Frigidaire GLEB27T8C User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
GLEB27T8CBA GLEB27T8C 3705691F3061 black North America
GLEB27T8CSA GLEB27T8C 37056791F3011 white North America
Publication No.
5995383394
021226
-EN/SERVICE /ECL
377
ELECTRIC
WALL OVEN
Model No.
GLEB27T8C
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318046110
OWNER’S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200130
INSTALLATION INSTRUCTIONS - # 318201510
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

12/02 2
Publication No. GLEB27T8C
5995383394
CONTROL PANEL

# = Functional Parts 3 12/02
* = Non-Illustrated Parts
GLEB27T8C Publication No.
5995383394
CONTROL PANEL
A = GLEB27T8C (GLEB27T8CSA)
B = GLEB27T8C (GLEB27T8CBA)
POS. NO PART NO DESCRIPTION
15 5303302286 A B Support,backguard ,RH
15A 5303302287 A B Support,backguard ,LH
18 5303311208 A - End Cap,white ,RH
18 5303311231 - B End Cap,black ,RH
18A 5303311209 A - End Cap,white ,LH
18A 5303311232 - B End Cap,black ,LH
19 318030040 A - Panel,control ,white
19 318030041 - B Panel,control ,black
20 # 318010501 A B Clock/Timer,EOC
21 5303302283 A - Trim,canopy ,white ,top
21 5303300968 - B Trim,canopy ,black ,top
23 318015110 A B Bracket,clock mtg
42 5303318709 A - Trim,vent ,white
42 5303316983 - B Trim,vent ,black
78 318036901 A - Cover,oven vent ,white
78 318036900 - B Cover,oven vent ,black
80 # 318022001 A B Relay Board
81 # 318022002 A B Relay Board,w/transformer
82A 5303317199 A B Support,snap-in ,(3)
99 5303316956 A - Screw,6-32 x 3/8 ,white ,(2)
99 5303307406 - B Screw,6-32 x 3/8 ,black ,(2)
* 3201861 A B Screw,6 x 0.375
* 5303211311 A B Screw,8 x 0.500
* 5303323136 A B Screw ground

12/02 4
Publication No. GLEB27T8C
5995383394
UPPER OVEN

# = Functional Parts 5 12/02
* = Non-Illustrated Parts
GLEB27T8C Publication No.
5995383394
UPPER OVEN
A = GLEB27T8C (GLEB27T8CSA)
B = GLEB27T8C (GLEB27T8CBA)
POS. NO PART NO DESCRIPTION
2 318070202 A B Cover,top
2A 318071502 A B Shield,oven top
3 318070610 A B Panel,bodyside ,upper,RH
3A 318070611 A B Panel,bodyside ,upper,LH
6 5303299719 A B Rack,oven
6A 318219500 A B Rack,broiler pan
6B 318025202 A B Shelf,oven
9 5303317977 A B Pan,broiler
10 5303317976 A B Insert,broiler pan
12 # 318089913 A B Switch,light
14 5308011085 A B Receptacle,oven light
15 5303013071 A B Bulb/Lamp,oven light
16 3201911 A B Cover,oven light ,glass
17 5304400195 A B Retainer,light cover
37 # 316111203 A B Sensor,oven temp probe
41 5303310526 A B Cover,hinge cutout
54 5303310514 A B Housing,oven light
58A 318133758 A B Insulation,oven wrapper
58B 318133749 A B Insulation,oven back
58C 5303316994 A B Insulation
59 318072510 A B Tube,oven vent
62 # 5303310518 A B Terminal Block
62* 5303323144 A B Nut,10-32
66 # 5303322963 A B Element,broil
67 # 5303299718 A B Element,bake
68 5304403015 A B Support,element hanger
70 5303300142 A B Shield,insulation
76 318056104 A B Front,oven
80 5303320846 A B Plate,oven mtg
81 318192400 A B Spring,oven
83 318089524 A B Liner,oven
86 5303310524 A B Receptacle,hinge
88 5303311222 A B Rod,latch
89 # 318095934 A B Motor,latch assy ,w/brkt & switch
89* 318120711 A B Switch
97 318066703 A B Wrapper,back and sides
107 318219401 A B Cover,fan
108# 318073012 A B Motor,blower
109 5303311203 A B Blade,fan
111 316136600 A B Nut,fan retainer
119# 318004900 A B Switch,thermal
125# 5303311202 A B Motor,convection
127 5303310542 A B Adapter,vent tube ,with converter
128 5303311163 A B Bushing
129 5303311164 A B Spring
156 318024100 A B Bracket,vent tube
157 318071602 A B Divider,upper oven
185 318014700 A B Spacer,oven shield
187 318013501 A B Tube,latch rod
222 318080000 A B Plate,oven temp probe
263 316136500 A B Washer,fan motor
272 5303311207 A B Tube,protector
* # 318078507 A B Box & wires assy
* 3015722 A B Clip-wire
* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 5303211311 A B Screw,8 x 0.500

12/02 6
Publication No. GLEB27T8C
5995383394
LOWER OVEN

# = Functional Parts 7 12/02
* = Non-Illustrated Parts
GLEB27T8C Publication No.
5995383394
LOWER OVEN
A = GLEB27T8C (GLEB27T8CSA)
B = GLEB27T8C (GLEB27T8CBA)
POS. NO PART NO DESCRIPTION
2A 318071502 A B Shield,oven top
6 5303299719 A B Rack,oven
6B 318025202 A B Shelf,oven
12 # 318089913 A B Switch,light
14 5308011085 A B Receptacle,oven light
15 5303013071 A B Bulb/Lamp,oven light
16 3201911 A B Cover,oven light ,glass
17 5304400195 A B Retainer,light cover
37 # 316111203 A B Sensor,oven temp probe
41 5303310526 A B Cover,hinge cutout
54 5303310514 A B Housing,oven light
56 5303302282 A - Trim,bodyside ,white ,(2)
56 5303300956 - B Trim,bodyside ,black ,(2)
58A 318133758 A B Insulation,oven wrapper
58B 318133749 A B Insulation,oven back
58C 5303316994 A B Insulation
59 5303300951 A B Tube,oven vent
59A 5303320844 A B Tube,oven vent
66 # 5303322963 A B Element,broil
67 # 5303299718 A B Element,bake
68 5304403015 A B Support,element hanger
70 5303300142 A B Shield,insulation
71 318071212 A B Shield,wire
76 318056104 A B Front,oven
80 5303320846 A B Plate,oven mtg
81 318192400 A B Spring,oven
82 318071801 A B Shield,oven bottom
83 318089524 A B Liner,oven
86 5303310524 A B Receptacle,hinge
88 5303311222 A B Rod,latch
89 # 318095934 A B Motor,latch assy ,w/brkt & switch
89* 318120711 A B Switch
96 5303317197 A B Duct,oven vent ,assy
96A 3016325 A B Duct,oven vent ,center
96B 3016327 A B Duct,vent pipe
97 318066703 A B Wrapper,back and sides
98 318029352 A B Trim,side ,inner,RH
98A 318029353 A B Trim,side ,inner,LH
99 318055420 A B Support,adjustable
101 318039512 A - Bracket,trim ,white
101 318039511 - B Bracket,trim ,black
103 318028701 A - Trim,base ,white
103 318028700 - B Trim,base ,black
107 318219401 A B Cover,fan
109 5303311203 A B Blade,fan
111 316136600 A B Nut,fan retainer
119# 318004900 A B Switch,thermal
124 318076902 A B Box,vent
125# 5303311202 A B Motor,convection
125* 318142100 A B Washer,motor ,convection
127 318072801 A B Adaptor assy
128 5303311163 A B Bushing
129 5303311164 A B Spring
150 318072205 A B Bracket,support ,LH
150A 318072204 A B Bracket,support ,RH
156 5303317198 A B Bracket,oven vent
185 318014700 A B Spacer,oven shield
187 318013501 A B Tube,latch rod
188 318014110 A B Spacer
209 318086210 A B Plate,retainer
222 318080000 A B Plate,oven temp probe
263 316136500 A B Washer,fan motor
272 5303311207 A B Tube,protector
* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 5303211311 A B Screw,8 x 0.500
* 5303302745 A B Screw,10-16x1-1/8 ,square drive

12/02 8
Publication No. GLEB27T8C
5995383394
DOOR

# = Functional Parts 9 12/02
* = Non-Illustrated Parts
GLEB27T8C Publication No.
5995383394
DOOR
A = GLEB27T8C (GLEB27T8CSA)
B = GLEB27T8C (GLEB27T8CBA)
POS. NO PART NO DESCRIPTION
3 318026110 A - Trim,oven door ,white
3 318026600 - B Trim,oven door ,black
4 318051615 A - Glass,oven door ,white ,outer
4 318051616 - B Glass,oven door ,black ,outer
6 318073502 A B Shield,air wash
7 318133751 A B Insulation,oven door
9 318048503 A B Liner,oven door
10 5303311217 A B Screw,handle ,door
12 318053100 A B Seal,oven door
16 318042300 A B Glass,oven door ,heat barrier ,(2)
17 318042000 A B Spacer,glass
18 318053000 A B Seal,rope
20 318014301 A - Spacer,handle ,white ,(2)
20 318014300 - B Spacer,handle ,black ,(2)
22 5303310511 A B Bar,glass retainer
23 5303310506 A B Hinge,oven door ,assembly
29 318014400 A B Spacer,door
31 318065102 A B Latch,door
39 316091107 A - Handle,door ,white ,oven
39 316091106 - B Handle,door ,black ,oven
54 5303308456 A B Screw,8-18 x 0.531 ,black ,door frame
59 3202113 A B Plug,button
* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box
* 5303211311 A B Screw,8 x 0.500
* 5303323277 A B Screw (8-18X13/32)

12/02 10
Publication No. GLEB27T8C
5995383394
WIRING DIAGRAM
