Frigidaire FFLE3911QW Operating manual

Publication #5995666392 October 2015
Technical Service Manual
Laundry Center

I

2
Table of Content
1. PURPOSE OF THIS MANUAL
2. WARNINGS
3. PRODUCT FEATURES
4. MODEL SPECIFICATIONS
4.1 SPECIFICATION – TOP LOAD LAUNDRY CENTER
FFLE3911QW AND FFLG4033QW ....................................... 10
5. EXPLODED VIEW AND LIST OF PARTS
5.1 FFLE3911QW.................................................................................. 13
5.1.1 Upper Cabinet/Drum Heater........................................................................... 13
5.1.2 Motor / Blower / Belt................................................................................................ 16
5.1.3 Control Panel ..................................................................................................................... 18
5.2 FFLG4033QW ................................................................................. 20
5.2.1 Upper Cabinet/Drum Heater........................................................................... 20
5.2.2 Motor / Blower / Belt................................................................................................ 23
5.2.3 Control Panel ..................................................................................................................... 26
5.3 FFLE3911QW AND FFLG4033QW ....................................... 28
5.3.1 Motor Gear Box Assembly/Tub...................................................................... 28
5.3.2 Control Board Washer............................................................................................. 29
5.3.3 Wash Assembly................................................................................................................ 30
5.3.4 Cabinet Assembly.......................................................................................................... 32
6. INSTALLATION - FFLE3911QW AND FFLG4033QW
6.1 PRE-INSTALLATION REQUIREMENTS...................................34
6.2 INSTALLATION REQUIREMENTS ........................................... 35
6.2.1 Electrical requirements for Laundry center
with Electric Dryer....................................................................................................... 35
6.2.2 Electrical requirements for Laundry center
with Gas Dryer...................................................................................................................36
6.2.3 Gas Supply Requirements.................................................................................... 36
6.2.4 Water Supply Requirements.............................................................................. 36
6.2.5 Drain System Requirements.............................................................................. 36
6.2.6 Exhaust System Requirements....................................................................... 38
6.3 MANUFACTURED OR MOBILE HOME INSTALLATION.. 40
6.3.1 Installation in a Recess or Closet .................................................................. 41
6.4 LAUNDRY CENTER DIMENSIONS.......................................... 42
6.5 ELECTRICAL INSTALLATION ..................................................... 43
6.5.1 Grounding requirements - Electric dryer (Canada)................. 44
6.5.2 Grounding requirements - Gas dryer (USA and Canada)..44
6.5.3 Electrical connection (non-Canada) - 3 wire cord................... 44
6.5.4 Electrical connection (non-Canada) - 4 wire cord................... 45
6.6 GAS CONNECTION ....................................................................... 50
6.7 WATER SUPPLY REQUIREMENTS............................................51
6.8 DRAIN SYSTEM REQUIREMENTS.............................................51
7. OPERATING INSTRUCTIONS -
FFLE3911QW AND FFLG4033QW
7.1 WASHING PROCEDURES .......................................................... 53
7.2 WASHING CYCLE SELECTION................................................. 56
7.3 WASHING CYCLE SETTINGS .................................................... 57
7.4 DRYING PROCEDURES............................................................... 59
7.5 DRYING CYCLE SELECTION ..................................................... 61
8. ELECTRICAL CHARACTERISTICS -
FFLE3911QW AND FFLG4033QW
8.1 ELECTRONIC CONTROL............................................................. 64
8.1.1 Electronic Control Board (Dryer)................................................................. 64
8.1.2 Main Control Board (Washer).......................................................................... 66
8.1.3 User Interface (UI) Board Washer)................................................................67
8.1.4 Motor Control Board (Washer)........................................................................70
8.2 SCHEMATIC DIAGRAM FOR LAUNDRY CENTER
DRYER ELECTRONIC CONTROL BOARD
FFLE3911QW AND FFLG4033QW........................................ 71
8.3 SCHEMATIC DIAGRAM FOR LAUNDRY CENTER
WASHER MAIN CONTROL BOARD – FFLE3911QW
AND FFLG4033QW....................................................................... 72
8.4 SCHEMATIC DIAGRAM FOR LAUNDRY CENTER
WASHER USER INTERFACE (UI) – FFLE3911QW
AND FFLG4033QW........................................................................ 73
8.5 SCHEMATIC DIAGRAM FOR LAUNDRY CENTER
WASHER MOTOR CONTROL BOARD –
FFLE3911QW AND FFLG4033QW....................................... 74
8.6 WIRING DIAGRAM –
FFLE3911QW (ELECTRIC DRYER MODEL) ..................... 75
8.7 WIRING DIAGRAM – FFLG4033QW
(GAS DRYER MODEL) .................................................................. 76
8.8 WIRING DIAGRAM – FFLE3911QW AND
FFLG4033QW (WASHER MODEL)..........................................77
9. ELECTRICAL COMPONENTS -
FFLE3911QW AND FFLG4033QW
9.1 ELECTRICAL COMPONENT RESISTANCE AND
SPECIFICATION TABLE................................................................ 78
9.2 HEATING ELEMENT -
FFLE3911QW AND FFLG4033QW....................................... 81
9.2.1 General Characteristics........................................................................................... 81
9.3 OUTLET CONTROL THERMISTOR -
FFLE3911QW AND FFLG4033QW....................................... 83
9.3.1 General Characteristics........................................................................................... 83
9.4 DOOR SWITCH AND DRUM LIGHT -
FFLE3911QW AND FFLG4033QW....................................... 85
9.4.1 General Characteristics........................................................................................... 85
9.5 SINGLE -PHASE INDUCTION MOTOR -
FFLE3911QW AND FFLG4033QW (DRYER).................... 86
9.5.1 General Characteristics........................................................................................... 86
9.6 CONTACT / MOISTURE SENSOR -
FFLE3911QW AND FFLG4033QW....................................... 88
9.6.1 General characteristics............................................................................................ 88
9.7 INLET THERMAL LIMITER -
FFLE3911QW AND FFLG4033QW....................................... 89
9.7.1 General Characteristics........................................................................................... 89
9.8 OUTLET THERMAL LIMITER - FFLE3911QW................... 89
9.8.1 General Characteristics........................................................................................... 89
9.9 HIGH LIMIT THERMOSTAT -
FFLE3911QW AND FFLG4033QW....................................... 91

3
9.9.1 General Characteristics........................................................................................... 91
9.10 DRAIN PUMP - FFLE3911QW AND FFLG4033QW.... 92
9.10.1 General Characteristics....................................................................................... 92
9.11 PRESSURE SENSOR - FFLE3911QW AND
FFLG4033QW .............................................................................. 94
9.11.1 General Characteristics....................................................................................... 94
9.12 LID / DOOR LOCK - FFLE3911QW
AND FFLG4033QW .................................................................. 96
9.12.1 General Characteristics....................................................................................... 96
9.13 THREE - PHASE SYNCHRONOUS MOTOR -
FFLE3911QW AND FFLG4033QW ................................... 97
9.13.1 General Characteristics....................................................................................... 97
9.14 SOLENOID / WATER VALVES (INLET VALVE) -
FFLE3911QW AND FFLG4033QW ................................... 98
9.14.1 General Characteristics....................................................................................... 98
9.14.2 Operating principle................................................................................................... 98
9.14.3 Mechanical jamming of the solenoid valve.................................... 98
9.14.4 Low water pressure................................................................................................. 98
9.15 MOTOR BRAKE CLUTCH (MBC) -
FFLE3911QW AND FFLG4033QW ..................................100
9.15.1 General Characteristics................................................................................... 100
10. HEATER (GAS) ASSEMBLY CHARACTERISTICS -
FFLG4033QW
10.1 BURNER ........................................................................................101
10.1.1 General Characteristics................................................................................... 101
10.2 GAS VALVE ...................................................................................101
10.2.1 General Characteristics................................................................................... 101
10.3 IGNITER .........................................................................................101
10.3.1 General Characteristics................................................................................... 101
10.4 RADIANT / FLAME SENSOR................................................101
10.4.1 General Characteristics................................................................................... 101
11. ELECTRICAL COMPONENT ACCESSIBILITY -
FLE3911QW AND FFLG4033QW (DRYER)
11.1 CONTROL PANEL ACCESSIBILITY –
FFLE3911QW (ELECTRIC DRYER) ..................................102
11.1.1 Electronic Control Board Accessibility............................................ 103
11.1.2 Program Selector Accessibility................................................................ 103
11.1.3 Temperature Selector Accessibility..................................................... 103
11.2 CONTROL PANEL ACCESSIBILITY –
FFLG4033QW (GAS DRYER)..............................................104
11.2.1 Electronic Control Board Accessibility............................................ 105
11.2.2 Program Selector Accessibility................................................................ 105
11.2.3 Temperature Selector Accessibility..................................................... 105
11.2.4 Chime Selector Accessibility......................................................................106
11.3 FRONT PANEL ASSEMBLY ACCESSIBILITY....................106
11.4 DOOR SWITCH ACCESSIBILITY..........................................107
11.5 MOISTURE SENSOR ACCESSIBILITY................................107
11.6 COMPONENTS ACCESSIBILITY FROM
FRONT PANEL ...........................................................................108
11.6.1 Motor / Blower Accessibility...................................................................... 108
11.6.2 Drum Accessibility .................................................................................................109
11.6.3 Exhaust Thermistor Accessibility........................................................... 111
11.6.4 Thermostat (Safety) Accessibility........................................................... 111
11.6.5 Inlet Thermal Limiter Accessibility........................................................111
11.6.6 Outlet Thermal Limiter Accessibility................................................. 112
11.7 HEATER (ELECTRIC) ASSEMBLY ACCESSIBILITY.........112
11.8 HEATER (GAS) ASSEMBLY ACCESSIBILITY.....................113
11.8.1 Radiant / Flame Sensor Accessibility................................................. 114
11.8.2 Igniter Accessibility................................................................................................ 115
11.8.3 Gas Valve Assembly Accessibility........................................................... 115
12. DIAGNOSTIC SYSTEM –
FFLE3911QW AND FFLG4033QW (DRYER)
13. TROUBLESHOOTING BASED ON ALARM CODES –
FFLE3911QW AND FFLG4033QW
(DRYER MODEL)
E31: CONTACT SENSOR (MOISTURE SENSOR)
FREQUENCY IS TOO HIGH / LOW...................................121
E41: DOOR OPEN...............................................................................122
E51: MOTOR RELAY FAILURE........................................................123
E52: MOTOR RELAY STUCK CLOSE............................................125
E53: MOTOR FAULT- MOTOR STOPPED IN
THE MIDDLE OF A CYCLE.....................................................126
E54: MOTOR CENTRIFUGAL SWITCH 2, HEATER,
THERMAL LIMITER-2, WIRING FAILURE.......................127
E55: MOTOR SENSING FAILURE ON MAIN BOARD.............128
E56: BELT FAULT ..................................................................................128
E61: HEATER RELAY FAILURE........................................................129
E62: HEATING TIMEOUT..................................................................130
E65: HIGH LIMIT THERMOSTAT TRIP COUNT
IS TOO HIGH ...............................................................................131
E67: HEATER SENSING FAILURE..................................................131
E71: NTC OPEN CIRCUIT.................................................................132
E72: NTC CLOSED CIRCUIT ............................................................133
E81: PROGRAM SELECTOR / ENCODER FAULT....................134
E82: KEY STUCK ..................................................................................134
E93: SOFTWARE CONFIGURATION ERROR...........................135
E94: SOFTWARE CONFIGURATION ERROR...........................135
E97: SOFTWARE CONFIGURATION ...........................................135
EA1: MAIN SUPPLY FREQUENCY OUT OF RANGE..............136
EA2: VOLTAGE TOO HIGH...............................................................136
EA3: VOLTAGE TOO LOW................................................................137
EA5: LINE AMPLITUDE SENSING
FAILURE ON MAIN BOARD..................................................137
14. ELECTRICAL COMPONENT ACCESSIBILITY -
FFLE3911QW AND FFLG4033QW (WASHER)
14.1 CONTROL PANEL ACCESSIBILITY .....................................138
14.1.1 User Interface (UI) Board Accessibility............................................138
14.1.2 Program Selector Accessibility................................................................ 139
14.1.3 Temperature Selector Accessibility..................................................... 139
14.1.4 Fabric Softener Accessibility.........................................................................140

4
14.1.5 Energy Saver Switch Accessibility....................................................... 140
14.2 FRONT PANEL ACCESSIBILITY ...........................................141
14.3 MOTOR CONTROL BOARD ACCESSIBILITY..................141
14.4 DRAIN PUMP ACCESSIBILITY ..............................................142
14.5 MOTOR BRAKE CLUTCH (MBC) ACCESSIBILITY..........143
14.6 MOTOR GEAR BOX ASSEMBLY ACCESSIBILITY..........143
14.7 MAIN CONTROL BOARD ACCESSIBILITY.......................144
14.8 LID / TOP PANEL ASSEMBLY ACCESSIBILITY...............145
14.8.1 Lid Lock Accessibility.......................................................................................... 146
14.9 PRESSURE SENSOR ACCESSIBILITY................................147
14.10 SOLENOID / WATER VALVE ACCESSIBILITY..............148
15. DIAGNOSTIC SYSTEM -
FFLE3911QW AND FFLG4033QW (WASHER)
15.1 READING ERROR CODES......................................................149
15.2 DIAGNOSTIC MODE ................................................................149
15.3 ENTERING DIAGNOSTIC MODE.........................................149
15.4 DIAGNOSTIC TESTS.................................................................150
15.5 EXITING DIAGNOSTICS MODE...........................................150
15.6 USER INTERFACE TEST..........................................................151
15.7 HOT WATER VALVE TEST......................................................151
15.8 COLD WATER VALVE TEST...................................................151
15.9 DOOR LID UNLOCK TEST .....................................................151
15.10 THREE WATER VALVES TEST............................................152
15.11 DRAIN AND CLUTCH TEST.................................................152
15.12 DRAIN AND SPIN TEST........................................................152
15.13 ALARM HISTORY TEST.........................................................152
15.14 ALARMS SUMMARY TABLE ................................................153
16. TROUBLESHOOTING BASED ON ALARM CODES –
FFLE3911QW AND FFLG4033QW
(WASHER MODEL)
E11: DIFFICULTIES IN WATER FILL FOR WASHING.............158
E13: WATER LEAKAGE......................................................................161
E21: DRAINING PROBLEM..............................................................163
E31: PRESSURE SENSOR FAULT ..................................................165
E32: ELECTRONIC PRESSURE SENSOR
CALIBRATION PROBLEMS ....................................................166
E35: WATER OVERLOAD .................................................................168
E41: DOOR / LID OPENED..............................................................170
E42: DOOR / LID LOCK FAILURE..................................................171
E43: DOOR / LID LOCK TRIAC FAILURE....................................172
E44: DOOR / LID CLOSED SENSING FAILURE .......................173
E45: DOOR / LID TRIAC SENSING FAILURE ............................174
E55: MOTOR UNDER-SPEED FAILURE .....................................175
E58: MOTOR OVER CURRENT......................................................177
E59: MOTOR NOT FOLLOWING...................................................179
E5A: MOTOR CONTROL OVER HEATING.................................181
E5H: MOTOR CONTROL UNDER VOLTAGE ............................183
E5C: MOTOR CONTROL OVER VOLTAGE................................183
E5D: MOTOR CONTROL BOARD UNKNOWN
MESSAGE.....................................................................................184
E5E: MOTOR CONTROL TO MAIN BOARD
COMMUNICATION INCORRECT........................................184
E5F: MOTOR CONTROL BOARD FAULT....................................185
E71: WASHING NTC FAILURE ........................................................185
E87: USER INTERFACE MICROCONTROLLER FAULT..........186
E91: USER INTERFACE AND MAIN BOARD
COMMUNICATION ERROR ..................................................186
E92: USER INTERFACE AND MAIN BOARD
PROTOCOL INCONGRUENCE ERROR...........................187
E93: MACHINE CONFIGURATION ERROR ...............................187
E94: CYCLE CONFIGURATION ERROR......................................188
E97: SOFTWARE SELECTOR AND CYCLES
CONFIGURATION ERROR....................................................188
E98: MOTOR CONTROL TO MAIN BOARD
SOFTWARE ERROR................................................................189
E9C: USER INTERFACE CONFIGURATION FAULT.................189
EB1:(EH1): POWER SUPPLY FREQUENCY OUT OF MITS.190
EB2:(EH2): POWER SUPPLY VOLTAGE TOO HIGH ..............190
EB3:(EH3): POWER SUPPLY VOLTAGE TOO LOW...............191
EBE:(EHE): MOTOR CONTROL BOARD RELAY ERROR .....191
EBF:(EHF): MOTOR CONTROL BOARD RELAY
SENSING ERROR.......................................................................191
EC6: CLUTCH ALARM.........................................................................192
EC7: CLUTCH TRIAC SENSING FAILURE....................................193
EF2: FOAM WARNING.......................................................................194
EF6: SAFETY RESET...........................................................................194

5
Safety Information
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
NOTE
Used to address practices not related to personal injury.
IMPORTANT
Information that requires special attention from the user.
CAUTION
Used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
Read the entire manual before attempting to Install, Assemble or Operate this product. Pay attention to all Warnings,
Cautions and Notes. Failure to do so could result in serious personal injury and /or equipment damage.
DEFINITIONS

6
Purpose of this Manual
This manual provides repairing procedures for appliances. It also provides information regarding Laundry Center with gas and
electric dryers fitted with the Electronic Control System. This manual is intended to use for service engineers of Electrolux.
The manual includes:
• Product Features, Specifications, Exploded Views and Bills of Materials (BOM)
• Installation
• Operating Instructions
• Electrical Characteristics and Specifications
• Accessibility to the Electrical Components
• Settings: Diagnostics
• Error alarm codes
• Troubleshooting based on alarm codes
1. Purpose of this Manual

7
Warnings
• Any work on electrical appliances must be carried out by qualified professionals.
• Confirm that the power system is operational before working on the appliance.
• Check that the appliance is restored to its original safety condition after the operation is complete.
• Take the plug out of the socket to disconnect the power supply before you access internal componenets. This platform is
not fitted with an ON / OFF switch.
• Warning sensors located on the display board could be at a potential of 220 Volts (If applicable).
• Do not place any container under the appliance to avoid collecting drips of water.
• Always empty the appliance before laying it on its side for any servicing.
• The resistance values of the components shown in this Service Manual (SM) are purely indicative and approximate.
• Replace the heating element with one that has the same characteristics to maintain safety
measures for the appliance.
• Ensure gas pipelines are connected properly as mentioned in the installation section for gas
dryer models.
• Lay down the machine on either side while servicing the unit. In such cases, some water in the detergent dispenser could
sip into the electrical / electronic components and cause these to burn.
• Always place the cotton cloth below the machine to absorb water. There is a possibility of water leakage while servicing
the Drain Pump and Dispenser.
2. Warnings

8
3. Product Features

9
Laundry Center (LC) Key Features Difference
Description FFLE/FFLG3911QW FFLE/FFLG4033QW
Heater Assembly
Electric
Gas
Electric
Gas
Moisture Bar No
Softener Valve
2 Valve 3 Valve
Bleach / Softener
Dispenser
Bleach Dispenser Bleach, Softner Dispenser
Energy Saver Option No

10
4.1 Specification – Top Load Laundry Center -
FFLE/FFLG3911QW and FFLE/FFLG4033QW
Model No.
FFLE/FFLG3911QW FFLE/FFLG4033QW
HE Top Load HE Top Load
Total Capacity D.O.E. (Cu. Ft.) 2.95 3.3
Controls Ready-Select® Ready-Select®
Washer Interior Polypropylene Polypropylene
Vibration Control System Ye s Ye s
Suspension System Sure-Spin™ Sure-Spin™
Wash System Immersion Care™ Action Immersion Care™ Action
Fresh Water Rinse Ye s Ye s
Automatic Temperature Control - Ye s
Water Level Adjustments Ye s Ye s
Bleach Dispenser Yes Yes
Fabric Softener Dispenser - Ye s
Agitate Speeds (Strokes / Min.) Variable Variable
Spin Speeds (RPM) 600 600
Sound Package - Silent Design™
Wash Cycles
Wash Cycles / Specialty Cycles 8 / 0 9 / 0
Washer Options
Temperature Selections 3 (Rotary) 3 (Rotary)
Water Levels 3 Automatic
Energy Saver Option - Ye s
Dryer Features
Total Capacity D.O.E. (Cu. Ft.) 5.5 5.5
Dryer Drum Interior Painted Steel Painted Steel
Interior Light - No
DrySense™ Technology - Ye s
Moisture Sensor - Ye s
Cycle Signal - Chime
Cycle Signal “On/Off ” - Ye s
Tumble Speed (RPM) 50 50
Lint Screen Ye s Ye s
4. Model Specifications

11
4.1 Specification – Top Load Laundry Center -
FFLE/FFLG3911QW and FFLE/FFLG4033QW
Model No.
FFLE/FFLG3911QW FFLG/FFLE4033QW
Sound Package - Silent Design™
Dry Cycles -
Dry Cycles / Specialty Cycles 8 / 0 9 / 0
Dryer Options
Temperature Selections 3 4
Dryness Level Selections 0 0
Timed Dry (Minutes) 15, 30, 60, 90 60, 90
Optional Accessories
Drain Hose Extension Kit PN # 134592700 PN # 134592700
LP Gas Conversion Kit PN # PCK3100
Drying Rack PN # DRLC PN # DRLC
Certifications
ENERGY STAR® - Ye s
Specifications
Maximum Exhaust Duct Length1 (Ft.) 56 56
Gas Connection - Rear
Power Supply Connection Location Middle Rear Middle Rear
Water Inlet Connection Location Middle Rear Middle Rear
Voltage Rating 240V / 60Hz / 30A 120V / 60Hz / 15A
Connected Load (kW Rating) @ 240
Volts
5.1 1.03
Amps @ 240 Volts 22 13 @ 120 Volts2
Heating Element @ 240 Volts (Watts) 4,500 20,000 (BTU / HR)
Shipping Weight (Approx.) 275 Lbs. 275 Lbs. (Approx.)
Product Dimensions - -
A - Height 76" 76"
B - Width 27" 27"
C - Depth 31-1/2" 31-1/2"
Depth with Door Open 90° 47-1/2" 47-1/2"

12
The following specifications are subject to change:
• For planning purposes only. Always consult local and national electrical and plumbing codes. Refer to Product Installation
Guide on the web at www.frigidaire.com for detailed installation instructions.
• 1 Rigid metal duct preferred, semi-rigid optional and allow deductions for elbows and vents. Refer to Installation Guide on
the web at www.frigidaire.com for additional information.
• 2 For use on adequately wired 120 V, dedicated circuit having 2-wire service with a separate ground wire. Appliance must
be grounded for safe operation.

13
5.1 FFLE3911QW
5.1.1 Upper Cabinet / Drum Heater
5. Exploded View and List of Parts

14
5.1.1 Upper Cabinet / Drum Heater
POS. NO DESCRIPTION
1 Panel, left side, white
3 Panel, top
4 Panel, Rear, Dryer, stainless
5 Ball, grounding
6 Clip, Ball, Steel, flat nut
7 Duct, air
7A Seal, air duct
8 Limiter, thermal, heater
9 Panel, motor access, washed
12 Bearing, drum support
13 Bracket, bearing support
14 Screw, bracket mtg., 10-16B x 1.375, cr/sq drive
15# Heater Asmy w/hsg, w/thermistor
17 Baffle, heater shield
18 Screw,10-16AB x 0.375,
20 Glide, flat dryer
21 Drum, dryer svc kit, galv. steel
22 Panel, Front weld, white
22* Plug, light hole
22A Pin, panel locator
23 Seal, felt ,lower
24 Seal, felt, upper
25 Door Catch, upper
26# Switch, door
27 Lint Trap
29 Screw, quadrex head, 10-14 x 1.00, vane mtg., special
30 Vane, straight, low
31 Screw, 10-16AB x 0.625
32 Shaft, drum support, ball hitch
33# Thermostat, safety
35 Screw, 6-20B x 0.230
36# Thermal Limiter
38 Panel, right side, white
38A* Seal, exhaust tube
39 Panel, access
41 Hinge, dryer door
42 Screw, flat head, 8-18AB x 0.44, quad drive
44 Gasket, door

15
5.1.1 Upper Cabinet / Drum Heater
POS. NO DESCRIPTION
46 Handle, door, white
47 Panel, inner door, white
48 Panel, outer door, white
49 Door Strike
50 Insulator, heat shield, outer door
51 Insulator, heater housing
52# Terminal Block, heater housing
54*# Wiring Harness, door switch, w/o light
62 Screw, 10-16AB x 0.500
80 Screw, pan head, 8-18B x 0.31
# Functional parts
* Non-Illustrated parts

16
5.1.2 Motor/Blower/Belt

17
5.1.2 Motor/Blower/Belt
POS. NO DESCRIPTION
1 Seal, air duct
3 Shield, air duct
4 Fastener, push-in
6 Duct, air
7 Seal, housing, to air duct
9 Clamp
10 Housing, blower, front w/seal
10A Housing, blower, rear
12 Blower Wheel
15# Thermistor, control
16 Screw, pan head, 8-18AB x 0.375
18 Cradle, motor w/idler
19 Pan ,Upper L/C, dryer, formed
22 Spring, idler
23 Idler Arm Assy, with pulley
23*# Terminal Block, main
25 Belt, dryer, LC
26 Block, support
27 Clamp, motor mtg.
28# Motor, dryer drive ,with pulley
33 Shield-access
38 Elbow, 90 Deg 4" Fixed
39 Screw ,#8 pan head, 10-10B x 0.500, cr/sq drive
41 Bracket, support, side
42 Bracket, marriage, dryer
44 Bracket, L mounting, cabinet rear, external
48 Pan, bottom LC dryer
50 Cover, support, LCD
51 Bushing, snap-in
80 Screw, pan head, 8-18B x 0.31
# Functional parts
* Non-Illustrated parts

18
5.1.3 Control Panel

19
5.1.3 Control Panel
POS. NO DESCRIPTION
1 # Control Board, main, with housing
3 # Wiring Harness, dryer, LC upper
4 Knob,switch
6# Harness, UI, washer, LC
8# PC Board, communication, with housing
15# Switch, PTS cycle select, 8 position
18 Console, decorated, white
21 Knob, Cycle Selector
22 Screw ,#8 pan head, 10-10B x 0.500, cr/sq drive
23 # Wiring Harness, main, LC
23*# Terminal Block, main
29 # Wiring Harness, LC Dryer, electrical
32 Cable Tie, 5.60 inch, plastic
39 # Switch, Option 3 pos
80 Screw, Phillips, 6-19 x 0.650
# Functional parts
* Non-Illustrated parts
