Frigidaire FEC32C4ACD Instruction Manual

Product No. FEC32C4ACD FEC32C4AQD FEC32C4ASD
38054311610C4 3805431161044 3805431161014
Series 32" elec 32" elec 32" elec
Color stainless bisque white
Market North America North America North America
Wiring Diagram 318046901 318046901 318046901
Owner's Guide 318200612 318200612 318200612
FEC32C4A.eps LA9923G28A.eps LA9923V31.eps 318046901.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995403036
04/02/02
(EN/SERVICE/ECL)
377
ELECTRIC COOK-TOP
RANGE
Model No.
FEC32C4A
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995403036 FEC32C4A
02/04 2
CONTROL PANEL

FEC32C4A Publication No: 5995403036
# Functional Parts 3 02/04
* Non-Ilustrated Parts
CONTROL PANEL
Model Index: AFEC32C4A (FEC32C4ASD)
BFEC32C4A (FEC32C4ACD)
CFEC32C4A (FEC32C4AQD)
POS. NO PART NO. DESCRIPTION
14 5303323991 A B C Lamp, indicator
19 318183502 A - - Insert, white
19 318183504 - B - Insert, black
19 318183503 - - C Insert, bisque
36 318196633 A - - Knob, control, white
36 318196634 - B - Knob, control, black
36 318196635 - - C Knob, control, bisque
46 5303200418 A B C Lens, indicator light
54 # 318220014 A B C Switch, surface unit, small
54A# 318220015 A B C Switch, surface unit, large
69 5303305528 A B C Screw, 8-32 x 1/4
74 318146010 A B C Bushing, switch
* 5303308449 A B C Fastener, wire tie
* 08002868 A B C Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303323140 A B C Screw, ground, 10-32 x 0.375

Publication No: 5995403036 FEC32C4A
02/04 4
MAIN TOP/SURFACE UNITS

FEC32C4A Publication No: 5995403036
# Functional Parts 5 02/04
* Non-Ilustrated Parts
MAIN TOP/SURFACE UNITS
Model Index: AFEC32C4A (FEC32C4ASD)
BFEC32C4A (FEC32C4ACD)
CFEC32C4A (FEC32C4AQD)
POS. NO PART NO. DESCRIPTION
15 # 5308011964 A B C Element, surface, large/8 inch, (2), medallion incl
15A# 5304437241 A B C Element, surface, small/6 inch, 1250W, medallion incl
16 5303299756 A - - Main Top, white
16 5303299758 - B - Main Top, stainless
16 318158900 - - C Main Top, bisque
19 # 318067056 A B C Pan, surface element, large, chrome
19A# 318067046 A B C Pan, surface element, small, chrome
27 # 318223405 A B C Terminal Block, surface element, 6", yellow leads
27 # 318223406 A B C Terminal Block, surface element, 12", white leads
27 # 318223408 A B C Terminal Block, surface element, 18", orange leads
27 # 318223425 A B C Terminal Block, surface element, 12", brown leads
28 5303301461 A B C Medallion, surface element
46 5304410269 A B C Burner Box
63 318014110 A B C Spacer
93 318122500 A B C Support, terminal block, (4)
136 3008711 A B C Bracket, mounting
137 5303325981 A B C Screw, 10-16 x 1 1/2
138 08016269 A B C Clip
162 3008713 A B C Shield wire
* # 318078525 A B C Box & wires assy
* 08002868 A B C Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box
* 5303300195 A B C Screw, 10-32 x 0.375, terminal block, (2)
* 5303323140 A B C Screw, ground, 10-32 x 0.375

Publication No: 5995403036 FEC32C4A
02/04 6
WIRING DIAGRAM
