Frigidaire FFEF3052T Owner's manual

808527510 Rev D (Jan 2018)
TABLE OF CONTENTS
Product Record and Registration . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . 3
Cooking Recommendations . . . . . . . . . . . . . . . . . . 8
Before Setting Surface Controls . . . . . . . . . . . . . . 11
Setting Surface Controls . . . . . . . . . . . . . . . . . . . . 14
Before Setting Oven Controls . . . . . . . . . . . . . . . . 18
Setting Oven Controls . . . . . . . . . . . . . . . . . . . . . . 19
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 24
Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

22017 Electrolux Home Products, Inc. All rights reserved. Printed in the USA
Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . .2
Product Record and Registration . . . . . . . . . . . . . . . . . 2
Need Help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 3
Cooking Recommendations . . . . . . . . . . . . . . . . . . . . . 8
Before Setting Surface Controls . . . . . . . . . . . . . . . . 11
Setting Surface Controls . . . . . . . . . . . . . . . . . . . . . . 14
Before Setting Oven Controls . . . . . . . . . . . . . . . . . . 18
Setting Oven Controls . . . . . . . . . . . . . . . . . . . . . . . . . 19
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Oven Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Questions?
For toll-free telephone support in the U.S. and Canada call
1-800-944-9044.
For online support and Internet production information visit
http://www.frigidaire.com.
Product Registration
Registering your product with Frigidaire enhances our
ability to serve you. You can register online at
http://www.frigidaire.com or by dropping your Product
Registration Card in the mail.
Record model & serial numbers here
Purchase Date
Frigidaire model number
Frigidaire serial number
Serial Plate Location
Serial plate location: open lower oven drawer (some
models) or storage drawer (some models).
PRODUCT RECORD AND REGISTRATION
Thank you for choosing Frigidaire.
Important: This Use and Care Guide is part of our commit-
ment to customer satisfaction and product quality
throughout the service life of your new appliance. We view
your purchase as the beginning of a relationship. To ensure
our ability to continue serving you, please use this page to
record important product information.
Need Help?
Visit the Frigidaire web site at www.frigidaire.com
Before you call for service, there are a few things you can
do to help us serve you better.
Read this Use & Care Manual
This manual contains instructions to help you use and
maintain your range properly.
If You Received a Damaged Range...
Immediately contact the dealer (or builder) that sold you the
range.
Save Time and Money
Check the section title “Before You Call”. This section helps
step you through some common problems that might occur.
If you do need service, help is only a phone call away. Call
Frigidaire Customer Services at 1-800-944-9044.

3
Read all instructions before using this appliance.
This manual contains important safety symbols
and instructions. Please pay attention to these
symbols and follow all instructions given.
Do not attempt to install or operate your appliance
until you have read the safety precautions in this
manual. Safety items throughout this manual are
labeled with a WARNING or CAUTION statement
based on the risk type.
Warnings and important instructions appearing in
this guide are not meant to cover all possible
conditions and situations that may occur.
Common sense, caution, and care must be
exercisedwithinstalling,maintaining, or operating
your appliance.
DEFINITION
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol
to avoid possible injury or death.
Indicates a potentially hazardous situation
which, if not avoided, may result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury.
Indicates installation, operation, maintenance,
or valuable information that is not hazard
related.
Indicates a short, informal reference –
something written down to assist the memory or
for future reference.
WARNING
CAUTION
IMPORTANT
NOTE
WARNING
Tip Over Hazard
• A child or adult can tip
the range and be killed.
• Verify the anti-tip device
has been installed to floor
or wall.
• Ensure the anti-tip device is
re-engaged to floor or wall when the
range is moved.
• Do not operate the range without the
anti-tip device in place and engaged.
• Failure to follow these instructions can
result in death or serious burns to
children and adults.
Range
leveling
leg Anti-tip
bracket
To check if the anti-tip bracket is installed
properly, use both arms to grasp the rear edge
of the range back. Carefully attempt to tilt
range forward. When properly installed, the
range should not tilt forward.
Refer to the anti-tip bracket installation instruc-
tions supplied with your range for proper
installation.
IMPORTANT SAFETY INSTRUCTIONS

4
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR
UNPACKING AND INSTALLATION
IMPORTANT - Read and follow the below instruc-
tions and precautions for unpacking, installing,
and servicing your appliance:
Remove all tape and packaging before using the
appliance. Destroy the carton and plastic bags
after unpacking the appliance. Never allow
children to play with packaging material. Do not
remove the wiring label and other literature
attached to the appliance. Do not remove model/
serial number plate.
Cold temperatures can damage the electronic
control. When using this appliance for the first
time, or when the appliance has not been used
for an extended period of time, be sure the
appliance has been in temperatures above 32ºF
(0ºC) for at least 3 hours before turning on the
power to the appliance.
Never modify or alter the construction of the
appliance by removing the leveling legs, panels,
wire covers, anti-tip brackets/screws, or any other
part of the appliance.
Be sure to have an appropriate foam-type fire
extinguisher available, visible, and easily acces-
sible located near the appliance.
GROUNDING INSTRUCTIONS
Proper Installation—Be sure your appliance is
properly installed and grounded by a qualified
technician. In the United States, install in accor-
dance with the National Fuel Gas Code ANSI
Z223.1/NPFA No. 54, latest edition and National
Electrical Code NFPA No. 70 latest edition, and
local electrical code requirements. In Canada,
install in accordance with CAN/CGA B149.1 and
CAN/CGA B149.2 and CSA Standard C22.1,
Canadian Electrical code, Part 1-latest editions
and local electrical code requirements. Install only
per installation instructions provided in the litera-
ture package for this appliance.
For personal safety, this appliance must be
properly grounded. For maximum safety, the
power cord must be securely connected to an
electrical outlet or junction box that is the correct
voltage, is correctly polarized and properly
grounded, and protected by a circuit breaker in
accordance with local codes.
It is the personal responsibility of the consumer to
have the appropriate outlet or junction box with
the correct, properly grounded wall receptacle
installed by a qualified electrician. It is the respon-
sibility and obligation of the consumer to contact a
qualified installer to assure that the electrical
installation is adequate and is in conformance
with all local codes and ordinances.
See the installation instructions packaged with
this appliance for complete installation and
grounding instructions.
Avoid fire hazard or electrical shock. Failure to
follow this warning may cause serious injury,
fire, or death. Do not use an adapter plug, use
an extension cord, or remove grounding prong
from the power cord. Failure to follow this
warning may cause serious injury, fire, or death.
WARNING

5
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR USING THE
APPLIANCE
Storage In or On Appliance—Flammable materials
should not be stored in an oven or microwave, near
surface burners or elements, or in the storage or
warmer drawer (if equipped). This includes paper,
plastic, and cloth items, such as cookbooks, plastic
ware, and towels, as well as flammable liquids. Do
not store explosives, such as aerosol cans, on or
near the appliance.
Do not leave children alone - Children should not be
left alone or unattended in the area where appliance
is in use. They should never be allowed to sit or
stand on any part of the appliance, including the
storage drawer, lower broiler drawer, warmer
drawer, or lower double oven.
Do not store items of interest to children in the
cabinets above the appliance or on the backguards
of ranges. Children climbing on or near the
appliance to reach items could be seriously injured.
Do not allow children to climb or play around the
appliance. The weight of a child on an open over
door may cause the appliance to tip, resulting in
serious burns or other injury. An open drawer when
hot may cause burns.
Stepping, leaning, or sitting on the door or drawers
of this appliance can result in serious injuries and
also cause damage to the appliance.
Never cover any slots, holes, or passages in the
oven bottom or cover an entire oven rack with any
materials, such as aluminum foil or aftermarket oven
liners. Aluminum foil and other liners may trap heat,
causing a fire hazard.
Do not use oven or warmer drawer (if equipped) for
storage.
Never use your appliance as a space heater to heat
or warm the room. Doing so may result in carbon
monoxide poisoning and overheating of the appli-
ance.
WARNING
When heating fat or grease, watch it closely. Grease
may catch fire if it becomes too hot.
Do not use water or flour on grease fires. Smother
fire or flame or use dry chemical or foam-type extin-
guisher. Cover the fire with a pan lid or use baking
soda.
Use dry potholders. Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let
potholders touch hot cooking areas. Do not use
towels or other bulky cloths.
Do not heat unopened food containers - Build-up of
pressure may cause container to burst and result in
injury.
Wear proper apparel - Loose-fitting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other flammable
materials contact hot surfaces.
Do not touch surface burners or elements, areas
near these burners or elements, interior surfaces of
the oven, or the warmer drawer (if equipped).
Surface burners and elements may be hot even
though they appear cool. Areas near surface
burners and elements may become hot enough to
cause burns. During and after use, do not touch, or
let clothing or other flammable materials touch these
areas until they are cool. These areas may include
the cooktop, surfaces facing the cooktop, oven vent
areas, oven door, and oven window.
Do not attempt to operate the appliance during a
power failure. If the power fails, always turn off the
appliance. If the appliance is not turned off and the
power resumes, electric surface elements may
resume operation when power is restored. Once the
power resumes, reset the clock and the oven
function.
CAUTION

6
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR USING
YOUR RADIANT COOKTOP
Know which knob or key controls each surface
heating area. Place cookware with food on the
cooking area before turning it on. Turn the
cooking area off before removing the cookware.
Cookware handles should be turned inward and
not extend over adjacent surface elements — To
reduce the risk of burns, ignition of flammable
materials, and spillage due to unintentional
contact with the utensil, the handle of the
cookware should be positioned so that it is turned
inward, and does not extend over other cooking
areas.
Use proper pan size - This appliance is equipped
with one or more surface units of different sizes.
Select cookware with flat bottoms that match the
surface unit size. Using the proper cookware on
the cooking area will improve efficiency.
Glazed cooking utensils— Only certain types of
glass, glass/ceramic, ceramic, earthenware, or
other glazed utensils are suitable for cooktop
service without breaking due to the sudden
change in temperature. Check the manufacturer’s
recommendations for cooktop use.
Improper cookware may break due to sudden
changes in temperature. Check the cookware
manufacturer’s recommendations for cooktop
use.
Never leave surface elements unattended. Boil-
overs may cause smoking and greasy spills that
may ignite. A pan that has boiled dry could be
damaged and may damage the cooktop.
Do not use a searing grill meant for use with a
broiler pan on the cooktop. The searing grill is not
designed for use on the cooktop. Doing so may
result in a fire.
When you are flaming foods under a ventilating
hood, turn on the fan.
IMPORTANT INSTRUCTIONS FOR GLASS
AND CERAMIC COOKTOPS
Do Not Clean or Operate a Broken Cooktop. If
cooktop should break, cleaning solutions and
spillovers may penetrate the broken cooktop and
create a risk of electric shock. Contact a qualified
technician immediately.
Clean cooktop glass with caution. If a wet sponge
or cloth is used to wipe spills on a hot cooking
area, be careful to avoid a steam burn. Some
cleaners can produce harmful fumes if applied to
a hot surface.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
Protective liners—Do not use aluminum foil, after-
market oven liners, or any other materials or
devices to line oven bottom, oven racks, or any
other part of the appliance. Only use aluminum as
recommended for baking, such as lining
cookware or as a cover placed on food. Any other
use of protective liners or aluminum foil may
result in a risk of electric shock or fire or a short
circuit.
Use care when opening oven door, lower oven
door, or warmer drawer (some models). Stand to
the side of the appliance when opening the door
of a hot oven. Let hot air or steam escape before
you remove or replace food in the oven.
Keep oven vent ducts unobstructed. Touching
surfaces in this area when the oven is on may
cause severe burns. Do not place plastic or heat-
sensitive items on or near the oven vent. These
items can melt or ignite.
Placement of oven racks - Always place oven
racks in desired location while oven is cool. If rack
must be moved while oven is hot, do not let
potholder contact hot burner or element in oven.
Use potholders and grasp the rack with both
hands to reposition. Remove all cookware and
utensils before moving the rack.

7
IMPORTANT SAFETY INSTRUCTIONS
Do not use a broiler pan without its insert. Broiler
pans and inserts allow dripping fat to drain away
from the high heat of the broiler. Do not cover the
broiler insert with aluminum foil; exposed fat and
grease could ignite.
Do not cook food on the oven bottom. Always
cook in proper cookware and always use the
oven racks.
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR APPLIANCE
Clean the appliance regularly to keep all parts
free of grease that could catch fire. Do not allow
grease to accumulate. Greasy deposits in the fan
could catch fire.
Always follow the manufacturer’s recommended
directions for use of kitchen cleaners and
aerosols. Be aware that excess residue from
cleaners and aerosols may ignite causing
damage and injury.
Clean ventilating hoods frequently - Grease
should not be allowed to accumulate on hood or
filter. Follow the manufacturer’s instructions for
cleaning vent hoods.
IMPORTANT INSTRUCTIONS FOR SERVICE
AND MAINTENANCE
Do not repair or replace any part of the appliance
unless specifically recommended in the manuals.
All other servicing should be done only by a
qualified technician. This reduces the risk of
personal injury and damage to the appliance.
Always contact your dealer, distributor, service
agent, or manufacturer about problems or condi-
tions you do not understand.
Ask your dealer to recommend a qualified techni-
cian and an authorized repair service. Know how
to disconnect the power to the appliance at the
circuit breaker or fuse box in case of an emer-
gency.
Remove the oven door from any unused oven if it
is to be stored or discarded.
Do not touch a hot oven light bulb with a damp
cloth. Doing so could cause the bulb to break.
Handle halogen lights (if equipped) with paper
towels or soft gloves. Disconnect the appliance or
shut off the power to the appliance before
removing and replacing the bulb.
Important Safety Notice - The California Safe
Drinking Water and Toxic Enforcement Act
requires the governor of California to publish a list
of substances known to cause cancer, birth
defects, or other reproductive harms, and
requires businesses to warn customers of
potential exposures to such substances.
Before manually cleaning any part of the appli-
ance, be sure all controls are turned off and the
appliance is cool. Cleaning a hot appliance can
cause burns.
CAUTION

8
COOKING RECOMMENDATIONS
Bakeware
The material of bakeware affects how evenly and quickly it transfers heat from the pan to the food.
Material Attributes Recommendation
Shiny metal bakeware Shiny, aluminum, and non-coated
bakeware is the best for even heating.
It is suitable for all baked goods.
Recommended cooking temperatures and
times are based on shiny metal bakeware.
Dark metal bakeware Dark bakeware cooks hotter than shiny
bakeware. Reduce the cooking temperature by 25° F
(13-14° C) when using dark bakeware.
Glass bakeware Glass bakeware cooks hotter than
shiny bakeware.
Glass is convenient, as the same piece
of bakeware can be used for cooking,
serving, and storing food.
Reduce the cooking temperature by 25° F
(13-14° C) when using glass bakeware.
Insulated bakeware Insulated bakeware cooks cooler than
shiny bakeware.
Insulated bakeware is designed for
baking in gas ovens.
Increase the cooking temperature by 25° F
(13-14° C) when using insulated bakeware.
COOKING RECOMMENDATIONS

9
COOKING RECOMMENDATIONS
Cooking Conditions
Conditions in your kitchen can affect the performance of your appliance when cooking food.
Condition Attributes Recommendation
Aging cookware As pans age and become discolored,
cooking times may need to be reduced
slightly.
If food is too dark or overcooked, use the minimum cook
time in the recipe or packaging.
If food is too light or undercooked, use the middle to
maximum cook time in the recipe or packaging.
High altitude Air is drier and air pressure is lower.
Water boils at a lower temperature, and
liquids evaporate faster.
Foods may take longer to bake.
Doughs may rise faster.
Adjust cooking temperature, cooking time, or recipes as
needed.
Increase amount of liquid in baking recipes.
Increase cook time on cooktop. Cover dishes to reduce
evaporation.
Increase bake time or oven temperature.
Reduce amount of baking soda or baking powder in
recipe. Reduce rising time or punch down dough and
allow it to rise twice.
Cooking Results
Small adjustments may fix a problem with food not being as done as you like or more done than you like.
Result Recommendation
Food too light Use the middle to maximum cook time recommended on packaging or recipe.
Food too dark Use the minimum cook time recommended on packaging or recipe.
Cooking Tips
Use these additional tips to get the best results from your appliance.
Cooking Tips
Baking
Rack placement Follow the instructions in “Setting Oven Controls” on starting on page 19.
When using only one rack, place the rack so the food is in the center of the oven.
Preheat Fully preheat the oven before baking items like cookies, cakes, biscuits and breads. Insert food
immediately after the beep.
Checking food Use the window and oven light when checking food. Opening the door may reduce baking perfor-
mance.
Food placement Allow at least 2 inches (5 cm) of space between bakeware for proper air circulation.

10
COOKING RECOMMENDATIONS
Broiling / Roasting
Broiling pan For best results when broiling, use a broil pan with a broil pan insert designed to drain the fat from
the food, help avoid spatter, and reduce smoking. The broiler pan will catch grease spills, and the
insert helps prevent grease splatters.
If a broiler pan and insert are not supplied with this appliance, they may be purchased from Frigid-
aire.com.
Cooking Tips

11
Using Proper Cookware
The size and type of cookware used will influence the heat
setting needed for best cooking results. Be sure to follow
the recommendations for using proper cookware as illus-
trated in Figure 1 and Figure 2.
Cookware Material Types
The cookware material determines how evenly and quickly
heat is transferred from the surface element to the pan
bottom. The most popular materials available are:
• Aluminum - Excellent heat conductor. Some types of
food will cause it to darken (Anodized aluminum
cookware resists staining and pitting). If aluminum pans
slide across the ceramic cooktop, they may leave metal
marks which will resemble scratches. Remove these
marks immediately.
• Copper - Excellent heat conductor but discolors easily
(see Aluminum).
•Stainless- Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
•CastIron- A slow heat conductor that will retain heat
very well. Cooks evenly once cooking temperature is
reached. If cast iron pans slide across the ceramic
cooktop, they may leave metal marks which will
resemble scratches. Remove these marks immediately.
• Porcelain-enamel on metal - Heating characteristics
will vary depending on base material. Porcelain-enamel
coating must be smooth to avoid scratching ceramic
cooktops.
•Glass- Slow heat conductor. Not recommended for
ceramic cooktop surfaces because it may scratch the
glass.
Check for flatness by rotat-
ing a ruler across the bottom
of the cookware (see
Figure 1). Cookware should
have flat bottoms that make
good contact with the entire
surface heating element (see
Figure 2).
Figure 1: Testing cookware
Figure 2: Proper cookware
• Flat bottom and straight
sides.
• Tight fitting lids.
• Weight of handle does
not tilt pan. Pan is well
balanced.
• Pan sizes match the
amount of food to be
prepared and the size
of the surface element.
• Made of material that
conducts heat well.
• Easy to clean.
• Always match pot
diameter to element
size.
• Curved and warped pans.
• Cookware larger than
cooking area marked on
cooktop by more than
one-half inch or 12mm.
• Heavy handle tilts pan.
• Pan is smaller than the
heating area marked on
cooktop.
Do not place empty aluminum, glass, or porcelain-enamel
coated cookware on the ceramic cooktop. The melting
point of cookware made with these materials may be
reached quickly, especially if left empty, and they may
bond to the ceramic cooktop. If the cookware melts it will
damage the cooktop. Follow all the cookware manufac-
turer’s recommendations for use and care of cookware.
IMPORTANT
BEFORE SETTING SURFACE CONTROLS

12
BEFORE SETTING SURFACE CONTROLS
About the Ceramic Glass Cooktop
The ceramic glass cooktop has heating elements below a
smooth glass surface. The designs on the ceramic cooktop
outline the areas of the surface elements underneath.
Always match the pan size with the diameter of the element
outline on the cooktop. Only flat-bottomed cookware should
be used.
Prior to using your cooktop for the first time, apply a
ceramic cooktop cleaning cream (available in most
hardware, grocery and department stores) to the ceramic
surface. Clean and buff with a clean paper towel. This will
make cleaning easier when soiled from cooking. Cooktop
cleaning creams leave a protective finish on the glass to
help prevent scratches and abrasions.
The type and size of cookware, the number of surface
elements in use, and their settings will all affect the amount
of heat that will spread to areas beyond the surface
elements. The areas surrounding the elements may
become hot enough to cause burns.
About the Radiant Surface Elements
The element temperature rises gradually and evenly. As the
temperature rises, the element will glow red. To maintain
the selected setting the element will cycle on and off. The
heating element retains enough heat to provide a uniform
and consistent heat during the off cycle.
For efficient cooking, turn the element off several minutes
before cooking is complete. This will allow residual heat to
complete the cooking process.
•The cooktop should not be used as a cutting board or
work surface.
•Dropping heavy or hard objects on the cooktop may
crack it.
•Placing food directly on the smoothtop surface
(without a cooking utensil) is not recommended, as
difficult cleaning will result, and foods may smoke and
cause potential fire hazard.
•Always lift cookware before moving on the ceramic
glass cooktop. Any cookware that has a rough or dirty
bottom can scratch the ceramic cooktop. Always start
with clean cookware.
White glass cooktops only - Due to the high intensity of
heat generated by the surface elements, the glass
surface may discolor when the element is turned off. This
is normal and the glass will return to its original white
color after it has completely cooled down.
IMPORTANT
NOTE
•Surface elements may appear to have cooled after
they have been turned off. The element surface may
still be hot, and burns may occur if the element or
surrounding area is touched before it has cooled to a
safe temperature.
• Do not place flammable items such as plastic salt
and pepper shakers, spoon holders, or plastic
wrapping on top of the range when it is in use. These
items could melt or ignite. Potholders, towels, or
wooden spoons could catch fire if placed too close to
the surface elements.
• Do not allow aluminum foil, or any material that can
melt, to make contact with the ceramic glass cooktop.
If these items melt on the cooktop, they will damage
the ceramic cooktop.
Radiant elements have a limiter that allows the element to
cycle on and off, even at the HI setting. This helps to
prevent damage to the ceramic smooth top. Cycling at the
HI setting is normal and can occur if the cookware is too
small for the radiant element or if the cookware bottom is
not flat.
Be sure to read detailed instructions for ceramic glass
cooktop cleaning in the “Care and Cleaning” section
(page 24) and “Before You Call” checklist section
(page 30) of this Use and Care Guide.
CAUTION
NOTE

13
BEFORE SETTING SURFACE CONTROLS
Element On and Hot Surface Indicator Lights
The ELEMENT ON indicator light will turn on when one or
more elements are turned on.
A quick glance at this indicator light when cooking is
finished is an easy check to be sure all surface elements
are turned off.
The HOT SURFACE indicator light will turn on when the
burner is hot enough to cause burns and will remain on after
the burner is turnedoff until the surface has cooled to asafe
temperature.
Types of ceramic cooktop elements
The circles on the ceramic glass cooktop outline the size
and type of element underneath. The elements on your
cooktop depend on the model.
•A single radiant element has one circle.
•A dual radiant element (some models) has two circles.
The dual radiant element may be set using only the
smaller inner element or both inner and outer elements
may be set to heat together for a larger surface.
•Dual elements allow more flexibility with the size of
cookware.
•A keep warm element (some models) has one small
circle. It is used to keep food warm after cooking. The
keep warm element is not designed to cook food.
Figure 3: On indicator light
Figure 4: Hot surface indicator light
Figure 5: Single and double elements

14
Single radiant surface elements (all models)
To operate the single radiant element:
1. Place correctly sized cookware on surface element.
2. Push in and turn the surface control knob in either
direction (Figure 6) to the desired setting (refer to the
“Suggested radiant surface element settings” in
Table 1).
3. When cooking is complete, turn the radiant surface
element OFF before removing the cookware.
Start most cooking operations on a higher setting and then
turn to a lower setting to finish cooking. The surface control
knobs do not have to be set exactly on a particular spot.
Use the graphics provided as a guide and adjust the control
knob as needed (see Figure 6).
A glowing red surface heating area extending beyond the
bottom edge of the cookware indicates the cookware is too
small for the surface heating area.
Suggested radiant surface element settings
The suggested settings found in Table 1 below are based
on cooking with medium-weight aluminum pans with lids.
Settings may vary when using other types of pans.
Settings Type of Cooktop
High (HI - 9) Start most foods, bring water to a
boil, pan broiling
Medium High (7 - 8) Continue a rapid boil, fry, deep fat
fry
Medium (5 - 6) Maintain a slow boil, thicken sauces
and gravies or steam vegetables
Medium Low (2 - 4) Keep foods cooking, poach, stew
Low (1) Low temperature cooking
Low (LO) Keep warm, melt
Table 1: Suggested radiant surface element settings
Do not allow aluminum foil or ANY material that can melt
to make contact with the ceramic glass cooktop. If these
items melt on the cooktop, they will damage the ceramic
cooktop.
IMPORTANT
Figure 6: Single element knob
•Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface
may still be hot and burns may occur if the glass
surface is touched before it has cooled sufficiently.
• Do not place flammable items such as plastic salt
and pepper shakers, spoon holders, or plastic
wrappings on top of the range when it is in use. These
items could melt or ignite. Potholders, towels, or
wooden spoons could catch fire if placed too close to
the surface elements.
•The size and type of utensil used, and the amount
and type of food being cooked will influence the
setting needed for best cooking results.
•The Element ON indicator lights will turn on when one
or more elements are turned ON. A quick glance at
these indicator lights when finished cooking is an
easy check to be sure all control knobs are turned
OFF. The Hot Surface indicator light will remain on
AFTER the control knob is turned to the “OFF”
position and will stay on until the heating surface area
has cooled sufficiently.
CAUTION
NOTE
SETTING SURFACE CONTROLS

15
SETTING SURFACE CONTROLS
Dual radiant surface elements (some models)
Symbols on the backguard will help choose which portion of
the dual radiant element to set. The symbol indicates a
setting for the inner element only. The symbol indicates a
setting for both inner and outer elements.
To operate a dual radiant element:
1. Place correctly sized cookware on the surface element.
2. Push in and turn the surface control knob clockwise to
begin heating both the inner and outer elements. If only
the inner element is needed for smaller cookware, push
in and turn the knob counter-clockwise (see Figure 7).
3. When cooking is complete, turn the knob to OFF before
removing the cookware.
Start most cooking operations on a higher setting and then
turn to a lower setting to finish cooking. The surface control
knobs do not have to be set exactly on a particular mark.
Use the marks as a guide and adjust the control knob as
needed.
A glowing red surface heating area extending beyond the
bottom edge of the cookware indicates the cookware is too
small for the surface heating area.
You may switch from either single or dual element setting at
any time during cooking. See “Suggested radiant surface
element settings” on page 14.
•Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface
may still be hot and burns may occur if the glass
surface is touched before it has cooled sufficiently.
• Do not place flammable items such as plastic salt
and pepper shakers, spoon holders or plastic
wrappings on top of the range when it is in use. These
items could melt or ignite. Potholders, towels or
wooden spoons could catch fire if placed too close to
the surface elements.
Do not allow aluminum foil or ANY material that can melt
to make contact with the ceramic glass cooktop. If these
items melt on the cooktop, they will damage the ceramic
cooktop.
CAUTION
IMPORTANT
Figure 7: Dual element knob settings
•The size and type of utensil used and the amount and
type of food being cooked will influence the setting
needed for best cooking results.
•The Element ON indicator lights will turn on when one
or more elements are turned ON. A quick glance at
these indicator lights when finished cooking is an
easy check to be sure all control knobs are turned
OFF. The Hot Surface indicator light will remain on
AFTER the control knob is turned to the “OFF”
position and will stay on until the heating surface area
has cooled sufficiently.
NOTE

16
SETTING SURFACE CONTROLS
Keep warm (some models)
Use the keep warm feature to keep cooked foods hot.
Always start with hot food. It is not recommended to heat
cold food on the keep warm zone. All food placed on the
warming zone should be covered with a lid to maintain
quality.
For best results, when warming pastries or breads, the
cover should have an opening to allow moisture to escape.
Do not use plastic wrap to cover food. Plastic may melt
onto the surface and be very difficult to clean. Use only
dishware, utensils, and cookware recommended for oven
and cooktop use on the keep warm zone.
Setting the keep warm control:
1. Push in the knob and turn in either direction (see
Figure 8). The temperatures are designated by hi and
lo. However, the control can be set at any position
between hi and lo for different levels of warming.
2. When ready to serve, turn the control to OFF. The hot
surface indicator light will remain on until the warm zone
cools.
Temperature selection - Refer to the recommended keep
warm zone settings table (see Table 2). If a particular food
is not listed, start with the medium level and adjust as
needed. Most foods can be kept at serving temperatures by
using the medium level.
•Unlike the surface elements, the keep warm zone will
not glow red when it is hot. To avoid burns always use
potholders or oven mitts when removing food from the
cooktop, including the keep warm zone, as cookware
and plates will be hot.
•Radiant surface elements may appear to have cooled
after they have been turned off. The glass surface
may still be hot and burns may occur if the glass
surface is touched before it has cooled sufficiently.
• Do not place flammable items such as plastic salt
and pepper shakers, spoon holders, or plastic
wrappings on the cooktop when it is in use. These
items could melt or ignite. Potholders, towels, or
wooden spoons could catch fire if placed too close to
the surface elements.
CAUTION
Figure 8: Keep warm knob
Food Item Heating Level
Breads/Pastries LO (Low)
Casseroles LO (Low)
Dinner Plates with Food LO (Low)
Eggs LO (Low)
Gravies LO (Low)
Meats MED (Medium)
Sauces MED (Medium)
Soups (cream) MED (Medium)
Stews MED (Medium)
Vegetables MED (Medium)
Fried Foods HI (High)
Hot Beverages HI (High)
Soups (liquid) HI (High)
Table 2: Recommended keep warm zone settings
Do not allow aluminum foil or ANY material that can melt
to make contact with the ceramic glass cooktop. If these
items melt on the cooktop, they will damage the ceramic
cooktop.
IMPORTANT

17
SETTING SURFACE CONTROLS
Home Canning
Be sure to read and observe all the following points when
home canning with your appliance. Check with the USDA
(United States Department of Agriculture) Web site and be
sure to read all the information they have available as well
as follow their recommendations for home canning proce-
dures.
•Use only a completely flat bottom canner with no ridges
that radiate from the bottom center when home
canning. Heat is spread more evenly when the bottom
surface is flat. Use a straight-edge to check canner
bottom.
•Make sure the diameter of the canner does not exceed
1 inch beyond the surface element markings or burner.
•It is recommended to use smaller diameter canners on
electric coil and ceramic glass cooktops and to center
canners on the burner grates.
•Start with hot tap water to bring water to boil more
quickly.
•Use the highest heat seating when first bringing the
water to a boil. Once boiling is achieved, reduce heat to
lowest possible setting to maintain that boil.
•Use tested recipes and follow instructions carefully.
Check with your local Cooperative Agricultural
Extension Service or a manufacturer of glass jars for
the latest canning information.
•It is best to can small amounts and light loads.
•Do not leave water bath or pressure canners on high
heat for an extended amount of time.

18
Oven Vent Location
The oven is vented as shown below. When the oven is on,
warm air is released through the vent. This venting is
necessary for proper air circulation in the oven and good
baking results. Do not block oven vent. Never close off the
openings with aluminium foil orany other material. Steam or
moisture may appear near the oven vent. This is normal.
Types of oven racks
• Flat oven racks may be used for most cooking needs
and may be placed in most oven rack positions.
•The offset oven rack (some models) provides addi-
tional step down positions from the standard flat rack
design. The offset design positions the base of the rack
about ½ of a rack position lower than the flat rack and
may be used in most oven rack positions. To maximize
oven cooking space, place the bottom oven rack in the
lowest rack position for baking or roasting large cuts of
meat.
Removing, replacing, and arranging flat or offset
oven racks
Always arrange the oven racks when the oven is cool.
To remove - Pull the oven rack straight forward until it
reaches the stop position. Lift up front of oven rack slightly
and slide out.
To replace - Place the oven rack on the rack guides on
both sides of oven walls. Tilt the front of oven rack upward
slightly and slide the oven rack back into place. Be sure
oven racks are level before using.
Figure 9: Oven vent
Protective Liners — Do not use aluminum foil or any
other material or liners to line the oven bottom, walls,
racks or any other part of the range. Doing so will alter the
heat distribution, produce poor baking results, and
possibly cause permanent damage to the oven interior.
Improper installation of these liners may result in risk of
electric shock or fire.
•Always use pot holders or oven mitts when using the
oven. When cooking, the oven interior, oven exterior,
oven racks, and cooktop will become very hot which
can cause burns.
•To prevent possible damage to the oven, do not
attempt to close the oven door until all the oven racks
are fully positioned back inside the oven cavity.
WARNING
CAUTION
Figure 10: Oven rack types
oset
oven rack
at
oven rack
BEFORE SETTING OVEN CONTROLS

19
1. Bake - Use to select for all baking.
2. Broil - Use to select the broil feature. When broil is
active the indicator light above the broil key will glow.
3. Timer On-Off - Use to set or cancel the minute timer.
The minute timer does not start or stop cooking.
4. Set Clock - Use with up or down arrows to set the time
of day.
5. OFF - Use to stop or to clear any feature previously
entered except time of day and minute timer. Press OFF
to stop cooking.
6. Up and Down arrow keys - Use with the feature or
function keys to set oven temperature or to adjust the
clock or minute timer.
Minimum and Maximum Setting
Setting the Clock
When the appliance is first plugged in or when the power
supply to the appliance has been interrupted, the display
will flash 12:00. It is recommended to always set the clock
for the correct time of day before using the appliance.
To set the clock:
1. Press Set Clock once (do not hold Set Clock key
down).
2. Within 5 seconds, press and hold or until
the correct time of day appears in the display.z
Bake
Broil
Timer Set
Clock
OFF
1
234 5
6
Feature Mode Min Temp or
Time Max.Temp or Time
Bake 170°F (77°C) 550°F (288°C)
Broil LO 400°F
(205°C) HI 550°F (288°C)
Timer 12 Hr. Mode
24 Hr. Mode 1 minute 11 hrs 59 mins
Clock
Time 12 Hr. Mode
24 Hr. Mode 1:00 Hr./Min. 0:00 Min 12:59 Hr./Min. 23:59 Hr./Min.
The clock cannot be changed when the oven is set for
cooking.
NOTE
SETTING OVEN CONTROLS

20
SETTING OVEN CONTROLS
Temperature display (Fahrenheit/Celsius)
The electronic oven control is set to operate in Fahrenheit
(°F) at the factory. The oven may be programmed for any
temperature from 170°F to 550°F (77°C to 288°C).
To change the temperature to Celsius (°C) or from °C to
°F:
1. Press Broil until F or C appears in the display.
2. Press or to change °F to °C or °C to °F.
To accept the change, wait 6 seconds until the oven
control provides an acceptance beep.
3. The display will return to the time of day.
Changing between continuous bake setting or 12-
hour energy saving feature
The oven control has a built-in 12-hour energy saving
feature that will shut off the oven if the oven is left on for
more than 12 hours. The oven control can be programmed
to override this feature for continuous baking.
To change the continuous bake setting:
1. Press and hold Timer on-off for 6 seconds until a tone
sounds. — — hr will appear in the display for contin-
uous cooking. The current time of day will return to the
display.
2. To cancel the continuous bake setting, press Timer on-
off and hold for 6 seconds until a tone sounds. 12 hr
will appear in display indicating that the control has
returned to the 12-hour energy saving feature.
Operating oven light
The interior oven light will automatically turn ON when the
oven door is opened. Press the oven light switch located on
the upper left control panel to turn the interior oven light ON
and OFF whenever the oven door is closed.
Setting the minute timer
1. Press Timer on-off.
2. Press to increase time in one-minute increments.
Press and hold to increase time in 10-minute
increments. The timer can be set for any amount of time
from 1 minute to 11 hours and 59 minutes.
When the set time expires, the timer will sound a 3 second
tone. The display will show 00:00 until the timer is cancelled
by pressing Timer On/Off.
To change the timer while it is in use:
While the timer is active and shows in the display, press and
hold or to increase or decrease the time
remaining.
To cancel the minute timer before the set time has run
out:
1. Press Timer on-off once.
oven light switch
If is pressed first, the timer will advance to 11 hours
and 59 minutes.
The minute timer will not start or stop the cooking
process. The minute timer can be used alone or while
using any of the other oven features. If another feature is
active when the minute timer is active, the minute timer
will show in the display. To view information about other
active features, press the key for that feature.
NOTE
NOTE
