth.
5. Rinse the cooling pad completely with clean water. Use a soft cloth to dry.
6. For a more thorough cleaning, use a mixture of water with a couple teaspoons
of distilled white vinegar or lemon juice.
7. Do not use gasoline, thinner, or any substance that may damage the unit
8. Change water in the water tank regularly. Wipe the tank clean and use your
diluted vinegar solution to remove any hard water stains in the tank.
9. Make sure the tank is completely dry and free of any leftover vinegar residue
before using the unit again.
10. Be careful handling the appliance while cleaning, as working around the
appliance with wet hands may cause electric shock.
11. After cleaning, ensure the outer dust filter, cooling pad and water tank are
correctly installed before use.
CLEANING THE SURFACE OF THE UNIT
1. To clean the surface of the machine, wipe with a damp cloth. It is strictly
prohibited to rinse directly with water. Never submerge the unit in water.
2. Do not use corrosive detergent or solvent.
3. When cleaning the body, be sure to turn off the power switch and unplug the
power cord, or else it may cause electric shock.
MAINTENANCE
1. When the product is not going to be used for an extended period, unplug the
power cord, package the product, and store in a way that prevents dust
buildup.
2. After packaging, store in a dry and well-ventilated location.

12
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year
from the original date of purchase, the manufacturer will repair or replace any
parts of this appliance that prove to be defective in materials and
workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective
due to materials or workmanship will be repaired or replaced, at the
manufacturer’s discretion, at no charge to the original purchaser. The
purchaser will be responsible for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective household wiring or
inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such as using non-
approved accessories, inadequate air circulation in the room or abnormal
operating conditions (extreme temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
•Use of force or damage caused by external influences
•Adjustments to temperature by removal of stickers and/or screws
•Partially or completely dismantled appliances
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
purchase date available. The purchaser will be responsible for any removal or
transportation costs. Replacement parts and/or units will be new,
remanufactured or refurbished and are subject to the manufacturer’s
discretion.
For technical support and warranty service, please email [e-mail]
