Frigidaire FEB27T5G Instruction Manual

FEB30T6DC.eps CPLEB30T9FCA.eps BUFEB27T5DCC.eps BLFEB27T5DCC.eps
DCFEB30S5GC1.eps 318046121.eps
UPPEROVEN LOWEROVEN
Low er OvenUpper Oven
Clock
Keep
warm
Controls
Clear
/Off
Bake
tim e
Start
tim e
Oven
ligh t
Timer
On/Off
STAR T
Broil
Bake Speed
clean
Speed
bake
Clean
Speed Bake O vens
Keep
warm
Controls
Clear
/Off
Bake
tim e
Start
time
Oven
ligh t
STAR T
Broil
Bake Speed
clean
Speed
bake
Clean
Product No. FEB27T5GCA
37054743E70S1
Series 27" double
Color stainless
Market North America
Wiring Diagram 318046121
Owner's Guide 318200924
Installation Instructions 316201514
Service Data Sheet 318047306
Timer Guide 318200137
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995488060
07/04/04
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB27T5G
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995488060 FEB27T5GCA
04/07 2
CONTROL PANEL

FEB27T5GCA Publication No: 5995488060
# Functional Parts 3 04/07
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257301 Shield, oven top
2B 318260101 Cover, box
19 318271538 Control Panel Assembly, steel/glass, stainless/black, w/touch pad
20 # 316443800 Control, electronic, ES610W1, dual oven
20* 5303311306 Screw, 8-18 x 0.375, (8)
77 316247900 Spacer, power board, (4)
77A 316114100 Spacer, (2)
97 316443903 Board, relay, dual oven
* 318231751 Harness, wiring, control-relay
* 5303211311 Screw, 8 x 0.500

Publication No: 5995488060 FEB27T5GCA
04/07 4
UPPER OVEN

FEB27T5GCA Publication No: 5995488060
# Functional Parts 5 04/07
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
1 318259212 Back, main
2 318258910 Shield, insulation, upper
6 318262602 Rack, oven, (2)
9 5303317977 Pan, broiler
10 5303317976 Insert, broiler pan
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
58A 318285060 Insulation, rear & bottom, oven wrapper
58B 318285059 Insulation, top & sides, oven wrapper
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
66 # 318255601 Element, broil, 3400W
67 # 318255103 Element, bake, 2300W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260001 Panel, rear box
76 318056222 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258710 Shield, insulation, lower
83 318261502 Liner, oven assy
86 318342400 Receptacle, hinge
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
99 318252800 Support, side
* 5303300265 Screw, 8-18 X 1/2, (2)
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
119# 318004900 Switch, thermal
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
264 318257711 Trim, oven, black, front
310 5304440067 Cabinet Mounting Kit
311 318246010 Bracket, cabinet mtg, (2)
311* 5304438005 Screw, 6 x 1, black
312 318246702 Tool, cabinet bracket, RH
312 318246703 Tool, cabinet bracket, LH
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995488060 FEB27T5GCA
04/07 6
LOWER OVEN

FEB27T5GCA Publication No: 5995488060
# Functional Parts 7 04/07
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
1 318259212 Back, main
2 318258910 Shield, insulation, upper
6 318345209 Rack, oven, (3)
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
54 318222400 Housing, oven light
56 318903604 Trim, side filler, black, RH
56A 318903605 Trim, side filler, black, LH
58A 318285060 Insulation, rear & bottom, oven wrapper
58B 318285059 Insulation, top & sides, oven wrapper
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255601 Element, broil, 3400W
67 # 318255103 Element, bake, 2300W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260001 Panel, rear box
71* 318340200 Bracket, insul. panel
76 318056222 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258710 Shield, insulation, lower
83 318261502 Liner, oven assy
86 318342400 Receptacle, hinge
87 318260601 Bracket, cable mtg.
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
90 318259711 Trim, oven front, black, bottom
99 318256200 Bracket, side, bottom, (2)
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
119# 318004900 Switch, thermal
127 318317100 Adapter Assembly, vent tube, w/converter
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
264 318257811 Trim, oven, black, front
* # 318078543 Box & wires assy
* 318231746 Harness, wiring, main
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995488060 FEB27T5GCA
04/07 8
DOORS

FEB27T5GCA Publication No: 5995488060
# Functional Parts 9 04/07
* Non-Illustrated Parts
DOORS
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260510 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372001 Insulation, door, 20.5 x 2.375, (2)
8 318212200 Glass, oven door, heat barrier
9 318259615 Liner, upper door
10 5303311174 Screw, 10-24 x 3/8
12 318053135 Seal, oven door, upper
13 318272111 Door Assy, w/glass, stainless steel, outer, w/tape & foil
17 318264700 Spacer, glass, (2)
23 318024722 Hinge, door, upper, (2)
24 318260311 Trim, door, black, lower
39 318264500 Handle, oven door, black
40 318242702 Bracket, glass holder, (2)
41 318370600 Bracket, glass retainer, (2)
42 318382301 Bracket, glass retainer, (4)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 318163602 Cleaner, stainless steel
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995488060 FEB27T5GCA
04/07 10
WIRING DIAGRAM
