Frigidaire FEF367CGSB User manual

© 2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
P.O. Box 212378
Augusta, Georgia 30917
PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF367CGSB FEF367CG WHITE/WHITE USA
FEF367CGTB FEF367CG ALMOND/ALMOND USA
Publication No.
5995344818
001013
-EN/SERVICE /CML
369
WIRING DIAGRAM # - 316002695
OWNER’S GUIDE # - 316135911
INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE
FEF367CGSB
FEF367CGTB

10/00 2
Publication number
5995344818 FEF367CGSB, FEF367CGTB
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD

# - Fast Moving Parts
* - Non Illustrated Parts 3 10/00
Publication number
FEF367CGSB, FEF367CGTB 5995344818
CAUTION: Use the part number on all orders, not the position number.
BACKGUARD
A = FEF367CG (FEF367CGSB)
B = FEF367CG (FEF367CGTB)
POS. NO PART NO DESCRIPTION
* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,black,back/bodyside
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome ,
hinge,ind light,manifold panel
* 316021110 A B Screw,semi gimlet ,8-18 x 0.500 ,black
* 316085600 A B Insulator
1 316081600 A B Shield-backguard,galv steel ,rear wall
2 316015905 A B Shield-backguard,inner
11 316083720 - B Trim-wrapper,textured,almond
11 316083721 A - Trim-wrapper,textured ,white
14 316022503 A B Light/Lamp, indicator , surface ,250 V
14A 316022500 A B Light/Lamp, warmer, indicator , drawer/zone, 125 V
15 316023108 A B Support-backguard,RH
15A 316023109 A B Support-backguard,LH
19 316100539 A - Panel-control,white
19 316100540 - B Panel-control,almond
20 316101008 A B Clock-timer
20A 316101502 A - Overlay-clock,white
20A 316101504 - B Overlay-clock,almond
23 316100301 A B Bracket-timer
24 # 316118101 A - Switch-oven light,rocker ,white
24 # 316118102 - B Switch-oven light,rocker ,almond
24C# 316114000 A - Switch-Speed Bake,white
24C# 316114001 - B Switch-Speed Bake, almond
36 316025106 A - Knob-control,infinite sw ,white
36 316025107 - B Knob-control,infinite sw ,almond
40 316025808 A - Panel-manifold,white
40 316025809 - B Panel-manifold,almond
46 316040201 A B Lens-light/lamp,indicator ,red
54 # 316021500 A B Switch,infinite , 6" element
54A# 316021501 A B Switch,infinite , 8" element
69 5303292005 A B Screw,8-32 x 5/32 ,switch/handle
96* 316113700 A B Relay

10/00 4
Publication number
5995344818 FEF367CGSB, FEF367CGTB
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 5 10/00
Publication number
FEF367CGSB, FEF367CGTB 5995344818
CAUTION: Use the part number on all orders, not the position number.
BODY
A = FEF367CG (FEF367CGSB)
B = FEF367CG (FEF367CGTB)
POS. NO PART NO DESCRIPTION
* 3203550 A B Plug-button,oven bottom
* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,
black,back/bodyside
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome ,
hinge,ind light,manifold panel
* 316045000 A B Clip-wiring harness,retainer ,green ,main top
* 316101600 A B Insulator-vent,smoothtop
* 5303051099 A B Nut,hex ,#10-32
* 5303308427 A B Nut,hex ,10-32
* 5308014215 A B Screw,6-20 x 0.312
1 316080803 A B Panel-main back,galv steel ,short
3 316081034 A - Panel-bodyside,white ,RH
3 316081035 A - Panel-bodyside,white ,LH
3 316081036 - B Panel-bodyside,almond ,RH
3 316081037 - B Panel-bodyside,almond ,LH
5 316129200 A B Screw-leveling,plastic ,with stop
6 316067902 A B Rack-oven
7 316007002 A B Hinge-oven door,(2)
8 3203540 A B Panel-oven bottom
9 316081900 A B Pan-broiler
10 316082000 A B Insert-broiler pan
12 # 316027701 A B Switch-oven light
13 316026800 A B Rod-light switch /door
14 316116400 A B Socket-light/lamp,oven
15 5303013071 A B Light Bulb/Lamp
16 08011086 A B Lens-light/lamp, glass , oven
17 316087500 A B Retainer-lens
18 # 316036300 A B Latch-door
21 3014099 A B Spacer-bodyside, (8)
25 3200848 A B Shield-heat,lower
29 3051162 A B Glide-drawer,front
37 # 316111202 A B Probe-oven temp
41 3131570 A B Cover-hinge cutout
44 3131903 A B Bumper-door/drawer, rubber
45 316066100 A B Shield-wire,s/t vent
57 316081100 A B Cover-access
58 3200847 A B Insulation,oven bottom
58A 316047708 A B Insulation, 2" ,oven wrapper
58B 316054201 A B Insulation,oven back
59 316073602 A B Tube-oven vent
59A 316023600 A B Tube-oven vent,upper
59B 316040100 A B Bracket-mounting,vent tube
62 # 5303935061 A B Terminal Block Kit
63 5301145190 A B Plate-ground strap
66 # 5303051140 A B Element-broil,2950 W
67 # 316075103 A B Element-bake
68 316075300 A B Support-element, broil
71 316015804 A B Shield-rear wall,galv steel
72 5303285692 A B Cover-light/switch rod
82 5303289913 A B Shield-insulation
87 316081200 A B Bracket-cable mtg
88 316026400 A B Rod-latch,auto

10/00 6
Publication number
5995344818 FEF367CGSB, FEF367CGTB
CAUTION: Use the part number on all orders, not the position number.
BODY

# - Fast Moving Parts
* - Non Illustrated Parts 7 10/00
Publication number
FEF367CGSB, FEF367CGTB 5995344818
CAUTION: Use the part number on all orders, not the position number.
BODY
89 # 316028107 A B Motor-latch/lock
106 316026600 A B Bracket-motor mtg
107 316026701 A B Cover-fan
108* 316021111 A B Screw,8-18 x 1.500
108# 316090500 A B Motor-fan
109 316090600 A B Fan Blade
110 316090700 A B Washer,fan motor
111 316090800 A B Nut-fan retainer
112 316082700 A B Relay,oven door lock
170 5303935180 A B Anti-tip Kit,w/bracket,screw
170* 316107200 A B Bracket,anti-tip
170* 316112500 A B Template, Anti-tip bracket
170* 316116000 A B Screw,concrete tpg ,1.75 inch ,
anti-tip brkt

10/00 8
Publication number
5995344818 FEF367CGSB, FEF367CGTB
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER

# - Fast Moving Parts
* - Non Illustrated Parts 9 10/00
Publication number
FEF367CGSB, FEF367CGTB 5995344818
CAUTION: Use the part number on all orders, not the position number.
TOP/DRAWER
A = FEF367CG (FEF367CGSB)
B = FEF367CG (FEF367CGTB)
POS. NO PART NO DESCRIPTION
* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,
black,back/bodyside
* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome ,
hinge,ind light,manifold panel
* 316021110 A B Screw,semi gimlet ,8-18 x 0.500 ,black
* 316021112 A - Screw-8-18x1/2 Tr Sqd White
* 316021113 - B Screw-8-18x1/2 Tr Sqd Almond
* 316045000 A B Clip-wiring harness,retainer ,green ,main top
* 316089600 A B Spacer-drawer,(2)
* 316112101 A B Cleaner-cooktop
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312
* 5308014215 A B Screw,6-20 x 0.312
1 316011501 A B Drawer-utility
2 5303288582 A B Shield-drawer,galv steel ,front panel
4 316084405 A - Panel-drawer front,white
4 316084406 - B Panel-drawer front,almond
7 3051163 A B Glide-drawer,rear
10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2
15 # 316010206 A B Element-surface,radiant , large/8 inch ,2100 W
15A# 316010205 A B Element-surface,radiant , small/6 inch ,1200 W
16 316098104 - B Main top,smooth top ,almond
16 316098105 A - Main top, smoothtop, white
18 5303273062 A B Hinge-main top,RH
18A 5303273063 A B Hinge-main top,LH
26 316099100 A B Channel-support,element ,galv steel ,(2)
26A 316099200 A B Bracket-support,chassis ,galv steel
44 3131903 A B Bumper-door/drawer, rubber
48 316100200 A B Shield-wire,main top
52 316099400 A B Clip-spring, element mtg,(8)
53 316099300 A B Bracket-indicator light,hot surface ,4 hole
88 316099500 A B Pin-guide, (2)

10/00 10
Publication number
5995344818 FEF367CGSB, FEF367CGTB
CAUTION: Use the part number on all orders, not the position number.
DOOR

# - Fast Moving Parts
* - Non Illustrated Parts 11 10/00
Publication number
FEF367CGSB, FEF367CGTB 5995344818
CAUTION: Use the part number on all orders, not the position number.
DOOR
A = FEF367CG (FEF367CGSB)
B = FEF367CG (FEF367CGTB)
POS. NO PART NO DESCRIPTION
* 3131737 A B Washer-hinge,black
* 3203618 A B Rivet-pop,warning-plate
* 316021110 A B Screw,semi gimlet ,8-18 x 0.500 ,black
* 316065306 A B Plate-warning/caution
* 316132100 A B Spacer,sponge pad
* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2 ,
* 5303280311 A B Screw,wafer hd sq dr ,10-32 x 0.312 ,
* 5303285179 A B Screw-oven door,wafer head ,8-32T x 1/2
* 5303292005 A B Screw,8-32 x 5/32 ,switch/handle
3 316067803 - B Trim-oven door,almond
3 316067804 A - Trim-oven door,white
4 316089004 - B Glass-oven door,almond ,outer
4 316089005 A - Glass-oven door,white ,outer
5 316088700 A B Glass-oven door,airwash
6 316088401 A B Shield-wool
7 316076403 A B Insulation-door
8 316088600 A B Glass-oven door,inner
9 316066610 A B Liner-oven door
10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2
10* 316008401 A B Washer,3/4 OD x 1/4 ID ,steel
12 # 5303131601 A B Seal-oven door
14 3131361 A B Reflector,aluminum foil
14A 3131360 A B Reflector,aluminum foil ,(2)
15 316081403 A B Bracket-glass mtg
16 316085701 A B Glass-oven door,heat barrier
39 316091115 A - Handle-door,white ,oven
39 316091116 - B Handle-door,almond ,oven
52 316081301 A - Shield-oven door,white ,top
52 316081302 - B Shield-oven door,almond ,top

10/00 12
Publication number
5995344818 FEF367CGSB, FEF367CGTB
CAUTION: Use the part number on all orders, not the position number.
WIRING DIAGRAM
