Frigidaire FD5122 User manual

INSTRUCTION MANUAL
STAND MIXER WITH ROTATABLE BOWL
MODELNO.: FD5122
Read this booklet thoroughly before using and save it for future
reference

1
IMPORTANT SAFEGUARDS
Before using the electrical appliance, the basic precautions
should always be followed including the following:
1. Read all instructions carefully.
2. Before use check the voltage of your wall outlet corresponds to
the one on the rating label of the mixer which is on the bottom of
the appliance.
If this is not the case, do not use the appliance & immediately
contact your dealer.
3. Household use only. Do not use Outdoors OR for Commercial
purpose.
4. Do not operate the appliance with a damaged cord or plug, after
the appliance malfunction, or if it is dropped or damaged in any
manner. Return the appliance to the nearest authorized service
center for examination, repair or electrical or mechanical
adjustment.
5. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
6. Do not use the appliance with bare feet OR wet hands or feet.
7. Do not leave mixer unattended while it is operating.
8. Do not let cord hang over edge of table or counter or hot surface.
9. Unplug the appliance from outlet while not in use, before putting
on or taking off parts and before cleaning. Remove beaters from
mixer before washing.
10. Always check that the control is OFF before plugging cord into
wall outlet. To disconnect turn the control to OFF then remove
plug from wall outlet.

2
11. To protect against risk of electrical shock, do not put mixer or
cord in water or other liquid, this may cause personal injury or
damage to the product.
12. The use of attachments not recommended by the manufacturer
may cause fire, electric shock or injury.
13. Avoid contacting with moving parts.
14. Keep hands, hair, clothing, as well as spatulas and other utensils
away from beaters during operation to reduce the risk of injury to
persons, and/or damage to the mixer
15. Close supervision is necessary when your appliance is being used
near children or infirm persons.
16. Children should be supervised to ensure that they do not play
with the appliances.
17. Do not place an appliance on or near a hot gas or on a heated
oven.
18. Never eject beaters or dough hooks when the appliance is in
operation.
19. Do not use the beaters to mix too hard ingredients.
20. Do not continuously operate the mixer for longer period, The
motor may over heat.
Note: For Speed 1-5: Continuous operating time must be less
than 3minutes.
For Turbo speed: Continuous operating time must be less
than 1minute.
21. The use of attachments or accessories not recommended or sold
by the manufacturer may cause fire, electric shock OR injury.

22. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliances
by a person responsible for their safety.
23. Switch off the appliance before changing accessories or
approaching parts which move in use.
24. Save these instructions.
HOUSEHOLD USE ONLY
KNOW YOUR STAND MIXER
1. Speed Selector
2. Ejector Button
3

4
3. Hand Mixer Body
4. Dough Hooks / Beaters
5. Accelerate Switch
6. Stand release button
7. Cord
8. Bowl
9. Base/Stand
USINGYOUR HAND/STAND MIXER
For the first use, clean the beaters, dough hooks and bowl. Before
assembling the mixer, be sure the power cord is unplugged from the
power outlet and the speed selector is on the “0” position.
1. Place the food that need to be blend into bowl, than place the
bowl on position.
2. Before putting the mixer on the base, make sure the bowl is
properly fitted on the base.
3. Insert the beaters by holding mixer from handle in one hand &
inserting the beaters/hooks form the other hand. Put it in hole,
press and twist it until beater/hooks clicks into position.
4. Choose the proper attachments based on the task to be performed
and assemble it in position. Dough hooks are used for mixing
dough and beaters are only used for beating eggs or similar food.
Note: Beaters can be inserted in either socket, as the beaters are
identical. For dough hooks, the one with washer can only be

5
inserted into the big socket and the other one can only be inserted
into small socket. The two dough hooks cannot be inserted in
reverse.
5. Ensure that the unit is at the 0 setting before connecting it to
power supply.
6. Start using the appliance from lower speed, i.e. Speed 1. You can
increase the speed as per need up to Speed 5.
7. IF you need more power, you may press the TURBO button for
maximum speed.
Warning: Do not place knife, metal spoon, fork and so on into
bowl when operating.
8. The max operation time for Speed 1 to 5 MUST be less than
3minutes. And for Turbo speed MUST be less than 1 minute.
Allow the appliance to cool down to room temperature before
performing next operation cycle. When kneading yeast dough, we
suggest that the speed selector should be at low speed firstly and
then use high speed to achieve the best results.
9. During operation the bowl will rotate itself.
10. When mixing is completed, turn the speed selector to 0 position,
unplug the cord from power outlet.
11. Press stand release button and pull up the hand mixer.
12. If necessary you can scrape the excess food particles from the
beaters or dough hooks by rubber or wooden spatula.
13. Hold the beaters/dough hooks with one hand and press the

6
Ejector button firmly down with the other hand, remove the
beater/dough hooks.
Note: Remove the beaters/dough hooks only at the 0 setting.
14. The hand mixer can be used separately without the stand in
position.
CLEANINGAND MAINTENANCE
1. Unplug the appliance and allow it to completely cool down
before cleaning.
2. Wipe over the outside surface of the mixer with a dampened cloth
and polish with a soft dry cloth.
3. Wipe any excess food particles from the power cord.
4. Wash the bowl, the beaters and dough hooks in warm soapy
water and wipe dry. The beaters and dough hooks may be washed
in the dishwasher.
Caution: the mixer cannot be immersed in water or other liquid.
COOKERY TIPS
1. Refrigerated ingredients, such as butter and eggs, should be at
room temperature before mixing begins. Set these ingredients out
ahead of time.
2. To eliminate the possibility of shells or deteriorated-off eggs in
your recipe, break eggs into separate container first, then adding

7
to the mixture.
3. Do not over-beat. Be careful that you only mix/blend mixtures
until recommended in your recipe. Fold into dry ingredients only
until just combined. Always use the low speed.
4. Climatic conditions. Seasonal temperature changes, temperature
of ingredients and their texture variation from area to area all
play a part in the required mixing time and the results achieved.
5. Always start mixing at lower speed. Gradually increase to the
recommended speed / higher speed as stated in the recipe.
SPECIFICATIONS:
PRODUCT STAND MIXER WITH ROTATABLE
BOWL
MODEL NO: FD5122
CAPACITY 2.4LITRES
VOLTAGE 220 – 240V
HERTZ 50/60Hz
WATTS 300W
WORK TIME (SPEED
1-5)
WORK TIME (TURBO)
LESS THAN 3 MINUTES
LESS THAN 1 MINUTE
MADE IN CHINA

ENVIRONMENT FRIENDLY DISPOSAL
8
You can help protect the environment!
Please remember to respect the local regulations: hand
in the non-working electrical equipments to an
appropriate waste disposal center.
IS A REGISTERED TRADEMARK USED UNDER LICENSE
FROM FRIGIDAIRE INTERNATIONAL COMPANY, U.S.A
10200 David Taylor Drive, Charlotte NC28262
U.S.A.
