Frigidaire FGUI1849L F Manual

frigidaire.com
Product Dimensions
Height 66-5/8"
(Including Hinges & Rollers)
Width 30"
Depth 30-1/8"
More Easy-To-Use Features
Humidity-Controlled Crisper
Drawers
Keep your fruits and vegetables fresh in
our humidity-controlled crisper drawers.
Cool Zone™ Drawer
Clear Dairy Door
Attractive Stainless Steel Exterior2
Available in Stainless Steel
Left-Swing Door2
ENERGY STAR® Most Ecient3
Available in:
1Left-Swing Door.
2Select models only.
3Exceeds minimum ENERGY STAR® standard by at
least 30%.
Signature Features
SpaceWise®
Organization System
Our SpaceWise® Organization system
makes it easy to keep food organized
and easy to find when you need it.
Smudge-Proof Stainless Steel2
Protective coating reduces fingerprints
and smudges so it’s easy to clean.
Bright Lighting
Our bright lighting makes it easy to
see what’s inside.
SpillSafe® Shelves
Designed to keep spills contained,
making cleanup a breeze.
Top Mount Refrigerators
FGUI1849L F / R1 / P / E 18 Cu. Ft. Top Mount
Stainless
(F / R1)
Pearl
(P)
Ebony
(E)

Top Mount Refrigerators
Frigidaire Gallery
Top Mount Refrigerators
FGUI1849L F / R / P / E 18 Cu. Ft.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGUI1849L 07/12 © 2012 Electrolux Home Products, Inc.
Specifications
subject to change.
Product Dimensions
A - Height (Incl. Hinges & Rollers)
B - Width
C - Depth (Incl. Door)
Depth with Door Open 90˚
66-5/8"
30"
30-1/8"
58-1/2"
NOTE: For planning purposes only. Always consult local and national
electric and plumbing codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
Accessories information available
on the web at frigidaire.com
Features
Door Design
Door Handle Design
Cabinet Finish (Textured)
Door Stops
Door Hinge Covers
Door Reverse Option
Left-Swing Door
Rollers – Front / Rear
Sound Package
Toe Grille
Refrigerator Features
Interior Lighting
Refrigerator Shelves
Cool Zone™ Drawer
Wine / Can Rack
Store-More™ Crisper Drawers
Humidity Controls
Dairy Compartment
Door Bins
Door Racks
Non-Slip Bin Liner
Tall Bottle Retainers
Gallon Door Storage
Freezer Features
Door Bins
Door Racks
Freezer Shelves
Factory Ice Maker w/ Large Ice Bin
Lighting
Certifications
ENERGY STAR® Most Ecient1
Specifications
Total Capacity (Cu. Ft.)
Refrigerator Capacity (Cu. Ft.)
Freezer Capacity (Cu. Ft.)
Power Supply Connection Location
Water Inlet Connection Location
Voltage Rating
Connected Load (kW rating)
@ 120 Volts2
Amps @ 120 Volts
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
UltraSoft™
Stainless Steel (F / R),
Color-Coordinated (P / E)
Grey (F / R),
Color-Coordinated (P / E)
Yes
Grey (F / R),
Color-Coordinated (P / E)
No (F / R),
Yes (P / E)
Yes (R Model Only)
Adjustable / Yes
Quiet Pack
Grey (F / R),
Color-Coordinated (P / E)
Bright
1 Sliding and 3 Fixed
SpillSafe® Adjustable Glass
Clear
2 Clear
2
Clear Dairy Door
1 Quick-Find,
3 Adj. Half-Width Clear,
1 Fixed Full-Width White
3
1 Full-Width White
1 Tilt-Out Full-Width Wire
1 Full-Width Glass
Included (PN # IM115)
Yes
Yes
18.3
14.21
4.07
Right Bottom Rear
Bottom Right
120V / 60Hz / 15 or 20A
.54
4.5
15
205 Lbs.
1Exceeds minimum ENERGY STAR® standard by at least 30%.
2For use on adequately wired 120V, dedicated circuit having 2-wire service
with a separate ground wire. Appliance must be grounded for safe
operation.

Specifications
subject to change.
Top Mount Refrigerator - 18 Cu. Ft.
Gallery
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGUI1849L 07/12 © 2012 Electrolux Home Products, Inc.
•To ensure optimum performance, do not install in areas where
temperature drops below 55° F or rises above 110° F and
avoid installing in direct sunlight or close proximity to range,
dishwasher or other heat source.
•For proper ventilation, front grille MUST remain unobstructed.
•Recess electrical outlet when possible.
•Water recess on rear wall recommended to prevent water line damage.
•Water Pressure – Cold water line must provide between 30 and 100
pounds per square inch (psi).
•Copper tubing with 1/4" O.D. recommended for water supply line
with length equal to distance from rear of unit to household water
supply line plus 7 additional feet. Optional Water Supply Installation
Kits available.
•Adjustable front rollers to assist with door alignment.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Top Mount Refrigerator Specifications
•Product Shipping Weight (approx.) – 205 Lbs.
•An electrical supply with grounded three-prong receptacle is
required. The power supply circuit must be installed in accordance
with current edition of National Electrical Code (NFPA 70) and
local codes & ordinances.
•Voltage Rating – 120V / 60 Hz / 15 or 20 Amps
•Connected Load (kW Rating) @ 120 Volts = .54 kW
•Amps @ 120 Volts = 4.5 Amps
•Always consult local and national electric & plumbing codes.
•Floor should be level surface of hard material, capable of supporting
fully loaded refrigerator.
•Minimum 3/8" clearance required for sides and top of refrigerator
with 1" clearance at rear to allow for ease of installation, proper air
circulation, and plumbing / electrical connections.
•
When installing refrigerator adjacent to wall, cabinet or other
appliance that extends beyond front edge of unit, 20" minimum
clearance recommended to allow for optimum 140° door swing,
providing complete crisper access and removal. (Absolute 3"
minimum clearance will ONLY allow for 90° door swing which
will provide limited crisper access with restricted removal.)
Top Mount Refrigerators
FGUI1849L F / R / P / E 18 Cu. Ft.

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 02/12 © 2012 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator
