Drop-In Cooktop
FPEC3085K S 30" Electric30" Electric
Signature Features
Ready-Select® Controls
Select options or control cooking
temperature with our easy-to-use
controls.
Even Baking Technology
Our latest technology ensures
even baking every time.
One-Touch Self Clean
Start the self-cleaning cycle with
just the touch of a button.
Product Dimensions
Height (Max.) 47-1/2"
Width 29-7/8"
Depth (Including Handle) 28-1/2"
More Easy-To-Use Features
Store-More™ Storage Drawer
Our convenient drawer gives you extra
storage space in your kitchen.
Quick Clean
For a quick, light oven cleaning.
Extra-Large Window
Our extra-large oven window lets you
easily see what’s inside.
Delay Start Baking Option
Delay Clean
Set the oven to begin cleaning on
your schedule.
Hi /Lo Broil Option
Offers two-position broiling and
variable temperature control for
more control.
Auto Shut-O
As an extra safety measure, the oven will
automatically shut off after 12 hours.
Timed Cook Option
Bright Lighting
Our bright lighting makes it easy
to see what’s inside.
Attractive Stainless Steel Exterior1
Available in:
1Select model only.
Freestanding Ranges
FFEF3017L S / W / B
Elements
Right Front
Right Rear
Left Front
Left Rear
Watts
2,500
1,200
2,500
1,200
Size
9"
6"
9"
6"
Large Capacity
Our large capacity oven gives you
room to cook more at once.
Stainless
(S)
White
(W)
Black
(B)

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
30" Electric Freestanding Ranges
Frigidaire Baseline
C
A
36"
(Adjustable)
B
Features
Oven Control / Timing System
Surface Type
Window
Exterior Door Finish
Handle Design
Exterior Finish (Side Panels)
Convection System
Oven Cleaning System
Drawer Functionality
Oven Controls
Bake
Broil
Add-a-Minute
Delay Bake
Self-Clean
Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Auto Oven Shuto
Cooktop Features
Right Front Element (Watts)
Right Rear Element (Watts)
Left Front Element (Watts)
Left Rear Element (Watts)
Center Element (Watts)
Hot Surface Indicator Light
Coil Cooktop / Drip Bowls
Oven Features
Capacity (Cu. Ft.)
Oven Light
Hidden Bake Element
Rack Configuration
Even Baking System
Broiling System
Bake Element / Broil Element (Watts)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Ready-Select® Controls
Black Ceramic Glass
Extra-Large
Stainless Steel ( S ),
Color-Coordinated ( W/B )
Black ( S ),
Color-Coordinated ( W/B )
Black ( S ),
Color-Coordinated ( W/B )
Self Clean
Storage
Yes
Low and High
Yes
Yes
Yes
Yes
Yes
Yes
12 Hours
9" – 2,500
6" – 1,200
9" – 2,500
6" – 1,200
5.3
1
2 Standard
Yes
Vari-Broil™ Hi / Lo
2,600 / 3,000
21" x 24-3/8" x 19-1/8"
Middle Bottom Rear
240V / 208V / 60Hz
12.5 / 9.5
40
140 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFEF3017L 12/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Freestanding Ranges
FFEF3017L S / W / B 30" Electric
Product Dimensions
A - Height (Max.)
B - Width
C - Depth (Including Handle)
Depth with Door Open 90˚
47-1/2"
29-7/8"
28-1/2"
48-3/8"
Cutout Dimensions
Height (Standard)
Width (Min.)
Depth (Min.)
36"
30"
24"

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 10/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
