Frigidaire GLET1142F User manual

Product No. GLET1142FS0
Market North America
Color white
Volts 240
Wiring Diagram 134807000
Owner's Guide 134809600
Installation Instructions 134809200
Energy Guide 134810500
P17L0006.eps P17U0052.eps P17B0049.eps P17C0076.eps P17R0020.eps P17t0059.eps
P17M0015.eps 134807000_en.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995483350
07/01/30
(EN/SERVICE/WC)
361
LAUNDRY CENTER
WITH ELECTRIC
DRYER
Model No.
GLET1142f
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995483350 GLET1142FS0
01/07 2
UPPER CABINET/DRUM HEATER
35 36 4
562
2
9
2
11
12
13
2
17
38
32
24
20
20
1
62
3
22
27
18
23
62
25
26 28
21
39
31
47
44
49
18
30
29
29
54
46
48
42
50
33
34
14
15
P17U0052
42 41
64
65
59

GLET1142FS0 Publication No: 5995483350
# Functional Parts 3 01/07
* Non-Illustrated Parts
UPPER CABINET/DRUM HEATER
POS. NO PART NO. DESCRIPTION
1 131084710 Panel, white, left side
2 131168200 Screw, pan head, 8-18B x 0.31
3 131883301 Panel, top
4 134799902 Panel, rear, steel, galvanized
5 5303281019 Ball, grounding
6 5303281020 Clip, ball, steel, flat nut
9 3204249 Panel, motor access, rear
11 3204250 Cover, terminal block
12 131825900 Bearing, drum support
13 131724300 Bracket, bearing support
14 131205400 Screw, bracket mtg., 10-16B x 1.375, cr/sq drive
15 # 131475300 Heater Assy, w/housing
17 3204254 Baffle, heater shield
18 131477000 Screw, 10-16AB x 0.375
20 131963900 Glide, drum
21 134122552 Drum, dryer, stainless steel, service kit
22 131636237 Panel, front, white
23 134134700 Seal, felt, lower
24 134036400 Seal, felt, upper
25 131658800 Door Catch
26 # 131843101 Switch, door, with drum light
27 131359600 Lint Trap
28 134440000 Clip, guide
29 131382300 Screw, quadrex head, 10-14 x 1.00, vane mtg., special
30 5304405283 Vane, straight, gray
31 131202300 Screw, 10-16AB x 0.625
32 131777700 Shaft, drum support, ballhitch
33 # 3204267 Thermostat, safety
34 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
35 131892100 Screw, 6-20B x 0.230
36 # 134120900 Thermal Limiter
38 131084810 Panel, white, right side
39 131084402 Panel, access, white, front
41 134222900 Hinge, dryer door
42 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
44 131129900 Gasket, door seal
46 131789400 Handle, door, white
47 131579103 Panel, inner door, white
48 131789303 Panel, outer door, white
49 5303211430 Door Strike
50 134535300 Insulator, heat shield, outer door
54 # 134403200 Wiring Harness, door switch, with light
59 # 131843500 Lamp Assy, drum light, w/mtg bracket
62 131258400 Screw, 10-16AB x 0.500
64 # 131891000 Control Board, temperature, ATC
64*# 134805600 Wiring Harness, ATC jumper
65 131894600 Housing, temp cont board

Publication No: 5995483350 GLET1142FS0
01/07 4
MOTOR/BLOWER/BELT
P17B0049
4
6
8
12
10A
2
9
10
27
28
15
13
16
39
250
26
48
44
42
38
43
2
33
2
19
18
2
2
23
25
22
2
2
2
43
2
16
7
57
1

GLET1142FS0 Publication No: 5995483350
# Functional Parts 5 01/07
* Non-Illustrated Parts
MOTOR/BLOWER/BELT
POS. NO PART NO. DESCRIPTION
1 131295200 Seal, air duct
2 131168200 Screw, pan head, 8-18B x 0.31
4 131477000 Screw, 10-16AB x 0.375
6 134086300 Duct, air
7 3204490 Seal, housing, to air duct
8 3205245 Screw, pan head, 6-18AB x 0.60
9 5303304824 Clamp
10 134611700 Housing, blower, front, with seal
10A 134608200 Housing, blower, rear
12 131476300 Blower Wheel
13 134608400 Ground Strap, thermostat
15 # 134048800 Thermostat, control
16 131243700 Screw, pan head, 8-18AB x 0.375
18 131413600 Cradle, motor mount, with idler stud
19 134613501 Panel, motor cradle mt, upper
22 3205241 Spring, idler
23 131863100 Idler Arm Assy, with pulley
25 # 134503900 Belt, dryer drive
26 5303212870 Block, support, bottom panel
27 134242400 Clamp, motor mtg.
28 # 134196600 Motor, dryer drive, with pulley
33 131731400 Shield, access area, cover
38 3204320 Elbow, exhaust duct
39 131205100 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive
42 5304439185 Bracket, marriage, interior
43 131751500 Screw, hex head, 12-24T 0.63
44 3204326 Bracket, L mounting, cabinet rear, external
48 131731310 Panel, dryer, bottom rear
50 3204329 Cover, safety, lower front
57 131729300 Cover, moisture sensor

Publication No: 5995483350 GLET1142FS0
01/07 6
CONTROL PANEL

GLET1142FS0 Publication No: 5995483350
# Functional Parts 7 01/07
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
1 # 131960800 Timer, dryer, 4 off
2 131168200 Screw, pan head, 8-18B x 0.31
3 # 134136700 Wiring Harness, dryer control
4 134034970 Knob, rotary, white
5 # 134487800 Switch, pressure, infinite
6 # 134542600 Wiring Harness, washer control, w/temp switch
8 # 134237200 Timer, washer, 5 off
10 # 134399700 Switch, start, LCD
11 5303283289 Screw, cr pan head, 8-32 x 0.250, thread forming
12 # 134040800 Switch, on/off, white, round
15 # 134192400 Switch, water temp, 4 posn rotary
17 134263400 Bracket, control mount
18 134284500 Panel, trimplate, console front
20 131288101 End Cap, white, LH
21 134043000 Knob, dryer timer, white/dark gray
21A 134043200 Knob, washer timer, white
22 3161259 Screw, switch mtg, 6-32 x 0 .19, (2), sems
23 # 134605500 Wiring Harness, main
23* 5304426200 Screw, terminal block
23*# 134101400 Terminal Block, main
24 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
25 131976804 Indicator, timer pointer, white/dark gray, washer
27 131892100 Screw, 6-20B x 0.230
29 # 134769600 Wiring Harness, washer, lower
31 131288211 End Cap, white, RH
32 3204357 Clip, grounding
34 131243700 Screw, pan head, 8-18AB x 0.375
35 5308014350 Clip, end cap mtg, U-type
38 # 5303286537 Buzzer
39 # 134399900 Switch, dryer temp, LCD
51 131587400 Bracket, pc board mtg., (2)
52 134216300 Control Board, moisture sensor

Publication No: 5995483350 GLET1142FS0
01/07 8
LOWER CABINET/TOP
P17R0020
1
54
1
5
233
34
38
43A
37
36
44
44
43
43
41
35
46
45
20
55
54
11
9
3A
9A
2
42
45A
53
6
4
2
47
47A
50
56
58

GLET1142FS0 Publication No: 5995483350
# Functional Parts 9 01/07
* Non-Illustrated Parts
LOWER CABINET/TOP
POS. NO PART NO. DESCRIPTION
1 134203900 Screw, pan hd phillips, 6-32 x 0.337, dog point
2 131168200 Screw, pan head, 8-18B x 0.31
3A 134075500 Bumper, lid, front
4 3205250 Hinge Bar
5 5303208743 Grommet, hinge
6 5303212872 Lid, washer, white
9 131390000 Lid Strike
9A 134768500 Insert, striker plate, lid slot
11 3204368 Screw, lid strike mtg, 6-20B X 0.375
20 3204374 Pin, slide, side to top
33 # 134210800 Valve, water, 115 V
34 131205500 Screw, cab body, 1/4-14 x 0.625, side-to-base
35 5308002385 Snubber Ring
36 3204380 Shipping Block
37 131658900 Screw, shipping, 1/4-20 x 1.001, yellow, unit base, thread forming
38 5303311213 Base Assembly
41 131258400 Screw, 10-16AB x 0.500
42 131104303 Panel, front, white
43 131422100 Pad, leveling leg
43A 131422200 Pad, self lvlg leg, rear
44 5303309673 Screw, leveling leg, with pad
45 131346400 Pin, panel locator
45A 131346401 Pin, panel locator, front
46 134046600 Cabinet Assy, white, back and sides
47 131106701 Bracket, marriage, RH
47A 131091001 Bracket, marriage, LH
50 # 134101800 Lock, lid, w/ext switch
53 131452510 Panel, washer top, white
54 3204394 Dispenser, bleach
55 5303212876 Spring, lid assist
56 131243700 Screw, pan head, 8-18AB x 0.375
58 131744202 Damper, vibration

Publication No: 5995483350 GLET1142FS0
01/07 10
MOTOR/TUB
58
43
P17T0059
26
20
23
21
45
48
35 36 37
38
34
33
30
29
27
28
24
23A
22
40
3
39
13
18
53
51
15
16
14
12
10
6
7
9
55
11
57
56
54
41
62
4
49
48
48
69
68
