Frigidaire FMF2K5BK00 User manual

Manual v1.0
OUTDOOR MISTING
FAN
FMF2K5BK00
Owner’s Manual

2
READ AND SAVE THESE
INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online.......................................................................3
Important Safety Instructions/Warnings................................................ 4
Parts Lists ..............................................................................................................6
Assembly Instructions......................................................................................7
Operating Instructions .....................................................................................9
Cleaning and Maintenance ...........................................................................10
Troubleshooting ............................................................................................... 12
Limited Manufacturer’s Warranty ............................................................. 13
SPECIFICATIONS
MODEL
NO
FMF2K5BK00
RATED VOLTAGE
120V
RATED FREQUENCY
60 Hz
RATED POWER
55W
CURRENT
0.45A
FAN SPEEDS
3
SPRAY NOZZLES
3
AIRFLOW
2400 CFM
COVERAGE
500 square feet
Frigidaire is a registered trademark of Electrolux Home Products, Inc.
All rights reserved.
Manufactured under license by:
NewAir, LLC
6600 Katella Ave, Cypress, CA 90630
Comments/questions:
s[email protected] | 855-963-9247

3
REGISTER YOUR PRODUCT ONLINE
Register Your Frigidaire Product Online Today!
Take advantage of all the benefits product registration has to
offer:
Service and Support
Diagnose troubleshooting and service issues faster and
more accurately
Recall Notifications
Stay up-to-date on safety notices, system updates, and
recall notifications
Special Promotions
Opt-in for NewAir promotions and offers
Registering your product information online is safe &
secure and takes less than 2 minutes to complete:
Alternatively, we recommend you attach a copy of your sales
receipt below and record the following information, which can
be found on the manufacturer’s nameplate on the back of the
unit. You will need this information if it becomes necessary to
contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: _____________________________________________
Model Number: ____________________________________________
newair.com/register

4
IMPORTANT SAFETY INSTRUCTIONS/WARNINGS
CAUTION: Read rules for safe operation and instructions carefully.
When using any electrical appliance, basic safety precautions must be
followed in order to reduce the risk of fire, electrical shock and/or injury
to persons or property. Be sure to read all instructions before using this
appliance and observe the following safety tips:
1. To reduce the risk of fire or electrical shock, do not use this fan with
any solid state speed control device (e.g. a dimmer switch).
2. This product must be grounded properly when plugged in. If the
unit should malfunction or break down, a grounded power cord will
keep you safe. This product is equipped with a grounded power
cord. Plug into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
3. This fan is provided with a ground fault circuit interrupter (GFCI)
built into the power supply cord. This device provides additional
protection from the risk of electric shock. Should replacement of
the plug or cord become necessary, use only identical replacement
parts that include GFCI protection.
4. Do not leave the fan running unattended.
5. Do not use the fan where it may get wet from rain, sprinklers, etc.
Water could leak inside of the unit and damage the internal
components.
6. Do not insert anything through the fan cover, especially while the
fan is running.
7. Before using the unit, check if the voltage indicated corresponds
with the intended outlet (120V).
8. Connect power after the fan is fully assembled.
9. Unplug from the outlet when not in use, when moving the fan from
one location to another, before putting on or taking off parts, and
before cleaning.
10. Be sure the fan is on a stable surface when operating to avoid it
falling over, and ensure the power cord is not a trip hazard.
11. Do not use any appliance with a damaged cord or plug. Discard fan
or return to an authorized service facility for examination and/or
repair if the power cord or plug are damaged.
12. Children should be supervised to ensure they do not play with or
around the appliance.

5
13. This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit. If the fuse blows, unplug
the product from the outlet. Replace the fuse as per the user
servicing instructions and check the product. If the replacement
fuse blows, a short-circuit may be present and the product should
be discarded or customer service should be contacted
immediately.
14. Press the TEST button (then RESET button) on the power cable
GFCI box once every month to ensure proper operation.
15. Risk of Fire: Do not replace or modify any part of the power cord,
GFCI or wall plug. Do not remove the fuse unless you are
replacing it. If any of these parts are damaged, contact customer
service immediately.
16. Place the fan on a level surface. Plug the grounding type
attachment plug into a standard 120V AC 3-Pring wall outlet.
SAVE THESE INSTRUCTIONS

6
PARTS LIST
A. Front grille
B. Blade cap
C. Fan blade
D. Plastic nut
E. Rear grille
F. Motor shaft
G. Clutch knob
H. Motor housing
I. Control panel
J. Thumb screw
K. Power cord
L. Waterproof cover
M. Misting line clip
N. Internal pole
O. Height adjustment knob
P. External pole
Q. Misting line
R. Filter washer
S. Water valve
T. Fan base
U. Screw for base

7
ASSEMBLY INSTRUCTIONS
Before beginning assembly of this product, make sure all parts
are included in the box (see chart on previous page). If any part
is missing or damaged, do not attempt to assemble the product.
Contact customer service for replacement parts. You should
only need a philips head screwdriver for assembly, and about
15 minutes of time.

8
FAN BASE ASSEMBLY – FIG. 1
1. Unscrew the screw (U) from the external pole (P) and
attach the external pole (P) to the base (T) by
tightening the screw (U).
2. Remove the height adjustment knob (O) by unscrewing it
counterclockwise.
3. Use your finger to pull out the internal pole (N), slide height
adjustment knob (O) over internal pole (N). Fasten it to external
pole (P) by turning the knob while holding the pole. Make sure the
knob (O) is tightly fastened before final assembly.
FAN HEAD ASSEMBLY – FIG. 2 & 3
1. Remove the blade cap (B) by turning clockwise. Remove the plastic
nut (D) by turning counter clockwise.
2. Position the rear grille (E) over the motor shaft (F), making certain
that the handle is at the top, and that the one notch on the back of
of rear grille (E) fits over the three prong attachment on the motor
housing (H on parts list).
3. Secure rear grille (E) by turning the plastic nut (D) clockwise
and tightening firmly.
4. Slide the fan blade (C), with the hollow interior of the blade facing
toward rear grille (E), onto motor shaft (F).
5. Secure fan blade (C) onto motor shaft (F) by turning
the blade cap (B) counterclockwise until firmly in
place.
6. Loosen the bolt on the bottom of front grille (A) and mount the
front grille (A) with the logo right side up to rear grille (E) by
snapping both together firmly. Ensure all snaps around front
grille (A) are secured onto rear grille (E).
7. Tighten the bolt on the bottom of front grille (A).
FINAL ASSEMBLY – FIG. 4
1. Loosen the thumb screw (J) by turning it counterclockwise.
2. Always keep the waterproof cover (L) match with the height
adjustable knob (O) when adjusting the internal pole (N).
3. Insert internal pole (N) into the neck joint and tighten by
turning thumb screw (J) clockwise. Make sure it is tight
enough to support the fan head.
4. Attach the Misting Line holder (M) onto the Internal pole (N).
5. Secure the Misting Line (Q) to the clip under front grille (A) and the
misting line clip (M).

9
OPERATING INSTRUCTIONS
FAN-ONLY MODE
1. Plug in the unit, press the reset button on the
GFCI, and select a fan speed on the control
panel. The fan will start running as soon as you
select a fan speed.
2. To start/stop fan oscillation, push down/pull up
the clutch knob (G).
3. To adjust the airflow upward or downward,
simply tilt the fan head by hand and move to the
desired angle.
4. The height of the fan can be adjusted by
loosening the height adjustment knob (O) and
carefully raising or lowering the fan and
retightening the knob.
MISTING MODE
1. Connect a standard ¾” garden hose to the misting hose
valve (S). Water pressure should not exceed 550 kPa (5.6
kfg/cm2). Only use a hose in good condition.
2. With the garden hose turned on at the spigot, turn the lever
on the misting hose valve to the right to turn on water to the
fan.
3. Turn the lever back (to the left) to temporarily disable the
misting feature. To disable the misting feature for a longer
period of time, close the water valve lever and turn the
spigot off as well.
3
2
1
0

10
CLEANING AND MAINTENANCE
1. Disconnect from the electrical socket during cleaning or initial
assembly.
2. To ensure adequate air circulation to the motor, keep the vents
at the rear of the motor housing clear of dust, dirt, etc. Unplug
the fan before using a vacuum cleaner or compressed air to
clean the grilles. It should not be necessary to disassemble the
fan to clean it.
3. Wipe the exterior housing of the fan with a soft cloth soaked in
a mild detergent. Do not use any abrasive detergents or
solvents to avoid damaging the surface. Do not use gasoline,
thinner, or bending to clean the fan.
4. Do not allow water or any other liquid into the motor housing or
interior parts.
5. When dismantling the fan (we recommend following the
assembly instructions in reverse), be sure to clean each of the
components before storage. Allow all parts to dry completely
before storing.
6. To test the GFCI feature, press the "TEST" button. The fan
should immediately shut off as if the GFCI has been tripped.
Press the "RESET" button and the fan should be able to be
turned on again, and the light on the GFCI box should light up
orange. If it does, then the unit (as well as the GFCI feature)
are functioning normally.
7. If the fuse in the power cord plug needs to be replaced, follow
these instructions:
a) Pull the power plug from the outlet, being careful not to
pull from the cord.
b) Slide open the fuse access cover.
c) Remove the fuse slowly and carefully by inserting a small
tool into the fuse slot and prying it out. When one side of the
fuse has been lifted out, you will be able to remove it entirely.
d) Only replace the fuse with 5 Amp / 125 Volt fuses. Using an
incompatible fuse may cause a fire.
e) Close the fuse cover.
f) Caution: Do not attempt to replace the plug or the power
cord itself. Only replace a broken fuse with a compatible fuse.
If any part of the plug or cord are damaged, contact customer
service for assistance.

11
USER SERVICING INSTRUCTIONS
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
2. Open fuse cover. Slide open fuse access cover on top of
attachment plug towards blades.
3. Remove fuse carefully. Insert the tip of your tool into fuse
slot (close with the terminal), then prize the fuse gradually
and slowly, but not overexert. If you feel tight, you can try it
at several times and prize the fuse little by little. When one
side of the fuse has been prized, then you can get the fuse
out entirely.
4. Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse.
5. Close fuse cover. Slide closed the fuse access cover on top
of attachment plug.
6. Risk of fire. Do not replace attachment plug. Contains a
safety device (fuse) that should not be removed. Discard
product if the attachment plug is damaged.
MISTING NOZZLE MAINTENANCE
If the misting nozzles become clogged, unscrew them from the
fan grille and soak in vinegar or a lime scale remover until they
are clear of buildup. Use a non-metallic brush to scrub them if
necessary. If the nozzles remain obstructed, contact customer
service for replacement.
Warning: never try to clear the nozzles with pins or other sharp
objects as this can cause damage to the nozzles, affecting their
efficiency.
If the misting hose valve becomes clogged, unscrew the head of
the valve and flush it with running water to clear debris. Make
sure the screen inside the misting hose is clean as well.

12
TROUBLESHOOTING
Problem
Possible Causes
Solution
The fan has no
power.
The unit may be
plugged in using a
different voltage.
Check if using the wrong
voltage.
The circuit breaker
may be tripped or
there is a blown fuse.
Reset the circuit breaker or
check for a broken fuse.
The fan is not
rotating.
There is an
obstruction.
Check for obstructions in
the fan. If you find
something, turn the fan
off. Unplug the fan and
carefully remove the
obstruction. Plug the fan in
and turn it on again by
referring to the operating
instructions.
No mist is
produced.
There is no water
coming from the hose.
Make sure the garden hose
is correctly connected to
the spigot and the misting
hose valve, that the spigot
is turned on, and that the
valve is open.
Nozzles are
leaking or
dripping.
The nozzles are
clogged.
Clean the clogged nozzles
on the front of the fan as
described under “Cleaning
& Maintenance.”

13
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty.
For one year from the original date of purchase, the
manufacturer will repair or replace any parts of this appliance
that prove to be defective in materials and workmanship,
provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to
be defective due to materials or workmanship will be repaired or
replaced, at the manufacturer’s discretion, at no charge to the
original purchaser. The purchaser will be responsible for any
removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the
following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply such as low voltage, defective
household wiring or inadequate fuses
•Accident, alteration, misuse or abuse of the appliance such
as using non-approved accessories, inadequate air circulation
in the room or abnormal operating conditions (extreme
temperatures)
•Use in commercial or industrial applications
•Fire, water damage, theft, war, riot, hostility or acts of God
such as hurricanes, floods, etc.
•Use of force or damage caused by external influences
•Removal of stickers and/or screws
•Partially or completely dismantled appliances
Obtaining Service:
When making a warranty claim, please have the original bill of
purchase with purchase date available. The purchaser will be
responsible for any removal or transportation costs.
Replacement parts and/or units will be new, remanufactured or
refurbished and are subject to the manufacturer’s discretion.
For technical support and warranty service, please email
[e-mail]
Frigidaire is a registered trademark of Electrolux Home Products, Inc.
All rights reserved.
Manufactured under license by:
NewAir, LLC
6600 Katella Ave, Cypress, CA 90630
