Frigidaire FEF366CG User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FEF366CGSA FEF366CG white USA
FEF366CGSB FEF366CG white USA
FEF366CGSC FEF366CG white USA
©
Publication No.
5995309571
980629
-EN/SERVICE /CML
369
ELECTRIC - RANGE
Model No.
FEF366CG
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
ELECTRIC RANGE
WIRING DIAGRAM # - 316002627
OWNER’S GUIDE # - 316000275
INSTALLATION INST. # - 316003018
104 Warren Road
Augusta, Georgia 30907-3755

BACKGUARD
Publication No. FEF366CGSA,FEF366CGSB,FEF366CGSC
5995309571
07/98 2

A = FEF366CG (FEF366CGSA)
B = FEF366CG (FEF366CGSB)
C = FEF366CG (FEF366CGSC)
POS. NO PART NO DESCRIPTION
1 316081601 A B C Shield-backguard,rear wall
2 316015905 A B C Shield-backguard,inner
11 316083721 A B C Trim-wrapper, textured, white,white
13A 316095500 A B C Switch-warmer,infinite ,drawer/zone ,
(2)
14 316022500 A B C Light/Lamp,indicator ,125 V
14 316022503 A B C Light/Lamp,indicator ,yellow ,250 V
15 316023108 A B C Support-backguard,RH
15A 316023109 A B C Support-backguard,LH
19 316100528 A B C Panel-control,metal ,white
20 # 316101001 A B C Clock/Timer,electronic
20* 316101502 A B C Overlay-clock
23 316100300 A B C Bracket-clock mtg
24# 316005607 A B C Switch-rocker,oven light ,white
31A 316095601 A B C Knob-warmer,white
36 316025106 A B C Knob-control,infinite sw ,white ,(4)
40 316025808 A B C Panel-manifold
46 316040201 A B C Lens-light/lamp,indicator ,red
54 # 316021500 A B C Switch-6" element,(2)
54A# 316021501 A B C Switch-8" element,(2)
69 5303292005 A B C Screw-switch mtg,8-32 x 5/32
* 316021105 A B C Screw,hex ,8-18 x 3/8 ,back\bodyside
* 316071902 A B C Gasket-edge
BACKGUARD
FEF366CGSA,FEF366CGSB,FEF366CGSC Publication No.
5995309571
# = Functional Part 3 07/98
* = Non-Illustrated Part

BODY
Publication No. FEF366CGSA,FEF366CGSB,FEF366CGSC
5995309571
07/98 4

A = FEF366CG (FEF366CGSA)
B = FEF366CG (FEF366CGSB)
C = FEF366CG (FEF366CGSC)
POS. NO PART NO DESCRIPTION
1 316080804 A B C Back-main, short,dipped ,black
3 316081028 A B C Panel-bodyside,white ,RH
3* 316081029 A B C Panel-bodyside,white ,LH
5 5303203397 A B C Screw-leveling
5* 3934058 A B C Anti-tip Kit
5* 316078600 A B C Screw,anti-tip ,(4)
5A 5303288460 A B C Nut,T-type ,leveling screw
6 316067902 A B C Rack-oven
7 316007002 A B C Hinge-oven door,(2)
8 3203540 A B C Panel-oven bottom
9 316073800 A B C Pan-broiler
10 3205234 A B C Insert-broiler pan
12 # 316027701 A B C Switch-oven light
13 316026800 A B C Rod-light switch /door
14 3014073 A B C Socket-light/lamp,oven
15 5303013071 A B C Light Bulb/Lamp
16 08011086 A B C Lens-light/lamp,glass ,oven
17 316087500 A B C Retainer-lens
18 # 316036300 A B C Latch-door
21 3014099 A B C Spacer-bodyside,(8)
25A 316092400 A B C Shield-warmer,upper
28 3011813 A B C Clip-wire,bodyside
30 5303283574 A B C Bracket-hinge,main top RH
30A 5303283575 A B C Bracket-hinge,main top LH
33A 316095301 A B C Shield-rear wall,lower
37 # 316111200 A B C Probe-oven temp
41 3131570 A B C Cover-hinge cutout
44 3131903 A B C Bumper-door/drawer,rubber
45 316066100 A B C Shield-wire, s/t vent
57 316081101 A B C Cover-access
58 3200847 A B C Insulation,oven bottom
58A 316047708 A B C Insulation,oven wrapper
58B 316054202 A B C Insulation,oven back
58C 3131304 A B C Insulation,oven top
59 316073602 A B C Tube-oven vent
59* 316040100 A B C Bracket-mounting,vent tube
59A 316023601 A B C Tube-oven vent,upper
62 # 5303935061 A B C Terminal Block
63 5301145190 A B C Plate-ground strap
66 # 5303051140 A B C Element-broil
67 # 316075102 A B C Element-bake,lower oven
68 316075300 A B C Support-element
71 316015805 A B C Shield-rear wall
72 5303285692 A B C Cover-light/switch rod
77 316094900 A B - Rail-drawer RH, outer
77A 316094901 A B - Rail-drawer,LH,outer
77 316105500 - - C Glide-warmer,outer/RH & LH ,(2)
82 5303289913 A B C Shield-insulation
87 316081200 A B C Bracket-cable mtg
88 316026400 A B C Rod-latch,auto
89 # 316028103 A B C Motor-latch/lock
155 316095201 A B C Shield-drawer,front warmer
* 3203550 A B C Plug-button
* 316021105 A B C Screw,hex ,8-18 x 3/8 ,back\bodyside
* 316021108 A B C Screw,cup pt ,#8-18 x 3/8 ,hinge
* 316045000 A B C Clip-wire,harness ,main top
* 316101600 A B C Shield-vent,smoothtop
* 5303051099 A B C Nut,hex ,#10-32
BODY
FEF366CGSA,FEF366CGSB,FEF366CGSC Publication No.
5995309571
# = Functional Part 5 07/98
* = Non-Illustrated Part

TOP/DRAWER
Publication No. FEF366CGSA,FEF366CGSB,FEF366CGSC
5995309571
07/98 6

A = FEF366CG (FEF366CGSA)
B = FEF366CG (FEF366CGSB)
C = FEF366CG (FEF366CGSC)
POS. NO PART NO DESCRIPTION
1 316094601 A B C Drawer-warmer
2 316092901 A B C Liner,drawer
4 316056201 A B C Panel-drawer,white
13 316096500 A B - Channel-drawer,rh,inner
13A 316096501 A B - Channel drawer,lh,inner
13 316105600 - - C Glide-drawer,rear,RH
13A 316105601 - - C Glide-drawer,rear,LH
14 3206216 A B C Plug-button,glide
15 # 316010203 A B C Element-surface,radiant ,small/6 inch ,
1200W,(2) ,limit sw incl
15A# 316010204 A B C Element-surface,radiant ,
large/8 inch/RF,2100W ,(2) ,
limit sw incl
16 316098105 A B C Main Top,white
18 5303273062 A B C Hinge-main top,RH
18A 5303273063 A B C Hinge-main top,LH
26 316099101 A B C Channel-support,element ,(2)
26A 316099201 A B C Bracket-support,chassis
39 316026106 A B C Handle-drawer,white
48 316100200 A B C Shield-wire,main top
52 316099400 A B C Clip-spring, element mtg,(8)
53 316099300 A B C Bracket-indicator light,hot surface ,
4hole
60 316021105 A B C Screw,hex ,8-18 x 3/8 ,back\bodyside
80 316109700 A B C Seal-door,warmer drawer
81 # 316093100 A B C Element,warmer drawer
82 316093200 A B C Bracket-mounting,warmer element
83 316093300 A B C Shield-terminal,warmer
84 316093500 A B C Thermo disc,warmer
85 316093600 A B C Rack,warmer drawer
86 316095800 A B C Clip-hold down,warmer element
87 316091902 A B C Base-warmer
* 316021112 A B C Screw-8-18x1/2 Tr Sqd White
* 316045000 A B C Clip-wire,harness ,main top
* 5303280311 A B C Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 5309951550 A B C Cleaner-cooktop
TOP/DRAWER
FEF366CGSA,FEF366CGSB,FEF366CGSC Publication No.
5995309571
# = Functional Part 7 07/98
* = Non-Illustrated Part

DOOR
Publication No. FEF366CGSA,FEF366CGSB,FEF366CGSC
5995309571
07/98 8

A = FEF366CG (FEF366CGSA)
B = FEF366CG (FEF366CGSB)
C = FEF366CG (FEF366CGSC)
POS. NO PART NO DESCRIPTION
3 316067804 A B C Trim-oven door,white
4 316089005 A B C Glass-oven door,white ,outer
5 316088700 A B C Glass-oven door,inner
6 316088401 A B C Shield-wool
7 316076403 A B C Insulation-door
8 316088600 A B C Glass-oven door,airwash
9 316066610 A B C Liner-oven door
10 5303280308 A B C Screw-handle mtg,wafer head ,10-24T x 2
12 # 5303131601 A B C Seal-oven door
14 3131361 A B C Reflector,aluminum foil
14A 3131360 A B C Reflector,aluminum foil ,(2)
15 316081401 A - - Bracket-glass mtg
15 316081403 - B C Bracket-glass mtg
16 316085700 A - - Glass-oven door,heat barrier
16 316085701 - B C Glass-oven door,heat barrier
39 316091115 A B C Handle-door,white ,oven
39* 316008401 A B C Washer,3/4 x 1/4 ,steel ,(2)
52 316081301 A B C Shield-oven door,white ,top
* 316065301 A B C Plate warning/caution
* 5303212671 A - - Screw,cr pan hd sems ,8-32BP x 1.00
* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 1/2
* 5303280311 A B C Screw,waf hd sdr ,10-32 x 5/16 ,(2)
* 5303285179 A B C Screw-oven door,wafer head ,8-32T x 1/2
DOOR
FEF366CGSA,FEF366CGSB,FEF366CGSC Publication No.
5995309571
# = Functional Part 9 07/98
* = Non-Illustrated Part

WIRING DIAGRAM
Publication No. FEF366CGSA,FEF366CGSB,FEF366CGSC
5995309571
07/98 10
