Frigidaire FRS26H5D Instruction Manual

N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAB1.eps
N58SBBIBD1.eps N58TAAAAB4.eps N58CAAAAC0.eps N58XBAAAB0.eps
N58YDAAACO.eps n58I115T.eps W241526901A.eps S241526901A.eps
Product No. FRS26H5DSB1 FRS26H5DSB2
Series R134a R134a
Color stain/black stain/black
Volts 115 115
Wiring Diagram 241526901 241526901
Owner's Guide 241572800 241572800
Market North America North America
Energy Guide 241538755 241538755
Service Data Sheet 240389618 240389618
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995415394
04/08/19
(EN/SERVICE/DCS)
357
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26H5D
Copyright ©All rights reserved.

Publication No: 5995415394 FRS26H5D
08/04 2
FREEZER DOOR
21C
21
21
21
21C
21C
21
74
74
74
72
72
73
73
73
18
37
22C
11
1
4A
68
4B
4B
13A
22A
21A
N58FCCBBB2

FRS26H5D Publication No: 5995415394
# Functional Parts 3 08/04
* Non-Illustrated Parts
FREEZER DOOR
Model Index: AFRS26H5D (FRS26H5DSB1)
BFRS26H5D (FRS26H5DSB2)
POS. NO PART NO. DESCRIPTION
1 # 240390606 A B Gasket-frzr door, black, magnetic
4A 240334201 A B Bin-door, frzr-upper
4B 240351601 A B Bin-door
11 240554228 A B Door-frzr, stainless steel, complete assy
13A 240581906 A B Door Stop, black, frzr
18 240359108 A B Handle-door, black, LH
21 218781100 A B Screw, pan head, 8-18 x 0.625
21A 240598401 A B Screw, 10-32 x 1/2
21C 240521302 A B Screw, #8-18 x 3/4
22A 240328204 A B Bearing-hinge, closer
22C 240328404 A B Bearing-hinge, black, upper
37 240359203 A B Trim-handle, 30.13", black, lower
68 241525101 A B Chute-ice
72 240421701 A B Button-handle mtg, dovetail
73 218396700 A B Block-handle mtg, dovetail
74 215503200 A B Screw, cr pan hd, 10-16 x 0.500
* 218490901 A B Cleaner, stainless steel
* 240352102 A B Connector-water, straight
* 240552101 A B Harness-wiring, door
* 5303918256 A B Dispenser heater kit

Publication No: 5995415394 FRS26H5D
08/04 4
REFRIGERATOR DOOR
21C
21
21
21
21C
21C
21
74
74
74
21A
22
13
72
72
73
73
73
18
37
15
22B
2
7
49
49
4
4
N58RCCBBB5

FRS26H5D Publication No: 5995415394
# Functional Parts 5 08/04
* Non-Illustrated Parts
REFRIGERATOR DOOR
Model Index: AFRS26H5D (FRS26H5DSB1)
BFRS26H5D (FRS26H5DSB2)
POS. NO PART NO. DESCRIPTION
2 240390605 A B Gasket-refr door, black, magnetic
4 240323001 A B Bin-door, pseudo, bottom
7 240326203 A B Door-dairy
13 240581905 A B Door Stop, black, ref
15 240451982 A B Door-refr, stainless steel, complete assy
18 240359103 A B Handle-door, black, RH
21 218781100 A B Screw, pan head, 8-18 x 0.625
21A 240598401 A B Screw, 10-32 x 1/2
21C 240521302 A B Screw, #8-18 x 3/4
22 240328203 A B Bearing-hinge, closer
22B 240328404 A B Bearing-hinge, black, upper
37 240359203 A B Trim-handle, 30.13", black, lower
49 240356401 A B Bin-door, gallon
72 240421701 A B Button-handle mtg, dovetail
73 218396700 A B Block-handle mtg, dovetail
74 215503200 A B Screw, cr pan hd, 10-16 x 0.500
* 218490901 A B Cleaner, stainless steel

Publication No: 5995415394 FRS26H5D
08/04 6
CABINET
58
58
40 66
40
92
92
38
38
37
37
14A
14
91
41
100
89
83
82
43
21C
21C
28
42
42
23
22
23
22
30A
30
72
10A
N58BAAAAB1
10
90
11
45
45
150
81
81
81
47

FRS26H5D Publication No: 5995415394
# Functional Parts 7 08/04
* Non-Illustrated Parts
CABINET
Model Index: AFRS26H5D (FRS26H5DSB1)
BFRS26H5D (FRS26H5DSB2)
POS. NO PART NO. DESCRIPTION
10 240435908 A B Cover-air duct
10A 240475907 A B Cover-evap coil, lower
11 5303208309 A B Plug-hole, factory test
14 # 240505801 A B Switch, light/lamp
14A# 215486600 A B Switch-light/lamp
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 240457702 A B Plate-door closer
23 240402701 A B Screw-#10-32 x 1/4 flat hd
28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240419101 A B Bracket-lower hinge, ref
30A 240419102 A B Bracket-lower hinge
37 240337603 A B Trim-cabinet corner, black, (2)
38 240327201 A B Bracket-upper hinge
40 240327007 A B Cover-upper hinge, black
41 241550801 A B Grommet-shelf mtg, 1.40" long
41* 241550701 A B Grommet-shelf mtg, .96" long
42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B Roller Assy, front, (2)
45 241500301 A B Screw, hex washer head, 8-18AB x 0.500
47 240349402 A B Channel-shelf mtg, side, (2)
58 218781100 A B Screw, pan head, 8-18 x 0.625
66 5304424968 A B Damper Cover Assy
66* 240518802 A B Pin-push, push-in, plastic
72 240324406 A B Grille/Kickplate, black
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326104 A - Cover, access, system compt, with label
89 241574602 - B Cover access
90 218249808 A B Seal-coil cover
91 240380101 A B Duct-ice maker
92 216850900 A B Screw, hex washer hd, 1/4 x 7/8, hinge mtg
100 240423701 A B Support, crisper cover, front, (4)
100* 240350802 A B Support, crisper cover, rear, (4)
150 240368701 A B Guide-control bulb
* 240396801 A B Clamp, tube/wiring, nylon, black/natural
* 240479601 A B Plug, button, cab liner holes, (2)
* 240481601 A B Shim-lower hinge
* 5303305345 A B Paint, touch-up, black

Publication No: 5995415394 FRS26H5D
08/04 8
SHELVES
140
25
47
26A
N58SBBIBD1
26
27
26A
51
100
25A
47A
52
101
49
2
2
101
97
81
51
52
52
49B
49B
2
11A
126
81
81
126
11
39
51
62
123
42
39A
24
24A
24B
101
11C
42A
120
122
121

FRS26H5D Publication No: 5995415394
# Functional Parts 9 08/04
* Non-Illustrated Parts
SHELVES
Model Index: AFRS26H5D (FRS26H5DSB1)
BFRS26H5D (FRS26H5DSB2)
POS. NO PART NO. DESCRIPTION
2 241510604 A B Trim-basket
11 240338802 A B Shelf-freezer, flip-up
11A 240338704 A B Shelf-freezer, fixed wire
11C 240324101 A B Shelf-pizza
24 240355208 A B Shelf-"Spill-Safe", fixed
24A 240355207 A B Shelf-"Spill-Safe", cantilever, half width, fixed
24B 240350108 A B Shelf-"Spill-Safe", cantilever, sliding
25 240350702 A B Cover-crisper pan, upper
25* 240362101 A B Clip-slide, cover-crisper
25A 240350902 A B Cover-crisper pan, lower
26 240351005 A B Pan-crisper, upper
26* 240349801 A B Clip-slide, pan-crisper
26A 240362201 A B Control-humidity
27 240351205 A B Pan-crisper, lower
39 240430706 A B Trim-shelf, 11.21", front
39A 240430702 A B Trim-shelf, 12.39", front
42 240356501 A B Track, meat pan hanger, RH
42A 240349701 A B Hanger-meat pan, LH
42A* 240349901 A B Block-meat pan rail, LH
42A* 240350001 A B Spring-meat pan rail
42A* 240356702 A B Seal-meat pan
47 240350633 A B Insert-pan cover, glass
47A 240350603 A B Insert-pan cover, glass
49 240530402 A B Basket-sliding
49B 240530502 A B Basket-sliding, upper, half
51 240343002 A B Hanger-basket, RH
52 240343102 A B Hanger-basket, LH
62 240342805 A B Pan-meat
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
97 240545303 A B Water Tank Assy, coiled tubing, front filter
100 240326302 A B Cover-water tank
101 218493100 A B Screw, hex washer head, 8-18AB x 1-3/4
101* 215005000 A B Screw, hex wshr hd, 8-18AB x 0.750, gusset/hanger
120 241559001 A B Shelf-ice cream
121 241561001 A B Rail-ice cream shelf, LH
122 241561201 A B Rail-ice cream shelf, RH
123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438
126 218867405 A B Channel, auger mtg, LH
126 218867406 A B Channel, auger mtg, RH
140 240430501 A B Channel, wtr tube cover

Publication No: 5995415394 FRS26H5D
08/04 10
CONTROLS
